Organic Letters
Letter
solvent of DMF/MeOH in the reaction system. Due to the
important role of nBu4NBF4 in the electrolysis, some other
ammonium salts as the supporting electrolytes were further
evaluated, such as Et4NCl and nBu4NClO4, but lower yields
were obtained (entries 6 and 7). A slight erosion in yield was
observed when using platinum plate as both electrodes (entry
8), while a moderate yield was observed with a graphite rod
anode and a platinum plate cathode (entry 9). Furthermore,
the use of other additives was explored but provided no
improvement over DABCO, and the reaction in the absence of
DABCO resulted in much lower yields of 3a (entries 10 and
11). As anticipated, control experiments revealed that electric
current was critical for the desired transformation (entry 12).
In addition, the yield was slightly reduced when the reaction
was performed under a nitrogen atmosphere (entry 13).
Encouraged by our results, we turned our attention to
exploring the generality of our reaction with aldehydes and
ketones. As shown from the results compiled in Scheme 2, the
reaction scope of aliphatic aldehydes was first examined with 4-
cyanopyridine (2a) as a coupling partner under the optimized
conditions. Gratifyingly, the method was applicable to a wide
range of aliphatic aldehydes with various substitution patterns.
Cyclic aldehydes with different ring sizes were all converted
into the corresponding secondary alcohols 3a−3e in good to
moderate yields. Substrates bearing acyclic hydrocarbons also
worked well (3f−3u). The chemoselectivity profile of our
method is illustrated by the fact that an alkene (3b, 3p, 3r, and
3u), ester (3c), alcohol (3q), or furan (3o), among others,
could all be well accommodated. Aromatic aldehydes could
also be employed as the reaction partner, and again formation
of the corresponding alcohols was observed. A variety of
functionalized aryl aldehydes were all converted into the
corresponding alcohols in good to high yields (3v−3ii),
including substrates containing methoxy (3x, 3cc, 3ee, and
3hh), fluorine (3z), and thiol ether (3aa), regardless of
whether the substituents are in the ortho-, para-, or meta-
position. Notably, heteroaromatic aldehyde, such as furan-2-
carbaldehyde, was also effectively transformed into the
corresponding product 3ii. Additionally, the scope with respect
to ketones as the coupling partner was tested. A series of
acetophenone derivatives readily underwent the electro-
chemical arylation reaction with 2a to furnish the correspond-
ing tertiary alcohols in moderate to good yields (3ii−3pp).
The scope with respect to analogues of 4-cyanopyridine (2a)
as the aromatic partner was further explored (Scheme 3).
Cyano-substituted pyridine compounds, including 3-methyliso-
nicotinonitrile, 2,6-dimethylisonicotinonitrile, and 3-fluoro-
isonicotinonitrile, underwent electrochemical arylation reac-
tion with aliphatic aldehyde 1a to furnish the corresponding
pyridine-containing alcohols in moderate yields (4a−4c).
Cyano-substituted pyrazine is also a suitable substrate in this
electrochemical arylation, providing 4d in 76% yield. More-
over, direct arylation of benzaldehyde with methyl, tert-butyl,
and hydroxyl-substituted isonicotinonitrile derivatives (4f−
4h), as well as cyano-substituted pyrazine (4i) and quinoline
(4j), proceeded smoothly under the standard conditions.
Notably, electron-deficient arenes, such as 1,4-dicyanobenzene
and methyl 4-cyanobenzoate, were successfully employed,
giving 4k and 4l in 79% and 67% yields, respectively.
Scheme 1. Aldehyde/Ketone to Alcohol Conversion
(2a) in a simple undivided cell equipped with a platinum plate
anode and a graphite rod cathode as the working electrodes
(Table 1). After careful optimization of the reaction
conditions,17 a combination of nBu4NBF4, DABCO, and
DMF under 10 mA constant current electrolysis at room
temperature under air afforded secondary alcohol 3a in 75%
isolated yield. As shown in entries 2 to 5, unsatisfying results
were obtained when using MeCN, DCE, DMSO, or a mixed
a
Table 1. Optimization Studies
a
b
entry
variations from standard conditions
3a (%)
1
none
75
36
NR
62
NR
49
50
71
55
50
31
NR
68
2
MeCN as solvent
3
DCE as solvent
4
DMSO as solvent
5
6
7
DMF/MeOH (1:1) as solvent
Et4NCl instead of nBu4NBF4
nBu4NClO4 instead of nBu4NBF4
8
9
10
11
12
13
Pt(+)/Pt(−) instead of Pt(+)/C(−)
C(+)/Pt(−) instead of Pt(+)/C(−)
Et3N instead of DABCO
without DABCO
without constant current
under N2 atmosphere
a
Standard conditions: Pt plate anode (10 × 10 × 0.2 mm3), graphite
To further evaluate this electrochemical process, a series of
cyclic voltammetry (CV) were conducted, suggesting that both
aldehyde substrate and 2a are likely to undergo cathodic
reduction to generate the corresponding radical intermedi-
rod cathode (φ = 6 mm), 1a (2.4 mmol), 2a (0.4 mmol), DABCO
(1.2 mmol), nBu4NBF4 (0.1 M), anhydrous DMF (5.0 mL), constant
current = 10 mA under air at room temperature for 6 h (5.6 F/mol).
b
Isolated yield. NR: no reaction.
3473
Org. Lett. 2021, 23, 3472−3476
