Benzo[b]tellurophenes as a Potential Histone H3
Lysine 9 Demethylase (KDM4) Inhibitor
Yoon-Jung Kim 1, Dong Hoon Lee 1, Yong-Sung Choi 1, Jin-Hyun Jeong 1,* and So Hee Kwon 1,2,
*
1
College of Pharmacy, Yonsei Institute of Pharmaceutical Sciences, Yonsei University, 85 Songdogwahak-ro,
Yeonsu-gu, Incheon 21983, Korea; sunshine333@sookmyung.ac.kr (Y.-J.K.); tci30@naver.com (D.H.L.);
uriys2@gmail.com (Y.-S.C.)
Department of Integrated OMICS for Biomedical Science, Yonsei University, Seoul 03720, Korea
Correspondence: organicjeong@yonsei.ac.kr (J.-H.J.); soheekwon@yonsei.ac.kr (S.H.K.);
Tel.: +82-32-749-4509 (J.-H.J.); +82-32-749-4513 (S.H.K.)
2
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
Received: 1 November 2019; Accepted: 23 November 2019; Published: 25 November 2019
ꢀꢁꢂꢃꢄꢅꢆ
Abstract: Gene expression and tumor growth can be regulated by methylation levels of lysine
residues on histones, which are controlled by histone lysine demethylases (KDMs). Series of
benzo[b]tellurophene and benzo[b]selenophene compounds were designed and synthesized and
they were evaluated for histone H3 lysine 9 demethylase (KDM4) inhibitory activity. Among the
carbamates, alcohol and aromatic derivatives, tert-butyl benzo[b]tellurophen-2-ylmethylcarbamate
(compound 1c) revealed KDM4 specific inhibitory activity in cervical cancer HeLa cells, whereas the
corresponding selenium or oxygen substitute compounds did not display any inhibitory activity
toward KDM4. Compound 1c also induced cell death in cervical and colon cancer but not in normal
cells. Thus, compound 1c, a novel inhibitor of KDM4, constitutes a potential therapeutic and research
tool against cancer.
Keywords: tellurium; benzo[b]tellurophene; benzo[b]selenophene; KDM4 inhibitor; histone H3K9
demethylases
1. Introduction
Benzofuran and benzothiophene are famous molecular frameworks that are oxygen- or
sulfur-containing heterocycles. These frames provide useful ligands for more than one type of receptor
or enzyme target via structural modifications, called privileged structure [1–4]. The benzofuran structure
is found in amiodarone (calcium, potassium, and sodium channels; antiarrhythmic), dronedarone
(calcium, potassium, and sodium channels; antiarrhythmic), vilazodone (serotonin receptor;
antidepressant), and many opioid drugs (opioid receptors; analgesic) [
raloxifene (estrogen receptor, osteoporosis in postmenopausal women), zileuton (5-lipoxygenase,
asthma), sertaconazole (14 -demethylase, antifungal), and benocyclidine N-methyl-d-aspartate
receptor (NMDAR), psychostimulant) [ ]. These privileged structures serve as structural motif
1,3,4]. Benzothiophene is part of
α
2
templates, which play important roles in medicinal chemistry.
Selenium and tellurium belong to the calcogens: The same periodic table group as oxygen
and sulfur. They have been considered nonessential and toxic elements in the past. Recently,
selenium has been found in the human body as selenoproteins like glutathione peroxidase (GPx), and
organoselenium compounds including ebselen have been synthesized and evaluated for biological
functions [
selenium improves their antioxidant effect in vitro and in vivo
also are of interest, and several groups have reported their biological activities [
derivative containing tellurium mimicking the action of GPx shows catalytic antioxidant activity [13].
5
,6
]. Our group reported that the substitution of oxygen in flavonoid structures with
]. Organotellurium compounds
12]. A vitamin E
[
7
8–
Int. J. Mol. Sci. 2019, 20, 5908; doi:10.3390/ijms20235908
www.mdpi.com/journal/ijms

Int. J. Mol. Sci. 2019, 20, 5908
2 of 14
Selenium- and tellurium-containing molecules are likely to be new privileged structures that could
widen the molecular universe to find novel medicines for many unconquered targets.
