PAPER
Facile Deuteration of Chiral N,N’-Substituted Piperazines
237
13C NMR (67.94 MHz, CDCl3): d = 141.8 (C-i), 128.0 (C-o), 127.0
(C-p), 126.2 (C-m), 73.2 (C-2’), 60.5 (C-1’), 58.4 (t, JCD = 20.8 Hz,
C-2), 41.7 (C-5), 12.4 (C-8), 11.5 (C-7).
1H NMR (270.17 MHz, CDCl3): d = 7.35-7.24 (5 H, m, H-o,m,p),
4.91 (1 H, d, J = 4.0 Hz, H-2’), 2.69 (1 H, dq, J = 4.0, 7.0 Hz, H-1’),
2.70-2.61 (2 H, br AB, CH2-5), 0.84 (3 H, d, J = 7.0 Hz, CH3-7).
13C NMR (67.94 MHz, CDCl3): d = 141.9 (C-i), 128.0 (C-o), 126.9
(C-p), 125.9 (C-m), 71.9 (C-2’), 64.3 (C-1’), 50.9 (C-5), 49.9 (br s,
CD2-2), 10.2 (C-7).
(1S,2R)-N,N’-Bis-[(1-hydroxy-2-methyl-1-phenyl)ethyl]ethyl-
ene-d4-diamine (5-d4)
To a solution of diamide 416-18 (1.0 g, 2.8 mmol) in a mixture of an-
hyd THF (15 mL) and anhyd toluene (20 mL) was added LiAlD4
(0.47 g, 11.2 mmol) at 0 °C and the mixture was refluxed for 48 h.
After cooling, H2O (10 mL) was added and the solution was filtered
through Celite, dried (Na2SO4) and evaporated under reduced pres-
sure to afford 5-d4 (0.91 g, 97%) as a white solid; mp 91-92 °C;
[a]D25 -4.03 (c = 0.322, CH2Cl2).
(2’S,1’R,5R,6R)-1,4-Bis-[(2’-hydroxy-1’-methyl-2’-phenyl)eth-
yl]-2,2,3,3,5,6-d6-piperazine (7b-d6)
To a solution of bisoxazolidine 6-d4 (0.45 g, 1.27 mmol) in anhyd
THF (30 mL) was added LiAlH4 (0.21 g, 5.08 mmol) at 0 °C and the
mixture was refluxed for 5 h. After cooling, H2O (10 mL) was add-
ed, the suspension filtered through Celite, dried (Na2SO4) and evap-
orated under reduced pressure to yield the piperazine 7b-d6 (0.321
g, 70%) as a white solid; mp 168-170 °C; [a]D25 +8.08 (c = 0.099,
CH2Cl2).
MS (EI): m/z (%) = 361 (M+ + 1, 1), 265 (3), 254 (22), 253 (100),
119 (8), 118 (9), 117 (8), 89 (10), 88 (12), 77 (20), 60 (11), 58 (15),
57 (12).
MS (EI): m/z (%) = 334 (M+ + 2, 2), 333 (M+ + 1, 6), 226 (21), 225
(100), 207 (40), 164 (24), 148 (19), 117 (10), 107 (29), 91 (10), 79
(28), 77 (24), 76 (16), 74 (12), 60 (22), 47 (14), 44 (10), 42 (10), 32
(11).
IR (KBr): n = 3150, 3086, 3068 3026, 2968, 2908, 2850, 1492,
1452, 1422, 1406, 1374, 1138, 1084, 1010, 1000, 942, 760, 708,
698, 550 cm-1.
1H NMR (270.17 MHz, CDCl3): d = 7.36-7.20 (5 H, m, H-o,m,p),
4.69 (1 H, d, J = 4.0 Hz, H-1), 2.88 (1 H, dq, J = 4.0, 6.4 Hz, H-2),
0.84 (3 H, d, J = 6.4 Hz, CH3-4).
13C NMR (67.94 MHz, CDCl3): d = 141.6 (C-i), 128.2 (C-o), 127.2
(C-p), 126.2 (C-m), 76.6 (C-1), 58.5 (C-2), 46.1 (quint, JCD = 20.0
Hz, CD2-3), 14.9 (C-4).
IR (KBr): n = 3400, 2960, 2916, 2900, 1012, 976, 748, 706, 700,
cm-1.
1H NMR (270.17 MHz, CDCl3): d = 7.35-7.22 (5 H, m, H-o,p,m),
4.91 (1 H, d, J = 3.7 Hz, H-2’), 2.68 (1 H, dq, J = 3.7, 7.0 Hz, H-1’),
2.58 (1 H, br s, CHD-5), 0.83 (3 H, d, J = 7.0 Hz, CH3-7).
13C NMR (67.94 MHz, CDCl3) d = 141.9 (C-i), 128.0 (C-o), 126.9
(C-p), 125.9 (C-m), 71.9 (C-2’), 64.3 (C-1’), 50.5 (br, CHD-5, CD2-
2), 10.2 (C-7).
(5S,5’S,4R,4’R,2R,2’R)-N,N’-Ethylene-d4-[(4,4’-dimethyl-5,5’-
diphenyl)]-2,2’-bisoxazolidine (6-d4)
A solution of diamine 5-d4 (0.91 g, 2.74 mmol) in EtOH (40 mL)
and aq glyoxal (0.39 mL, 40%) was refluxed for 12 h. After cooling,
the solvent was removed under reduced pressure to afford 6-d4
(0.68 g, 70%) as a white solid; mp 194-195 °C; [a]D25 -48.48
(c = 0.099, CH2Cl2).
