ROS-mediated cytotoxic effect of copper(II) hydrazone complexes against human glioma cells

Article abstract of DOI:10.3390/molecules191117202

2-Acetylpyridine acetylhydrazone (H2AcMe), 2-benzoylpyridine acetylhydrazone (H2BzMe) and complexes [Cu(H2AcMe)Cl₂] (1) and [Cu(H2BzMe)Cl₂] (2) were assayed for their cytotoxicity against wild type p53 U87 and mutant p53 T98 glioma c

Full text of DOI:10.3390/molecules191117202

Molecules 2014, 19, 17202-17220; doi:10.3390/molecules191117202
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
ROS-Mediated Cytotoxic Effect of Copper(II) Hydrazone
Complexes against Human Glioma Cells
Angel A. Recio Despaigne 1,†, Jeferson G. Da Silva 1,2,†, Pryscila R. da Costa 3,†
Raquel G. dos Santos 3,† and Heloisa Beraldo 1,*
,
1
Departamento de Química, Universidade Federal de Minas Gerais, 31270-901 Belo Horizonte,
Brazil; E-Mails: areciod@yahoo.com (A.A.R.D.); jefersonpi1@yahoo.com.br (J.G.D.S.)
Departamento de Farmácia, Universidade Federal de Juiz de Fora (UFJF),
Campus Governador Valadares, Av. Dr. Raimundo Monteiro de Rezende, 330, Centro,
35010-177 Governador Valadares, Brazil
2
3
Centro de Desenvolvimento da Tecnologia Nuclear (CDTN), 31270-901 Belo Horizonte, Brazil;
E-Mails: pryrodriigues@yahoo.com.br (P.R.C.); raqueou@uol.com.br (R.G.S.)
†
These authors contributed equally to this work.
* Author to whom correspondence should be addressed; E-Mail: hberaldo@ufmg.br;
Tel.: +55-31-3409-5740; Fax: +55-31-3409-5700.
External Editor: Derek J. McPhee
Received: 25 September 2014; in revised form: 15 October 2014 / Accepted: 15 October 2014 /
Published: 27 October 2014
Abstract: 2-Acetylpyridine acetylhydrazone (H2AcMe), 2-benzoylpyridine acetylhydrazone
(H2BzMe) and complexes [Cu(H2AcMe)Cl2] (1) and [Cu(H2BzMe)Cl2] (2) were assayed
for their cytotoxicity against wild type p53 U87 and mutant p53 T98 glioma cells, and
against MRC-5 fibroblast cells. Compounds 1 and 2 proved to be more active than the
corresponding hydrazones against U87, but not against T98 cells. Compound 1 induced
higher levels of ROS than H2AcMe in both glioma cell lines. H2AcMe and 1 induced
lower levels of ROS in MRC5 than in U87 cells. Compound 2 induced lower levels of
ROS in MRC5 than in T98 cells. The cytotoxic effect of 1 in U87 cells could be related to
its ability to provoke the release of ROS, suggesting that the cytotoxicity of 1 might be
somehow p53 dependent.

Molecules 2014, 19
17203
Keywords: pyridine-derived hydrazones; copper(II) complexes; cytotoxicity; glioma cells;
ROS generation
1. Introduction
[cis(Diaminedichloro)platinum(II)], “cisplatin” is one of the most active anticancer drugs, but its
use is limited by undesirable side-effects and the appearance of cellular resistance. The mode of action of
cisplatin involves covalent DNA binding, hence the search for more effective target-specific
non-covalently DNA binding anticancer drug candidates is of great interest [1]. Considerable effort has
been devoted to the development of copper-based anticancer agents that can bind to and cleave DNA
under physiological conditions [1].
Copper is a component of numerous enzymes and participates in scavenging free radicals, as in the
case of copper-zinc superoxide dismutases [2]. Inside cells, free copper ions can go from one redox
state to another under physiological conditions. This redox cycling is responsible for both the catalytic
and the toxic potential of copper. Cu(II) directly interacts with several biological molecules and promotes
their oxidation in a redox reaction in which Cu(I) is formed. In turn, Cu(I) reacts with molecular
oxygen to form the superoxide anion O2, which dismutates to H2O2 and O2, ultimately producing
hydroxyl radicals and other reactive oxygen species (ROS). ROS generation can cause oxidative DNA
damage, is responsible for the clastogenic potential of copper [3,4] and can result in cell death [5].
The tumor suppressor protein p53 is a transcription factor which regulates cell cycle progression,
cell survival, and DNA repair in cells exposed to genotoxic stress. Exposure to DNA damage induces
p53 to accumulate in the nucleus, to bind to specific DNA sequences, and to activate several genes
including effectors of the cell cycle. In many cell types, activation of p53 results in transient cell cycle
arrest. In other cells, accumulation of p53 triggers apoptosis. Both processes suppress the proliferation
of cells that have undergone DNA damage and contribute to prevent the propagation of cells with
potentially oncogenic mutations. It has been shown that the intracellular levels and the redox activity
of copper are critical for p53 protein conformation and DNA-binding activity suggesting that copper
ions may participate in the physiological control of p53 function [3].
Hydrazones and their metal complexes constitute an important class of compounds with a wide
range of pharmacological applications as antiviral, antimicrobial, anti-inflammatory [6] and cytotoxic
agents [7]. The bioactivities of copper complexes with a variety of hydrazones have been investigated.
These complexes proved to present cytotoxic [8] and antimicrobial [9] activities. It has been shown
that a number of copper(II) complexes with hydrazones bind significantly to and are able to cleave
DNA [10–12].
We previously prepared a family of copper(II) complexes with 2-acetylpyridine- and
2-bezoylpyridine-derived hydrazones [9]. In the present work [dichloro(2-acetylpyridineacetyl-
hydrazone)copper(II)], [Cu(H2AcMe)Cl2] (1) and [dichloro(2-benzoylpyridineacetylhydrazone)copper(II)],
[Cu(H2BzMe)Cl2] (2) were studied for their cytotoxic activities against U87 (p53 wild-type
glioblastoma multiforme) and T98 (p53 mutant glioblastoma multiforme) tumor cells. The interactions

