2,4,6-tris-tert-butylpyridine. In accord with this premise, the
additive suppressed formation of the spirocyclic lactone and
cleanly produced the allene with up to 89% ee (Table 3,
entries 2 and 3) using the segphos ligand (7b). Alternatively,
(tmeda)Zn(SbF6)2 was found to selectively absorb water,
improving selectivity to 94% ee (entry 4; tmeda = tetra-
methylethylenediamine). Notably, the allene and spirolactone
products were quite stable; for example, stirring with
0.25 equiv of trifluoroacetic acid in CH2Cl2 overnight at
ambient temperature caused no decomposition.
The potential clinical significance of spirocyclic oxin-
doles[16] has led to a demand for efficient methods for their
enantioselective synthesis.[17,18] Apart from their presence in
a large number of biologically active natural products,[19] their
topology allows functionalization of all four faces of a tetra-
hedron centered on the spirocyclic center, creating an ideal
environment for structural diversity. For these reasons, the
tandem formation of spirocyclic lactone 9 warranted further
study. Isolation of TES-substituted allene 4k (90% ee) and
TIPS-substituted 4q (89% ee) followed by resubjection to the
reaction conditions resulted in conversion to 9k (90% ee) and
9q (89% ee), respectively. Furthermore, the
a-silylketone A (Scheme 4) from the TBS-substituted alkyne
3m was isolated and found to cyclize to the spirocyclic lactone
in the presence of the palladium catalyst. From these results,
we propose a mechanism involving palladium-catalyzed
allene hydration to form A followed by palladium-catalyzed
cyclization (Scheme 4). Consistent with this mechanism,
addition of a small amount of water (5–10 mol%) provided
spirolactone products 9 in one step with high efficiency
(Table 3, entries 5–13). This class of compounds is particularly
difficult to prepare, with only two examples reported[9,20] for
the synthesis of the racemic, saturated versions of these
spirooxindoles. With our method, substrates with different
esters or indole substituents were well-tolerated, providing
the spirooxindoles with good yields and enantioselectivities
(Table 3, entries 5–13). Reactions conducted on a larger scale
also proceeded well (Table 3, entry 5). A key component of
this mechanism is stabilization of the carbocationic inter-
mediate B through the b-silyl effect;[21] indeed, non-silyl
substrates reluctantly formed the spirolactone, resulting in
a mixture of rearrangement product 4 and intermediate A.
Further study of the mechanism of the formation of allene
4 from 3 was undertaken by reacting two different substrates
in the same flask (Scheme 5). The lack of any crossover of the
alkyne portion points to a concerted Saucy–Marbet Claisen
rearrangement rather than a stepwise ionic mechanism.
Scheme 6. Transformations of the allenyl oxindoles. TBAF=tetra-
butylammonium fluoride, M.S.=molecular sieves.
The allenyl products 4 of the Saucy–Marbet Claisen
rearrangement were found to be useful substrates for
a number of transformations (Scheme 6), in addition to the
formation of the spirolactone (see above). For example,
protodesilation of 4k readily provided the simplest congener
4a, which was not directly accessible with high selectivity by
the rearrangement (see entry 1 in Tables 1 and 2). Hydration
of the allene also readily occurred with Hg(O2CCF3)2
providing a-silyl ketone 10, which could be further induced
to undergo a Brook rearrangement to provide silyl enol ether
11.
In summary, the first catalytic, enantioselective Claisen
rearrangement utilizing alkynyl substrates has been devel-
oped. This concerted Saucy–Marbet Claisen rearrangement
constitutes a mild entry to a range of allenyl oxindoles bearing
a quaternary stereocenter. Furthermore, tandem reactions of
silyl-substituted substrates permit the rapid assembly of
complex spiroooxindoles, an important class of biologically
active structures, in one operation. Moreover, this discovery
provides promise for the general use of alkynyl vinyl ethers in
catalytic, asymmetric rearrangement reactions, providing an
alternative route to valuable allenes.
Experimental Section
(R)-Ethyl 3-(1-(tert-butyldimethylsilyl)propa-1,2-dien-1-yl)-5-meth-
oxy-2-oxoindoline-3-carboxylate (4n): A solution of 3n (19.4 mg,
0.05 mmol) in toluene (1 mL) was added to a solution of the Pd[(R)-
binap](SbF6)2 complex (12 mg, 0.01 mmol, 20 mol%) in C6H5Cl
(1 mL) at ambient temperature. The resulting solution was stirred
in the absence of light at room temperature until the starting material
was completely consumed, as determined by TLC. Filtration through
a plug of SiO2 (5 mm ꢀ 2 cm) with diethyl ether, concentration of the
filtrate, and purification by column chromatography using 50%
diethyl ether/hexanes afforded 4n as a white solid in 82% yield: mp
23
136–1378C; ½aꢁD ¼ + 158.18 (c = 0.17, 93% ee, CH2Cl2). 1H NMR
(500 MHz, CDCl3): d = 7.92 (bs, 1H), 6.89 (d, J = 2.0 Hz, 1H), 6.79–
6.74 (m, 2H), 4.60 (d, J = 11.5 Hz, 1H), 4.41 (d, J = 11.5 Hz, 1H), 4.22
(qd, J = 7.5, 11.0 Hz, 1H), 4.13 (qd, J = 7.5, 11.0 Hz, 1H), 3.78 (s, 3H),
1.23 (t, J = 7.5 Hz, 3H), 0.92 (s, 9H), 0.12 (s, 3H), 0.10 ppm (s, 3H);
13C NMR (125 MHz, CDCl3): d = 212.5, 174.8, 168.8, 155.7, 134.3,
129.7, 114.5, 113.2, 110.2, 100.2, 93.6, 74.1, 62.4, 56.1, 27.6, 19.4, 14.2,
ꢀ4.0, ꢀ4.2 ppm; IR (film) n˜ = 3252, 2958, 2858, 1931, 1746, 1622, 1468,
1259, 1089, 1027 cmꢀ1
; HRMS (ES) m/z = 386.1788 calcd for
C21H28NO4Si [MꢀH]ꢀ, found 386.1776; CSP HPLC (Chiralpak IA,
Scheme 5. Crossover mechanism experiment.
1 mLminꢀ1, 95:5 hexanes/iPrOH) tR(1) = 14.0 min, tR(2) = 21.6 min.