Interestingly, ebselen and some selenium compounds have shown inhibitory activity toward
histone H3 lysine 9 demethylase (KDM4) by ejection of structural Zn(II) [14]. Histone methylation
performs an important role in the regulation of eukaryotic cellular systems such as transcriptional
regulation, chromatin organization, and gene expression [15–17]. Methylation of specific lysine
residues is regulated by histone methyltransferases (HMTs) and histone demethylases (KDMs) [15].
Lysine-specific demethylases, KDM proteins in the JmjC-domain-containing demethyalse (JMJD) family
function as a 2-oxoglutarate-dependent Fe(II) oxygenase and catalyzes hydroxylation reactions [16].
Recent data indicate that abnormal expression of KDM4 proteins can promote the progression of cancer,
including breast cancer, prostate cancer, and lymphomas [18], and thus have emerged as potential
therapeutic targets. For example, KDM4A–C are overexpressed at both the protein and mRNA levels
in breast tumors, and their overexpression contributes to breast tumorigenesis by stimulating estrogen
receptor
α (ERα) activity [18–21]. Overexpression of KDM4C increases the expression of the mouse
double minute 2 (MDM2) oncogene in a manner dependent on its demethylase activity, leading to a
decrease of tumor suppressor p53 target genes including proapoptotic genes [20] and to promotion of
breast tumor growth [21]. Thus, KDM4 inhibitors represent potential selective cancer therapeutic agents
for cancer treatment [22–25]. Moreover, ebselen has a selenium-containing benzo-fused five-membered
heterocycle, similar to that of benzofuran and benzothiophene, as its core structure. We set out to
identify structurally unique, selective inhibitor of KDM4 in cancer cells, and based on the evidence
above, we were inspired to synthesize benzo[b]selenophene and benzo[b]tellurophene compounds and
evaluate their activity against KDMs. Especially, benzo[b]tellurophenes having carbamate or alcohol
groups are novel compounds that have never been synthesized to our knowledge.
Figure 1 depicts
α-substituted benzo[b]tellurophenes and benzo[b]selenophenes (1) and our
synthetic strategy for the preparation of these compounds. We expected to synthesize compound
1 by the ring cyclization of 2 with NaHTe/NaHSe [26], which was obtained from the commercially
available compound 1-bromo-2-iodobenzene, by a Sonogashira reaction. Herein, we prepared novel
benzo[b]tellurophenes and benzo[b]selenophenes (1) and evaluated their inhibitory activity on KDM4.
Figure 1. Representative structure and the synthetic strategy of benzo[b]tellurophene and
benzo[b]selenophene (compound 1).
2. Results and Discussion
2.1. Chemistry
Preparation of the benzo[b]tellurophene, benzo[b]selenophene, and benzo[b]furanderivatives
is outlined in Scheme 1. Compounds 2a–g and 3 were easily obtained by Sonogashira reaction of
1-bromo-2-iodobenzene with corresponding terminal alkynes. Compound 4 was obtained by reductive
removal of the trimethylsilyl (TMS) group of 3 under K2CO3 and MeOH conditions. The reaction
of 1-bromo-2-ethynylbenzene (4) with various iodoaryl compounds yielded compounds 2h–2k by
Sonogashira reaction. Treatment of compounds 2a–k with sodium hydrogen telluride (selenide),
generated in situ from tellurium (selenium) powder and sodium borohydride in dimethylformamide
(DMF) at 100 ◦C, resulted in ring closure, affording the desired benzo[b]tellurophenes and
benzo[b]selenophenes (1a–o). Benzo[b]furans (1p,q) were also synthesized from 2-iodophenol with
corresponding terminal alkynes under Sonogashira reaction conditions to compare their biological
activity with benzo[b]tellurophene and benzo[b]selenophene compounds. Benzo[b]tellurophene,

Int. J. Mol. Sci. 2019, 20, 5908
3 of 14
benzo[b]selenophene, and benzo[b]furan derivatives with carbamates, alcohol, and aromatic moieties
were designed and synthesized. Compounds 1a,lp have the most similar structure with ebselen which
has a simple phenyl group conjugated with a benzo-fused five-membered heterocyle. This phenyl
group was replaced with carbamate (1c–g,m,q), alcohol (1b), or heteroaryl (1h,j,n) moieties, which can
form a polar interaction with internal metals or the hydrophilic residues of proteins. Other compounds
(1i,k,o) contained phenyl groups with halogens, which also can interact with polar atoms. All the
prepared compounds are listed in Table 1 (Supplementary Materials).
