Organic Letters
Letter
a
a substrate bearing electronically similar aryl substituents at
the alkyne and the sulfonamide group affords a ∼1:1 mixture
of inseparable regioisomers (3f, 3f′). The regioisomeric ratio
improved to 2.8:1.0 (3g:3g′) where cyclization onto the p-
tolyl group from the sulfonamide was favored over cyclization
onto the alkynes m-methoxyphenyl group. Replacing the m-
methoxyphenyl substituent on the ynamide with a fluoro-
benzene substituent led to greater selectivity (3h:3h′ =
4.0:1.0). A single product 3i was obtained from the m-fluoro-
substituted ynamide in 64% yield, demonstrating that sole
indole products might be obtained by exploiting electronic
differences between the two aryl groups.
The scope of the reaction was then explored with
consideration of the electronic properties between two aryl
groups. First, a series of ynamides containing p-alkyl and p-
alkoxy substituents on the sulfonamide and electron-with-
drawing substituents on the aryl ethynyl portion were
examined. Exclusive formation of the indole products resulting
from cyclization onto the sulfonamide-derived aryl unit was
observed. Halide (3j−3n), ester (3o), including those derived
from (−)-menthol and (+)-fenchol (3r; 3s), and nitrile (3p;
3q) groups on the other aryl ring were well tolerated.
Selective cascade reactions that deliver a different skeletal
assembly can also be realized by inverting the electronic
properties of the two aryl groups: Substrates with more
electron-deficient aryl groups on the sulfonamide and
electron-donating substituents on the aryl ethynyl moiety
see the latter aryl group incorporated into the indole (3t−3ad,
43%−70%). Alkyl-, alkoxy-, and thioether substituents are all
tolerated. The use of p-substituted aryl groups lead to 6-
substituted indoles, while a 3,5-dimethylbenzene derivative
provides access to the 5,7-substituted indole 3aa. Aryl
sulfonamides bearing o-, m-, and p-halo, 3,5-difluoro, p-
trifluoromethyl, and p-nitro groups were all effective in the
reaction. The reaction also proceeded using an ynamide with a
monosubstituted alkene to generate a tertiary stereocenter
(3y). In addition, a pyridine-containing substrate also
functioned well in the reaction, with cyclization observed
onto the p-methoxyphenyl unit derived from the alkyne
substituent (3ad).
Table 1. Optimization Studies
b
entry
deviation from standard conditions
yield of 3a (%)
1
none
72 (63)
67
67
n.d.
n.d.
46
59
47
n.d.
n.d.
55
2
3
4
5
6
7
8
9
CuBr instead of CuCl
CuI instead of CuCl
Cu(OAc)2 instead of CuCl
Cu(OTf)2 instead of CuCl
room temperature instead of 60 °C
80 °C instead of 60 °C
DCM instead of CH3CN
THF instead of CH3CN
DMA instead of CH3CN
Togni reagent II instead of 2
0.05 M in CH3CN
10
11
12
13
14
62
47
n.d.
0.02 M in CH3CN
no CuCl
a
Standard conditions: 1a (0.1 mmol), 2 (0.12 mmol, 1.2 equiv), CuCl
(20 mol %) in CH3CN (3 mL) in a Schlenk tube at 60 °C under N2
b
atmosphere for 2 h. Yields were determined by 1H NMR
spectroscopy of the crude reaction mixture using mesitylene as an
internal standard; an isolated yield is shown in parentheses. Togni
reagent II: 1-trifluoromethyl-1,2-benziodoxol-3-(1H)-one. n.d. = not
detected.
We started our study with ynamide 1a, using Togni’s
reagent 2 as the radical source for the putative cascade. After
evaluation of various reaction parameters, the annulated
indole product 3a was achieved in 72% 1H NMR yield
using CuCl (20 mol %) in CH3CN (0.033 M) at 60 °C
(Table 1, entry 1). CuBr and CuI were also efficient catalysts
in this transformation, albeit giving slightly lower yields (Table
1, entries 2−3). Copper(II) complexes such as Cu(OAc)2 and
Cu(OTf)2 failed to deliver the desired product 3a (Table 1,
entries 4−5). An elevated temperature of 60 °C improved the
efficiency of the reaction (46% yield at room temperature,
Table 1, entry 6) but lower yields were seen at higher
temperature (Table 1, entry 7). Other solvents were not
suitable for this transformation (Table 1, entries 8−10).
Higher or lower concentration of solvent gave diminished
yields (Table 1, entries 12−13). A control experiment showed
that CuCl was indispensable in this transformation (Table 1,
entry 14).
With the optimized reaction conditions in hand, we then set
out to evaluate the generality of this approach (Scheme 2).
Annulated indoles were obtained in good yields from a series
of ynamides with matching p-substituted aryl groups on both
the ethynyl and sulfonamide regions of the ynamide (3b−3e,
45%−71%). The structure of 3e was confirmed by single
crystal X-ray diffraction. The practicality and ready imple-
mentation of this method is demonstrated by the preparation
of 3e on one gram scale.
Isomeric sets of starting materials (4a/4a′ and 4b/4b′,
Scheme 3a) showed very similar reaction efficiencies under
standard reaction conditions and converged to the same
regioisomers (5a and 5b, respectively), with more electron-
rich p-methoxyphenyl group embedded in the indole
regardless of its original position. Hence starting materials
can be designed and prepared on the basis of synthetic
accessibility.
More diverse [1,2]-annulated indole skeletons can also be
prepared by this approach. Pyrido[1,2-a]indole and azepino-
[1,2-a]indole (7a−7c) are accessed by increasing the alkyl
chain length between the alkene and the nitrogen (Scheme
n
3b). Unbranched and butyl branched alkene groups are also
tolerated. In all cases site-selective C(sp2)−N bond formation
occurs onto the more electron-rich aryl group.
Next, we examined the reaction efficiency of this cascade
process under photoredox-catalyzed conditions with different
radical precursors. Analogous [1,2]-annulated indole systems
could be formed under iridium photoredox-catalysis allowing
the introduction of the α,α-difluoroamidyl and α,α-difluor-
ocarbonyl functional groups (8a−8e, Scheme 3c). The site-
selective arylation was also retained under these photoredox
conditions (8d and 8e). Keto-ynamide 9 underwent fast
Initial studies with ynamides containing different aryl
groups on the sulfonamide and alkyne showed that isomeric
products could be realized from these reactions. Either aryl
group can be incorporated into the indole motif. For example,
B
Org. Lett. XXXX, XXX, XXX−XXX
