Organic Letters
Letter
afford the desired vinyl sulfones 3aa−3fa in moderate to good
yields (54−75%) with exclusive trans-stereoselectivity. Specif-
ically, vinyl sulfone 3aa was successfully prepared on a 1 mmol
scale with 60% yield, and the stereochemistry was
unambiguously confirmed by X-ray crystallographic analysis
of 3ba. Interestingly, 1,4-diethylbenzene underwent exclusive
dehydrogenative olefinsulfonation on only one of the ethyl
moieties even in the presence of excess N-sulfonylbenzo[d]-
imidazole to afford 3ea. However, the dehydrogenative
olefinsulfonation became inefficient with those substrates
bearing trimethylsilyethynyl and allyloxy (3ga and 3ha) groups
due to decomposition under the reaction conditions. Using the
present method, (E)-1-(2-tosylvinyl)naphthalene 3ia was
obtained in good yield by employing ethyl naphthalene as
substrate. It was noteworthy that alkyl heteroarenes were also
amenable to this methodology, producing vinyl sulfones 3ja
and 3la in moderate yields. The dehydrogenative olefinsulfo-
nation can also occur on cycloalkenes. Tetrahydronaphthalene
was used to furnish 3-tosyl-1,2-dihydronaphthalene 3ka and 3-
(cyclopropylsulfonyl)-1,2-dihydronaphthalene 3kt in good
yields with different sulfonation reagents, respectively.
However, 4-ethylpyridine failed to participate in the reaction,
and no desired product 3ma was observed.
tolerated, the reaction was not efficient with a bulky
substituent (3ao, 34%). 1-Naphthyl and 2-naphthyl N-
sulfonylbenzo[d]imidazoles were amenable to our strategy in
good yields (3ap, 74% and 3aq, 61%). In addition, heterocyclic
substituents behaved differently in our reactions. Sulfonation
reagent with pyridyl group led to a very low yield (3ar, 10%),
while the thiofurylsulfonation reagent could still offer a good
yield (3as, 56%). This might be due to pyridine’s susceptibility
to the radical process. Thus, the present reaction pathway was
interrupted. We also tested alkyl-substituted N-sulfonylbenzo-
[d]imidazoles such as 1-(cyclopropylsulfonyl)-1H-benzo[d]-
imidazole and 1-(butylsulfonyl)-1H-benzo[d]imidazole, and
olefinsulfonation products 3at and 3au were obtained in 70%
and 30% yield, respectively.
To gain insight into the present reaction process, a radical
scavenger TEMPO (2,2,6,6-tetramethyl-1-piperidinyloxy) was
added into the reaction systems in Scheme 3a. Although
Scheme 3. Mechanistic Investigation
Next, the dehydrogenative olefinsulfonation of 1a with
diverse N-sulfonylbenzo[d]imidazoles were examined. A
variety of alkyl and aryl N-sulfonylbenzo[d]imidazoles took
part in the present reaction to afford the corresponding vinyl
sulfones 3ab−3au in moderate to good yields. Evaluation of
substituted N-sulfonylbenzo[d]imidazoles revealed that both
electron-deficient and electron-rich derivatives were effective in
the dehydrogenative olefinsulfonation. This transformation was
compatible with fluoro (3ae), chloro (3af, 3am and 3an),
bromo (3ag), alkyl (3ad, 3al), alkoxy (3ac, 3ah), trifluor-
omethyl (3ai), and cyano (3aj) functional groups summarized
in Scheme 2. Although both electron-donating and electron-
withdrawing groups on N-sulfonylbenzo[d]imidazole could be
TEMPO-trapped products were not detected, the formation of
3aa was suppressed substantially, which was indicated that a
single-electron-transfer radical process may be involved. To
validate the radical process, another radical scavenger, 2,6-di-
tert-butyl-4-methylphenol (BHT), was added to the reaction
under standard reaction conditions in Scheme 3b. No desired
product 3aa was found. To further clarify the reaction pathway
of the dehydrogenative olefinsulfonation, experiments with
styrene (the proposed intermediate C) instead of ethylbenzene
were carried out under the standard conditions in Scheme 3c.
Sulfonation product 3aa was then obtained in 67% isolated
yield, which may be indicated that the in situ generated styrene
was one of the key intermediates during the dehydrogenative
olefinsulfonation process.
Scheme 2. Substrate Scope for N-
Sulfonylbenzo[d]imidazole
On the basis of the above results and previous reports, a
possible mechanism was illustrated in Scheme 4, though it
might be controversial.11 Initially, N-sulfonylbenzo[d]-
imidazole is reduced by Cu(I) via a single-electron-transfer
(SET) process to generate tosyl radical and Cu(II) complex
A.12 While benzylic radical is generated by a radical transfer
process initiated by decomposition of DTBP.13 Subsequently,
metal alkyl complex B is formed via a Cu(II)-mediated SET
oxidation process.14 β-Hydride elimination of intermediate B
releases the styrene C and Cu(I) species.12b,15 This metal
hydride species is then oxidized into the Cu(II) catalyst by N-
sulfonylbenzo[d]imidazole or DTBP to close the first catalytic
cycle. The second catalytic circle is continued with the styrene
C and the tosyl radical generated before. The in situ generated
a
Reaction conditions: 1a (1.4 mmol), 2a (0.2 mmol), [Cu(OTf)]2·
toluene (10 mol %), DTBP (0.4 mmol), L1 (6 mol %), NCS (1.2
equiv), Fe(ClO4)3·H2O (10 mol %), LiBr (2 equiv), 3 Å MS (25 mg),
Li2CO3 (2 equiv), toluene (1.0 mL), 120 °C, 36 h, argon.
C
Org. Lett. XXXX, XXX, XXX−XXX
