16 (260 kg, 49.1%). Assay (HPLC area %) >98%, cinnamic
acid <1.0%.
C.; Merkle, K. M.; Lynch, R.; Lynch, J. J.; Rodan, S. B.; Duggan, M. E.
Bioorg. Med. Chem. Lett. 2002, 12, 2463.
(5) Haycock-Lewandowski, S. J.; Wilder, A; Åhman, J. Org. Process
Res. Dev. 2008, 12, 1094.
(S)-3-Amino-3-phenylpropanoicAcid:8. The racemic amino
acid 16 (430 kg, 2.60 kmol) and n-propanol (1935 L, 25.6 kmol)
were charged to a 4000-L glass-lined reactor. Thionyl chloride
(341 kg, 2.87 kmol) was added over 1ꢀ2 h, at a reaction
temperature of <40 °C, while the off-gases (SO2 and HCl) were
absorbed in an NaOH scrubber. Following the addition, the
reaction was held for 3 h at 47ꢀ50 °C for complete formation
of the propyl ester. Unreacted thionyl chloride and n-propanol
(∼1300 L) were removed by distillation (45 °C, 50 mbar), and
then toluene (850 L) was added and the distillation repeated to
ensure complete removal of n-propanol. Water (1500 L) was
added, and the propyl ester was extracted into the aqueous phase.
The aqueous layer was adjusted to pH 3ꢀ4 with 25% NaOH
solution, and any residual organic solvent was removed by
distillation (45 °C, 50 mbar). The cooled aqueous solution was
stirred with tert-butyl methyl ether (MTBE) (600 L) and the pH
adjusted to 8.0ꢀ8.2 with 25% NaOH (∼300 L). The layers
were separated, and the aqueous layer was extracted with MTBE
(600 L). Amano lipase PS (21 kg) was dissolved in water (800 L)
and filtered into a 4000-L glass-lined reactor. The filter was washed
with water (400 L). The MTBE extracts were added to the lipase
solution and stirred for 15 h at 28ꢀ30 °C, while maintaining a pH
of 8.1ꢀ8.3 by the addition of 25% NaOH. During this period, the
β-amino acid 8 crystallised from the reaction. The product was
centrifuged in portions and washed with acetone (total 2 ꢁ 200
L). The wet product was dried in vacuo to give the pure (S)-β-
amino acid 8 (178 kg, 41.3%). Assay (titration) 99.0%, assay
(HPLC, area %) 99.5%, (R)-enantiomer (chiral phase HPLC)
<0.3%.
(6) Liu, M.; Sibi, M. P. Tetrahedron 2002, 58, 7991.
(7) Seebach, D.; Overhand, M.; K€uhnle, F. N. M.; Martinoni, B.;
Oberer, L.; Hommel, U.; Widmer, H. Helv. Chim. Acta 1996, 79, 913.
(8) Davies, S. G.; Ichihara, O. Tetrahedron: Asymmetry 1991, 2, 183.
(9) (a) Heller, D.; Holz, J.; Drexler, H.-J.; Lang, J.; Drauz, K.;
Krimmer, H.-P.; B€orner, A. J. Org. Chem. 2001, 66, 6816. (b) Heller,
D.; Holz, J.; Komarov, I.; Drexler, H.-J.; You, J.; Drauz, K.; B€orner, A.
Tetrahedron: Asymmetry 2002, 13, 2735.
(10) Holz, J.; Monsees, A.; Jiao, H.; You, J.; Komarov, I. V.; Fischer,
C.; Drauz, K.; B€orner, A. J. Org. Chem. 2003, 68, 1701.
(11) catASium is a registered trade mark of Evonik, licensed to
Solvias AG, Switzerland.
(12) Kadyrov, R.; Iladinov, I. Z.; Almena, J.; Monsees, A.; Riermeier,
T. H. Tetrahedron Lett. 2005, 46, 7397.
(13) Kadyrov, R.; Riermeier, T.; Almena, J.; Monsees, A.; Gross, P.;
Rossen, K. Eur. Pat. Appl. EP 1862446, 2007.
(14) Zhang, X.; Huang, K.; Hou, G.; Cao, B.; Zhang, X. Angew.
Chem., Int. Ed. 2010, 49, 6421.
