Breathing and Twisting: An Investigation of Framework Deformation and Guest
Packing in Single Crystals of a Microporous Vanadium Benzenedicarboxylate
Xiqu Wang,*,† Juergen Eckert,‡ Lumei Liu,† and Allan J. Jacobson*,†
†Department of Chemistry, University of Houston, Houston, Texas 77204-5003, United States, and ‡Materials
Research Laboratory, University of California, Santa Barbara, California 93106-5121, United States
Received December 15, 2010
The structural details of the compounds vanadium benzenedicarboxylate VO(bdc) Guest, where the Guests are the
3
absorbed six-ring molecules: benzene, 1,4-cyclohexadiene, 1,3-cyclohexadiene, cyclohexene and cyclohexane, have
been determined from single crystal X-ray data. All of the six-ring guest molecules show a high degree of ordering
inside the channels of VO(bdc). The interactions between the guests and the host framework are dominated by van
der Waals bonding. The six-ring molecules are all packed in two columns in the channels, either in herringbone or close
to parallel patterns. The packing changes the space group symmetry of VO(bdc) from Pnma to the noncentrosym-
metric space group P212121. The VO(bdc) framework deforms to closely adapt to the shape and thickness changes of
the double columns of the guest molecules. In addition to the well studied breathing deformation, a twisting
deformation mechanism that involves a cooperative rotation of the octahedral chains accompanied by bending of the
bdc ligand is apparent in the detailed structural data. More quantitative information on the remarkable flexibility of the
VO(bdc) framework was obtained from ab initio calculations.
Introduction
oxide units with different dimensionalities.4-6 Among them,
a group of compounds with the general framework formula
The remarkable progress in the synthesis of inorganic-
organic hybrid compounds has greatly enhanced the chemical
and structural diversity of crystalline microporous materials
and the potential for novel applications. The design of
metal-organic open frameworks (MOFs) can take advan-
tage of both the variety of organic linkers and specific
physical properties of the inorganic core structural units.1,2
Relative to conventional inorganic porous solids such as
zeolites, hybrid organic-inorganic porous frameworks
have the advantage of flexibility upon loading and unloading
of guest species. The high flexibility can give rise to tunable
adsorption selectivity by using changes in external conditions
to adjust pore shapes. Compounds with such properties
have been categorized as “third generation” microporous
materials.3
ꢀ
MX(bdc), first reported by Ferey and co-workers, are based
on chains of trans corner-sharing octahedra MX2O4 (M =
V,7 Cr,8 Al,9,10 Fe,11,12 In,13 Ga,14 Mn15 and X = O, OH, F)
cross-linked by 1,4-benzene dicarboxylate. The framework
that results contains one-dimensional wide channels. Upon
removal or adsorption of guest species inside the channels of
the structure, large deformations occur without changes in
the topology of the framework. Interesting adsorption prop-
erties of several members of the family have attracted great
(5) Eddaoudi, M.; Kim, J.; Rosi, N.; Vodak, D.; Wachter, J.; O’Keeffe,
M.; Yaghi, O. M. Science 2002, 295, 469–472.
(6) Rao, C. N. R.; Cheetham, A. K.; Thirumurugan, A. J. Phys.: Condens.
Matter 2008, 20, 159801/1.
(7) Barthelet, K.; Marrot, J.; Riou, D.; Ferey, G. Angew. Chem., Int. Ed.
ꢀ
The dianion of 1,4-benzenedicarboxylic acid is a particu-
larly well studied organic linker. A large number of com-
pounds with high porosity and various pore sizes have been
synthesized by using this ligand to connect together metal
2002, 41, 281–284.
(8) Serre, C.; Millange, F.; Thouvenot, C.; Nogues, M.; Marsolier, G.;
ꢀ
Louer, D.; Ferey, G. J. Am. Chem. Soc. 2002, 124, 13519–26.
ꢀ
(9) Ferey, G.; Latroche, M.; Serre, C.; Millange, F.; Loiseau, T.; Percheron-
Guegan, A. Chem. Commun. 2003, 2976–2977.
