Full Papers
doi.org/10.1002/ejoc.202100677
128.72, 128.63, 128.62, 128.42, 128.38, 128.33, 128.32, 127.10, 92.58,
Experimental Section
73.31, 72.71, 70.87, 68.84, 62.69, 36.23; HRMS (ESI) calcd for
C39H32N2O11Na [M+Na]+ 727.1898, found 727.1901.
General Information. Commercial reagents were used without
further purification unless specialized. Crushed 4 Å molecular sieves
were activated through flame-drying under high vacuum immedi-
ately prior to use. Dry CH2Cl2 were obtained by refluxing with CaH2
(5%, w/v) under argon. Flash column chromatography was
performed on silica gel SiliaFlash P60 (40–63 μm, Silicycle). The TLC
plates were visualized with UV light and/or by staining with EtOH/
H2SO4 (8%, v/v). Flash column chromatography was performed on
Silica Gel 60 (40–64 μm, Fluka, Canada). NMR spectra were
2,3,4,6-Tetra-O-benzyl-D-glucopyranosyl-1-methylimidazole-2-carboxy-
late (3b) Esterification of hemiacetal 2b (5.0 g, 9.3 mmol) with acid
1 (1.8 g, 14 mmol) employing the General Procedure A afforded
donor 3b (5.1 g, 85%, α/β=1:1.3) as a colorless syrup: [α]25 D=
1
36.0 (c 1.0, CHCl3); H NMR (500 MHz, CDCl3) δ 7.36–7.26 (m, 23.1H),
7.25–7.21 (m, 3.3H), 7.21–7.17 (m, 3.70H), 7.06 (d, J=0.9 Hz, 1H),
7.04 (d, J=0.9 Hz, 0.67H), 6.57 (d, J=3.6 Hz, 0.7H), 5.85 (d, J=
7.9 Hz, 1H), 5.02 (d, J=6.0 Hz, 0.7H), 4.99 (d, J=5.9 Hz, 1H), 4.97 (d,
J=10.9 Hz, 1H), 4.89 (s, 0.74H), 4.88–4.84 (m, 3.55H), 4.80–4.71 (m,
1.52H), 4.64–4.60 (m, 1.75H), 4.59–4.54 (m, 1.61H), 4.51 (d, J=
12.1 Hz, 1H), 4.47 (d, J=12.1 Hz, 0.77H), 4.23 (t, J=9.4 Hz, 0.78H),
4.13 (dt, J=10.0, 2.6 Hz, 0.80H), 3.97 (d, J=1.0 Hz, 4.64H), 3.89–3.83
(m, 1.16H), 3.83–3.75 (m, 5.46H), 3.72–3.64 (m, 1.72H); 13C NMR
(126 MHz, CDCl3) δ 157.55, 138.68, 138.37, 138.23, 138.18, 138.05,
138.01, 137.78, 137.66, 135.94, 135.66, 129.88, 129.65, 128.39,
128.37, 128.33, 128.29, 128.18, 128.01, 128.00, 127.93, 127.90,
127.89, 127.87, 127.85, 127.76, 127.73, 127.68, 127.67, 127.58,
127.55, 127.53, 126.85, 126.61, 94.97, 91.20, 84.59, 81.61, 81.08,
78.76, 77.26, 76.96, 75.90, 75.72, 75.70, 75.09, 75.07, 75.04, 73.47,
73.43, 73.21, 73.09, 68.43, 68.02, 36.02, 35.91; HRMS (ESI) calcd for
C39H40N2O7Na [M+Na]+ 671.2728, found 671.2732.
measured on Bruker AM 400, Agilent 500 or 600 MHz NMR
1
spectrometer at 25 C. H and 13C NMR signals were calibrated to
°
the residual proton and carbon resonance of the solvent (CDCl3:
δH=7.26 ppm; δC=77.31 ppm). High-resolution mass spectra were
recorded with IonSpec 4.7 Tesla FTMS or APEXIII 7.0 Tesla FTMS.
Elemental analysis was obtained on a Vario EL III elemental
analyzer. Optical rotations were measured on an Anton Paar
MCP5500 polarimeter. Single crystal X-ray data were collected on a
Bruker Apex II CCD diffractometer operating at 50 kV and 30 mA
using Mo Kα radiation (λ=0.71073 Å) at 133 K.
General Procedure A for the Preparation of Glycosyl 1-Meth-
ylimidazole-2-carboxylates. To a solution of glycosyl hemiacetals 2
(1.0 eq.) in dry DMF (0.20 M) were added 1-methyl-2-imidazolecar-
boxylic acid 1 (1.5 eq.), EDCI (1.6 eq.), and DMAP (1.6 eq.). The
mixture was stirred at room temperature and monitored by TLC.
