Synthesis of symmetrical thiol-adenosine conjugate and 50 thiol-RNA
preparation by efficient one-step transcription
⇑
Faqing Huang , Yongliang Shi
Department of Chemistry and Biochemistry, University of Southern Mississippi, Hattiesburg, MS 39406-5043, USA
a r t i c l e i n f o
a b s t r a c t
Article history:
A symmetrical transcription initiator containing two adenosines and conjugated thiol functionality (Thio-
AMP dimer) is chemically synthesized. Transcription in the presence of ThioAMP dimer under the T7
U
on the concentration ratio of ThioAMP dimer to ATP. The resulting 50 HS-RNA may be used directly or
after thiopropyl Separose 6B affinity column purification. Biotinylation of 50 HS-RNA and formation of
gold nanoparticle-RNA nanoplexes are demonstrated.
Received 26 July 2010
Accepted 19 August 2010
Available online 25 August 2010
2.5 promoter yields 50 thiol-labeled RNA (50 HS-RNA) with up to 90% labeling efficiency, depending
Keywords:
Transcription initiator
RNA labeling
Ó 2010 Elsevier Ltd. All rights reserved.
RNA biotinylation
Gold nanoparticle-RNA nanoplexes
Functionally derivatized RNAs have broad applications in chem-
istry and biomedical research.1–6 50 Thiol-labeled RNA (50 HS-RNA)
may be used to immobilized RNA on thiopropyl Separose 6B affin-
ity resins1 and on gold surfaces.7,8 Biotin-labeled RNA may be pre-
pared from 50 HS-RNA.1,4 Recently, 50 HS-RNAs have been used to
construct gold nanoparticle-siRNA (AuNP-siRNA) nanoplexes.9 In
addition, 50 thiol-functionalized RNA may be used to conjugate
with other macromolecules.10–15
transcription initiators that have been successfully used to label
the 50 end of RNA with high efficiencies.3,6,5,23 Herein we report
the synthesis of a symmetrical transcription initiator (4) that con-
tains two adenosines and a disulfide bond. Under transcription
conditions, the disulfide bond is reduced to a free thiol group.
Therefore, the resulting RNA transcript (5) is conjugated by a free
thiol group at the 50 end. Depending on the concentration ratio of
the transcription initiator and ATP, 50 thiol-labeling of RNA can
reach 90% labeling efficiency. The resulting thiol-labeled RNA
may be used directly in applications after a simple purification step
by membrane filtration. Additionally, thiol-labeled RNA may be en-
riched to near 100% purity by thiopropyl column purification.1 Fol-
lowing thiol-RNA preparation, we show that the RNA can be
further modified by biotin through the imidazole-catalyzed thioes-
terization reaction.4 Finally, we demonstrate the utility of our
thiol-labeled RNA for the preparation AuNP-RNA nanoplexes.
Synthesis of a symmetrical transcription initiator—ThioAMP dimer
(4). Starting with 6-aminohexanethiol (1, Dojindo Molecular Tech-
nologies), the transcription initiator ThioAMP dimer (4) was syn-
thesized in two chemical steps, as shown in Scheme 1. In the
first step, 1 was oxidized to form dithiobis(6-hexaneamine) (2)
by 0.5 molar equivalent of hydrogen peroxide oxidation in water,
pH 8. Extraction by dichloromethane followed by solvent removal
led to a white powder 2 (90% recovered yield), whose structure
was confirmed by NMR and MS: 1H NMR (400 MHz, DMSO-d6),
d = 1.248–1.647 (m, 20H, S–C–C4H8–C–NH2), 2.499 (t, 4H, J = 7.2
Hz, S–CH2), 2.691 (t, 4H, J = 7.2 Hz, N–CH2), MS calcd for
50 HS-RNA may be prepared by either chemical synthesis via
phosphoramidite chemistry,8,10,11,9,12–15 in vitro transcription,7,1–
3,16–21 or polynucleotide-catalyzed thiophosphorylation.8 For small
RNA sizes, 50 thiol-labeling of RNA by chemical synthesis is simple
and commercially available. However, RNA synthesis and 50 thiol-
labeling by phosphoramidite chemistry become impractical when
RNA sizes exceed a certain limit, typically around 60 nucleotides
(nt), due to low yields of full RNA sequences and high costs of
chemical synthesis. On the contrary, 50 thiol-labeling of RNA by
in vitro transcription is fast, relatively inexpensive for small quan-
tities, and unrestricted from RNA size limit. 50 Thiol-labeling of
RNA may be achieved by transcription under either the T7 class
II promoter (U2.5) or the class III promoter (U6.5). The former uses
a thiol-conjugated transcription initiator containing an adeno-
sine,1–3 while the latter utilizes thiol-containing guanosine deriva-
tives.7,16–21
We have previously demonstrated that transcription under the
T7
U
2.5 produces RNA transcripts that are superior to those pre-
pared under the T7
U
6.5.22 Taking the advantage of the T7
U
2.5
promoter, we have synthesized a number of adenosine-containing
C
12H28N2S2 [M+H]+ 265.18, found 265.17 (ESI).
In the second step, 2 was incubated at room temperature with
4 molar equivalent of adenosine 50-phosphorimidazolide (Im-
⇑