Scheme 1. Reagents and conditions: (
) K2CO3, MeOH, RT, 1 h; (
(M = Te, Se), DMF, 100 ◦C, o/n.
a
) HC
≡
CR, PdCl2(PPh3)2, CuI, piperidine,◦toluene, 45 ◦C, 4 h;
(
b
c) I-R, PdCl2(PPh3)2, CuI, piperidine, toluene, 45 C, 4 h; (d) NaHM
Table 1. Synthesized benzo[b]tellurophen, benzo[b]selenophen, and benzo[b]furan derivatives and
their inhibitory activities on histone H3 lysine 9 demethylase (KDM4).
Cpds
1a
Structure
Activity *
Cpds
1j
Structure
Activity *
1.03
1.06
1b
1c
1.00
1.79
1k
1l
0.98
0.97
1d
1e
1.06
1.03
1m
1n
0.90
1.04

Int. J. Mol. Sci. 2019, 20, 5908
4 of 14
Table 1. Cont.
Activity * Cpds
Cpds
1f
Structure
Structure
Activity *
1.30
0.88
1o
0.86
1g
1p
1q
0.96
1.13
1h
1i
1.29
1.63
* Activity is noted as the relative H3K9me3 level normalized to histone H3 levels compared to NC group.
2.2. Biological Evaluation
2.2.1. Effects of Compounds on Histone Methylation in cervical cancer HeLa Cells
All the prepared compounds were tested for inhibition of KDM4 in HeLa cells by immunoblot
analysis of acid-extracted histones using antibodies specific for methylated histone H3 lysine 9 (H3K9me)
(a substrate of KDM4) and in vitro histone demethylase assay. Human cervical cancer HeLa cells
were cultured with 10 µM of 15 different benzo[b]tellurophen, benzo[b]selenophen, or benzo[b]furan
derivatives for 24 h (Table 1) and we analyzed the methylated levels of H3K9 by immunoblotting.
Levels of trimethylated H3K9 (H3K9me3) were semi-quantified relative to histone H3; the levels in the
negative control (NC) groups were set to 1, and a >1.5-fold increase in H3K9me3 level was considered to
indicate a significant inhibitory effect for KDM4. Based on immunoblot analysis, Benzo[b]tellurophene
compounds 1c and 1i inhibited KDM4 activity as identified by increased H3K9me3 level compared to
NC even when considering the effects of DMSO (Figure 2 and Table 1). The carbamate compound 1c
especially showed much significant inhibition, whereas the corresponding selenium compound 1m
and oxygen compound 1q did not display any inhibitory activity toward KDM4 (Table 1). Although
the exact mechanisms of action of compound 1c or 1i are not clear, our present results show that the
benzo[b]tellurophene structure is critical to inhibition of KDM4 activity.
To date, two possible mechanisms of KDM inhibition are known. Inhibitors adhere to the binding
site of oxo-glutarate or the zinc binding region of KDMs. Both of these inhibition mechanisms are
mediated by nonbonding interactions with the metal (Fe or Zn) coexisting with KDMs. Oxygen,
selenium, and tellurium have six valence electrons, but tellurium has the lowest electronegativity of
these. For this reason, tellurium is more easily coordinated with metals. Nitrogen or oxygen atoms of
carbamate groups also can interact with metals. Tellurium and the carbamate moiety of compound
1c might interact with metals by bi- or tri-dentate modes. Thus, they could be stronger inhibitors of
KDM4 than 1a. From the result that other carbamate derivatives (1d–g) show weak inhibition activity,
we conclude that the tertiary-butyl group of 1c might be the most effective structure for inhibiting
KDM4. A partial charge between carbon- and a halogen (δ+ −) has the potential to interact with
-δ
polar atoms near the molecule. The KDM4 inhibition activity of compound 1i may be due to an
additional interaction between the ortho-trifluoromethyl substitution of the phenyl group and polar
residues of the protein. However, the compound with a meta-chloro substituted phenyl ring (1k)
showed no different activity than the compound with a simple phenyl ring (1a). Compounds (1b,h,j),
which have heteroatoms at a three-bond distance from tellurium that could interact with metal, did

Int. J. Mol. Sci. 2019, 20, 5908
5 of 14
not sufficiently inhibit KDM4. Therefore, we have selected 1c as the most potent candidate through the
above considerations.