Molecules 2014, 19
17204
of complexes 1 and 2 with DNA and bovinum serum albumin (BSA) were investigated as well as the
role of ROS generation in the mechanism of their cytotoxic effect.
2. Results and Discussion
2-Acetylpyridine acetylhydrazone (H2AcMe), 2-benzoylpyridine acetylhydrazone (H2BzMe) and
complexes 1 and 2 were prepared as previously reported by some of us [13] and by other authors [14,15].
The synthetic routes for the ligands and their Cu(II) complexes are outlined in Scheme 1.
Scheme 1. Schematic representation of the syntheses of the hydrazones (A), and their
copper(II) complexes 1 and 2 (B).
2.1. Cytotoxic Activity against Malignant U-87 and T-98 Glioma Cells and against MRC5 Cells
The in vitro cytotoxic effects of H2AcMe, H2BzMe and complexes 1 and 2 against wild type p53
U87 and mutant p53 T98 glioblastoma cells and against MRC-5 fibroblasts cells were tested using
cisplatin as a positive control. To determine the IC50 (concentration that inhibits 50% of cell survival)
values the cytotoxic effects were quantified using the 3-(4,5-dimethyl-2-thioazolyl)-2,5-diphenyl
tetrazolium bromide (MTT) colorimetric assay [16]. All tested compounds were cytotoxic against both
glioma cell lines in a dose-dependent way. The IC50 values (see Table 1) were found in the micromolar
range. Despite their cytotoxic activity, all compounds were less toxic to fibroblasts cells than cisplatin.
CuCl2 evoked only mild cytotoxicity in all cell lineages with IC50 higher than 100 µM.
Table 1. Cytotoxic effect of 2-acetylpyridine acetylhydrazone (H2AcMe), 2-benzoylpyridine
acetylhydrazone (H2BzMe) and their copper(II) complexes 1 and 2.
IC50 [µM]
Compounds
U87
67.6 ± 4.08 13.80 ± 4.89 19.80 ± 4.15
[Cu(H2AcMe)Cl2] (1) 3.02 ± 0.85 5.08 ± 0.41 22.50 ± 3.13
T98
MRC5
H2AcMe
H2BzMe
[Cu(H2BzMe)Cl2] (2)
CuCl2
52.30 ± 10.03 19.70 ± 1.06 62.30 ± 7.76
5.95 ± 0.74 29.40 ± 7.06 49.40 ± 8.83
>100
>100
>100
Cisplatin
1.76 ± 0.22
5.31 ± 1.94 5.05 ± 0.71

Molecules 2014, 19
17205
H2AcMe and H2BzMe were significantly more potent against p53 mutant T98 cells (IC50 = 13.80
and 19.80 µM, respectively) than against p53 wild-type U87 cells (IC50 = 67.60 and 52.30 µM,
respectively) (p < 0.05). Complexes 1 and 2 proved to be more active than the corresponding
hydrazones against U87 cells (p < 0.001 and p < 0.01, respectively). Although complex 1 seemed to be
more active than its ligand H2AcMe against T98 cells, this effect was not statistically significant
(p > 0.05). Coordination to Cu(II) did not result in activity improvement against T98 cells in both
complexes (see Table 1).
The hydrazones presented low selectivity index (SI = IC50MRC5/IC50tumor cell) in U87 cells. Only
H2BzMe presented a good selectivity index in T98 cells (p < 0.05). In contrast, both complexes
presented good selectivity indexes against the two glioma cell lineages (p < 0.05). For complex (1)
SI = 7.45 (U87); SI = 4.42 (T98); for complex (2) SI = 8.30 (U87); SI = 1.68 (T98) and for cisplatin
SI = 2.87 (U87); SI = 0.95 (T98).
2.2. Analysis of Morphological Changes
Morphological alterations in the cells are shown in Figure 1. It can be observed that the treatment
with test compounds induced morphological alterations such as retraction of cytoplasmatic expansions,
detachment, formation of round shaped cells, cell shrinkage and membrane blebs formation.
Figure 1. Morphological changes induced by 2-acetylpyridine acetylhydrazone (H2AcMe),
2-benzoylpyridine acetylhydrazone (H2BzMe) and their copper(II) complexes 1 and 2.
Photomicrographs of human glioblastoma cells: U-87 (p53 wild type), T-98 (expressing
p53 mutant) and human fetal lung fibroblast cells, MRC5. Changes such as cell rounding,
cell shrinkage and blebs formation suggest the induction of programmed cell death
(magnification ×400).
All of these morphological changes are associated to cell death.

Molecules 2014, 19
17206
2.3. Analysis of Chromosomal DNA Alterations
A number of anticancer drugs exert their effects by inducing apoptosis [17]. Cytotoxic compounds
that disrupt DNA and chromosomal integrity leading to apoptotic death evoke DNA condensation and
fragmentation that can be visualized as very small focal bright points when stained by DAPI [18].
Analysis of chromosomal alterations were made using 4',6-diamidine-2'-phenindole dihydrocloride
(DAPI) [19] (Figure 2). Unlike the untreated control cells both U87 and T98 glioma cells treated with
the test compounds showed chromatin condensation and apoptotic bodies. The non-malignant
fibroblast cells presented no significant chromosomal damage.
Figure 2. Nuclear changes induced by treatment with 2-acetylpyridine acetylhydrazone
(H2AcMe), 2-benzoylpyridine acetylhydrazone (H2BzMe) and their copper(II) complexes
1 and 2. Cells were treated with 1 × 10−5 mol/L of the compounds or diluent (control) and
stained with DAPI. Treated cells show nuclear condensation and apoptotic bodies
visualized as small focal bright points (magnification ×400).
2.4. Measurement of Reactive Oxygen Species (ROS) Generation
To examine the effects of H2AcMe, H2BzMe and their complexes 1 and 2 on the generation of free
radicals (reactive oxygen species, ROS), we used the 2',7'-dichlorodihydrofluorescein diacetate
(DCFH-DA) assay [20]. As shown in Figures 3 and 4, treatment of the glioma cells with all
compounds for 24 h resulted in marked increase of the intracellular ROS levels.

Molecules 2014, 19
17207
Figure 3. Generation of reactive oxygen species (ROS) in cells treated with 2-acetylpyridine
acetylhydrazone (H2AcMe), 2-benzoylpyridine acetylhydrazone (H2BzMe) and their
copper(II) complexes (1) and (2). Cells were treated for 24 h with 1 × 10−5 mol/L of
compounds and stained with DCF-DA. Treated cells show increased fluorescence intensity
(magnification ×400).
Figure 4. ROS production (measured as relative fluorescence increase) in cells treated with
2-acetylpyridine acetylhydrazone (H2AcMe), 2-benzoylpyridine acetylhydrazone (H2BzMe)
and their copper(II) complexes 1 and 2 at 1 × 10−5 M.