After stirring for 8 h, the mixture was diluted with CH2Cl2, and was
then washed with water and brine. The organic layer was dried
over Na2SO4, filtered, and concentrated in vacuo. The resulting
residue was purified by silica gel column chromatography to afford
the desired esterification product.
2,3,4,6-Tetra-O-benzoyl-D-mannopyranosyl-1-methylimidazole-2-car-
boxylate (3c) Esterification of mannopyranosyl hemiacetal 2c (1.0 g,
1.7 mmol) with acid 1a (0.32 g, 2.5 mmol) employing general
procedure B afforded donor 3c (1.1 g, 94%, α/β=1:3.3) as a white
solid. Alternatively, esterification of mannopyranosyl hemiacetal 2c
(100 mg, 0.17 mmol) with acid 1a (32 mg, 0.25 mmol) using the
General Procedure A afforded donor 3c (90 mg, 76%, α/β=1/1.5)
1
General Procedure B for the Preparation of Glycosyl 1-Meth-
ylimidazole-2-carboxylates. To a solution of glycosyl hemiacetals 2
(1.0 eq.) in dry CH2Cl2 (0.20 M) were added 1-methyl-2-imidazole-
carboxylic acid 1a (1.5 eq.), DCC (1.6 eq.), and DMAP (0.2 eq.). The
mixture was stirred at room temperature and monitored by TLC.
After stirring for 8 h, the reaction mixture was filtered through a
pad of Celite and concentrated in vacuo. The resulting residue was
purified by silica gel column chromatography to afford the
esterification product.
as a white solid: [α]25 D=À 21.8 (c 1.0, CHCl3); H NMR (500 MHz,
CDCl3) δ 8.15–8.05 (m, 5.81H), 8.01–7.97 (m, 2H), 7.97–7.93 (m,
1.25H), 7.90–7.87 (m, 1.21H), 7.87–7.82 (m, 2H), 7.62–7.54 (m, 3H),
7.52–7.46 (m, 1.65H), 7.46–7.33 (m, 10.65H), 7.31–7.21 (m, 4H), 7.14
(d, J=0.9 Hz, 1H), 7.11–7.08 (m, 0.65H), 6.94 (s, 0.63H), 6.64 (d, J=
2.0 Hz, 1H), 6.49 (d, J=1.3 Hz, 0.63H), 6.35 (t, J=10.2 Hz, 1H), 6.16
(td, J=6.3, 3.0 Hz, 2H), 5.96 (dd, J=3.3, 2.0 Hz, 1H), 5.83 (dd, J=9.6,
3.2 Hz, 0.72H), 4.83 (d, J=10.1 Hz, 1H), 4.79 (dd, J=12.2, 2.9 Hz,
0.67H), 4.75 (dd, J=12.5, 2.5 Hz, 1H), 4.61 (dd, J=12.3, 4.6 Hz,
0.70H), 4.52 (dd, J=12.5, 3.2 Hz, 1H), 4.40 (ddd, J=9.3, 4.5, 2.9 Hz,
0.70H), 4.03 (s, 3H), 3.79 (s, 1.85H); 13C NMR (126 MHz, CDCl3) δ
165.94, 165.39, 165.32, 165.28, 165.15, 165.05, 156.47, 156.32,
135.31, 135.01, 133.57, 133.52, 133.46, 133.42, 133.33, 133.16,
133.02, 132.98, 130.29, 129.91, 129.87, 129.84, 129.80, 129.71,
129.66, 129.12, 128.94, 128.87, 128.78, 128.67, 128.57, 128.52,
128.42, 128.38, 128.36, 128.28, 128.24, 127.36, 126.87, 91.69, 91.34,
73.38, 71.30, 71.27, 69.92, 69.35, 68.79, 66.35, 65.97, 62.59, 62.10,
36.06, 35.94; HRMS (ESI) calcd for C39H32N2O11Na [M+Na]+
727.1898, found 727.1902.
