Selective and Sensitive Fluoride Detection
through Alkyne Cruciform Desilylation
ꢀ
ꢁ
Minyoung Jo, Jaebum Lim, and Ognjen S. Miljanic*
Department of Chemistry, University of Houston, 112 Fleming Building, Houston,
Texas 77204-5003, United States
miljanic@uh.edu
Received April 22, 2013
ABSTRACT
Desilylation of silylethynyl-substituted benzobisoxazole cruciforms can be achieved using stoichiometric amounts of fluoride, leading to a significant
change in their UVꢀvis absorption and fluorescence. This response is observable at micromolar concentrations of fluoride, and, in the case of a
triisopropylsilyl-substituted cruciform fluorophore, extraordinarily selective for fluoride over other small inorganic anions, including hydroxide, acetate,
and phosphate.
During the past decade, cross-conjugated cruciform
fluorophores1 have been explored as versatile sensors for
Brønsted and Lewis acids,1a,2 metals,3 anions,4 amines,4a,5
phenols,2b and other analytes. A great majority of these
sensing protocols are reversible in nature, based on either
coordinative or dynamically covalent interactions. While
reversibility generally presents a desirable feature in sensor
design, low association constants between the cruciforms
and their analytes can limit the sensitivity of analyte
detection. Conversely, operation of an irreversible and
high-yielding covalent reaction on a cruciform sensor
constitutes a pathway for highly sensitive detection, as an
analyte needs to be added only in close-to-stoichiometric
amounts relative to the highly dilute fluorescent sensor.
In this contribution, we illustrate this principle through
the first use of benzobisoxazole cruciforms1b,2b,d,4b,6 as
irreversible, specific, and sensitive sensors for fluoride.
Fluorine and silicon form a very strong bond (135 kcal
molꢀ1),7 and thus fluoride-induced desilylation reactions
proceed rapidly and irreversibly.8 Sensing of fluoride ions
through the cleavage of OꢀSi bonds (and the exploration
of reactivity of the resultant OꢀH groups) was achieved by
(1) (a) Zucchero, A. J.; McGrier, P. L.; Bunz, U. H. F. Acc. Chem.
Res. 2010, 43, 397–408. (b) Feldman, A. K.; Steigerwald, M. L.; Guo, X.;
Nuckolls, C. Acc. Chem. Res. 2008, 41, 1731–1741.
(2) (a) Schwaebel, T.; Trapp, O.; Bunz, U. H. F. Chem. Sci. 2013, 4,
ꢀ
ꢁ
273–281. (b) Lim, J.; Nam, D.; Miljanic, O. S. Chem. Sci. 2012, 3, 559–
563. (c) Davey, E. A.; Zucchero, A. J.; Trapp, O.; Bunz, U. H. F. J. Am.
Chem. Soc. 2011, 133, 7716–7718. (d) Lim, J.; Albright, T. A.; Martin,
ꢀ
ꢁ
B. R.; Miljanic, O. S. J. Org. Chem. 2011, 76, 10207–10219. (e) Spitler,
E. L.; Haley, M. M. Tetrahedron 2008, 64, 11469–11474. (f) Marsden,
J. A.; Miller, J. J.; Shirtcliff, L. D.; Haley, M. M. J. Am. Chem. Soc. 2005,
127, 2464–2476.
€
(3) (a) Hauck, M.; Schonhaber, J.; Zucchero, A. J.; Hardcastle, K. I.;
€
Muller, T. J.; Bunz, U. H. F. J. Org. Chem. 2007, 72, 6714–6725.
(b) Wilson, J. N.; Bunz, U. H. F. J. Am. Chem. Soc. 2005, 127, 4124–4125.
ꢁ
(6) (a) Lim, J.; Osowska, K.; Armitage, J. A.; Martin, B. R.; Miljanic,
ꢀ
ꢀ
(4) (a) Lirag, R. C.; Le, H. T. M.; Miljanic, O. S. Chem. Commun.
ꢁ
ꢁ
O. S. CrystEngComm 2012, 14, 6152–6162. (b) Osowska, K.; Miljanic,
ꢀ
ꢀ
ꢁ
2013, 49, 4304–4306. (b) Lim, J.; Miljanic, O. S. Chem. Commun. 2012,
48, 10301–10303. (c) Brombosz, S. M.; Zucchero, A. J.; Phillips, R. L.;
Vazquez, D.; Wilson, A.; Bunz, U. H. F. Org. Lett. 2007, 9, 4519–4522.
(5) (a) Kumpf, J.; Bunz, U. H. F. Chem.;Eur. J. 2012, 18, 8921–
8924. (b) Patze, C.; Broedner, K.; Rominger, F.; Trapp, O.; Bunz,
U. H. F. Chem.;Eur. J. 2011, 17, 13720–13725. (c) McGrier, P. L.;
Solntsev, K. M.; Miao, S.; Tolbert, L. M.; Miranda, O. R.; Rotello,
V. M.; Bunz, U. H. F. Chem.;Eur. J. 2008, 14, 4503–4510.
O. S. Chem. Commun. 2010, 46, 4276–4278. (c) Klare, J. E.; Tulevski, G.
S; Nuckolls, C. Langmuir 2004, 20, 10068–10072. (d) Klare, J. E.;
Tulevski, G. S.; Sugo, K.; de Picciotto, A.; White, A. K.; Nuckolls, C.