Molecules 2014, 19
17208
H2AcMe and its complex 1 induced higher levels of ROS in U87 cells (p < 0.05) than in T98 cells.
H2BzMe and 2 proved to be equally effective in both cell lineages (p > 0.05). Upon coordination of
H2AcMe to Cu(II) higher levels of ROS were observed for complex 1 in U87 cells (p < 0.05). H2BzMe
and 2 showed a similar effect on ROS generation in both malignant cell lineages (p > 0.05).
Interestingly, H2AcMe and its complex 1 induced lower levels of ROS in MRC5 cells (p < 0.05)
than in U87 glioma cells. H2BzMe induced the same increasing in ROS levels in MRC5 and in both
malignant cells (p > 0.05). Complex 2 exhibited similar effects on U87 and T98 glioma cells (p > 0.05).
However, 2 induced lower levels of ROS in MRC5 than in T98 glioma cells (p < 0.05).
Several studies have implicated mitochondria-derived ROS in cell death induced by p53 [21,22]. It
has also been revealed that ROS act as both an upstream signal that triggers p53 activation and a
downstream factor that mediates apoptosis [23]. Sawada and colleagues have proposed two separate
signaling cascades, ROS-mediated-p53-dependent and ROS-mediated-p53-independent pathways,
both of which contribute to apoptosis of human glioma cells [24]. Taking together the foregoing results
show that the cytotoxicity induced by the compounds under study is mediated by ROS.
In agreement with the important role of ROS in cell death induced by p53 and corroborating MTT
data, complex 1 proved to be more potent against wild-type p53 U87 cells and more effective in
promoting ROS generation in this cell lineage (p < 0.05). The p53 tumor suppressor is a pivotal
regulating component that senses various intrinsic and extrinsic stresses and initiates apoptotic cell
death [25]. Although the detailed mechanisms underlying the effects of the hydrazones and their
copper complexes on the down-regulating p53 levels warrant further research, the present results
suggest that complex 1 might induce p53-dependent apoptotic pathways mediated by ROS.
2.5. DNA Binding Studies
Complexes can bind to DNA via both covalent and/or non-covalent (intercalation, electrostatic or
groove binding) interactions. In covalent binding the labile ligand of the complexes is replaced by a
nitrogen atom from a DNA base such as guanine N7. Non-covalent DNA interactions include
intercalative, electrostatic and groove (surface) binding. Intercalation involves the partial insertion of
aromatic heterocyclic rings of the ligands between the DNA base pairs [26]. The spectroscopic
techniques of electronic absorption and fluorescence are two of the most useful for DNA-binding
studies of small molecules [27].
2.5.1. Absorption Spectroscopy Studies of DNA Binding
The electronic absorption spectra of free complexes 1 and 2 in Tris-HCl buffer consist of two well
resolved bands in the range from 250 to 400 nm. The absorption that appears at 273 nm in 1 and
279 nm in 2 is characteristic of π→π* transitions of aromatic rings. The band that was found at 341 nm
in 1 and 353 nm in 2 is attributed to n→π* transitions from the ligands overlapped with ligand-to-metal
charge transfer (LMCT) transitions [28].
The absorption spectra of 1 and 2 in the absence and in the presence of CT-DNA (at constant
concentration of the complex) are shown in Figure 5.
With the increasing of CT-DNA concentration, a small shift was observed for the absorptions at
342 and 353 nm in the spectra of 1 and 2, respectively, with a strong decrease in intensity. In addition,

Molecules 2014, 19
17209
the bands at 273 nm for 1 and 279 nm for 2 underwent a considerable red shift. This behavior is in
accordance with an intercalative binding mode, since hypochromism occurs due to π-stacking
interactions between aromatic heterocyclic groups and the DNA base pairs, as in the case of classic
intercalators (e.g., ethidium bromide) [29]. In addition, the isosbestic point observed at 312 nm (1) and
316 nm (2) indicated the presence of two species in solution, providing evidence of complex-DNA
interaction. These results are similar to those previously reported for various metallointercalators [30–32].
Figure 5. (A) Electronic absorption spectra of complexes (1) (7.25 µM) and (2) (6.78 µM)
in Tris-HCl buffer (pH = 7.20) in the absence and in the presence of increasing
amounts of CT-DNA (ten different complex: DNA molar ratios ranging from 1:1 to 1:10).
Arrows show the changes in absorbance with increasing DNA concentration. (B) Plot of
[DNA]/[εa − εf] vs. [DNA].
In order to quantitatively compare the binding strength of the complexes, the intrinsic binding
constants (Kb) of 1 and 2 with CT-DNA were obtained using Equation (1) [28]:
[DNA]/[εa − εf] = [DNA]/[εb − εf] + 1/Kb[εb − εf]
(1)
where [DNA] is the concentration of DNA base pairs, εa is the extinction coefficient of the complex at
a given DNA concentration, εf is the extinction coefficient of the complex in free solution and εb is the
extinction coefficient of the complex when fully bound to DNA. A plot of [DNA]/[εa − εf] vs. [DNA]
gives 1/[εb − εf] as slope and 1/Kb[εb − εf] as the intercept. Kb is calculated as the ratio between slope
and intercept.
The determined Kb values were (8.08 ± 0.33) × 105 M−1 (compound 1) and (1.42 ± 0.70) × 105 M−1
(compound 2), indicating that the order of binding affinity was 2 < 1. The Kb values of the complexes
are in the same order of magnitude of that of ethidium bromide (EB), [Kb = (1.23 ± 0.07) × 105 M−1] [33].

