Graphene-supported ZnO nanoparticles: An efficient heterogeneous catalyst for the Claisen-Schmidt condensation reaction without additional base

Article abstract of DOI:10.1016/j.tetlet.2017.09.011

ZnO nanoparticles supported on reduced graphene oxide (ZnO/RGO) were prepared by the hydrothermal method and characterized by TEM, XPS, XRD, and Raman spectroscopy. As a green catalyst, ZnO/RGO was applied to the Claisen-Schmidt condensation reaction of aryl aldehydes and aryl ketones under microwave irradiation. Therein, chalcone products could be efficiently synthesized and easily separated from the heterogeneous catalysis system. The catalyst could be recycled four times without significant loss of catalytic activity.

Full text of DOI:10.1016/j.tetlet.2017.09.011

Accepted Manuscript
Graphene-supported ZnO nanoparticles: an efficient heterogeneous catalyst for
the Claisen-Schmidt condensation reaction without additional base
Zhuofei Li, Hongyan Zhao, Huatao Han, Yang Liu, Jinyi Song, Weihao Guo,
Wenyi Chu, Zhizhong Sun
PII:
S0040-4039(17)31128-0
DOI:
http://dx.doi.org/10.1016/j.tetlet.2017.09.011
TETL 49281
Reference:
To appear in:
Tetrahedron Letters
Received Date:
Revised Date:
Accepted Date:
4 July 2017
1 September 2017
7 September 2017
Please cite this article as: Li, Z., Zhao, H., Han, H., Liu, Y., Song, J., Guo, W., Chu, W., Sun, Z., Graphene-supported
ZnO nanoparticles: an efficient heterogeneous catalyst for the Claisen-Schmidt condensation reaction without
additional base, Tetrahedron Letters (2017), doi: http://dx.doi.org/10.1016/j.tetlet.2017.09.011
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to our customers
we are providing this early version of the manuscript. The manuscript will undergo copyediting, typesetting, and
review of the resulting proof before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.

Tetrahedron Letters
Tetrahedron Letters
Graphene-supported ZnO nanoparticles: an efficient heterogeneous catalyst for the
Claisen-Schmidt condensation reaction without additional base
a, b
a, b
a, b
a, b
a, b
a, b
a, b
Zhuofei Li, Hongyan Zhao, Huatao Han, Yang Liu, Jinyi Song, Weihao Guo, Wenyi Chu
a, b
and Zhizhong Sun*
a
School of Chemistry and Materials Science, Heilongjiang University, Harbin 150080, P. R. China
Key Laboratory of Chemical Engineering Process & Technology for High-efficiency Conversion, College of Heilongjiang Province, Harbin 150080, P. R.
b
China
ARTICLE INFO
ABSTRACT
Article history:
Received
Received in revised form
Accepted
ZnO nanoparticles supported on reduced graphene oxide (ZnO/RGO) were prepared by the
hydrothermal method and characterized by TEM, XPS, XRD, and Raman spectroscopy. As a
green catalyst, ZnO/RGO was applied to the Claisen-Schmidt condensation reaction of aryl
aldehydes and aryl ketones under microwave irradiation. Therein, chalcone products could be
efficiently synthesized and easily separated from the heterogeneous catalysis system. The
catalyst could be recycled four times without significant loss of catalytic activity.
Available online
Keywords:
ZnO/RGO
2
017 Elsevier Ltd. All rights reserved.
Claisen-Schmidt
Chalcone
Heterogeneous catalysis
Introduction
2
In recent years, reduced graphene oxide (RGO) has received extensive attention on account of its unique sp hybrid
structural characteristics, large specific surface area, and stable chemical structure, as well as excellent mechanical, physical
1
-4
5
6
7
and other properties. Therefore, RGO has been applied in the catalyst carrier, solar cell, and super capacitor fields. So far,
8
9
10
11
a large number of groups have reported various metal oxides, including TiO , CuO, ZnO, and SnO2, supported on RGO
2
as catalysts. With advantages including plentiful raw material availability, low cost, non-toxicity, good thermal stability,
1
2
chemical stability and easy availability; ZnO as a catalyst has become a research hotspot. ZnO nanoparticles dispersed on a
RGO layer can not only avoid the phenomenon of agglomeration, but also produce synergistic effects and good catalytic
1
3
activity. These materials are typically used as photocatalysts in photodegradation reactions. Bai and co-workers reported
that graphene/ZnO hybrids showed excellent photocatalytic activity in the photodegradation of deoxynivalenol under UV
1
4
light, while Xu and co-workers reported the photocatalytic activities of ZnO-graphene in the degradation of methyl orange
and water splitting under visible light. However, little attention has been paid to organic synthesis reactions catalyzed by ZnO
nanocomposites supported on RGO. Rajesh and co-
1
5
workers reported RGO/ZnO nanocomposites as a catalyst for the synthesis of 3-substituted indoles in water.
Chalcone derivatives are found in many natural products, and are also important synthetic intermediates for the formation of
1
6, 17
flavonoids and isoflavones.
The various bioactivities of chalcones mainly depend on the number and position of substituents on the
two benzene rings. The flexible structures of chalcones and the ability to interact with different receptors leads to a wide range of
1
7-20
biological activities, such as anti-tumor, antibacterial, antiallergic, antiviral, and antimalarial properties.
Therefore, many synthetic
methods have been developed for the synthesis of these compounds. Since the 1970s, one of the most important tools has been the use
2
1
of a strong base or Lewis acid to catalyze the Claisen-Schmidt reaction; however, this method is, to a certain extent, not
environmentally friendly. A way to overcome this problem is the use of a heterogeneous catalyst instead of a base or Lewis acid. So far,
numerous heterogeneous catalysts, such as hydroxyapatite, activated carbon, ZSM-5 zeolite, and magnesium oxide hollow spheres,
2
2-25
have been developed.
pollution or other aspects.
However, these methods also have some limitations and shortcomings in terms of cost, environmental
—
——