Acknowledgement
The authors thank CONACYT for financial support and G. Uribe
for NMR spectra.
MS (EI): m/z (%) = 356 (M+ + 2, 5), 355(M+ + 1, 13), 354 (M+, 10),
353 (10), 326 (21), 235 (38), 208 (13), 207 (33), 148 (22), 135 (15),
134 (10), 130 (25), 119 (16), 118 (100), 105 (14), 101 (14), 91 (36),
78 (10), 77 (15), 54 (15).
References
(1) Giardinà, D.; Gulini, U.; Massi, M.; Piloni, M. G.; Pompei, P.;
Rafaiani, G.; Melchiorre, C. J. Med. Chem. 1993, 36, 690.
(2) Bøgesø, K. P.; Arnt, J.; Frederiksen, K.; Hansen, H. O.;
Hyttel, J.; Pedersen, H. J. Med. Chem. 1995, 38, 4380.
(3) Dorsey, B. D.; Levin, R. B.; McDaniel, S. L.; Vacca, J. P.;
Guare, J. P.; Darke, P. L.; Zugay, J. A.; Emini, E. A.; Schleif,
W. A.; Quintero, J. C.; Lin, J. H.; Chen, I. W.; Holloway, M.
K.; Fitzgerald, P. M. D.; Axel, M. G.; Ostovic, D.; Anderson,
P. S.; Huff, J. R. J. Med. Chem. 1994, 37, 3443.
IR (KBr): n = 2894, 2810, 1452, 1284, 1234, 1224, 1192, 1128,
1114, 1098, 1090, 986, 978, 748, 738, 708 cm-1.
1H NMR (270.17 MHz, CDCl3): d = 7.35 (2 H, d, J = 7.7 Hz, H-o),
7.32 (2 H, t, J = 7.7 Hz, H-m), 7.26 (1 H, t, J = 7.7 Hz, H-p), 5.14 (1
H, d, J = 7.7 Hz, H-5), 4.00 (1 H, s, H-2), 3.07 (1 H, dq, J = 6.2, 7.7
Hz, H-4), 0.70 (3 H, d, J = 6.2 Hz, CH3-7).
(4) Katsura, Y.; Zhang, X.; Homma, K.; Rice, K.C.; Calderon, S.
N.; Rothman, R. B.; Yamamura, H. I.; Davis, P.; Flippen-
Anderson, J. L.; Xu, H.; Becketts, K.; Foltz, E. J.; Porreca, F.
J. Med. Chem. 1997, 40, 2936.
13C NMR (67.94 MHz, CDCl3): d = 139.7 (C-i), 127.9 (C-o), 127.7
(C-m), 127.6 (C-p), 93.8 (C-2), 83.2 (C-5), 60.0 (C-4), 45.2 (quint,
JCD = 20.0 Hz, CD2), 14.3 (C-7).
(5) Warshawsky, A. M.; Patel, M. V.; Cheng, T. M. J. Org. Chem.
(2’S,1’R)-1,4-Bis-[(2’-hydroxy-1’-methyl-2’-phenyl)ethyl]-
2,2,3,3-d4-piperazine (7a-d4)
1997, 62, 6439.
(6) Schanen, V.; Cherrier, M. P.; de Melo, S. J.; Quirion, J. C.;
Husson, H. P. Synthesis 1996, 7, 833.
(7) Schanen, V.; Riche, C.; Chiaroni, A.; Quirion, J. C.; Husson,
To a solution of bisoxazolidine 6-d4 (0.18 g, 0.508 mmol) in anhyd
THF (30 mL) was added LiAlH4 (0.077 g, 2.03 mmol) and the mix-
ture was refluxed for 5 h. After cooling, H2O (10 mL) was added
and the solution was filtered through Celite, dried (Na2SO4) and
evaporated under reduced pressure to afford 7a-d4 (0.130 g, 72%)
as a white solid; mp 164-165 °C; [a]D25 -0.45 (c = 0.297, CH2Cl2).
H. P. Tetrahedron Lett. 1994, 35, 2533.
(8) Soukara, S.; Wünsch, B. Synthesis 1999, 10, 1739.
(9) Mickelson, J. W.; Belonga, K. L.; Jacobsen, E. J. J. Org.
Chem. 1995, 60, 4177.
MS (EI): m/z (%) = 253 (4), 252 (21), 251 (100), 117 (15), 116 (14),
115 (14), 88 (12), 86 (18), 79 (13), 77 (13), 74 (11), 59 (10), 58 (18),
56 (13).
(10) Abdel-Jalil, R. J.; Al-Qawasmeh, R. A.; Al-abed, Y.; Voelter,
W. Tetrahedron Lett. 1998, 39, 7703.
(11) Santes, V.; Ortiz, A.; Santillan, R.; Gutiérrez, A.; Farfán, N.
Synth.Commun. 1999, 29, 1277.
(12) Santes, V.; Gómez, E.; Jiménez, G.; Santillan, R.; Gutiérrez,
A.; Farfán, N. Synth.Commun. 2000, 30, 2721.
IR (KBr): n = 3402, 3062, 2928, 2850, 998, 932, 752, 710, 700, 550
cm-1.
Synthesis 2001, No. 2, 235–238 ISSN 0039-7881 © Thieme Stuttgart · New York
