COMMUNICATION
www.rsc.org/chemcomm | ChemComm
Catalytic asymmetric synthesis of 1,1-disubstituted
tetrahydro-b-carbolines by phase-transfer catalyzed alkylationsw
Seiji Shirakawa, Kun Liu, Hironobu Ito and Keiji Maruoka*
Received 16th October 2010, Accepted 1st November 2010
DOI: 10.1039/c0cc04447d
Efficient catalytic asymmetric synthesis of 1,1-disubstituted
tetrahydro-b-carbolines has been achieved via asymmetric
alkylation of 1-cyanotetrahydro-b-carbolines using a binaphthyl-
modified N-spiro-type chiral phase-transfer catalyst. This is a
valuable example of hitherto difficult highly enantioselective
alkylations at a-carbon of the cyano group under phase-transfer
conditions.
alkylation product 3 can be transformed into various useful
functional groups. Although many examples of phase-transfer
catalyzed asymmetric alkylations at a-carbon of the carbonyl
group to create quaternary stereocenter via ammonium enolate
A (Scheme 2) are known,11,12 only limited examples of the
alkylations at a-carbon of the cyano group via intermediate B
(Scheme 2) have been reported14,15 despite the high synthetic
utility of this group. Here we wish to report highly
enantioselective alkylations of 1-cyanotetrahydro-b-carbolines
2 under mild phase-transfer conditions. The present reaction is
a valuable example of hitherto difficult highly enantioselective
a-alkylations of cyano compounds under these conditions.
As a key substrate for the asymmetric synthesis of 1,1-
disubstituted tetrahydro-b-carboline of type 1 under phase-
transfer conditions, 1-cyanotetrahydro-b-carboline 2a was
selected as a model substrate. An attempted reaction of
1-cyanotetrahydro-b-carboline 2a with benzyl bromide
(1.2 equiv.) in aqueous KOH/toluene under the influence of
N-spiro-type phase-transfer catalyst (S,S)-4a (2 mol%) at 0 1C
for 24 h afforded benzylation product 3a with 71% ee (Table 1,
entry 1). Switching the 3,30-aromatic substituent (Ar) of the
catalyst to a 3,5-bis(trifluoromethyl)phenyl group (4b) resulted
in improved enantioselectivity, and the product 3a was
obtained with high enantioselectivity (94% ee, entry 2).
Further screening of 3,30-aromatic substituent (Ar) of (S,S)-
416 did not improve the enantioselectivity (entries 3 and 4). The
use of phase-transfer catalyst (S)-5,17 which has one binaphthyl
unit, gave a product with moderate enantioselectivity (entry 5).
With optimal reaction conditions in hand, we further studied
the generality of the asymmetric alkylation of 1-cyanotetrahydro-
b-carboline 2a under the influence of chiral phase-transfer
catalyst (S,S)-4b, as shown in Table 2. A series of benzylic
bromides with different steric and electronic properties
The structure of 1-substituted tetrahydro-b-carboline appears
in many important natural products and biologically active
compounds, hence numerous synthetic efforts especially in
a stereoselective manner have been made to build up this
structure.1–5 Several efficient catalytic methods were developed
for the synthesis of these compounds via asymmetric hydro-
genations,3 Mannich-type reactions,4 and Pictet–Spengler
reactions.5 On the other hand, only two examples of the
catalytic asymmetric synthesis of 1,1-disubstituted tetrahydro-
b-carbolines of type 1 possessing a chiral quaternary carbon
center6 have been reported recently,7 despite the importance of
these compounds in natural product chemistry8 and medicinal
chemistry9 (Fig. 1). Notably, these two examples included
similar Pictet–Spengler-type intramolecular cyclizations, and
the structural motif of the obtained products was limited to a
tetracyclic lactam structure. For these reasons, the development
of novel catalytic asymmetric methods for the synthesis of
different types of 1,1-disubstituted tetrahydro-b-carbolines 1 is
highly desirable.10
Our strategy for the synthesis of 1,1-disubstituted tetrahydro-
b-carbolines of type 1 involves asymmetric phase-transfer
alkylation11,12 of racemic 1-cyanotetrahydro-b-carboline 2,
which can be prepared easily from 3,4-dihydro-b-carboline via
cyanation (Scheme 1).13 The electron-withdrawing nature of
the cyano group in compound 2 offers appropriate reactivity
for phase-transfer alkylations, and the cyano group of
Scheme 1 Synthetic scheme of 1,1-disubstituted tetrahydro-b-carboline.
Fig. 1 1,1-Disubstituted tetrahydro-b-carboline.