Corresponding author. Tel.: + 86-451-86609135; fax: + 86-451-86609135; e-mail: wenyichu@hlju.edu.cn; sunzz@hlju.edu.cn

2
Tetrahedron Letters
2
6
27
Our team has previously studied the use of metals supported on RGO composites, such as Pd@PdO-NDG, Cu NPs@RGO and
2
8
WO /RGO, to catalyse organic synthesis reactions. Based on these publications, we proposed ZnO nanocomposites supported on RGO
3
(ZnO/RGO) by the hydrothermal method, to catalyze the Claisen-Schmidt condensation reaction.
Scheme 1. Synthesis and application of the ZnO/RGO catalyst.
Results and Discussion
As shown in Figure 1, the morphology and particle size of ZnO/RGO could be observed by transmission electron microscopy (TEM).
The representative crinkles of graphene were present, and the ZnO nanoparticles were dispersed on the surface of graphene without
aggregation (Fig. 1a). It could also be seen that the ZnO nanoparticles were successfully anchored on RGO; after centrifugation and
sonication, the nanoparticles still existed, indicating a strong bond between the two materials. The high-resolution transmission electron
microscopy (HRTEM) image showed the lattice fringe was 0.248 nm, corresponding to the (101) crystal plane of the wurtzite ZnO
2
9
crystal (Fig. 1b).
Figur
e 1. (a)
TEM
and
HRTEM
(b)
images
of ZnO/RGO.
Figure 2. XRD pattern of GO and ZnO/RGO.
Figure 2 depicts the XRD pattern of the ZnO/RGO composite. The
diffraction peaks at 31.5°, 34.1°, 36.3°, 47.6°, 56.7°, 62.7°, and 68.1° were
consistent with those of (100), (002), (101), (102), (110), (103), and (112),
2
9
respectively,
indicating that ZnO was hexagonal wurtzite. The
diffraction peak around 25°, which could be seen as a broad absorption
peak, is the typical absorption peak for graphene. However, there was no
strong absorption at the diffraction peak of 10°, which proved that the graphene oxide is fully transformed into graphene during the
reduction process.
-
1
The Raman spectrum of GO and ZnO/RGO composites are shown in Figure 3a. Two strong absorption peaks at 1368 cm and 1600
-
1
2
cm , for the G band and D band, respectively, are clearly observed. The G band corresponded to the sp hybridized carbon, while the D
band was mainly caused by defects or disordered carbon. The I and I intensity ratios indicate the structural regularity of the graphitic
D
G
carbon; when the I /I values are closer to zero, the regularity is higher. In Figure 3a, the I /I value of the graphene oxide was 0.83,
D
G
D G
whereas the value of the ZnO/RGO nanocatalyst was 1.02. The reason why the value increased was that a large amount of the
2
+
functional groups on GO (such as carboxyl and hydroxyl) are anchored as reaction sites for Zn demonstrating ZnO/RGO
3
0
nanocomposites are obtained, which was consistent with the TEM results. It also indicated that the structure of the carbon was
destroyed and the degree of crystallinity decreases during reduction of the graphene oxide.

