Helvetica Chimica Acta – Vol. 94 (2011)
227
(ddd, J ¼ 1.9, 5.8, 10.7, 1 H); 1.48 – 1.67 (m, 6 H). 13C-NMR (75 MHz): 159.2; 130.5; 129.2; 113.6; 72.5;
69.6; 58.9; 57.1; 55.2; 44.6; 31.1; 29.3; 22.5. ESI-MS: 307 ([M þ Na]þ). HR-ESI-MS: 307.1809 ([M þ Na]þ,
C15H21ClNaOþ3 ; calc. 307.1077).
(2R,6R)-10-[(4-Methoxyphenyl)methoxy]dec-4-yne-2,6-diol (9). To freshly dist. NH3 (50 ml), in a
two-necked round-bottomed flask fitted with a cold finger condenser, was added a cat. amount of
Fe(NO3)3, followed by the portion-wise addition of Li metal (0.48 g, 68.82 mmol) at ꢀ 338. The resulting
gray suspension was stirred for 30 min. Then 11 (2.8 g, 9.83 mmol) in dry THF (20 ml) was added within
20 min, and the mixture was stirred for 2 h at ꢀ 338. Then the addition of a cat. amount of BF3 · Et2O
followed by (2R)-2-methyloxirane (12; 3.44 ml, 49.16 mmol) was carried out successively, the mixture
stirred for 5 h at ꢀ 338 and quenched by the addition of solid NH4Cl (10 g), and NH3 then allowed to
evaporate. The mixture was diluted with H2O (10 ml) and AcOEt (50 ml) and filtered over a small pad of
Celite. The filtrate was extracted with AcOEt (3 ꢁ 50 ml), the combined org. layer dried (Na2SO4) and
concentrated, and the residue purified by CC: 9 (2.41 g, 80%). Pale yellow viscous liquid. [a]2D5 ¼ ꢀ5.4
(c ¼ 2.2, CHCl3). IR (neat): 3383, 2928, 2860, 1774, 1611, 1572, 1457, 1371, 1300, 1248, 1173, 1089, 1033.
1H-NMR (500 MHz): 7.19 (d, J ¼ 8.3, 2 H); 6.81 (d, J ¼ 8.3, 2 H); 4.38 (s, 2 H); 4.25 – 4.30 (m, 1 H); 3.76
(s, 3 H); 3.85 – 3.91 (m, 1 H); 3.41 (t, J ¼ 6.2, 2 H); 2.35 (ddq, J ¼ 2.1, 4.2, 16.6, 1 H); 2.24 (ddq, J ¼ 2.1, 4.2,
16.6, 1 H); 1.57 – 1.67 (m, 4 H); 1.44 – 1.51 (m, 2 H); 1.20 (d, J ¼ 6.24, 3 H). 13C-NMR (75 MHz): 159.1;
130.5; 129.2; 113.7; 83.7; 81.6; 72.5; 69.8; 66.2; 62.3; 55.2; 37.6; 29.2; 29.1; 22.3; 21.9. ESI-MS: 324 ([M þ
NH4]þ), 307 ([M þ H]þ). HR-ESI-MS: 329.1725 ([M þ Na]þ, C18H26NaOþ4 ; calc. 329.1729).
(2R,4E,6R)-10-[(4-Methoxyphenyl)methoxy]dec-4-ene-2,6-diol (13). To a stirred suspension of
LiAlH4 (0.409 g, 10.77 mmol) in dry THF (30 ml) at 08 was added dropwise a soln. of 9 (2.2 g, 7.18 mmol)
in dry THF (20 ml). The mixture was allowed to warm to r.t. and stirred for 4 h. After cooling to 08, the
mixture was diluted with Et2O and quenched by dropwise addition of sat. aq. Na2SO4 soln. (10 ml). The
solid material was filtered and washed thoroughly several times with hot AcOEt. The combined org.
layer dried (Na2SO4), the solvent evaporated, and the residue purified by CC: 13 (1.88 g, 85%). Viscous
liquid. [a]2D5 ¼ ꢀ3.4 (c ¼ 2.6, CHCl3). IR (neat): 3397, 2925, 2853, 1776, 1611, 1512, 1459, 1374, 1300, 1248,
1170, 1082, 1034. 1H-NMR (300 MHz): 7.19 (d, J ¼ 8.5, 2 H); 6.85 (d, J ¼ 8.5, 2 H); 5.47 – 5.68 (m, 2 H);
4.39 (s, 2 H); 4.0 – 4.14 (m, 2 H); 3.79 (s, 3 H); 3.40 (t, J ¼ 6.2, 2 H); 2.0 – 2.25 (m, 2 H); 1.36 – 1.64 (m,
6 H); 1.17 (d, J ¼ 6.3, 3 H). 13C-NMR (75 MHz): 159.1; 136.3; 130.5; 129.2; 127.2; 113.6; 72.4; 69.8; 67.0;
55.1; 41.7; 36.8; 29.9; 29.4; 22.6; 22.08. ESI-MS: 331 ([M þ Na]þ). HR-ESI-MS: 331.1880 ([M þ Na]þ,
C18H28NaOþ4 ; calc. 331.1885).