Figure 2. Effects of various compounds on histone H3 lysine 9 (H3K9) methylation. Cervical
cancer HeLa cells were treated with negative control (NC), 0.1% DMSO, or 10 µM of the indicated
compounds. After 24 h, histones extracted from HeLa cells were resolved on a 15% SDS-polyacrylamide
gel. Immunoblotting was performed with anti-pan histone H3, anti-H3K9me3, anti-H3K9me2, and
anti-H3K3me1 antibodies. Levels of H3K9me were semi-quantified relative to H3, with the levels in
the NC groups set at 1. Histone H3 is shown as an equal loading control.
To further confirm the potency and specificity of compound 1c as a KDM4 inhibitor, we tested
other histone modifications as well as histone H3 lysine 9 (H3K9) methylation by immunoblot analysis.
Treatment of HeLa cells with 1c (10 µM) led to a substantial increase in global H3K9me3 levels, which
signifies the accumulation of methylated lysine by inhibition of the demethylation process of KDM4
(Figure 3A). We also tested the expression levels of four different KDM4 (KDM4A–D) proteins in
HeLa cells (Figure 3B). Levels of monomethylated and dimethylated H3K9 (H3K9me2/me1), which are
specifically demethylated by KDM3, were not increased by 1c, allowing us to conclude that 1c is not an
inhibitor of KDM3. Compound 1c did not influence the methylation of other lysine residues such as
K27, K4, or K36 of histone H3. Because KDM6, KDM5, and KDM2/7 demethylate histones H3K27,
H3K4, and H3K36, respectively, this result suggests that 1c does not inhibit KDM6, KDM5, or KDM2/7.
In addition, 1c did not affect histone H3 acetylation by histone acetyltransferase (Ace-H3 in Figure 3A).
This finding indicates that 1c can selectively inhibit KDM4 activity.
2.2.2. KDM4 Inhibitory Assays
To directly monitor the potency of 1c against KDM4, we tested its effect on the demethylase activity
of recombinant KDM4A on a H3K9me3 peptide using a formaldehyde dehydrogenase (FDH)-coupled
assay. Consistent with immunoblotting, the compound 1c demonstrated concentration-dependent
inhibition of KDM4 enzymatic activity with an IC50 of 30.24
These results strongly imply that 1c can specifically inhibit histone H3 lysine 9 demethylase KDM4.
±
4.60 µM, as illustrated in Figure 3C.

Int. J. Mol. Sci. 2019, 20, 5908
6 of 14
Figure 3. Compound 1c inhibits demethylase activity of KDM4. (A) HeLa cells were treated with NC,
0.1% DMSO (control) or 10 µM of 1c, as indicated. After 24 h, histones extracted from HeLa cells were
resolved on a 15% SDS-polyacrylamide gel. Immunoblotting was performed with anti-pan histone
H3, anti-H3K9me3, anti-H3K9me2, anti-H3K3me1, anti-H3K27me3, anti-H3K4me3, anti-H3K36me3,
and anti- ace-H3 antibodies. Levels of H3K9me and ace-H3 were semi-quantified relative to H3
and the levels in the DMSO groups were set at 1. Histone H3 is shown as an equal loading control.
(B) Expression levels of KDM4 proteins in HeLa cells. (C) Inhibitory data (IC50) of KDM4 demethylation
activity by 1c. Formaldehyde dehydrogenase (FDH)-coupled demethylase assay was used for IC50
determination. Data are expressed as mean ± SD from three independent experiments.