Tetrahedron Letters
Figure 3. (a) Raman spectra of ZnO/RGO and GO. (b) Zn 2p XPS spectra of ZnO/RGO catalyst. (c) C1s XPS spectra of ZnO/RGO. (d) C1s
XPS spectra of GO.
The XPS spectra of the ZnO/RGO composites are shown in Figure 3b. The binding energies at 1021.8 and 1044.9 eV, which were
3
1
assigned to Zn2p3/2 and Zn2p , respectively, indicated that zinc was present in the form of ZnO. These results indicate that there are
1/2
3
2
no impurities within the sample. Figure 3c depicts the C 1s fitting spectrum of the composites. The peak at 284.5 eV corresponded to
the sp carbon atom, whereas the deconvoluted peaks at 285.7 eV and 289.8 eV were attributed to C-OH, C=O and COOH oxygen-
containing carbonaceous bands, respectively. The C 1s spectrum of ZnO/RGO is consistent with the C 1s absorption peak spectrum of
graphene oxide (Fig. 3d). According to the comparison of Fig. 3c and Fig. 3d, the decrease of oxygen-containing functional groups in
theZnO/RGO nanocomposite proves that the graphene oxide is reduced
2
2
9
to graphene.
Figure 4. ZnO/RGO catalyst recycling.
Next, benzaldehyde and acetophenone were examined as model
substrates, and the reaction conditions for the ZnO/RGO catalyzed
Claisen-Schmidt condensation were optimized by screening the solvent,
temperature and time (Table 1).
Initially, various solvents, including water, ethanol, tetrahydrofuran,
N,N-dimethylformamide, and ethanol/water were examined. The yields
only reached 30% and 50% in water and ethanol, respectively (Entries 1-
2
), while yields of 20% were obtained in THF and DMF (Entries 3-4).
When different ratios of ethanol and water were utilised, a yield of 98%
was obtained in 2:1 ethanol/water (Entries 5-7). Note that the addition of
ethanol could increase the substrate solubility and the dispersibility of the
catalyst.
Subsequently, it was found that microwave irradiation for 15 minutes was the
optimal reaction time (Entries 6 and 8-9). The reaction yield was only 15% when
the reaction was heated at 80 °C without microwave irradiation (Entry 10). It was
also found that ZnO/RGO was a better catalyst than ZnO (Entries 6 and 11).
Without the catalyst, the reaction did not occur (Entry 12), Finally, ZnO/RGO
(10 mol%) was found to be the optimum catalyst loading (Entries 6 and 13-14).
a
Table 1. Optimization of the reaction conditions.
b
Entry
Catalyst
Solvent
Time (min)
Yield (%)
1
2
3
4
5
6
7
8
9
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO/RGO (10mol%)
ZnO
H
EtOH
THF
2
O
15
15
15
15
15
15
15
20
10
60
15
15
15
15
30
50
20
20
93
98
90
98
80
15
30
-
78
97
DMF
EtOH/H
EtOH /H
2
O (3:1)
2
2
2
2
2
2
2
2
2
O (2:1)
O (1:1)
O (2:1)
O (2:1)
O (2:1)
O (2:1)
O (2:1)
O (2:1)
O (2:1)
EtOH /H
EtOH /H
EtOH /H
EtOH /H
EtOH /H
EtOH /H
EtOH /H
EtOH /H
c
1
1
1
1
1
0
1
2
3
4
None
ZnO/RGO (5mol%)
ZnO/RGO (15mol%)
a
b
c
Reagents and conditions: aryl aldehyde (0.05 mol), aryl ketone (0.05 mol), catalyst (10 mol%), solvent (6 mL), MW (120W, reflux). Isolated yield.
Without microwave irradiation at 80°C.
Therefore, the optimum reaction conditions were as follows: benzaldehyde and the substituted acetophenone as substrates,
ZnO/RGO as catalyst, EtOH/H O (2:1) as solvent under microwave irradiation for 15 minutes. Using these conditions, high yields and
2
low by-product formation was observed, as well as simple catalyst separation.
Under the optimized reaction conditions, we broadened the range of substrates to various aryl aldehydes and aryl ketones to
investigate their electronic and steric hindrance characteristics in the Claisen-Schmidt condensation (Table 2).
Firstly, the reactions of acetophenone with different aryl aldehydes were studied. para-Substituted aryl aldehydes with electron-
withdrawing groups (–NO , –Cl and –Br) or electron-donating groups (–OCH and –CH ), gave the corresponding chalcone product in
2
3
3
over 90% yield (Entries 1-6). It could be seen that electron-withdrawing groups were beneficial to the reaction. Moreover, 4-
nitrobenzaldehyde gave a yield of 94% (Entry 4), while 2-nitrobenzaldehyde did not give the product (Entry 7); this could be due to
steric hindrance. Moreover, hydroxyl chalcones were synthesized in 90-91% yields (Entries 8-10). Furthermore, acetophenones with
different groups at various positions were investigated; these acetophenones all gave high yields (Entries 11-22). When furfural was
used as substrate, the corresponding product was obtained in 90% yield (Entries 17-18), indicating that the catalyst system was also
effective for heterocyclic aromatic aldehydes.