Molecules 2014, 19
17210
2.5.2. Competitive Binding between EB and Complexes 1 and 2 for CT-DNA
Steady-state competitive binding experiments using complexes 1 and 2 were undertaken to get
further proof for the binding of the complexes to DNA. The technique is based on the decrease of EB
fluorescence resulting from the competitive displacement of EB from a DNA groove by a compound
that competes for the same site.
As can be seen in Figure 6, with the increase of complex concentration hypochromism in the
emission band at 602 nm (up to 24% for 1 and 20% for 2) occurs accompanied by a small red shift of
the fluorescence band. These effects indicate that the EB molecules are displaced from their DNA
binding sites by the complexes under investigation.
Figure 6. (A) Emission spectra of EB-CT-DNA (10 µM Tris-HCl buffer, pH 7.20, T = 25 °C),
in the presence of 0, 10, 20, 30, 40, 50, 60, 70, 80, 90, and 100 µM of complexes 1 and 2.
Arrow indicates the changes in the emission intensity with increasing complex
concentration. (Inset: Plot of F0/F vs. [complex]). (B) Plot of log[F0 − F/F] vs. log[Q].
The quenching data were analyzed by the Stern-Volmer equation:
F0/F = Ksv[Q] + 1
(2)
where F0 is the emission intensity in the absence of quencher, F is the emission intensity in the
presence of quencher, Ksv is the quenching constant, and [Q] is the quencher concentration. The Ksv
value is obtained as a slope from the plot of F0/F vs. [Q] [34].
The apparent binding constants (Kapp) were calculated from Equation (3) [35]:
KEB [EB] = Kapp [complex]
(3)

Molecules 2014, 19
17211
where KEB is 1.0 × 107 M−1, [EB] = 10 µM, and [complex] is the complex concentration when the
fluorescence intensity of EB is 50%. This value is obtained from the plot F0/F vs. [complex] when
F0/F = 2.
The binding constants (K) were calculated by the Scatchard Equation (4) (see Figure 6):
log[(F0 − F)/F] = logK + nlog[Q]
(4)
where F0 and F are the fluorescence intensities of EB in the absence and presence of compound; [Q] is
the compound concentration; K is the binding constant of compound with EB and n is the number
of binding sites. K is the antilog of the intercept and n is the slope obtained from the plot of
log[(F0 − F)/F] vs. [Q]. Table 2 shows the obtained values of Ksv, Kapp and K.
Table 2. The Stern-Volmer quenching constant (Ksv), apparent binding constant (Kapp),
binding constant (K) and number of binding sites (n) for the competitive binding between
EB bound to CT-DNA and complexes (1) and (2).
Complexes
Ksv [M−1]
Kapp [M−1]
K [M−1]
n
[Cu(H2AcMe)Cl2] (1) (2.35 ± 0.03) × 103 2.34 × 105 (0.35 ± 0.01) × 104 1.04 ± 0.01
[Cu(H2BzMe)Cl2] (2) (2.05 ± 0.03) × 103 2.07 × 105 (0.38 ± 0.01) × 103 0.81 ± 0.02
The foregoing results suggest that complexes 1 and 2 are capable of binding DNA in an
intercalative way.
2.6. Studies of Interactions with Supercoiled Plasmid DNA
As shown in Figure 7, for complexes 1 and 2 and CuCl2 at 100 µM no alteration in the
electrophoretic mobility of pUC 19 plasmid DNA was observed in relation to free DNA, whereas
strong modification occurs for cisplatin. These results indicate that the complexes under study present
a mechanism of interaction with DNA which is different from that of cisplatin. Cisplatin is capable of
binding covalently to DNA forming intra-strand crosslinks which cause a decrease in the
electrophoretic mobility of all DNA forms. The absence of modifications in the presence of 1 and 2
suggests that both compounds do not form stable adducts with DNA, and hence, they probably do not
bind directly to DNA, but rather act as intercalators between the DNA base pairs.
Figure 7. Agarose gel electrophoresis of pUC 19 plasmid DNA treated with selected
compounds at 100 μM in Tris-HCl buffer (pH 7.20) incubated at 37 °C for 24 h.

Molecules 2014, 19
17212
2.7. Protein Binding Studies
Fluorescence Quenching of BSA by Complexes 1 and 2
Anticancer activity may be strongly affected by drug–protein interactions in the bloodstream.
Serum albumin, the most abundant and important protein in the plasma, is the major transport protein.
Albumin is capable of binding many endogenous and exogenous drugs reversibly. In addition, it may
aid in the selective delivery of drugs to the tumor region and facilitate drug access into the cell [36].
Bovine serum album (BSA) is the most extensively studied serum albumin due to its structural
homology with human serum albumin (HSA). BSA shows intrinsic fluorescence due to the tryptophan,
tyrosine, and phenylalanine residues. Hence, quenching of BSA fluorescence was used to investigate
the interaction between BSA and complexes 1 and 2.
Fluorescence quenching refers to any process that reduces the fluorescence intensity of the
fluorophore due to a variety of processes such as excited-state reactions, molecular rearrangement,
energy transfer, ground-state complex formation and collisional quenching [37].
Figure 8 shows the effect of increasing the concentration of 1 and 2 on the fluorescence emission of
BSA. Addition of the test compounds to BSA resulted in the quenching of fluorescence emission
intensity (~35% in 1 and ~40% in 2) together with a hypsochromic shift of 5–6 nm due to the
formation of a complex between the test compounds and BSA.
Figure 8. (A) Fluorescence emission spectra (excitation at 280 nm) for the
1-BSA and 2-BSA systems (phosphate buffer, pH 7.20, T = 25 °C); 1.0 µM of BSA in the
presence of 1.0, 2.0, 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, and 10.0 µM of compounds 1 and 2.
Inset: plot of F0/F vs. [Q]. (B) Plot of log [(F0 − F)/F] vs. log [Q] (λ = 345 nm).

Molecules 2014, 19
17213
Based on fluorescence data for λ = 345 nm at 25 °C, the Stern-Volmer quenching constant (Ksv) and
the bimolecular quenching rate constant (kq) were obtained using the classical Stern-Volmer equation
(Equation (3)). The value of kq was calculated by the Ksv/τ0 ratio, where τ0 is the average lifetime of the
fluorophore in the absence of quencher (τ0 =10 ns for BSA) [38].
The Ksv values for 1-BSA and 2-BSA systems were (0.55 ± 0.01) × 105 and (0.68 ± 0.01) × 105 M−1,
respectively. The calculated values of kq for the BSA-complex systems are in the order of 1012 M−1s−1
which are higher than 2.0 × 1010 M−1s−1, the maximum scatter collision quenching constant of
quenchers with BSA [38]. This indicates that the fluorescence quenching was not originated by
dynamic collision, but it must be caused by a specific interaction between BSA and the complexes,
suggesting a static quenching mechanism. Comparable results were obtained from studies of copper(II)
complexes with thiosemicarbazones [12].
From the Scatchard equation (Equation (4)) the values of the binding constant (K) and number of
binding sites (n) were calculated (see Figure 8). The K and n values for the 1-BSA and 2-BSA systems
were: (1.11 ± 0.04) × 105 M−1; 1.06 ± 0.01 and (1.37 ± 0.05) × 105 M−1; 1.06 ± 0.01, respectively.
From these values it is possible to suggest that complexes 1 and 2 interact with BSA.
Figure 9. Synchronous spectra of BSA (1.0 µM, phosphate buffer, pH = 7.20) in the
absence and in the presence of 1.0, 2.0, 3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, and 10.0 µM of 1
and 2 at λ = 15 nm and λ = 60 nm, respectively. Arrows indicate that the emission intensity
decreases with increasing concentrations of compounds.
Synchronous fluorescence spectroscopy is a very useful method to study the changes in the
microenvironment of tyrosine and tryptophan amino acid residues in BSA [39]. The spectra were
measured after and before the addition of test compounds. The synchronous fluorescence of BSA is
characteristic of tyrosine residues when the difference between excitation and emission wavelength Δλ
value is 15 nm and characteristic of tryptophan residues if Δλ value is 60 nm [40,41]. Figure 9 shows
the effect of increasing the concentration of compounds on the synchronous spectra of BSA at