2.2.3. Effects of 1c on Cytotoxicity of Human Cervical HeLa and Colon LoVo Cancer Cells
As KDM4 is deregulated in cancer, we examined the anticancer potential of 1c. To determine the
specificity of 1c for cancer cells, we conducted cell viability assays in cervical cancer HeLa cells, colon
cancer LoVo cells, and normal human foreskin fibroblast BJ cells using MTT assays. Compound 1c
decreased the viability of HeLa and LoVo cells but not BJ cells (Figure 4). This finding suggests that
KDM4-selective inhibition by compound 1c only induces cell death in transformed but not normal cells.

Int. J. Mol. Sci. 2019, 20, 5908
7 of 14
Figure 4. Effects of 1c on cell viability. BJ, HeLa, and LoVo cells were cultured with of 0.1% DMSO
(control) or 10 M 1c for 72 h, and MTT assays were performed to measure cell viability. Data are
µ
expressed as mean
DMSO control.
±
SD from three independent experiments. ** p < 0.01 and *** p < 0.001 vs. the
3. Materials and Methods
3.1. Chemistry
General Remarks. All reagents were purchased from commercial sources and used as received
without purification. Reactions were monitored by thin-layer chromatography on 0.25 mm silica
plate (F-254) visualizing with UV light (254 nm) and KMnO4 solution. Flash chromatography was
performed using silica gel (230–400 mesh) with hexanes and EtOAc as eluent. 1H and 13C NMR
spectra were recorded on Agilent 400 MHz NMR spectrometer. Chemical shifts (δ) are reported in
parts per million (ppm), and coupling constants (J) are expressed in hertz (Hz). IR spectra were
recorded on FT-IR using diamond attenuated total reflection (ATR) technique and were described as
wavenumbers (cm−1). High resolution mass spectrometry (HRMS) were measured with electrospray
ionization (ESI) and quadrupole time of flight (Q-TOF) mass analyzer. Physicochemical properties
were generated by CS ChemProp. Cellular fluorescence was measured with multi-plate reader
(Tecan, Männedorf, Switzerland) at 490 nm/520 nm. NMR spectra of compound 1a-1q is provided as
supplementary materials.
3.1.1. General Procedure for the Preparation of Compounds 2a, 2b, and 3
To a solution of acetylene compounds (3.6 mmol) in toluene (20 mL), piperidine (4 mL),
1-bromo-2-iodobenzene (1.27 g, 3.6 mmol), PdCl2(Ph3P)2 (127 mg, 0.2 mmol), and CuI (35 mg,
0.2 mmol) were added, which was then stirred at 45 ◦C for 4 hours. After the mixture was cool, water
was added and the resulting mixture was extracted with methylene chloride. The combined organic
layers were washed with water and brine, then dried over MgSO4, filtered, and concentrated in vacuo.
The residue was purified by flash column chromatography using n-hexane: ethyl acetate = 5:1 as
the eluent.

Int. J. Mol. Sci. 2019, 20, 5908
8 of 14
1
The 1-Bromo-2-phenylethynylbenzene (2a). Yield: 98%; IR (neat, cm−1) 3055, 2219; H NMR
(400 MHz, CDCl3) 7.64–7.50 (m, 3H), 7.39–7.32 (m, 1H), 7.29 (t, J = 7.6 Hz, 1H), 7.17 (t, J = 7.6 Hz, 1H);
13C NMR (100 MHz, CDCl3)
δ
δ
133.2, 132.4, 131.7, 129.3, 128.6, 128.3, 127.0, 125.6, 125.4, 122.9, 93.9, 88.0.
The 3-(2-Bromophenyl)prop-2-yn-1-ol (2b). Yield: 61%; IR (neat, cm−1) 3324, 2232; H NMR
1
(400 MHz, CDCl3)
δ 7.56 (d, J = 8.0 Hz, 1H), 7.45 (d, J = 7.6 Hz, 1H), 7.24 (t, J = 7.6 Hz, 1H), 7.15 (t,
J = 7.6 Hz, 1H), 4.54 (s, 2H), 2.34 (s, OH); 13C NMR (100 MHz, CDCl3)
δ 133.6, 132.4, 129.6, 127.0, 125.4,
124.7, 91.9, 84.1, 51.6.