(10) Liu, L.; Wang, X.; Jacobson Allan, J. Dalton Trans 2010, 39, 1722–5.
(11) Whitfield, T. R.; Wang, X.; Jacobson, A. J. Mater. Res. Soc. Symp.
Proc. 2002, 755, 191–196.
(12) Whitfield, T. R.; Wang, X.; Liu, L.; Jacobson, A. J. Solid State Sci.
2005, 7, 1096–1103.
*To whom correspondence should be addressed. Tel.: 713-743-2785. Fax:
713-742-2787. E-mail: ajjacob@uh.edu (A.J.J.), xiqu.wang@mail.uh.edu
(X.W.).
(13) Anokhina, E.,V.; Vougo-Zanda, M.; Wang, X.; Jacobson Allan, J.
J. Am. Chem. Soc. 2005, 127, 15000–1.
(14) Vougo-Zanda, M.; Huang, J.; Anokhina, E. V.; Wang, X.; Jacobson
Allan, J. Inorg. Chem. 2008, 47, 11535–42.
(15) Xu, G.; Zhang, X.; Guo, P.; Pan, C.; Zhang, H.; Wang, C. J. Am.
Chem. Soc. 2010, 132, 3656–3657.
(1) Long, J. R.; Yaghi, O. M. Chem. Soc. Rev. 2009, 38, 1213–1214.
ꢀ
(2) Ferey, G. Chem. Soc. Rev. 2008, 37, 191–214.
(3) Kitagawa, S.; Kitaura, R.; Noro, S.-i. Angew. Chem., Int. Ed. 2004, 43,
2334–2375.
ꢀ
(4) Ferey, G.; Mellot-Draznieks, C.; Serre, C.; Millange, F.; Dutour, J.;
Surble, S.; Margiolaki, I. Science (Washington, DC) 2005, 309, 2040–2042.
r
pubs.acs.org/IC
Published on Web 01/12/2011
2011 American Chemical Society

Article
Inorganic Chemistry, Vol. 50, No. 5, 2011 2029
interest because of potential applications including storage of
gases such as H2, CO2, and CH4; molecule separations, for
example, vapor phase adsorption and separation of xylene
isomers; and drug delivery.16-31 Functional groups of var-
ious polarities, hydrophilicities, and acidities were recently
introduced through substitution in the framework phenyl
groups, and their effects on pore opening and the host-guest
interactions were reported.32-34
We have reported the synthesis of [VO(bdc)](H2bdc)0.71
(traditionally designated as MIL-477) in the form of large
single crystals.35 After removal of the guest acid molecules by
heating the crystals of [VO(bdc)](H2bdc)0.71 in the air, we
observed that the VO(bdc) structure is sufficiently flexible
to undergo single-crystal-to-single-crystal transformations
upon the adsorption of aniline, acetone, thiophene, and other
molecules enabling the details of the guest structure, frame-
work-guest interactions, and framework deformations to
be determined from single crystal X-ray diffraction data.
Furthermore, we have observed the rapid and highly selective
adsorption of organic sulfur molecules from methane or
octane by VO(bdc), a process relevant to clean fuels.36,37
The details of the crystal structures show the importance of
noncovalent interactions in determining the guest molecule
packing within the nanochannels and are valuable in helping
to understand the adsorption properties. Most recently, Leus
et al. reported remarkable catalytic activity of VO(bdc) in the
epoxidation of cyclohexene.38
We have extended our earlier study to other guest mole-
cules with different shapes and chemical bonding possibili-
ties. In the structural study of the VO(bdc) framework loaded
with different six-ring organic molecules, a twisting deforma-
tion mode accompanied by a cooperative rotation of the
octahedral chains and bending of the bdc ligands has been
observed. This deformation mode is complementary to the
well investigated breathing deformation which corresponds
to a cooperative translation of the octahedral chains. In the
present work, we show that combinations of the twisting and
breathing deformations occur when different molecules are
absorbed into the VO(bdc) framework. Quantitative insights
into these deformations and the remarkable flexibility of the
VO(bdc) framework have been obtained from ab initio
calculations.