Molecules 2014, 19
17214
Δλ = 15 nm and Δλ = 60 nm. In both cases, a decrease in emission intensity of BSA with increasing
complex concentration was observed. In the spectra at Δλ = 15 nm, addition of compounds to the BSA
solution resulted in a small decrease of fluorescence intensity (~16% for 1 and ~18% for 2). In the
spectra at Δλ = 60 nm, an important decrease of the BSA fluorescence intensity (~41% for 1 and ~44%
for 2) accompanied by a small blue shift of 1nm occurs. These results indicate that the interaction of
compounds with BSA affect mainly the conformations of tryptophan residues.
In general, addition of the complexes affects the microenvironment of both tyrosine and tryptophan
residues during the binding process and synchronous measurements confirmed the effective binding of
the two complexes with BSA. Similar behavior was observed for the interaction between the BSA and
copper(II) complexes with other hydrazones [28,42].
In conclusion, our results suggested that complexes 1 and 2 bind to BSA and that this interaction
affects the conformations of tyrosine and tryptophan residues, the interaction with tryptophan residues
being probably stronger.
3. Experimental Section
3.1. General Information
All chemicals were purchased from Sigma-Aldrich Brasil (São Paulo, Brazil) and used without
further purification. Electronic spectra were acquired with a Shimadzu double beam UV-Vis
spectrophotometer UV-2401PC (P/N 206-82201) using 1 cm quartz cells. Measurements of
fluorescence were performed on a Varian Cary Eclipse spectrofluorimeter (FL1006m016)-Varian
system (Agilent Technologies, Santa Clara, CA, USA) using a 1 cm quartz cell.
3.2. Studies of Interactions with DNA
The interaction of complexes 1 and 2 with deoxyribonucleic acid from calf thymus (CT-DNA) was
studied in Tris-HCl buffer (NaCl 50 mM, Tris-HCl 5 mM, pH = 7.20). Stock solution of CT-DNA in
Tris-HCl buffer was prepared upon shaking in an orbital shaker at 120 rpm at 37 °C for 24 h. Then, the
solution was filtered with a Millipore filter (0.45 µm), and its concentration was calculated using the
absorption intensity at 260 nm and the molar absorption coefficient (ε) value at this wavelength
(6600 M−1·cm−1) [43]. The stock solutions of the complexes were freshly prepared by first dissolving
complexes in DMF and then diluting with Tris-HCl buffer (pH = 7.20). The amount of DMF was kept
less than 5% (by volume) for each set of experiments and it presented no effect on any of the
experimental results. Absorption titration experiments were performed by increasing the concentration
of CT-DNA via successive additions of its stock solution on a fixed concentration of complex. Upon
additions in each cuvette (sample and blank) of a same aliquot of CT-DNA (double beam mode), the
samples were shaken and left in equilibrium for 2 min, before recording each spectrum.
The affinity of the complexes for DNA was evaluated by a fluorescence technique using ethidium
bromide (EB) bound to CT-DNA (EB-CT-DNA) solution in Tris-HCl buffer (pH = 7.20). EB is a
planar cationic dye which is widely used as a sensitive fluorescence probe for native DNA. EB emits
intense fluorescent light in the presence of DNA due to its strong intercalation between the adjacent
DNA base-pairs [44]. The changes in the fluorescence intensity at 602 nm (excitation at 545 nm) of

Molecules 2014, 19
17215
EB-CT-DNA were measured with respect to the concentration of the copper(II) complexes. In fact,
when it is removed, EB is non-emissive in Tris-HCl buffer solution (pH = 7.20), due to fluorescence
quenching of the free EB by solvent molecules. A competitive binding of the complexes to CT-DNA
resulted in displacement of the bound EB, thereby decreasing its emission intensity.
3.3. Studies of Interactions with Supercoiled Plasmid DNA
Studies of interactions between the compounds under study and supercoiled plasmid DNA by agarose
gel electrophoresis were carried out. Thus, 136 ng of purified plasmid DNA-pUC 19 from Escherichia coli
(Sigma-Aldrich Brasil, São Paulo, Brazil) were incubated with compounds 1, 2 and cisplatin at 100 µM
in Tris-HCl buffer (NaCl 50 mM, Tris-HCl 5 mM, pH = 7.20). The mixture was incubated at 37 °C for
24 h. Thereafter, the reactions were quenched by adding 5 µL of the loading buffer solution (50 mM
Tris, pH 7.20, 0.01% bromophenol blue, 50% glycerol, and 250 mM EDTA). The samples were
analyzed by 1% agarose gel electrophoresis in 0.5 × TBE buffer for 1 h 40 min at 75 mV. The gel was
stained after electrophoresis in 0.5× TBE buffer with 2.5 µg·mL−1 ethidium bromide for 15 min and
visualized by UV light.
3.4. Albumin Binding Studies
The interaction of complexes 1 and 2 with bovine serum albumin (BSA) was studied in phosphate
buffer (8.3 mM, pH = 7.20). Stock solution of BSA (0.5 mM) was prepared in phosphate buffer and
stored in the dark in the refrigerator for further use. The stock solutions of complexes were freshly
prepared by first dissolving the compounds in DMF and then making the dilutions with phosphate
buffer (pH = 7.20). The amount of DMF was kept less than 5% (by volume) for each set of experiment
and had no effect on any experimental results.
The binding of the copper(II) complexes to BSA was studied using fluorescence spectra. The
emission spectra were recorded in the 295–600 nm range with excitation at 280 nm. The excitation and
emission slit widths and scan rates were constantly maintained for all the experiments. BSA solution
(1.0 µM) was titrated by successive additions of a stock solution of the complexes (50 mM) using a
micropipette. All experiments were performed at 298 K. The synchronous fluorescence spectra of BSA
varying the concentration of 1 and 2 were recorded at ∆λ (difference between excitation and emission
wavelength) = 15 nm and ∆λ = 60 nm.
If it is assumed that the binding of compounds with BSA occurs at equilibrium, the equilibrium
binding constant can be analyzed according to the Scatchard equation [28].
3.5. Cell Lines and Culture Conditions
U87 (p53 wild-type glioblastoma multiforme) and T98 (p53 mutant glioblastoma multiforme)
malignant human tumor cells and MRC5 (Human Fetal Lung Fibroblast) cells were obtained from the
American Type Culture Collection (ATCC, Manassas, VA, USA). Cell lines were grown as monolayer
in Dulbecco’s Modified Eagle’s Medium (DMEM, Gibco, Rockville, MD, USA), supplemented with
10% fetal bovine serum (Cultilab, Campinas, São Paulo, Brazil) and antibiotics (50 U/mL penicillin/50 µM
streptomycin), in a humidified atmosphere air/CO2 (95%/5%) at 37 °C. Cells 80% confluents were