The 2-Bromophenylethynyltrimethylsilane (3). Yield: 92%; IR (neat, cm−1) 2958, 2161, 1464, 1248;
1H NMR (400 MHz, CDCl3)
δ 7.56 (dd, J = 8.0, 1.2 Hz, 1H), 7.48 (dd, J = 7.6, 1.6 Hz, 1H), 7.23 (td, J = 7.6,
1.2 Hz, 1H), 7.15 (td, J = 7.6, 1.6 Hz, 1H), 0.28 (s, 9H); 13C NMR (100 MHz, CDCl3)
δ 133.6, 132.3, 129.5,
126.9, 125.7, 125.2, 103.0, 99.6, 0.2.
3.1.2. General Procedure for the Preparation of Compound 2c–2g
Chlorocarbonate derivatives (4.4 mmol, 2c: di-tert-butyl dicarbonate) were slowly added to a
solution of propagyl amine (200 mg, 3.6 mmol) in piperidine (4 mL) at 0 ◦C. The reaction mixture was
stirred at room temperature for 3 hours. Toluene (20 mL), 1-bromo-2-iodobenzene (1.27 g, 3.6 mmol),
PdCl2(Ph3P)2 (127 mg, 0.2 mmol), and CuI (35 mg, 0.2 mmol) were added to the resulting mixture,
which was then stirred at 45 ◦C for 4 hours. After the mixture was cooled, water was added and the
resulting mixture was extracted with methylene chloride. The combined organic layers were washed
with water and brine, then dried over MgSO4, filtered, and concentrated in vacuo. The residue was
purified by flash column chromatography using n-hexane: ethyl acetate = 5:1 as the eluent.
The tert-Butyl 3-(2-bromophenyl)prop-2-ynylcarbamate (2c). Yield: 92%; IR (neat, cm−1) 3345,
2969, 1677, 1518; 1H NMR (400 MHz, CDCl3)
δ 7.56 (dd, J = 8.0, 0.2 Hz, 1H), 7.44 (dd, J = 7.6, 1.6 Hz,
1H), 7.24 (td, J = 7.6, 1.0 Hz, 1H), 7.15 (td, J = 7.8, 1.6 Hz, 1H), 4.86 (NH, 1H), 4.20 (d, J = 4.4 Hz, 2H),
1.47 (s, 9H); 13C NMR (100 MHz, CDCl3)
31.3, 28.4.
δ 155.3, 133.5, 132.3, 129.5, 127.0, 125.5, 124.8, 90.1, 81.7, 80.0,
Methyl 3-(2-bromophenyl)prop-2-ynylcarbamate (2d). Yield: 93 %; IR (neat, cm−1) 3319, 2952,
1698; 1H NMR (400 MHz, CDCl3)
δ 7.56 (d, J = 8.0 Hz, 1H), 7.44 (d, J = 7.6 Hz, 1H), 7.25 (t, J = 8.0 Hz,
1H), 7.16 (t, J = 7.6 Hz, 1H), 5.05 (s, NH), 4.27 (d, J = 4.8 Hz, 2H), 3.72 (s, 3H); 13C NMR (100 MHz,
CDCl3) δ 156.5, 133.5, 132.4, 129.6, 127.0, 125.5, 124.6, 89.7, 81.9, 52.5, 31.8.
Ethyl 3-(2-bromophenyl)prop-2-ynylcarbamate (2e). Yield: 95%; IR (neat, cm−1) 3317, 2979, 1694,
1
1510, 1468; H NMR (400 MHz, CDCl3) 7.5 (d, J = 8.0 Hz, 1H), 7.43 (d, J = 7.6, 1.2 Hz, 1H), 7.22 (t,
J = 7.6 Hz, 1H), 7.14 (t, J = 8.0, 1.6 Hz, 1H), 5.26 (s, NH), 4.26 (d, J = 4.8 Hz, 2H), 4.17 (d, J = 6.8 Hz, 2H),
1.25 (t, J = 6.8 Hz, 3H); 13C NMR (100 MHz, CDCl3)
δ 156.2, 133.5, 132.3, 129.5, 127.0, 125.4, 124.7, 89.9,
81.7, 61.2, 31.6, 14.6.