Laboratory of Synthetic Organic Chemistry and Special Laboratory
of Organocatalytic Chemistry, Department of Chemistry, Graduate
School of Science, Kyoto University, Sakyo, Kyoto, 606-8502, Japan.
E-mail: maruoka@kuchem.kyoto-u.ac.jp; Fax: +81-75-753-4041;
Tel: +81-75-753-4041
w Electronic supplementary information (ESI) available: Experimental
details and characterization data for new compounds. CCDC 787177.
For ESI and crystallographic data in CIF or other electronic format see
DOI: 10.1039/c0cc04447d
Scheme 2 Phase-transfer catalyzed alkylations.
Chem. Commun., 2011, 47, 1515–1517 1515
c
This journal is The Royal Society of Chemistry 2011

View Article Online
Table 1 Screening of chiral phase-transfer catalystsa
Table 2 Asymmetric alkylation of a 1-cyanotetrahydro-b-carboline 2aa
Entry
RBr
Yieldb (%)
eec (%)
1
2
3
4
X = H
X = Me
X = F
72 (3a)
60 (3b)
88 (3c)
76 (3d)
94
92
95
96
X = Br
5
78 (3e)
94
Entry
PTC
Yieldb (%)
eec (%)
1
2
3
4
5
4a
4b
4c
4d
5
45
72
51
61
69
71
94
92
70
79
6
7
66 (3f)
75 (3g)
90
93
a
Reaction conditions: 2a (0.050 mmol) and benzyl bromide (0.060 mmol)
in the presence of 2 mol% of chiral phase-transfer catalyst (PTC)
in 50% aqueous KOH (0.25 mL)/toluene (0.50 mL) at 0 1C for
b
c
24 h. Yield of isolated products. Determined by chiral HPLC
analysis.
8
61 (3h)
86 (3i)
95
60
were tolerated, thus allowing the preparation of structurally
diverse, enantioenriched 1,1-disubstituted tetrahydro-b-carbolines
(90–96% ee, entries 1–7). The alkyl halide containing a hetero-
aromatic ring could also be applied to the reaction with high
enantioselectivity (95% ee, entry 8). The reaction with cinnamyl
bromide gave the product 3i in good yield with moderate
enantioselectivity (entry 9).18 The absolute configuration of 3d
was determined by X-ray diffraction analysis.19
9d
a
Reaction conditions: 2a (0.050 mmol) and alkyl halide (0.060 mmol)
in the presence of 2 mol% of (S,S)-4b in 50% aqueous KOH (0.25 mL)/
b
toluene (0.50 mL) at 0
c
products. Determined by chiral HPLC analysis. The reaction was
1C for 24 h. Yield of isolated
d
performed at ꢀ20 1C.
alkylations of cyano compounds to produce important
compounds are currently underway.
Other types of 1-cyanotetrahydro-b-carbolines 2 were found
to be employable for the reaction (Table 3). The introduction
of electron-donating and electron-withdrawing substituents on
the aromatic ring of tetrahydro-b-carboline core gave high
enantioselectivities (92–96% ee, entries 1 and 2). The use of N-
methyl and N-allyl substituted tetrahydro-b-carbolines also
gave high enantioselectivities (92–94% ee, entries 3 and 4).
The cyano group of the alkylation products 3 and 6 can be
readily transformed to other functional groups. For example,
the optically active alkylation product 3a was subjected to
alkaline hydrolysis to furnish amide derivative 7 possessing a
tetracyclic hydantoin structure (Scheme 3), which was observed
in biologically active compounds.20
This work was partially supported by a Grant-in-Aid for
Scientific Research from MEXT, Japan.
Table 3 Asymmetric benzylation of 1-cyanotetrahydro-b-carbolines 2a
Entry
X
R
Yieldb (%)
eec (%)
In summary, we have successfully developed the highly
enantioselective alkylation of 1-cyanotetrahydro-b-carbolines
for the synthesis of 1,1-disubstituted tetrahydro-b-carbolines
under mild phase-transfer conditions. The cyano group of the
products was easily transformed to other functional groups.
The present report illustrates a valuable example of hitherto
difficult highly enantioselective alkylations at a-carbon of
the cyano group under phase-transfer conditions. Further
investigations on the phase-transfer catalyzed asymmetric
1d
2
3
4
MeO
Cl
H
PhCH2
PhCH2
Me
CH2QCHCH2
77 (6a)
87 (6b)
89 (6c)
84 (6d)
92
96
92
94
H
a
Reaction conditions: 2 (0.050 mmol) and benzyl bromide (0.060 mmol)
in the presence of 2 mol% of (S,S)-4b in 50% aqueous KOH
b
(0.25 mL)/toluene (0.50 mL) at 0 1C for 24 h. Yield of isolated
products. Determined by chiral HPLC analysis. The reaction was
c
d
performed at ꢀ20 1C.