Molecules 2014, 19
17216
used in all experiments. For all experiments, cells were seeded in 96-well plates, at a density of
1000 cells/well. After 24 h incubation cells were treated.
3.6. Cytotoxic Activity
To determine the IC50 values the cytotoxic effects were quantified using the 3-(4,5-dimethyl-2-
thioazolyl)-2,5-diphenyltetrazolium bromide (MTT) colorimetric assay [16]. Briefly, cells were treated
with increasing concentrations (10−12, 10−11, 10−10, 10−9, 10−8, 10−7, 10−6, 10−5, 10−4 mol·L−1) of either
cisplatin (positive control) or test compounds (H2AcMe, H2BzMe, 1 and 2). The compounds were
previously dissolved in dimethyl sulfoxide (DMSO) and the final concentrations were adjusted in
DMEM in such manner that the final DMSO concentration was lower than 0.5%. Following 48 h
treatment, MTT reagent was added to each well. Following another 4 h of incubation at 37 °C, DMSO
was added to each well to dissolve formazan precipitate and absorbance was measured at 570 nm.
Tests using DMSO (0.5% in DMEM) as negative control were carried out in parallel. All tests were
performed in quadruplicates with full agreement between the results. Statistical analysis was carried
out by the unpaired, one-tailed Student’s t testing using a p value of 0.05. A value of p < 0.05 was
considered significant.
3.7. Morphological Analysis
Cells were plated in 96-well plates and treated with test compounds (1 × 10−5 mol·L−1).
Morphological changes were analyzed 48 h after the treatment by contrast-phase microscopy (Nikon
Eclipse TS100, Tokyo, Japan).
3.8. Analysis of Chromosomal Alterations
DAPI (4',6-diamidine-2'-phenindole dihydrocloride) is a fluorescent dye able to bind specifically to
double strands of chromosomal DNA [19]. For analysis of chromosomal DNA changes, tumor cells
were treated with test compounds at 1 × 10−5 mol·L−1 for 48 h. Then, cells were washed with
phosphate buffer (PBS) and fixed in methanol (70%) for 20 min. Cells were incubated for 30 min with
0.4 μg/mL of DAPI (Sigma). DNA alterations were observed by fluorescence microscopy at
385–410 nm (Nikon, Tokyo, Japan)
3.9. Measurement of Reactive Oxygen Species (ROS) Generation
ROS accumulation was detected using dichlorodihydrofluorescein diacetate (DCFH-DA, Sigma).
DCFH-DA is a non-fluorescent compound, that when it is taken up by passive diffusion into the cells,
is hydrolyzed by esterases to yield non-permeable DCFH. In the presence of ROS, DCFH is oxidized to
the fluorescent DCF. Tumor cells were treated with the compounds for 24 h and were then incubated
with DCFH-DA (1 × 10−5 mol·L−1) for 30 min at 37 °C. Following incubation, the cells were washed
twice with PBS. Thereafter, the cells were observed under the fluorescent microscope Zeiss Axionplan
coupled with a digital camera at excitation and emission wavelengths of 488 and 525 nm, respectively [20].
Data were analyzed using ImageJ (ImageJ, National Institute of Health, Bethesda, MD, USA) and
expressed as percentages of DCFDA fluorescence of the corresponding control [45].

Molecules 2014, 19
17217
3.10. Statistical Analysis
The data were expressed as mean + standard deviation (SD) of three independent experiments.
One-tailed unpaired Student’s t-test was used for significance testing, using a p value of 0.05. A value
of p < 0.05 was considered significant. When appropriate, the statistical significance for multiple
comparisons was determined using One Way ANOVA followed by Bonferroni’s test. A value of
p < 0.05 was considered significant. Prisma Graph Pad for Windows version 5.01 (GraphPad Software
Inc., La Jolla, CA, USA) software was used for the statistical analysis.
4. Conclusions
Coordination of the hydrazones to Cu(II) resulted in improved cytotoxic activity against U87 cells
in both complexes 1 and 2. The selectivity indexes of both complexes were higher than that of the
hydrazone ligands in the two malignant cell lineages.
Preliminary investigation on the mode of action of the studied compounds indicated that both
complexes 1 and 2 bind to DNA by an intercalative way. All compounds were able to induce high
levels of ROS in the glioma cell lines. Interestingly, H2AcMe and 1 induced lower levels of ROS in
MRC5 cells than in U87 glioma cells. Since the cytotoxic effect of complex 1 in wild type p53 U87
cells could be related to its ability to provoke the release of ROS, the cytotoxic effect of 1 on U87 cells
might be somehow p53 dependent. No correlation was observed between the cytotoxic effects of the
remaining compounds and their ability to provoke the release of ROS. Further studies are needed to
clarify the mechanisms of the cytotoxic effects of the compounds under study.
Acknowledgments
This work was supported by PNPD-CAPES, CNPq, INCT-MM and INCT-INOFAR (Proc. CNPq
988573.364/2008-6) from Brazil.
Author Contributions
H.B designed chemical experiments and analyzed chemical and biological assays. A.A.R.D and
J.G.D.S performed syntheses and studies on the interactions of compounds with DNA and BSA. P.R.C
performed biological assays and analyzed data; R.G.S designed biological assays and analyzed
biological data.
Conflicts of Interest
The authors declare no conflict of interest.
References
1. Rajendiran, V.; Karthik, R.; Palaniandavar, M.; Stoeckli-Evans, H.; Periasamy, V.S.;
Akbarsha, M.A.B.; Srinag, S.; Krishnamurthy, H. Mixed-ligand copper(II)-phenolate complexes:
Effect of coligand on enhanced DNA and protein binding, DNA cleavage, and anticancer activity.
Inorg. Chem. 2007, 46, 8208–8221.

