Kazuo Nagasawa et al.
in vacuo at below 258C. The residue was dissolved in toluene (10 mL),
and K2CO3 (354 mg) and MgSO4 (2.0 g) were added at room temperature
under N2 atmosphere. After stirring for 11 h at 408C, the reaction was
quenched with aqueous sat. NaHCO3 and extracted with ethyl acetate.
The combined organic layer was dried over MgSO4, filtered, and concen-
trated in vacuo at below 258C. The residue was purified by silica gel
column chromatography (n-hexane/ethyl acetate=3:1) to give isoxazoli-
dine 10 (179 mg, 0.70 mmol, 2 steps 33%). Spectral data for isoxazolidine
128.5, 128.0, 127.5, 118.4, 69.3, 65.6, 27.2, 19.1 ppm; HRMS (ESI, M+
Na+) calcd for C27H31NNaO3Si 468.1971, found 468.1961.
To a solution of hydroxylamine (251 mg, 0.564 mmol) and [PdACHTUNGTRENNUNG(PPh3)4]
(13 mg, 0.011 mmol) in THF (5 mL) was added morpholine (98 mL,
1.13 mmol) at 08C under N2 atmosphere. After stirring for 30 min, the re-
action was quenched with H2O and extracted with ethyl acetate. The or-
ganic layer was dried over MgSO4, filtered, and concentrated in vacuo.
The residue was purified by silica gel column chromatography (n-hexane/
ethyl acetate=15:1 to 2:1) to give carboxylic acid 21 (138 mg,
0.341 mmol, 60%). Spectral data for carboxylic acid 21: 1H NMR
(400 MHz, CDCl3) d=7.77–7.08 (m, 15H), 4.65 (s, 1H), 4.47 (s, 1H),
1.09 ppm (s, 9H); 13C NMR (100 MHz, CDCl3) d=177.8, 136.0, 135.6,
133.2, 132.8, 129.8, 129.6, 128.7, 128.6, 128.0, 127.6, 69.2, 27.2, 19.1 ppm;
HRMS (ESI, M+Na+) calcd for C24H27NNaO3Si 428.1658, found
428.1647.
1
10: H NMR (400 MHz, CDCl3) d=4.34 (d, J=12.4 Hz, 1H), 4.23 (q, J=
7.3 Hz, 2H), 4.13 (d, J=12.4 Hz, 1H), 4.06 (d, J=8.7 Hz, 1H), 4.05 (d,
J=16.5 Hz, 1H), 3.81 (d, J=16.5 Hz, 1H), 2.99 (t, J=7.3 Hz, 1H), 1.96–
1.76 (m, 6H), 1.30 ppm (t, J=6.9 Hz, 3H); 13C NMR (100 MHz, CDCl3)
d=168.7, 168.3, 80.0, 73.4, 70.5, 61.7, 56.9, 52.8, 35.0, 30.1, 23.2, 14.1 ppm;
HRMS (ESI, M+Na+) calcd for C12H17NNaO5 278.1004, found 278.1010.
Nitrone 19: To a solution of isoxazolidine 10 (21 mg, 0.083 mmol) in
CH2Cl2 (1 mL) was added m-CPBA (28 mg, 0.124 mmol) at 08C under
N2 atmosphere. After stirring for 1.5 h at room temperature, the reaction
was quenched with aqueous 10% Na2S2O3 and sat. NaHCO3, and extract-
ed with CH2Cl2. The organic layer was dried over MgSO4, filtered, and
concentrated in vacuo. The residue was purified by silica gel column
chromatography (n-hexane/ethyl acetate=1:1) to give nitrone 19
(12.4 mg, 0.046 mmol, 55%). Spectral data for nitrone 19: 1H NMR
(400 MHz, CDCl3) d=7.16 (s, 1H), 4.79 (d, J=12.6 Hz, 1H), 4.47 (d, J=
9.2 Hz, 1H), 4.22 (q, J=7.5 Hz, 2H), 4.19 (d, J=12.0, 1H), 3.18 (br, 1H),
Ester 22: To a solution of a-hydroxyketone 14 (92 mg, 0.457 mmol), car-
boxylic acid 21 (371 mg, 0.915 mmol), and DMAP (11 mg, 0.091 mmol) in
CH2Cl2 (4 mL) was added EDCI·HCl (377 mg, 1.371 mmol) at 08C under
N2 atmosphere. After stirring for 1.5 h, the reaction was quenched with
H2O and extracted with CH2Cl2. The organic layer was dried over
MgSO4, filtered, and concentrated in vacuo. The residue was purified by
silica gel column chromatography (n-hexane/ethyl acetate=50:1 to 30:1)
to give ester 22 (86 mg, 0.146 mmol, 32%). Spectral data for ester 22:
1H NMR (400 MHz, CDCl3) d=7.79–7.11 (m, 15H), 6.88 (dt, J=6.4,
15.1 Hz, 1H), 6.02 (br, 1H), 5.81 (d, J=15.6 Hz, 1H), 4.72 (d, J=2.8 Hz,
2H), 4.60 (s, 1H), 4.20 (q, J=6.9 Hz, 2H), 2.40 (dq, J=3.7, 7.3 Hz, 2H),
2.14 (q, J=6.9 Hz, 2H), 1.73 (quint, J=7.3 Hz, 2H), 1.30 (t, J=7.3 Hz,
3H), 1.12 ppm (s, 9H); 13C NMR (100 MHz, CDCl3) d=203.3, 171.9,
166.4, 147.7, 135.9, 135.6, 133.3, 132.7, 129.8, 129.6, 128.7, 128.6, 128.0,
127.5, 122.0, 69.1, 68.4, 60.2, 37.6, 31.0, 27.2, 21.1, 19.1, 14.2 ppm; HRMS
(ESI, M+Na+) calcd for C34H41NNaO6Si 610.2601, found 610.2572.
