7394 Journal of Medicinal Chemistry, 2005, Vol. 48, No. 23
Qi et al.
6-(1-Hydroxy-6,6,9-trimethyl-6a,7,10,10a-tetrahydro-
6H-benzo[c]chromen-3-yl)hexanenitrile (8). To a solution
of 3-(5-bromopentyl)-6,6,9-trimethyl-6a,7,10,10a-tetrahydro-
6H-benzo[c]chromen-1-ol (7, 2.16 g, 5.49 mmol) in acetonitrile
(60 mL) at room temperature under Ar were added DBU (2.51
g, 16.5 mmol) and acetone cyanohydrin (1.40 g, 16.5 mmol).
The reaction mixture was stirred for 17 h. After evaporation
of the solvent, the residue was partitioned between water and
EtOAc. The organic layer was washed with water and then
brine, dried over MgSO4, and evaporated. The residue was
purified by chromatography on silica gel, eluting with EtOAc/
hexane (1:3), to afford compound 8 as a yellow oil (1.61 g, 4.74
mmol, 86%). 1H NMR (400 MHz, CDCl3): δ 1.10 (s, 3H), 1.38
(s, 3H), 1.42-1.52 (m, 2H), 1.54-1.68 (m, 5H), 1.70 (br s, 3H),
1.74-1.90 (m, 2H), 2.10-2.20 (m, 1H), 2.33 (t, J ) 7.0 Hz, 2H),
2.47 (dt, J ) 2.8 and 7.6 Hz, 2H), 2.70 (dt, J ) 11.2 and 4.8
Hz, 1H), 3.19 (dd, J ) 16 and 4.4 Hz, 1H), 4.73 (s, 1H), 5.43
(brd, J ) 4.4 Hz, 1H), 6.10 (d, J ) 1.6 Hz, 1H), 6.25 (d, J ) 1.6
Hz, 1H). 13C NMR (100 MHz, CDCl3): δ 17.1, 18.5, 23.5, 25.2,
27.5, 27.8, 28.2, 29.9, 30.3, 31.5, 34.9, 35.9, 44.8, 107.6, 109.9,
110.8, 119.3, 119.8, 125.5, 134.7, 141.6, 154.9. HRMS (MALDI-
FTMS) calcd for C22H29NO2Na (MNa+) 362.2096, found
362.2091.
6a,7,10,10a-tetrahydro-6H-benzo[c]chromen-3-yl)hexanoylami-
no]propionic acid ethyl ester (10, 80 mg, 0.180 mmol) in THF/
H2O (3 mL/1 mL) at 60 °C under Ar was added LiOH/H2O (15
mg, 0.360 mmol). After being stirred for 1 h, the reaction
mixture was poured into water and extracted two times with
EtOAc. The organic layer was washed with saturated brine,
dried over MgSO4, and evaporated. The residue was purified
by chromatography on silica gel, eluting with MeOH/CH2Cl2
(1:9), to afford the desired compound 11 (TCD) as a yellow oil
1
(60.9 mg, 0.146 mmol, 81%). H NMR (400 MHz, CDCl3): δ
1.09 (s, 3H), 1.20-1.36 (m, 2H), 1.37 (s, 3H), 1.45-1.66 (m,
5H), 1.68 (s, 3H), 1.72-1.87 (m, 2H), 2.08-2.20 (m, 1H), 2.16
(t, J ) 7.4 Hz, 2H), 2.39 (t, J ) 7.4 Hz, 2H), 2.59 (t, J ) 5.6
Hz, 2H), 2.64-2.75 (m, 1H), 3.27 (brd, J ) 16.8 Hz, 1H), 3.45-
3.60 (m, 2H), 5.41 (brd, J ) 2.8 Hz, 1H), 6.12 (brs, 1H), 6.20
(brs, 1H), 6.39 (brs, 1H). 13C NMR (100 MHz, CDCl3): δ 18.4,
23.5, 25.4, 27.5, 27.9, 28.5, 29.7, 30.3, 31.6, 35.0, 35.3, 35.9,
36.3, 44.9, 76.8, 107.8, 109.3, 110.9, 119.2, 134.8, 141.8, 154.5,
155.7, 174.9. HRMS (MALDI-FTMS) calcd for C25H35NO5Na
(MNa+) 452.2407, found 452.2400.
6-(9-Chloro-1-hydroxy-6,6,9-trimethyl-6a,7,8,9,10,10a-
hexahydro-6H-benzo[c]chromen-3-yl)hexanoic Acid (12).