Molecules 2014, 19
17218
2. O’Halloran, T.V. Transition metals in control of gene expression. Science 1993, 261, 715–725.
3. Verhaegh, G.W.; Richard, M.J.; Hainaut, P. Regulation of p53 by metal ions and by antioxidants:
Dithiocarbamate down-regulates p53 DNA-binding activity by increasing the intracellular level of
copper. Mol. Cell. Biol. 1997, 17, 5699–5706.
4. Yamamoto, K.; Kawanishi, S. Site-specific DNA damage induced by hydrazine in the presence of
manganese and copper ions. J. Biol. Chem. 1991, 266, 1509–1515.
5. Matias, A.C.; dos Santos, N.V.; Chelegão, R.; Nomura, C.S.; Fiorito, P.A.; Cerchiaro, G.J.
Cu(GlyGlyHis) effects on MCF7 cells: Copper uptake, reactive oxygen species generation and
membrane topography changes. Inorg. Biochem. 2012, 116, 172–179.
6. Narang, R.; Narasimhan, B.; Sharma, S. A review on biological activities and chemical synthesis
of hydrazide derivatives. Curr. Med. Chem. 2012, 19, 569–612.
7. Despaigne, A.A.R; Parrilha, G.L.; Izidoro, J.B.; da Costa, P.R.; dos Santos, R.G.; Piro, O.E.;
Castellano, E.E.; Rocha, W.R.; Beraldo, H. 2-Acetylpyridine- and 2-benzoylpyridine-derived
hydrazones and their gallium(III) complexes are highly cytotoxic to glioma cells. Eur. J. Med. Chem.
2012, 50, 163–172.
8. Sathyadevi, P.; Krishnamoorthy, P.; Bhuvanesh, N.S.; Kalaiselvi, P.; Vijaya, P.V.; Dharmaraj, N.
Organometallic ruthenium(II) complexes: Synthesis, structure and influence of substitution at
azomethine carbon towards DNA/BSA binding, radical scavenging and cytotoxicity. Eur. J.
Med. Chem. 2012, 55, 420–431.
9. Recio Despaigne, A.A.; da Costa, F.B.; Piro, O.E.; Castellano, E.E.; Louro, S.R.W.; Beraldo, H.
Complexation of 2-acetylpyridine- and 2-benzoylpyridine-derived hydrazones to copper(II) as an
effective strategy for antimicrobial activity improvement. Polyhedron 2012, 38, 285–290.
10. Gokce, C.; Gup, R. Synthesis and characterisation of Cu(II), Ni(II), and Zn(II) complexes of
furfural derived from aroylhydrazones bearing aliphatic groups and their interactions with DNA.
Chem. Pap. 2013, 67, 1293–1303.
11. Pathan, A.H.; Gudasi, K.B. 1,3-Dioxolane-based ligands as a novel class of α1-adrenoceptor
antagonists. Med. Chem. Res. 2013, 22, 1504–1511.
12. Da Silva, J.G.; Recio Despaigne, A.A.; Louro, S.R.W.; Bandeira, C.C.; Souza-Fagundes, E.M.;
Beraldo, H. Cytotoxic activity, albumin and DNA binding of new copper(II) complexes with
chalcone-derived thiosemicarbazones. Eur. J. Med. Chem. 2013, 65, 415–426.
13. Recio Despaigne, A.A.; Da Silva, J.G.; do Carmo, A.C.M.; Piro, O.E.; Castellano, E.E.; Beraldo, H.
Structural studies on zinc(II) complexes with 2-benzoylpyridine-derived hydrazones.
Inorg. Chim. Acta 2009, 362, 2117–2122.
14. Choudhary, S.; Morrow, J. Dynamic acylhydrazone metal ion complex libraries: A mixed-ligand
approach to increased selectivity in extraction. Angew. Chem. Int. Ed. 2002, 41, 4096–4098.
15. Datta, A.; Das, K.; Yan-Ming, J.; Jui-Hsien, H.; Lee, H.M. Dichlorido{N'-[(pyridin-2-yl)methyl-
idene-κN]acetohydrazide-κ2 N',O}copper(II). Acta Crystallogr. Sect. E Struct. Rep. Online 2011,
67, doi:10.1107/S1600536810053195.
16. Freshney, R.I. Culture of Animal Cells: A Manual of Basic Technique, 6th ed.; Wiley-Blackwell:
New York, NY, USA, 2010.
17. Kaufmann, S.H.; Earnshaw, W.C. Induction of apoptosis by cancer chemotherapy. Exp. Cell Res.
2000, 256, 42–49.