J. Am. Chem. Soc. 2003, 125, 6030–6031. (e) Tlach, B. C.; Tomlinson,
A. L.; Bhuwalka, A.; Jeffries-EL, M. J. Org. Chem. 2011, 76, 8670–8681.
(7) See: Yoder, C. Wired Chemist: Common Bond Energies (D) and
Bond Lengths (r).http://www.wiredchemist.com/chemistry/data/bond-
energies-lengths, accessed July 8, 2013.
r
10.1021/ol401120a
XXXX American Chemical Society

Figure 1. Frontier molecular orbitals (FMOs) of silylated cruciforms 1ꢀ3. Spatial separation of FMOs is most pronounced in
compound 3.
Kim and Swager,9 and subsequently used by other groups,
including in the context of physiologically relevant10 sen-
sing of fluoride in aqueous solutions. We speculated that
fluoride could also be sensed by cleaving the CꢀSi bond
in silylated alkynes, and that the resultant change in the
electronics of the triple bond would be readily transmitted
through the conjugated circuit.
In order to assess the potential of silylated benzobisox-
azole cruciforms as fluoride sensors, we first computationally
evaluated the frontier molecular orbitals (FMOs) of trimethyl-
silyl (TMS)-substituted compounds 1ꢀ3 (Figure 1) using the
Gaussian 09W11 software package at the B3LYP/3-21G
(8) The strong SiꢀF bond was also utilized in fluoride detection via
the formation of hypervalent silicon complexes. See: (a) Lenormand, H.;
Goddard, J. P.; Fensterbank, L. Org. Lett. 2013, 15, 748–751. (b) Kim,
Y.; Kim, M.; Gabbaı, F. P. Org. Lett. 2010, 12, 600–602. (c) Yamaguchi,
S.; Akiyama, S.; Tamao, K. J. Am. Chem. Soc. 2000, 122, 6793–6794.
(d) Tamao, K.; Hayashi, T.; Ito, Y. J. Organomet. Chem. 1996, 506, 85–
91. (e) Jung, M. E.; Xia, H. Tetrahedron Lett. 1988, 29, 297–300.
(9) Kim, T.-H.; Swager, T. M. Angew. Chem., Int. Ed. 2003, 42, 4803–
4806.
Scheme 1. Synthesis of Fluorophores 1ꢀ3 and 7
(10) See, inter alia: (a) Ke, B.; Chen, W.; Ni, N.; Cheng, Y.; Dai, C.;
Dinh, H.; Wang, B. Chem. Commun. 2013, 49, 2494–2496. (b) Zheng, F.;
Zeng, F.; Yu, C.; Hou, X.; Wu, S. Chem.;Eur. J. 2013, 19, 936–942.
(c) Kim, D.; Singha, S.; Wang, T.; Seo, E.; Lee, J. H.; Lee, S.-J.; Kim,
K. H.; Anh, K. H. Chem. Commun. 2012, 48, 10243–10245. (d) Baker,
M. S.; Phillips, S. T. Org. Biomol. Chem. 2012, 10, 3595–3599. (e) Bao,
Y.; Liu, B.; Wang, H.; Tian, J.; Bai, R. Chem. Commun. 2011, 47, 3957–
3959. (f) Kim, S. Y.; Park, J.; Koh, M.; Park, S. B.; Hong, J.-I. Chem.
Commun. 2009, 4735–4737. (g) Jiang, X.; Vieweger, M. C.; Bollinger,
J. C.; Dragnea, B.; Lee, D. Org. Lett. 2007, 9, 3579–3582.
(11) Frisch, M. J.; Trucks, G. W.; Schlegel, H. B.; Scuseria, G. E.;
Robb, M. A.; Cheeseman, J. R.; Scalmani, G.; Barone, V.; Mennucci, B.;
Petersson, G. A.; Nakatsuji, H.; Caricato, M.; Li, X.; Hratchian, H. P.;
Izmaylov, A. F.; Bloino, J.; Zheng, G.; Sonnenberg, J. L.; Hada, M.;
Ehara, M.; Toyota, K.; Fukuda, R.; Hasegawa, J.; Ishida, M.; Nakajima,
T.; Honda, Y.; Kitao, O.; Nakai, H.; Vreven, T.; Montgomery, J. A., Jr.;
Peralta, J. E.; Ogliaro, F.; Bearpark, M.; Heyd, J. J.; Brothers, E.; Kudin,
K. N.; Staroverov, V. N.; Keith, T.; Kobayashi, R.; Normand, J.;
Raghavachari, K.; Rendell, A.; Burant, J. C.; Iyengar, S. S.; Tomasi, J.;
Cossi, M.; Rega, N.; Millam, J. M.; Klene, M.; Knox, J. E.; Cross, J. B.;
Bakken, V.; Adamo, C.; Jaramillo, J.; Gomperts, R.; Stratmann, R. E.;
Yazyev, O.; Austin, A. J.; Cammi, R.; Pomelli, C.; Ochterski, J. W.;
Martin, R. L.; Morokuma, K.; Zakrzewski, V. G.; Voth, G. A.; Salvador,
P.; Dannenberg, J. J.; Dapprich, S.;Daniels, A. D.; Farkas, O.; Foresman,
J. B.; Ortiz, J. V.; Cioslowski, J.; Fox, D. J. Gaussian 09, Revision B.01;
Gaussian, Inc.: Wallingford, CT, 2010.
level of theory. Graphical representations of highest occu-
pied (HOMOs) and lowest unoccupied molecular orbitals
(LUMOs) of 1ꢀ3 are shown in Figure 1. In phenyl-sub-
stituted cruciform 1, FMOs are largely overlapping, suggest-
ing that desilylation should have a similar effect on both
orbitals and thus lead to just a small change in the
B