2,3,4,6-Tetra-O-benzoyl-D-glucopyranosyl-1-methylimidazole-2-car-
boxylate (3a) Esterification of hemiacetal 2a (100 mg, 0.17 mmol)
with acid 1 (32 mg, 0.25 mmol) employing General Procedure A
afforded 3a (94 mg, 80%, α/β=1:3.5) as a white solid. Alter-
natively, esterification of hemiacetal 2a (1.0 g, 1.8 mmol) with acid
1 (0.33 g, 2.6 mmol) with General Procedure B afforded 3a (0.90 g,
71%, α/β=1:3) as a white solid. 3aα: [α]25 D=113.1 (c 1.0, CHCl3);
1H NMR (500 MHz, CDCl3) δ 8.06 (dd, J=8.4, 1.3 Hz, 2H), 7.99–7.91
(m, 4H), 7.89–7.85 (m, 2H), 7.57–7.53 (m, 1H), 7.51–7.45 (m, 2H),
7.45–7.40 (m, 3H), 7.38–7.26 (m, 7H), 7.08 (d, J=1.0 Hz, 1H), 6.90 (d,
J=3.8 Hz, 1H), 6.39 (t, J=10.0 Hz, 1H), 5.90 (t, J=10.0 Hz, 1H), 5.64
(dd, J=10.2, 3.8 Hz, 1H), 4.85 (dt, J=10.3, 3.3 Hz, 1H), 4.66 (dd, J=
12.5, 2.8 Hz, 1H), 4.49 (dd, J=12.5, 3.7 Hz, 1H), 3.82 (s, 3H); 13C NMR
(126 MHz, CDCl3) δ 166.06, 165.57, 165.49, 165.15, 157.13, 135.26,
133.4, 133.44, 133.21, 133.09, 130.01, 129.92, 129.81, 129.72, 129.59,
128.94, 128.70, 128.69, 128.41, 128.38, 128.37, 128.30, 127.15, 90.27,
70.80, 70.67, 70.32, 68.52, 62.16, 35.94. 3aβ: [α]25 D=26.1 (c 1.0,
CHCl3); 1H NMR (500 MHz, CDCl3) δ 8.02 (dd, J=8.3, 1.4 Hz, 2H),
7.95–7.88 (m, 4H), 7.88–7.84 (m, 2H), 7.55–7.45 (m, 3H), 7.45–7.37
(m, 3H), 7.36–7.31 (m, 4H), 7.31–7.26 (m, 2H), 7.18 (s, 1H), 7.01 (s,
1H), 6.40 (d, J=7.8 Hz, 1H), 6.02 (t, J=9.3 Hz, 1H), 5.89–5.75 (m, 2H),
4.65 (dd, J=12.3, 3.1 Hz, 1H), 4.53 (dd, J=12.3, 5.0 Hz, 1H), 4.40
(ddd, J=9.6, 5.0, 3.1 Hz, 1H), 3.92 (s, 3H); 13C NMR (126 MHz, CDCl3)
δ 166.04, 165.65, 165.05, 164.85, 156.44, 135.02, 133.52, 133.45,
133.33, 133.11, 130.03, 129.89, 129.84, 129.83, 129.79, 129.45,
2,3,4-Tri-O-benzoyl-L-rhamnopyranosyl-1-methylimidazole-2-carboxy-
late (3d) Esterification of rhamnopyranosyl hemiacetal 2d (1.0 g,
2.1 mmol) with acid 1a (0.40 g, 3.2 mmol) employing General
Procedure A afforded donor 3d (0.99 g, 81%, α/β=1.5:1) as a
white solid: [α]25 D=97.2 (c 1.0, CHCl3); 1H NMR (500 MHz, CDCl3) δ
8.14–8.07 (m, 3.40H), 8.02 (dt, J=8.4, 1.3 Hz, 2.11H), 7.98–7.93 (m,
1.34H), 7.81 (m, 3.20H), 7.62 (m, 1.61H), 7.50 (qt, J=7.4, 6.5 Hz,
5.29H), 7.45–7.36 (m, 5.26H), 7.34–7.32 (m, 1.15H), 7.29–7.21 (m,
3.20H), 7.20–7.17 (m, 1.22H), 7.13 (t, J=1.2 Hz, 0.61H), 6.98 (d, J=
1.1 Hz, 0.59H), 6.56 (d, J=1.9 Hz, 1H), 6.37 (d, J=1.3 Hz, 0.65H), 6.10
(dt, J=2.9, 1.4 Hz, 1H), 6.08 (dd, J=3.6, 1.7 Hz, 0.63H), 5.89 (dd, J=
3.5, 1.9 Hz, 1H), 5.80 (t, J=10.0 Hz, 1H), 5.72–5.68 (m, 1.21H), 4.71–
4.56 (m, 1H), 4.08 (d, J=2.5 Hz, 3.70H), 3.83 (s, 1.88H), 1.47 (d, J=
6.1 Hz, 1.95H), 1.40 (d, J=6.2 Hz, 3H); 13C NMR (126 MHz, CDCl3) δ
165.81, 165.64, 165.57, 165.42, 165.36, 165.33, 156.23, 135.43,
