Synthesis of pyridines by cyclocondensation of acetyl and benzoyl pyruvates with enamines

Article abstract of DOI:10.1007/s10593-011-0659-6

4-Ethoxycarbonylpyridines containing acetyl, benzoyl, cyclopropanoyl, and nitro groups at position 3 have been synthesized by the reaction of acetyl and benzoyl pyruvates with various enamines.

Full text of DOI:10.1007/s10593-011-0659-6

Chemistry of Heterocyclic Compounds, Vol. 46, No. 10, 2011
SYNTHESIS OF PYRIDINES BY CYCLOCONDENSATION
OF ACETYL AND BENZOYL PYRUVATES WITH ENAMINES
G. P. Sagitullina1**, A. K. Garkushenko1, M. A. Dushek1,
N. V. Poendaev1, and R. S. Sagitullin1*
4-Ethoxycarbonylpyridines containing acetyl, benzoyl, cyclopropanoyl, and nitro groups at position 3
have been synthesized by the reaction of acetyl and benzoyl pyruvates with various enamines.
Keywords: enamines, pyridines with acceptor substituents, one-pot synthesis.
The most valuable method for the synthesis pyridines with acceptor substituents in positions 3 and 5 of
the nucleus is the Hantzsch synthesis [1, 2]. In one variant of the Hantzsch synthesis for the preparation of
pyridines condensation of ethyl ethoxymethyleneacetoacetate (or other products of the reaction of β-dicarbonyl
compounds with ethyl orthoformate) with enamines of β-dicarbonyl compounds is used [3]. We have previously
successfully used a one-pot variant of this synthesis using methylene-activated nitroacetone and
nitroacetophenone [4, 5].
In a development of this work we have investigated the possibility of using a one-pot synthesis of
pyridines 8 and 9 by a triple-component of acetyl and benzoyl pyruvates. However it appears that esters 1 and 2
did not react under mild conditions with ethyl orthoformate to form ethoxymethylene derivatives and
consequently pyridines 8 and 9 were not formed. Under these conditions another variant of the Hantzsch
synthesis – the Guareschi-Thorpe reaction – led to the formation of pyridines 5-7 in preparative yields [6-9].
The spectral data for the previously undescribed pyridines 5-7 are given in Tables 1 and 2.
CO2Et
CO2Et
O
X
X
COMe
Me
HC(OEt)3, AcOH
30°C, N2, 72 h
AcOH, N2
30°C, 72 h
O
R
+
1
1
R
N
R
H2N
R
R
O
EtO2C
N
3a-e, 4a,e
1, 2
5a,e, 6a-e, 7a,e
8, 9
1, 8 R = Me, 2, 9 R = Ph; 3 R1 = Me, 4 R1 = Ph; 5 R = R1 = Me, 6 R = Ph, R1 = Me,
O
7 R = Me, R1 = Ph; 3–7 a X = CN, b X = COMe, c X = COPh, d X =
, e X = NO2
_______
* Deceased.
** To whom correspondence should be addressed, e-mail: Sagitullina@orgchem.univer.omsk.su.
1F. M. Dostoevsky Omsk State University, Omsk 644077, Russia.
__________________________________________________________________________________________
Translated from Khimiya Geterotsiklicheskikh Soedinenii, No. 10, 1546-1550, October 2010. Original
article submitted December 28, 2009.
1250
0009-3122/11/4610-1250©2011 Springer Science+Business Media, Inc.