4
Tetrahedron Letters
a
Table 2. Substrate scope of the ZnO/RGO-catalyzed Claisen-Schmidt condensation reaction.
1
2
b
Entry
R
R
Yield (%)
98
1
2
3
4
5
6
7
8
9
H
H
H
H
H
H
4-OCH
4- CH
3
91
90
94
93
94
Trace
90
91
91
90
95
96
92
93
92
90
90
3
4-NO
4- Cl
4- Br
2-NO
H
2
H
H
2
2-OH
2-OH
2-OH
3-Br
3-Br
4-OCH
4-OCH
4-OCH
4-OCH
4-OCH
4-CH
4-CH
4-CH
4-CH
4-CH
4-OCH
3
1
1
0
1
4-Br
4-Cl
H
1
1
1
1
1
1
1
1
2
2
2
2
3
4
5
6
7
8
9
0
1
2
H
3
3
3
3
3
4-OCH
4-Br
4-Cl
furfural
furfural
H
4-OCH
4-Br
4-Cl
3
3
3
3
3
3
96
91
94
3
93
a
b
Reagents and conditions: aryl aldehyde (0.05 mol), aryl ketone (0.05 mol), ZnO/RGO (10 mol%), EtOH/H
According to the literature, a possible mechanism for the ZnO/RGO catalyzed Clasien-Schmit condensation was proposed (Scheme
2
O (6 mL, 2:1), MW (120W, reflux). Isolated yield.
3
3
2
). The ZnO/RGO catalyst can both activate the aldehyde carbonyl group to form transition complex 1 and also promote formation of
the active enol form 2 of the ketone. The addition product 3 is then generated by nucleophilic addition. Finally an elimination reaction
gives the chalcone product with the loss of H O.
2
Scheme 2. Possible mechanism for the Clasien-Schmit condensation.
In order to demonstrate the reusability of ZnO/RGO, four cycles
of experiments were conducted (Fig. 4). The catalyst retained
considerable activity after four cycles; the yield of chalcone was
always greater than 90%, although it gradually decreased. This also
indicated that the catalyst had good stability and activity.
Using benzaldehyde and acetophenone as representative substrates,
the catalytic system was compared with earlier reports. The protocol
had good catalytic performance with lower reaction times and higher
yields (Entries 1-4). Therefore, the heterogeneous ZnO/RGO
catalytic system is more desirable and efficient than previous
methods.
Table 3. Comparisons of optimal protocol with earlier reports.
Entry
Catalyst
@MOF
Temperature
Time
24 h
1 h
Yield
96
Reference
o
1
2
3
4
5
Fe
3
O
4
110 C
21
22
hydroxyapatite
flower-like MgO
NAFAP
MW (700W)
110
80
2 h
99
25
r.t.
24 h
0.25 h
90
17
ZnO/RGO
MW (120W)
98
This work
In conclusion, ZnO nanoparticles supported on RGO were prepared by the hydrothermal method and utilised to efficiently catalyze
the Claisen-Schmidt condensation of aromatic aldehydes and ketones under microwave irradiation without additional base. The
catalytic system could be recycled four times without a dramatic loss of activity. The heterogeneous catalytic system had high catalytic
efficiency and good functional group tolerance.
Acknowledgments
The authors thank the financial support from the Research Project of the Natural Science Foundation of Heilongjiang Province of
China (No. B201207 and B201208).
References and notes
1
2
.
.
Kim, N. H.; Kuila, T.; Lee, J. H. J. Mater. Chem. A 2013, 1, 1349-1358.
Geim, A. K.; Novoselov, K. S. Nat. Mater. 2007, 6, 183-191.