To a solution of 6-(1-hydroxy-6,6,9-trimethyl-6a,7,10,10a-tet-
rahydro-6H-benzo[c]chromen-3-yl)hexanoic acid (400 mg, 1.12
mmol) and ZnCl2 (80 mg, 0.587 mmol) in toluene at -10 °C
(40 mL) was bubbled gasous HCl for 2 h. The mixture was
stirred for 1.5 h after stopping the bubbling of HCl. The
reaction mixture was poured into water and extracted two
times with EtOAc. The organic layer was washed with
saturated brine, dried over MgSO4, and evaporated. The
residue was purified by chromatography on silica gel, eluting
with EtOAc/hexane (1:1), to afford chloride 12 as a yellow oil
(409 mg, 1.03 mmol, 92%). 1H NMR (400 MHz, CDCl3): δ 1.13
(s, 3H), 1.30-1.50 (m, 3H), 1.39 (s, 3H), 1.54-1.70 (m, 8H),
1.67 (s, 3H), 1.71-1.79 (m, 2H), 2.14-2.22 (m, 1H), 2.35 (t, J
) 7.4 Hz, 2H), 2.44 (dd, J ) 6.8 Hz, 8.4 Hz, 2H), 3.05 (dt, J )
2.8 Hz, 11.2 Hz, 1H), 3.44 (dt, J ) 14 Hz, 2.8 Hz, 1H), 6.08 (d,
J ) 1.6 Hz, 1H), 6.24 (d, J ) 1.6 Hz, 1H). 13C NMR (100 MHz,
CDCl3): δ 19.1, 24.2, 24.4, 27.6, 28.5, 30.3, 31.3, 33.9, 34.2,
35.0, 42.0, 44.7, 48.7, 72.7, 76.9, 107.7, 109.1, 109.9, 142.3,
154.6, 155.0, 179.8. HRMS (MALDI-FTMS) calcd for C22H32-
ClO4 (MH+) 395.1984, found 395.1990.
6-(1-Hydroxy-6,6,9-trimethyl-6a,7,10,10a-tetrahydro-
6H-benzo[c]chromen-3-yl)hexanoic Acid (9, TCC). 6-(1-
Hydroxy-6,6,9-trimethyl-6a,7,10,10a-tetrahydro-6H-benzo[c]-
chromen-3-yl)hexanenitrile (8, 1.06 g, 2.65 mmol) in a solution
of 50% aqueous MeOH (25 mL) containing 15% NaOH was
refluxed for 4 h. The reaction mixture was acidified with 1 N
HCl and extracted two times with EtOAc. The combined
extracts were washed with saturated brine, dried over MgSO4,
and evaporated. The residue was purified by chromatogra-
phyon silica gel, eluting with EtOAc/hexane (1:1), to afford the
desired compound 9 (TCC) as a yellow amorphous solid (895
1
mg, 2.50 mmol, 94%). H NMR (400 MHz, CDCl3): δ 1.10 (s,
3H), 1.32-1.42 (m, 2H), 1.37 (s, 3H), 1.53-1.72 (m, 5H), 1.70
(brs, 3H), 1.74-1.90 (m, 2H), 2.06-2.20 (m, 1H), 2.35 (t, J )
7.3 Hz, 2H), 2.41-2.45 (m, 2H), 2.69 (dt, J ) 4.8 and 10.8 Hz,
1H), 3.19 (dd, J ) 4.2 and 16.2 Hz, 1H), 4.55-4.95 (br, 1H),
5.43 (d, J ) 4.0 Hz, 1H), 6.09 (d, J ) 1.6 Hz, 1H), 6.26 (d, J )
1.6 Hz, 1H). 13C NMR (100 MHz, CDCl3): δ 18.4, 23.5, 24.4,
27.5, 27.8, 28.6, 30.4, 31.5, 33.9, 35.1, 35.9, 44.8, 76.7, 107.7,
109.9, 110.7, 119.3, 134.7, 142.1, 154.7, 154.9, 180.0. HRMS
(MALDI-FTMS) calcd for C22H30O4Na (MNa+) 381.2036, found
381.2040.