2.41–2.35 (m, 1H), 2.16–2.10 (m, 2H), 2.06–1.94 (m, 2H), 1.92–1.86ACTHNUTRGENUG(N m,
1H), 1.65–1.57 (m, 1H), 1.29 ppm (t, 7.5 Hz, 3H); 13C NMR (100 MHz,
CDCl3) d=173.7, 159.1, 126.1, 77.7, 71.6, 71.2, 62.0, 50.8, 36.3, 30.3, 24.0,
14.1 ppm; HRMS (ESI, M+Na+) calcd for C12H17NNaO6 294.0954,
found 294.0953.
Imine 18: To a solution of nitrone 19 (96 mg, 0.35 mmol) in toluene
(4 mL) was added PPh3 (372 mg, 1.42 mmol) at room temperature under
N2 atmosphere. After stirring for 17 h at 1008C, the reaction was concen-
trated in vacuo. The residue was purified by silica gel column chromatog-
raphy (n-hexane/ethyl acetate=3:1) to give imine 18 (60.3 mg,
0.235 mmol, 66%). Spectral data for imine 18: 1H NMR (400 MHz,
CDCl3) d=7.71 (s, 1H), 4.55 (d, J=11.5 Hz, 1H), 4.31 (dd, J=5.5,
7.3 Hz, 1H), 4.22 (q, J=7.3 Hz, 2H), 4.15 (d, J=11.5 Hz, 1H), 3.50 (d,
J=8.7 Hz, 1H), 2.15–1.54 (m, 6H) 1.29 ppm (t, J=7.3 Hz, 3H);
13C NMR (100 MHz, CDCl3) d=174.1, 154.8, 150.6, 72.5, 71.7, 66.8, 61.5,
48.3, 36.9, 28.7, 23.6, 14.2 ppm; HRMS (ESI, M+Na+) calcd for
C12H17NNaO5 278.1004, found 278.0969.
Imine 25: To a solution of ester 22 (86 mg, 0.146 mmol) in CH2Cl2 (1 mL)
was added TFA (0.5 mL) at room temperature under N2 atmosphere.
After stirring for 1 h, the reaction was concentrated in vacuo, and the res-
idue was dissolved in 1,2-dichloroethane (1.5 mL). The mixture was then
heated at 508C for 30 min, concentrated in vacuo, and the residue was
purified by silica gel column chromatography (n-hexane/ethyl acetate=
50:1 to 30:1) to give imine 25 (35.8 mg, 0.106 mmol, 74%). Spectral data
for imine 25: 1H NMR (300 MHz, CDCl3) d=7.94–7.91 (m, 2H), 7.52–
7.40 (m, 3H), 4.52 (d, J=11.4 Hz, 1H), 4.35 (q, J=4.5 Hz, 1H), 4.23 (d,
J=11.4 Hz, 1H), 4.02 (q, J=7.2 Hz, 2H), 2.36–2.29 (m, 1H), 2.26–2.17
(m, 2H), 2.05–1.93 (m, 2H), 1.75–1.60 (m, 2H), 1.05 ppm (t, J=7.2 Hz,
3H); 13C NMR (75 MHz, CDCl3) d=174.0, 156.2, 155.3, 133.4, 131.2,
128.6, 128.2, 72.1, 66.8, 61.2, 47.6, 35.9, 28.6, 23.6, 13.7 ppm; HRMS (ESI,
M+Na+) calcd for C18H21NNaO5 354.1317, found 354.1330.