Tetrahedron Letters
Yang, F.; Chi, C.; Wang, C.; Wang, Y.; Li, Y. Green Chem. 2016, 18, 4254-4262.
Yang, H.; Li, J.; Yu, D.; Li, L. Cryst. Growth Des. 2016, 16, 4831-4838.
Sun, J. W.; Fu, Y. S.; He, G. Y.; Sun, X. Q.; Wang, X. Catal. Sci. Technol. 2014, 4, 1742-1748.
Blake, P.; Brimicombe, P. D.; Nair, R. R.; Booth, T. J.; Jiang, D.; Schedin, F.; Ponomarenko, L. A.; Morozov, S. V.; Gleeson, H. F.; Hill, E. W.;
Geim, A. K.; Novoselov, K. S. Nano Lett. 2008, 8, 1704-1708.
3
4
5
6
.
.
.
.
7
8
9
1
1
1
1
.
.
.
Stoller, M. D.; Park, S.; Zhu, Y.; An, J.; Ruoff, R. S. Nano Lett. 2008, 8, 3498-3502.
Mohamed, H. H. Appl. Catal. A: Gen. 2017, 541, 25-34.
Reddy, V. H.; Reddy, Y. V. R.; Sridhar, B.; Reddy, B. V. S. Adv. Synth. Catal. 2016, 358, 1088-1092.
0. Chen,Y.; Katsumata, K.; Chiu, Y.; Okada, K.; Matsushita, N.; Hsu, Y. Appl. Catal. A: Gen. 2015, 490, 1-9.
1. Liu, M.; Wang, X. Z.; Chen, Y. Q.; Dai, L. Y. RSC Adv. 2015, 5, 61481-61485.
2. Ahmed, G.; Hanif, M.; Zhao, L.; Hussain, M.; Khan, J.; Liu, Z. J. Mol. Catal. A: Chem. 2016, 425, 310-321.
3. Bai, X. J.; Sun, C. P.; Liu, D.; Luo, X. H.; Li, D.; Wang, J.; Wang, N. X.; Chang, X. J.; Zong, R. L. Zhu, Y. F. Appl. Catal. B: Environ. 2017, 204, 11-
2
0.
1
1
1
1
1
1
2
4. Xu, J. L.; Cui, Y.; Han, Y. D.; Hao, M.; Zhang, X. RSC Adv. 2016, 6, 96778-96784.
5. Rajesh, U. C.; Wang, J. F.; Prescott, S.; Tsuzuki, T.; Rawat, D. S. ACS Sustain. Chem. Eng. 2015, 3, 9-18.
6. Li, J.; Feng, J.; Li, M.; Wang, Q.; Su, Y.; Jia, Z. Solid State Sci. 2013, 21, 1-5.
7. Jioui, I.; Dânoun, K.; Solhy, A.; Jouiad, M.; Zahouily, M.; Essaid, B.; Len, C.; Fihri, A. J. Ind. Eng. Chem. 2016, 39, 218-225.
8. Sivakumar, P. M.; Ganesan, S.; Veluchamy, P.; Doble, M. Chem. Biol. Drug Des. 2010, 76, 407-411.
9. Kumar, D.; Kumar, N. M.; Akamatsu, K.; Kusaka, E.; Harada, H.; Ito, T. Bioorg. Med. Chem. Lett. 2010, 20, 3916-3919.
0. Kommidi, D. R.; Pagadala, R.; Rana, S.; Singh, P.; Shintre, S. A.; Koorbanally, N. A.; Jonnalagadda, S. B.; Moodley, B. Org. Biomol. Chem. 2015,
1
3, 4344-4350.
2
2
2
2
2
2
2
2
2
3
3
3
3
1. Ke, F.; Qiu, L. G.; Zhu, J. Nanoscale 2014, 6, 1596-1601.