c
1516 Chem. Commun., 2011, 47, 1515–1517
This journal is The Royal Society of Chemistry 2011

View Article Online
P. Krastel, E. Francotte, K. Kuhen, D. Plouffe, K. Henson,
T. Wagner, E. A. Winzeler, F. Petersen, R. Brun, V. Dartois,
T. T. Diagana and T. H. Keller, J. Med. Chem., 2010, 53, 5155.
10 Stoichiometric amounts of chiral silicon Lewis acid promoted
asymmetric synthesis of 1,1-disubstituted tetrahydro-b-carbolines
of type 1via Pictet–Spengler reaction, see: F. R. Bou-Hamdan and
J. L. Leighton, Angew. Chem., Int. Ed., 2009, 48, 2403.
11 For representative reviews on asymmetric phase-transfer catalysis,
see: (a) T. Shioiri, in Handbook of Phase-Transfer Catalysis, ed.
Y. Sasson and R. Neumann, Blackie Academic & Professional,
London, 1997, ch. 14; (b) M. J. O’Donnell, in Catalytic Asymmetric
Syntheses, ed. I. Ojima, Wiley-VCH, New York, 2nd edn, ch. 10,
2000; (c) K. Maruoka and T. Ooi, Chem. Rev., 2003, 103, 3013;
(d) M. J. O’Donnell, Acc. Chem. Res., 2004, 37, 506; (e) B. Lygo
and B. I. Andrews, Acc. Chem. Res., 2004, 37, 518; (f) T. Ooi and
K. Maruoka, Angew. Chem., Int. Ed., 2007, 46, 4222;
(g) T. Hashimoto and K. Maruoka, Chem. Rev., 2007, 107, 5656;
(h) K. Maruoka, Asymmetric Phase Transfer Catalysis, Wiley-
VCH, Weinheim, 2008; (i) S. Shirakawa and K. Maruoka, in
Catalytic Asymmetric Synthesis, ed. I. Ojima, John Wiley & Sons,
Hoboken, New Jersey, 3rd edn, ch. 2C, 2010.
12 For representative examples from our group on phase-transfer
catalyzed asymmetric alkylations to create quaternary carbon
center, see: (a) T. Ooi, M. Takeuchi, M. Kameda and
K. Maruoka, J. Am. Chem. Soc., 2000, 122, 5228; (b) T. Ooi,
T. Miki, M. Taniguchi, M. Shiraishi, M. Takeuchi and
K. Maruoka, Angew. Chem., Int. Ed., 2003, 42, 3796; (c) T. Ooi,
K. Fukumoto and K. Maruoka, Angew. Chem., Int. Ed., 2006, 45,
3839; (d) T. Hashimoto, K. Sakata and K. Maruoka, Angew.
Chem., Int. Ed., 2009, 48, 5014.
Scheme 3 Transformation of the alkylation product 3a.
Notes and references
1 For reviews, see: (a) Z. Czarnocki, A. Siwicka and J. Szawka"o,
Curr. Org. Synth., 2005, 2, 301; (b) E. L. Larghi, M. Amongero, A.
B. J. Bracca and T. S. Kaufman, ARKIVOC, 2005, (xii), 98.
2 Examples of enantioselective synthesis, see: (a) M. Nakamura,
A. Hirai and E. Nakamura, J. Am. Chem. Soc., 1996, 118, 8489;
(b) H. Yamada, T. Kawata, M. Matsumizu, A. Nishida,
K. Yamaguchi and M. Nakagawa, J. Org. Chem., 1998, 63, 6348;
(c) A. R. Hajipour and M. Hantehzadeh, J. Org. Chem., 1999, 64,
8475.
3 (a) N. Uematsu, A. Fujii, S. Hashiguchi, T. Ikariya and R. Noyori,
J. Am. Chem. Soc., 1996, 118, 4916; (b) L. F. Tietze, Y. Zhou and
E. Topken, Eur. J. Org. Chem., 2000, 2247; (c) C. Li and J. Xiao,
¨
J. Am. Chem. Soc., 2008, 130, 13208; (d) L. Evanno, J. Ormala and
P. M. Pihko, Chem.–Eur. J., 2009, 15, 12963; (e) N. Haraguchi,
K. Tsuru, Y. Arakawa and S. Itsuno, Org. Biomol. Chem., 2009, 7, 69.
4 (a) T. Itoh, M. Yokoya, K. Miyauchi, K. Nagata and A. Ohsawa,
Org. Lett., 2003, 5, 4301; (b) T. Itoh, M. Yokoya, K. Miyauchi,
K. Nagata and A. Ohsawa, Org. Lett., 2006, 8, 1533.
5 (a) M. S. Taylor and E. N. Jacobsen, J. Am. Chem. Soc., 2004, 126,
10558; (b) J. Seayad, A. M. Seayad and B. List, J. Am. Chem. Soc.,
2006, 128, 1086; (c) M. J. Wanner, R. N. S. van der Haas, K. R. de
Cuba, J. H. van Maarseveen and H. Hiemstra, Angew. Chem., Int.