(2R,4E,6R)-6-{[(tert-Butyl)dimethylsilyl]oxy}-10-[(4-methoxyphenyl)methoxy]dec-4-en-2-ol (14).
To a stirred soln. of 13 (1.6 g, 4.75 mmol) and 1H-imidazole (0.667 g, 9.51 mmol) in dry CH2Cl2
t
(20 ml) was added BuMe2SiCl (1.07 g, 7.13 mmol), portion-wise at 08. The mixture was stirred at 08
for 4 h and then quenched with sat. aq. NH4Cl soln. and extracted with CH2Cl2 (3 ꢁ 40 ml). The aq. layer
was extracted with additional CH2Cl2 (2 ꢁ 30 ml), the combined org. layer washed with H2O (30 ml) and
brine (30 ml), dried (Na2SO4), and concentrated, and the residue purified by CC: 14 (1.84 g, 86%).
Colorless liquid. [a]2D5 ¼ ꢀ3.3 (c ¼ 2.4, CHCl3). IR (neat): 3415, 2927, 2853, 1776, 1612, 1512, 1459, 1372,
1300, 1247, 1173, 1084, 1036, 972. 1H-NMR (300 MHz): 7.20 (d, J ¼ 9.1, 2 H); 6.82 (d, J ¼ 9.1, 2 H); 5.40 –
5.66 (m, 2 H); 4.39 (s, 2 H); 4.00 – 4.09 (m, 1 H); 3.80 (s, 3 H); 3.74 – 3.83 (m, 1 H); 3.38 (t, J ¼ 6.8, 2 H);
2.06 – 2.25 (m, 2 H); 1.54 – 1.65 (m, 2 H); 1.36 – 1.53 (m, 4 H); 1.17 (d, J ¼ 6.04, 3 H); 0.88 (s, 9 H); 0.03 (s,
3 H); 0.01 (s, 3 H). 13C-NMR (500 MHz): 159.0; 137.2; 130.7; 129.2; 125.7; 113.7; 73.2; 72.5; 70.0; 67.2;
55.2; 42.1; 38.1; 29.7; 25.9; 22.7; 22.0; 18.2; ꢀ 4.3; ꢀ 4.8. ESI-MS: 445 ([M þ Na]þ). HR-ESI-MS:
445.2748 ([M þ Na]þ, C24H42NaO4Siþ; calc. 445.2750).
(5R,6E,9R)-5-{[(tert-Butyl)dimethylsilyl]oxy}dec-6-ene-1,9-diol (15). To a soln. of 14 (1.6 g,
3.55 mmol) in CH2Cl2/H2O 19 :1 (30 ml), DDQ (1.208 g, 5.32 mmol) was added, and the soln. was
stirred for 1 h at r.t. The mixture was filtered, the filtrate washed with 5% NaHCO3 soln. (30 ml) and
brine (30 ml), dried (Na2SO4), and concentrated, and the residue purified by CC: 15 (1.06 g, 91%).
[a]2D5 ¼ ꢀ3.1 (c ¼ 1.4, CHCl3). IR (neat): 3358, 2928, 2854, 1777, 1613, 1513, 1546, 1262, 1155, 1080, 1040,
973. 1H-NMR (500 MHz): 5.45 – 5.66 (m, 2 H); 4.01 – 4.12 (m, 1 H); 3.74 – 3.86 (m, 1 H); 3.62 (t, J ¼ 6.8,
2 H); 2.06 – 2.28 (m, 2 H); 1.46 – 1.61 (m, 4 H); 1.33 – 1.42 (m, 2 H); 1.19 (d, J ¼ 6.04, 3 H); 0.89 (s, 9 H);
0.04 (s, 3 H); 0.01 (s, 3 H). 13C-NMR (75 MHz): 137.2; 125.9; 73.2; 67.2; 62.8; 42.1; 37.9; 32.6; 25.9; 22.7;