2. Solhy, A.; Tahir, R.; Sebti, S.; Skouta, R.; Bousmina, M.; Zahouily, M.; Larzek, M. Appl. Catal. A: Gen. 2010, 374, 189-193.
3. Winter, C.; Caetano, J. N.; Araújo, A. B. C.; Chaves, A. R.; Ostroski, I. C.; Vaz, B. G.; Pérez, C. N.; Alonso, C. G. Chem. Eng. J. 2016, 303, 604-610.
4. Bai, P.; Wu, P. P.; Xing, W.; Liu, D. L.; Zhao, L. M.; Wang, Y. H.; Xu, B. J.; Yan, Z. F.; Zhao, X. S. J. Mater. Chem. A, 2015, 3, 18586-18597.
5. Yang, S.; Huang, P.; Peng, L.; Cao, C.; Zhu, Y.; Wei, F.; Sun, Y.; Song, W. J. Mater. Chem. A 2016, 4, 400-406.
6. Jiang, B. J.; Song, S. Z.; Wang, J. Q.; Xie, Y.; Chu, W. Y.; Li, H. F.; Xu, H.; Tian, C. G.; Fu, H. G. Nano Res, 2014, 7, 1280-1290.
7. Zhao, H. Y.; Mao, G. J.; Han, H. T.; Song, J. Y.; Liu, Y.; Chu, W. Y.; Sun, Z. Z. RSC Adv. 2016, 6, 41108- 41113.
8. Han, H. T.; Zhao, H. Y.; Liu, Y.; Li, Z. F.; Song, J. Y.; Chu, W. Y.; Sun, Z. Z. RSC Adv. 2017, 7, 3790-3795.
9. Zhang, Q.; Tian, C. G.; Wu, A. P.; Tan, T. X.; Sun, L.; Wang, L.; Fu, H. G. J. Mater. Chem. 2012, 22, 11778-11784.
0. Guo, L. J.; Yang, Z.; Li, Y. S.; Zu, B. Y.; Dou, X. C. Sensor. Actuat. B: Chem. 2017, 239, 286-294.
1. Wu, X.; Wen, L.; Lv, K.; Deng, K.; Tang, D.; Ye, H.; Du, D.; Liu, S.; Li, M. Appl. Surf. Sci. 2015, 358, 130-136.
2. Wang, X.; Zhao, F.; Xie, P.; Liang, S.; Deng, S.; Xu, N. Opt. Commun. 2007, 276, 186-190.
3. Tamuly, C.; Saikia, I.; Hazarika, M.; Bordoloi, M. Hussain, N.; Das, M. R.; Deka, K. RSC Adv. 2015, 5, 8604-8608.

6
Tetrahedron Letters
Graphical Abstract
Graphene-supported ZnO nanoparticles: an efficient
catalyst for the heterogeneous catalysis Claisen-Schmidt
condensation reaction without additional base
Zhuofei Li, Hongyan Zhao, Huatao Han, Yang Liu, Jinyi Song, Weihao Guo, Wenyi Chu and
Zhizhong Sun*

Tetrahedron Letters
Highlights
1
2
3
4
. ZnO nanoparticles supported on reduced graphene oxide were prepared.
. ZnO/RGO as catalyst was applied to the Claisen-Schmidt condensation.
. A new catalytic system was developed under microwave conditions.
. ZnO/RGO could be recycled without obvious losses of catalytic activity.