(15) Liljeblad, A.; Kanerva, L. T. Tetrahedron 2006, 62, 5831.
(16) Soloshonok, V. A.; Fokina, N. A.; Rybakova, A. V.; Shishkina,
I. P.; Galushko, S. V.; Sorochinsky, A. E.; Kukhar, V. P.; Savchenko,
ꢀ
M. V.; Svedas, Y. K. Tetrahedron: Asymmetry 1995, 6, 1601.
(17) Chenault, H. K.; Dahmer, J.; Whitesides, G. M. J. Am. Chem.
Soc. 1989, 111, 6354.
(18) Gr€oger, H.; Trauthwein, H.; Buchholz, S.; Drauz, K.; Sacherer,
C.; Godfrin, S.; Werner, H. Org. Biomol. Chem. 2004, 2, 1977.
(19) Faulconbridge, S. J.; Holt, K. E.; Sevillano, L. G.; Lock, C. J.;
Tiffin, P. D.; Tremayne, N.; Winter, S. Tetrahedron Lett. 2000, 41, 2679.
(20) (a) Gr€oger, H.; Werner, H. Eur. Pat. Appl. EP 1367129, 2003.
(b) Gr€oger, H.; Werner, H. Eur. Pat. Appl. EP 1367279, 2003.
(21) Gr€oger, H; May, O.; H€usken, H.; Georgeon, S.; Drauz, K.;
Landfester, K. Angew. Chem., Int. Ed. 2006, 45, 1645.
’ AUTHOR INFORMATION
(22) H€usken, H.; Gr€oger, H. Unpublished results.
Corresponding Author
*Fax: (þ49)6181592604. E-mail: ian.grayson@evonik.com.
(23) Ter Wiel, M. K. J.; Arnold, M.; Peter, S.; Troltsch, I.; Merget, S.;
Glaser, F.; Schwarm, M.; Bhatti, H. S.; Kuriakose, B.; Pol, S. S.;
Balamurugan, M.; Joshi, V. V. Tetrahedron: Asymmetry 2009, 20, 478.
(24) Rodionov, W. M.; Malewinskaja, E. T. Ber. Dtsch. Chem. Ges.
1926, 59, 2952.
’ ACKNOWLEDGMENT
(25) Tan, C. Y. K.; Weaver, D. F. Tetrahedron 2002, 58, 7449.
We thank our co-workers from Evonik (Degussa) and our
academic collaborators for their contributions to the work
described here, as noted in the references. We particularly thank
Thomas Riermeier and Renat Kadyrov for their work on the
catalytic asymmetric hydrogenation routes, Harald Gr€oger and
Jens W€oltinger for their work on the biocatalytic processes, and
Franz-Rudolf Kunz for the analytical determinations.
’ REFERENCES
(1) This work was presented by J€urgen Roos at the Organic Process
Research and Development Conference, Clearwater, Florida, United
States, 28 Februaryꢀ2 March, 2011.
(2) Seebach, D.; Beck, A. K.; Bierbaum, D. J. Chem. Biodiversity 2004,
1, 1111.
(3) Juaristi, E., Soloshonok, V., Eds. Enantioselective Synthesis of
β-Amino Acids; Wiley: Hoboken, NJ, 2005; pp 19ꢀ75.
(4) (a) Coleman, P. J.; Brashear, K. M.; Hunt, C. A.; Hoffman, W. F.;
Hutchinson, J. H.; Breslin, M. J.; McVean, C. A.; Askew, B. C.; Hartman,
G. D.; Rodan, S. B.; Rodan, G. A.; Leu, C.-T.; Pruekasritanont, T.;
Fernandez-Metzler, C.; Ma, B.; Libby, L. A.; Merkle, K. M.; Stump, G. L.;
Wallace, A. A. Bioorg. Med. Chem. Lett. 2002, 12, 31. (b) Coleman, P. J.;
Askew, B. C.; Hutchinson, J. H.; Whitman, D. B.; Perkins, J. J.; Hartman,
G. D.; Rodan, G. A.; Leu, C.-T.; Pruekasritanont, T.; Fernandez-Metzler,
1206
dx.doi.org/10.1021/op200084g |Org. Process Res. Dev. 2011, 15, 1201–1206