Carboxylic acid 21: To
a
solution of (Æ)-mandelic acid (1.00 g,
6.57 mmol) and K2CO3 (2.72 g, 19.7 mmol) in DMF (40 mL) was added
allyl bromide (556 mL, 6.57 mmol) at room temperature under N2 atmos-
phere. After stirring for 5 h, the reaction was quenched with aqueous sat.
NH4Cl and extracted with ethyl acetate. The organic layer was dried over
MgSO4, filtered, and concentrated in vacuo. The residue was purified by
silica gel column chromatography (n-hexane/ethyl acetate=10:1 to 5:1)
to give the allyl ester (1.15 g, 5.98 mmol, 91%). Spectral data for the allyl
ester: 1H NMR (400 MHz, CDCl3) d=7.45–7.31 (m, 5H), 5.88–5.78 (m,
1H), 5.21–5.12 (m, 3H), 4.71–4.61 (m, 2H), 3.46 ppm (d, J=5.5 Hz, 1H);
13C NMR (75 MHz, CDCl3) d=173.3, 138.1, 131.0, 128.5, 128.4, 126.5,
118.7, 72.8, 66.4 ppm; HRMS (ESI, M+Na+) calcd for C11H12NaO3
215.0684, found 215.0699.
Lactam 27: To a solution of imine 25 (432 mg, 1.28 mmol) in methanol
(5 mL) was added HCl (1 mL) at room temperature. After stirring for
7 h at 508C, the reaction was concentrated in vacuo to give crude amine
9. To a solution of crude amine 9 in methanol (5 mL) was added Et3N
(1 mL) at room temperature. After stirring for 5 h at room temperature,
the reaction was concentrated in vacuo to give lactam 26. To a solution
of crude lactam 26 in Ac2O (7 mL) was added pyridine (7 mL) at room
temperature. After stirring for 5 h, the reaction was concentrated in
vacuo. The residue was purified by silica gel column chromatography (n-
hexane/ethyl acetate=1:1 to 1:5) to give lactam 27 (267 mg, 1.05 mmol,
82%, 3 steps). Spectral data for lactam 27: 1H NMR (300 MHz, CDCl3)
d=6.60–6.56 (br, 1H), 5.37 (d, J=8.9 Hz, 1H), 4.26 (d, J=11.4 Hz, 1H),
3.96 (d, J=11.4 Hz, 1H), 2.93–2.86 (m, 1H), 2.17 (s, 3H), 2.09 (s, 3H),
1.80–1.63 ppm (brm, 6H); 13C NMR (75 MHz, CDCl3) d=172.8, 170.6,
170.2, 71.7, 68.4, 67.6, 45.4, 36.8, 25.9, 24.6, 20.8, 20.6 ppm; HRMS (ESI,
M+Na+) calcd for C12H17NNaO5 278.1004, found 278.1004.
To a solution of allyl ester (28 mg, 0.143 mmol) and DIEA (98.5 mL,
0.572 mmol) in CH2Cl2 (1 mL) was added Tf2O (27 mL, 0.157 mmol) at
À788C under N2 atmosphere. After stirring for 15 min, NH2OTBDPS
(42 mg, 0.286 mmol) in CH2Cl2 (1 mL) was added to the above solution,
and the mixture was stirred at room temperature. After stirring for 2 h,
the reaction was quenched with aqueous sat. NaHCO3 at 08C. The mix-
ture was extracted with twice with CH2Cl2, and the combined organic
layer was dried over MgSO4, filtered, and concentrated in vacuo. The res-
idue was purified by silica gel column chromatography (n-hexane/ethyl
acetate=100:1 to 50:1) to give hydroxylamine (30.7 mg, 0.069 mmol,
48%). Spectral data for hydroxylamine: 1H NMR (400 MHz, CDCl3) d=
7.77–7.01 (m, 15H), 5.97–5.87 (m, 1H), 5.34–5.21 (m, 2H), 4.81–4.65 (m,
2H), 4.47 (s, 1H), 1.09 ppm (s, 9H); 13C NMR (100 MHz, CDCl3) d=
172.2, 136.0, 135.9, 135.8, 135.7, 133.5, 133.4, 133.2, 131.8, 129.7, 129.6,
Lactam 28: To a solution of lactam 27 (141 mg, 0.554 mmol), Et3N
(192 mL, 1.39 mmol), and DMAP (7 mg, 0.055 mmol) in CH2Cl2 (5 mL)
was added Boc2O (242 mg, 1.11 mmol) at room temperature under N2 at-
mosphere. After stirring for 1 h, the reaction was quenched with aqueous
sat. NH4Cl and extracted with CH2Cl2. The organic layer was dried over
MgSO4, filtered, and concentrated in vacuo. The residue was purified by
silica gel column chromatography (n-hexane/ethyl acetate=10:1 to 2:1)