Molecules 2014, 19
17219
18. Gabriel, L.M.; Sanchez, E.F.; Silva, S.G.; Santos, R.G. Tumor cytotoxicity of leucurolysin-B,
a P-III snake venom metalloproteinase from Bothrops leucurus. J. Venom. Anim. Toxins Incl.
Trop. Dis. 2012, 18, 24–33.
19. Kubota, Y.; Kubota, K.; Tani, S. DNA binding properties of DAPI (4',6-diamidino-2-phenylindole)
analogs having an imidazoline ring or a tetrahydropyrimidinering: Groove-binding and
intercalation. Nucleic Acids Symp. Ser. 2000, 44, 53–54.
20. Feng, X.; Xia, Q.; Yuan, L.; Yang, X.; Wang, K. Impaired mitochondrial function and oxidative
stress in rat cortical neurons: Implications for gadolinium-induced neurotoxicity. Neurotoxicology
2010, 31, 391–398.
21. Li, P.F.; Dietz, R.; von Harsdorf, R. p53 Regulates mitochondrial membrane potential through
reactive oxygen species and induces cytochrome c-independent apoptosis blocked by Bcl-2.
EMBO J. 1999, 18, 6027–6036.
22. Lee, J.M. Inhibition of p53-dependent apoptosis by the KIT tyrosine kinase: Regulation of
mitochondrial permeability transition and reactive oxygen species generation. Oncogene 1998, 17,
1653–1662.
23. Liu, B.; Chen, Y.; St Clair, D.K. ROS and p53: Versatile partnership. Free Radic. Biol. Med.
2008, 44, 1529–1535.
24. Sawada, M.; Kiyono, T.; Nakashima, S.; Shinoda, J.; Naganawa, T.; Hara, S.; Iwama, T.; Sakai, N.
Molecular mechanisms of TNF-α-induced ceramide formation in human glioma cells: P53-Mediated
oxidant stress-dependent and -independent pathways. Cell Death Differ. 2004, 11, 997–1008.
25. Haupt, S.; Berger, M.; Goldberg, Z.; Haupt, Y. Apoptosis—the p53 network. J. Cell Sci. 2003,
116, 4077–4085.
26. Kumar, R.S.; Sasikala, K.; Arunachalam, S. DNA interaction of some polymer-copper(II)
complexes containing 2,2'-bipyridyl ligand and their antimicrobial activities. J. Inorg. Biochem.
2008, 102, 234–241.
27. Barton, J.K.; Danishefsky, A.T.; Goldberg, J.M. Tris(phenanthroline)ruthenium(II) stereoselectivity
in binding to DNA. J. Am. Chem. Soc. 1984, 106, 2172–2176.
28. Krishnamoorthy, P.; Sathyadevi, P.; Cowley, A.H.; Butorac, R.R.; Dharmaraj, N. Evaluation of
DNA binding, DNA cleavage, protein binding and in vitro cytotoxic activities of bivalent
transition metal hydrazone complexes. Eur. J. Med. Chem. 2011, 46, 3376–3387.
29. Garbett, N.C.; Hammond, N.B.; Graves, D.E. Influence of the amino substituents in the
interaction of ethidium bromide with DNA. Biophys. J. 2004, 87, 3974–3981.
30. Raja, D.S.; Bhuvanesh, N.S.P.; Natarajan, K. DNA binding, protein interaction, radical scavenging
and cytotoxic activity of 2-oxo-1,2-dihydroquinoline-3-carbaldehyde(2'-hydroxybenzoyl)hydrazone
and its Cu(II) complexes: A structure activity relationship study. Inorg. Chim. Acta 2012, 385, 81–93.
31. Pyle, A.M.; Rehmann, J.P.; Meshoyrer, R.; Kumar, C.V.; Turro, N.J.; Barton, J.K. Mixed-ligand
complexes of ruthenium(II): Factors governing binding to DNA. J. Am. Chem. Soc. 1989, 111,
3051–3058.
32. Sathyadevi, P.; Krishnamoorthy, P.; Butorac, R.R.; Cowley, A.H.; Dharmaraj, N. Synthesis of
novel heterobimetallic copper(I) hydrazone Schiff base complexes: A comparative study on the
effect of heterocyclic hydrazides towards interaction with DNA/protein, free radical scavenging
and cytotoxicity. Metallomics 2012, 4, 498–511.

Molecules 2014, 19
17220
33. Dimiza, F.; Perdih, F.; Tangoulis, V.; Turel, I.; Kessissoglou, D.P.; Psomas, G. Interaction of
copper(II) with the non-steroidal anti-inflammatory drugs naproxen and diclofenac: Synthesis,
structure, DNA- and albumin-binding. J. Inorg. Biochem. 2011, 105, 476–489.
34. Lakowicz, J.R. Principles of Fluorescence Spectroscopy, 2nd ed.; Kluwer Academic Press/Plenum
Publishers: New York, NY, USA, 1999.
35. Kumar, P.; Baidya, B.; Chaturvedi, S.K.; Khan, R.H.; Manna, D.; Mondal, B. DNA binding and
nuclease activity of copper(II) complexes of tridentate ligands. Inorg. Chim. Acta 2011, 376, 264–270.
36. Bi, S.; Sun, Y.; Qiao, C.; Zhang, H.; Liu, C. Binding of several anti-tumor drugs to bovine serum
albumin: Fluorescence study. J. Lumin. 2009, 129, 541–547.
37. Bhattacharyya, M.; Chaudhuri, U.; Poddar, R.K. Evidence for cooperative binding of
chlorpromazine with hemoglobin: Equilibrium dialysis, fluorescence quenching and oxygen
release study. Biochem. Biophys. Res. Commun. 1990, 167, 1146–1153.
38. Shahabadi, N.; Mohammadpour, M. Study on the interaction of sodium morin-5-sulfonate with
bovine serum albumin by spectroscopic techniques. Spectrochim. Acta Part A 2012, 86, 191–195.
39. Chen, G.Z.; Huang, X.Z.; Zheng, Z.Z.; Xu, J.G.; Wang, Z.B. Methods of Fluorescence Analysis,
2nd ed.; Science Press: Beijing, China, 1990.
40. Miller, J.N. Recent advances in molecular luminescence analysis. Proc. Anal. Div. Chem. Soc.
1979, 16, 203–208.
41. Tang, J.H.; Luan, F.; Chen, X.G. Binding analysis of glycyrrhetinic acid to human serum
albumin: Fluorescence spectroscopy, FTIR, and molecular modeling. Bioorg. Med. Chem. 2006, 14,
3210–3217.
42. Raja, D.S.; Bhuvanesh, N.S.; Natarajan, K. Structure-activity relationship study of copper(II)
complexes with 2-oxo-1,2-dihydroquinoline-3-carbaldehyde (4'-methylbenzoyl) hydrazone:
Synthesis, structures, DNA and protein interaction studies, antioxidative and cytotoxic activity.
J. Biol. Inorg. Chem. 2012, 17, 223–237.
43. Reichmann, M.E.; Rice, S.A.; Thomas, C.A.; Doty, P. A further examination of the molecular
weight and size of desoxypentose nucleic acid. J. Am. Chem. Soc. 1954, 76, 3047–3053.
44. Meyer-Almes, F.J.; Porschke, D. Mechanism of intercalation into the DNA double helix by
ethidium. Biochemistry 1993, 32, 4246–4253.
45. ImageJ. Available online: http://imagej.nih.gov/ij/download/ (accessed on 17 October 2014).
Sample Availability: Samples of the complexes 1 and 2 are available from the authors.
© 2014 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/4.0/).