Isobutyl 3-(2-bromophenyl)prop-2-ynylcarbamate (2f). Yield: 92%; IR (neat, cm−1) 3323, 2959,
1697, 1509, 1467; 1H NMR (400 MHz, CDCl3)
δ 7.54 (d, J = 8.0 Hz, 1H), 7.43 (d, J = 7.6 Hz, 1H), 7.22 (t,
J = 7.6 Hz, 1H), 7.14 (t, J = 7.6 Hz, 1H), 5.29 (s, NH), 4.26 (d, J = 4.8 Hz, 2H), 3.89 (d, J = 6.6 Hz, 2H), 1.91
(sep, J = 6.6 Hz, 1H), 0.92 (d, J = 6.6 Hz, 6H); 13C NMR (100 MHz, CDCl3)
δ 156.4, 133.5, 132.3, 129.5,
126.9, 125.4, 124.7, 90.0, 81.3, 71.4, 31.7, 28.0, 19.0.
Neopentyl 3-(2-bromophenyl)prop-2-ynylcarbamate (2g). Yield: 97%; IR (neat, cm−1) 3303, 2957,
1
1694, 1515; H NMR (400 MHz, CDCl3)
δ 7.57 (d, J = 8.0 Hz, 1H), 7.45 (d, J = 7.6 Hz, 1H), 7.24 (td,
J = 7.6, 0.8 Hz, 1H), 7.17 (td, J = 8.0, 1.6 Hz, 1H), 4.97 (s, NH), 4.28 (d, J = 5.0 Hz, 2H), 3.81 (s, 2H), 0.94
(s, 9H); 13C NMR (100 MHz, CDCl3)
31.5, 26.4.
δ 156.4, 133.5, 132.4, 129.6, 127.0, 125.5, 124.7, 89.8, 81.9, 74.7, 31.7,
3.1.3. Procedure for the Preparation of Compound 4
The 1-Bromo-2-ethynylbenzene (4). K2CO3 (7.0 g, 51.01 mmol) was added to a solution of
compound 3 (4.3 g, 17.00 mmol) in MeOH (20 mL). The reaction mixture was stirred at room
temperature for 1 hour, then poured into water and extracted with ethyl acetate. The organic layers

Int. J. Mol. Sci. 2019, 20, 5908
9 of 14
were washed with brine, dried over MgSO4, filtered, and concentrated in vacuo (2.9 g, 15.9 mmol).
Yield: 94%; IR (neat, cm−1) 3289, 2111; 1H NMR (400 MHz, CDCl3)
δ 7.59 (dd, J = 8.0, 1.1 Hz, 1H), 7.53
(dd, J = 7.6, 1.6 Hz, 1H), 7.27 (td, J = 7.6, 1.6 Hz, 1H), 7.20 (td, J = 7.6, 1.6 Hz, 1H), 3.38 (s, 1H); 13C NMR
(100 MHz, CDCl3) δ 134.1, 132.5, 129.9, 126.9, 125.5, 124.3, 81.9, 81.8.
3.1.4. General Procedure for the Preparation of Compound 2h–2k
Piperidine (2 mL), PdCl2(Ph3P)2 (35 mg, 0.05 mmol), and CuI (9.5 mg, 0.05 mmol) were added to
a mixture of 1-Bromo-2-ethynylbenzene (4) (300 mg, 1.7 mmol) and iodoaryl compounds (1.1 mmol) in
toluene (10 mL). The reaction mixture was stirred at 45 ◦C for 4 hours. After the mixture was cooled,
water was added and the resulting mixture was extracted with methylene chloride. The combined
organic layers were washed with water and brine, then dried over MgSO4, filtered, and concentrated
in vacuo. The residue was purified by flash column chromatography using n-hexane as the eluent.