1251

1252

EXPERIMENTAL
1
IR spectra of compounds 5a,e, 6a-c, 7a,e were measured with a Simex FT-801 in CHCl3. H NMR
spectra of compounds 6a,b and 7a,e were recorded on a Bruker AC-250 (250 MHz) spectrometer with TMS as
internal standard, and 5a,e and 6c-e on a Bruker DRX-400 (400 MHz) instrument with CHCl3 as internal
standard (δC 7.26). 13C NMR spectra were recorded on a Bruker DRX-400 (100 MHz) spectrometer with CDCl3
as internal standard (δC 77.00). Elemental analyses were obtained on a Perkin-Elmer CHN analyzer Merck 60A,
60-200 μm silica gel was used for column chromatography. Monitoring of reactions and purity of the
compounds obtained was by TLC on Silufol UV-254 plates.
Ethyl 2,4-Dioxopentanoate (1) was synthesized according to [10] and Ethyl 2,4-Dioxo-4-phenyl-
butanoate (2) according to [11]. 4-Aminopent-3-en-2-one (3b), 3-Amino-1-phenyl-but-2-en-1-one (3c),
3-Amino-1-cyclo-propylbut-2-en-1-one (3d), and 3-Amino-3-phenylacrylonitrile (4a) were obtained as
described in [3, 12-14]. 1-Methyl-2-nitrovinylamine (3c) was obtained by the transamination of (1-methyl-
2-nitrovinyl)phenylamine [15-17]. 2-Nitro-1-phenylethylenamine (4e) was obtained by the transamination of
N-(2-nitro-1-phenyl-vinyl)aniline [16, 18, 19]. 3-Aminobut-2-enenitrile was obtained from Fluka.
Synthesis of Pyridines 5a,e, 6a-e, and 7a,e (General Method). A solution of ester 1 (or 2) (6 mmol)
and corresponding enamine 3a-e, 4a,e (6 mmol) in acetic acid (5 ml) was stirred for 72 h at 30°C. The reaction
mixture was diluted with water and ice and the crystals formed were filtered off.
Ethyl 3-Cyano-2,6-dimethylisonicotinate (5a). Yield 70%; mp 38-39°C (petroleum ether 40-70°C).
Found, %: C 64.56; H 5.98; N 13.87. C11H12N2O2. Calculated, %: C 64.69; H 5.92; N 13.72.
Ethyl 2,6-Dimethyl-3-nitroisonicotinate (5e). Yield 80%; mp 54-55°C (ethanol) (mp 58-59°C [20]).
Found, %: C 53.17; H 5.34; N 12.56. C10H12N2O4. Calculated, %: C 53.57; H 5.39; N 12.49.
Ethyl 3-Cyano-2-methyl-6-phenylisonicotinate (6a). Yield 75%; mp 94-95°C (ethanol). Found, %:
C 72.55; H 5.33; N 10.62; C16H14N2O2. Calculated, %: C 72.16; H 5.30; N 10.52.
Ethyl 3-Acetyl-2-methyl-6-phenylisonicotinate (6b). Yield 80%; mp 64-65°C (petroleum ether
40-70°C). Found, %: C 71.79; H 6.03; N 5.23. C17H17NO3. Calculated, %: C 72.07; H 6.05; N 4.94
Ethyl 3-Benzoyl-2-methyl-6-phenylisonicotinate (6c). Yield 72%; mp 111-112° (ethanol). Found, %:
C 76.56; H 5.62; N 4.45. C22H19NO3. Calculated, %: C 76.50;, H 5.54; N 4.06.
Ethyl 3-(Cyclopropylcarbonyl)-2-methyl-6-phenylisonicotinate (6d). Yield 60%; mp 112-113°C
(ethanol). Found, %: C 73.81; H 6.32; N 4.75. C19H19NO3. Calculated, %: C 73.77; H 6.19; N 4.53.
Ethyl 2-Methyl-3-nitro-6-phenylisonicotinate (6e). Yield 75%; mp 82-83°C (ethanol). Found, %:
C 62.57; 4.75; 9.84. C15H14N2O2. Calculated, %: C 62.93; H 4.93; N 9.79.
Ethyl 3-Cyano-6-methyl-2-phenylisonicotinate (7a). Yield 77%; mp 75-76°C (ethanol). Found, %:
C 71.92; H 5.37; N 10.61. C16H14N2O2. Calculated, %: C 72.16; H 5.30; N 10.52.
Ethyl 6-Methyl-3-nitro-2-phenylisonicotinate (7e). Yield 40%; mp 77-78°C (ethanol). Found, %:
C 62.55; H 4.82; N 9.56. C15H14N2O4. Calculated, %: C 62.93; H 4.93; N 9.79.
This work was supported by a financial subvention from the Russian Fund for Fundamental Research
(grant 07-03-000783-a).
REFERENCES
1.
2.
D. M. Stout and A. J. Meyers, Chem. Rev.,82, 223 (1982).
A. E. Sausinsh and G. Ya. Duburs, Khim. Geterotsikl. Soed., 435 (1992). [Chem. Heterocycl. Comp., 28,
363 (1992).
3.
B. E. M. Bottorff, R. G. Jones, E. C. Konfield, and M. J. Mann, J. Am. Chem. Soc., 73, 4380 (1951).
1253

4.
5.
6.
G. P. Sagitullina, A. K. Garkushenko, E. G. Atavin, and R. S. Sagitullin, Mendeleev Commun.,19, 155
(2009).
G. P. Sagitullina, A. K. Garkushenko, and R. S. Sagitullin, Khim. Geterotsikl. Soed., 1430 (2009).
[Chem. Heterocycl. Comp., 45, 1147 (2009)].
R. Elderfield, Heterocyclic Compounds [Russian translation], Izd-vo Inosrt. Lit., Moscow, 1955, Vol. 1,
p. 360.
7.
O. Mumm and H. Huneke, Ber.,50, 1568 (1917).
8.
O. Mumm and O. Bohme, Ber., 54, 726 (1921).
9.
G. D. Henry, Tetrahedron, 60, 6043 (2004).
10.
11.
12.
13.
14.
15.
16.
C. S. Marvel and E. E. Dreger, Org. Synth. Coll., Vol. 1, 238 (1941).
C. Beyer and L. Claisen, Ber., 20, 2178 (1887).
B. J. Compton and W. C. Purdy, Can. J. Chem., 58, 2207 (1980).
P. G. Baraldi, D. Simoni, and S. Manfredini, Synthesis, 902 (1983).
E. Hakr, J. Kuthan, and V. Jehlička, Coll. Czechosl. Chem. Commun., 32, 4309 (1967).
C. D. Hurd and M. E. Nilson, J. Org. Chem., 20, 927 (1955).
N. A. Sokolov, I. G. Tishchenko, and T. P. Kosharnaya, Vestn. Belorus. un-ta, Ser. 2, No. 2, 71 (1984):
RZhKhim, 22Zh121 (1984).
17.
18.
V. M. Lyubchanskaya, L. M. Alekseeva, and V. G. Granik, Khim. Geterotsikl. Soed., 40 (1992). [Chem.
Heterocycl. Comp., 28, 34 (1992)].
G. F. Gavrilin, L. U. Bykova, T. D. Rogachkova, E. I. Novikova, and G. S. Savel'eva, Khim.-farm. Zh.,
7, No. 3, 43 (1973).
19.
20.
T. Tokumitsu and T. Hayashi, J. Org. Chem., 50, 1547 (1985).
M. A. Yurovskaya and O. D. Mit'kin, Khim. Geterotsikl. Soed., 1502 (1997). [Chem. Heterocycl. Comp.,
33, 1299 (1997)].
1254