6-(1-Hydroxy-6,6,9-trimethyl-6a,7,8,10a-tetrahydro-6H-
benzo[c]chromen-3-yl)hexanoic Acid (13, TCA). To a
solution of KOtBu (44 mg, 0.391 mmol) in benzene (4 mL) at
4 °C under Ar was added 6-(9-chloro-1-hydroxy-6,6,9-trimethyl-
6a,7,8,9,10,10a-hexahydro-6H-benzo[c]chromen-3-yl)hexano-
ic acid (12, 52 mg, 0.112 mmol) in benzene (2 mL). After being
stirred for 30 min, the mixture was warmed to 65 °C for 20
min, cooled, and bubbled with CO2 for 30 min. The reaction
mixture was poured into water and extracted two times with
EtOAc. The organic extract was washed with saturated brine,
dried over MgSO4, and evaporated. The desired compound 13
(TCA) was obtained as a 1:1 mixture with 9 (TCC), in the form
3-[6-(1-Hydroxy-6,6,9-trimethyl-6a,7,10,10a-tetrahydro-
6H-benzo[c]chromen-3-yl)hexanoylamino]propionic Acid
Ethyl Ester (10). To a mixture of 6-(1-hydroxy-6,6,9-trimeth-
yl-6a,7,10,10a-tetrahydro-6H-benzo[c]chromen-3-yl)hexanoic acid
(9, 237 mg, 0.661 mmol), Et3N (0.1 mL, 0.728 mmol), and
HBTU (276 mg, 0.728 mmol) in DMF (12 mL) at room
temperature under Ar was added H-â-alanine ethyl ester
hydrochloride (112 mg, 0.728 mmol). After being stirred for 2
h, the reaction mixture was poured into water and extracted
two times with Et2O/EtOAc (1:1). The organic layer was
washed with saturated brine, dried over MgSO4, and evapo-
rated. The residue was purified by chromatography on silica
gel, eluting with EtOAc/hexane (1:1), to afford 10 as a yellow
oil (244 mg, 0.550 mmol, 83%). 1H NMR (400 MHz, CDCl3): δ
1.10 (s, 3H), 1.27 (t, J ) 7.2 Hz, 3H), 1.24-1.35 (m, 2H), 1.37
(s, 3H), 1.47-1.68 (m, 5H), 1.69 (s, 3H), 1.72-1.87 (m, 2H),
2.06-2.20 (m, 1H), 2.16 (t, J ) 7.2 Hz, 2H), 2.41 (t, J ) 7.8
Hz, 2H), 2.54 (t, J ) 6 Hz, 2H), 2.70 (dt, J ) 4.4 and 10.8 Hz,
1H), 3.28 (dd, J ) 4.4 and 16 Hz, 1H), 3.52 (q, J ) 6.0 Hz,
2H), 4.16 (q, J ) 7.2 Hz, 2H), 5.41 (brd, J ) 4.0 Hz, 1H), 6.16
(brs, 1H), 6.19 (brs, 1H), 6.27 (brt, J ) 6.0 Hz, 1H). 13C NMR
(100 MHz, CDCl3): δ 14.1, 18.4, 23.5, 25.4, 27.5, 27.9, 28.6,
30.4, 31.6, 33.9, 34.8, 35.1, 35.9, 36.6, 44.9, 60.8, 76.6, 107.7,
109.2, 110.7, 119.1, 134.9, 141.8, 154.6, 155.7, 172.9, 173.7.
HRMS (MALDI-FTMS) calcd for C27H40NO5 (MH+) 458.2902,
found 458.2092.
1
of a brown oil (41 mg, 96%). H NMR (400 MHz, CDCl3): δ
1.09 (s, 3H), 1.30-1.43 (m, 4H), 1.41 (s, 3H), 1.50-1.70 (m,
5H), 1.67 (brs, 3H), 1.86-1.95 (m, 1H), 2.12-2.18 (m, 1H), 2.34
(t, J ) 7.6 Hz, 2H), 2.44 (t, J ) 7.6 Hz, 2H), 3.15-3.22 (m,
1H), 6.13 (brs, 1H), 6.24 (brs, 1H), 6.32 (brs, 1H). 13C NMR
(100 MHz, CDCl3): δ 19.2, 23.3, 24.5, 25.0, 27.5, 28.5, 29.7,
30.4, 31.1, 33.6, 35.0, 45.7, 77.3, 107.6, 109.2, 109.9, 123.8,
134.2, 142.2, 154.3, 154.7, 180.0. HRMS (MALDI-FTMS) calcd
for C22H30O4Na (MNa+) 381.2036, found 381.2036.
3-[6-(9-Chloro-1-hydroxy-6,6,9-trimethyl-6a,7,8,9,10,
10a-hexahydro-6H-benzo[c]chromen-3-yl)hexanoylami-
no]propionic Acid tert-Butyl Ester (14). To a mixture of
6-(9-chloro-1-hydroxy-6,6,9-trimethyl-6a,7,8,9,10,10a-hexahy-
dro-6H-benzo[c]chromen-3-yl)hexanoic acid (12, 200 mg, 0.506
mmol), Et3N (0.18 mL, 1.27 mmol), and HBTU (231 mg, 0.608
mmol) in DMF (6 mL) at room temperature under Ar was
added H-â-alanine tert-butyl ester hydrochloride (114 mg,
0.608 mmol). After being stirred for 1 h, the reaction mixture
was poured into water and extracted two times with Et2O/
EtOAc (1:1). The organic extract was washed with saturated
3-[6-(1-Hydroxy-6,6,9-trimethyl-6a,7,10,10a-tetrahydro-
6H-benzo[c]chromen-3-yl)hexanoylamino]propionic Acid
(11, TCD). To a solution of 3-[6-(1-hydroxy-6,6,9-trimethyl-