Ed., 2007, 46, 7485; (d) N. V. Sewgobind, M. J. Wanner,
S. Ingemann, R. de Gelder, J. H. van Maarseveen and
H. Hiemstra, J. Org. Chem., 2008, 73, 6405.
6 K. Christoffers and A. Baro, Quaternary Stereocenters: Challenges
and Solutions for Organic Synthesis, Wiley-VCH, Weinheim, 2005.
7 (a) I. T. Raheem, P. S. Thiara, E. A. Peterson and E. N. Jacobsen,
J. Am. Chem. Soc., 2007, 129, 13404; (b) M. E. Muratore,
C. A. Holloway, A. W. Pilling, R. I. Storer, G. Trevitt and
D. J. Dixon, J. Am. Chem. Soc., 2009, 131, 10796.
8 (a) R. Sakai, K. L. Rinehart, Y. Guan and A. H.-J. Wang, Proc.
Natl. Acad. Sci. U. S. A., 1992, 89, 11456; (b) F. C. Seaman and
L. H. Hurley, J. Am. Chem. Soc., 1998, 120, 13028;
13 S. Veeraraghavan and F. D. Popp, J. Heterocycl. Chem., 1981, 18,
909.
14 D. Brozda, K. Hoffman and M. D. Rozwadowska, Heterocycles,
´
2006, 67, 119.
15 Asymmetric
alkylations
of
a-cyanocarboxylates,
see:
(a) K. Nagata, D. Sano and T. Itoh, Synlett, 2007, 547;
(b) K. Nagata, D. Sano, Y. Shimizu, M. Miyazaki, T. Kanemitsu
and T. Itoh, Tetrahedron: Asymmetry, 2009, 20, 2530.
16 (a) T. Ooi, M. Kameda and K. Maruoka, J. Am. Chem. Soc., 2003,
125, 5139; (b) K. Maruoka, E. Tayama and T. Ooi, Proc. Natl.
Acad. Sci. U. S. A., 2004, 101, 5824; (c) T. Ooi, M. Kameda,
M. Taniguchi and K. Maruoka, J. Am. Chem. Soc., 2004, 126,
9685.
17 (a) M. Kitamura, S. Shirakawa and K. Maruoka, Angew. Chem.,
Int. Ed., 2005, 44, 1549; (b) M. Kitamura, S. Shirakawa,
Y. Arimura, X. Wang and K. Maruoka, Chem.–Asian J., 2008, 3,
1702.
(c) R. Menchaca, V. Martınez, A. Rodrıguez, N. Rodrıguez,
´ ´ ´
M. Flores, P. Gallego, I. Manzanares and C. Cuevas, J. Org.
Chem., 2003, 68, 8859.
18 The reaction with simple alkyl halide such as methyl iodide did not
give the target product, probably due to the low reactivity of methyl
iodide.
9 (a) T. Nagyl, L. Jeannin, J. Sapil, J. Y. Laronze, P. Renard,
B. Pfeifferz and J. G. Bizot-Espiard, Eur. J. Med. Chem., 1995,
30, 575; (b) K. Pari, C. S. Sundari, S. Chandani and
D. Balasubramanian, J. Biol. Chem., 2000, 275, 2455;
(c) D. Fokas, L. Yu and C. M. Baldino, Mol. Diversity, 2005, 9,
81; (d) B. K. S. Yeung, B. Zou, M. Rottmann,
S. B. Lakshminarayana, S. H. Ang, S. Y. Leong, J. Tan,
J. Wong, S. Keller-Maerki, C. Fischli, A. Goh, E. K. Schmitt,
19 CCDC 787177.
20 (a) M. L. Lopez-Rodriguez, M. J. Morcillo, B. Benhamu,
E. Fernandez, J. Serrano and L. Orensanz, Chem. Pharm. Bull.,
1995, 43, 941; (b) S. Hotha, J. C. Yarrow, J. G. Yang, S. Garrett,
K. V. Renduchintala, T. U. Mayer and T. M. Kapoor, Angew.
Chem., Int. Ed., 2003, 42, 2379; See also, ref. 9c.
c
This journal is The Royal Society of Chemistry 2011
Chem. Commun., 2011, 47, 1515–1517 1517