The 2-(2-Bromophenylethynyl)thiophene (2h). Yield: 93%; IR (neat, cm−1) 2205, 1419, 1214, 1026;
1H NMR (400 MHz, CDCl3)
δ 7.58 (dd, J = 8.0, 1.0 Hz, 1H), 7.51 (dd, J = 7.7, 1.6 Hz, 1H), 7.31 (ddd,
J = 6.2, 4.4, 1.0 Hz, 2H), 7.26 (td, J = 7.6, 1.2 Hz, 1H), 7.15 (td, J = 7.6, 1.6 Hz, 1H), 7.00 (dd, J = 5.2,
1.6 Hz, 1H); 13C NMR (100 MHz, CDCl3)
122.8, 91.7, 87.2.
δ 133.1, 132.5, 132.5, 129.5, 127.9, 127.2, 127.1, 125.3, 125.2,
The 1-Bromo-2-(3-trifluoromethylphenylethynyl)benzene (2i). Yield: 89%; IR (neat, cm−1) 1713,
1338, 1128; 1H NMR (400 MHz, CDCl3)
(dd, J = 7.6, 1.6 Hz, 1H), 7.47 (t, J = 7.7 Hz, 1H), 7.30 (td, J = 7.6, 1.2 Hz, 1H), 7.20 (td, J = 7.8, 1.6 Hz,
1H); 13C NMR (100 MHz, CDCl3)
134.8 (d, J = 4.8), 133.4, 132.5, 131.0 (q, J = 32.4), 129.9, 128.9, 128.4
δ 7.82 (s, 1H), 7.73 (d, J = 7.6 Hz, 1H), 7.65–7.57 (m, 2H), 7.56
δ
(q, J = 3.8), 127.1, 125.7, 125.1 (q, J = 3.8), 124.8, 123.9, 123.7 (q, J = 271.0), 92.1, 89.4.
The 2-(2-Bromophenylethynyl)pyridine (2J). Yield: 94%; IR (neat, cm−1) 2920, 2224, 1578, 1472; 1H
NMR (400 MHz, CDCl3)
δ
8.63 (s, 1H), 7.69 (t, J = 7.6 Hz, 1H), 7.65–7.56 (m, 3H), 7.33-7.18 (m, 3H);
150.1, 143.1, 136.2, 133.8, 132.5, 130.1, 127.5, 127.1, 125.9, 124.5, 123.0,
13C NMR (100 MHz, CDCl3)
δ
92.7, 87.6.
The 1-Bromo-2-(4-chlorophenylethynyl)benzene (2k). Yield: 90%; IR (neat, cm−1) 1486, 1085; 1H
NMR (400 MHz, CDCl3)
δ 7.61 (dd, J = 8.01, 0.8 Hz, 1H), 7.54 (dd, J = 7.6, 1.6 Hz, 1H), 7.5 (d, J = 8.6 Hz,
2H), 7.34 (d, J = 8.6 Hz, 2H), 7.29 (td, J = 7.6, 1.2 Hz, 1H), 7.19 (td, J = 7.86, 1.2 Hz, 1H); 13C NMR
(100 MHz, CDCl3) δ 134.7, 133.2, 132.9, 132.5, 129.6, 128.7, 127.1, 125.6, 125.1, 121.4, 92.7, 88.9.
3.1.5. General Procedure for the Preparation of Benzo[b]tellurophenes and Benzo[b]selenophenes (1a−1o)
A solution of NaHTe (0.6 mmol) which was freshly prepared from tellurium powder (47 mg) and
NaBH4 (22 mg) in DMF (0.5 mL) was added to a solution of compound 2 (0.4 mmol) in DMF (4 mL) at
100 ◦C. The reaction mixture was stirred at 100 ◦C overnight. After addition of water, the aqueous
mixture was extracted with methylene chloride. The organic layers were washed with water and brine,
then dried over MgSO4, filtered, and concentrated in vacuo. The residue was purified by flash column
chromatography using n-hexane or n-hexane /ethyl acetate as the eluent.
1
The 2-Phenylbenzo[b]tellurophene (1a) [27]. Yield: 50%; IR (neat, cm−1) 1482, 1428; H NMR
(400 MHz, CDCl3) δ 7.99 (phenyl, s, 1H), 7.90 (ArH, d, J = 7.8 Hz, 1H), 7.80 (ArH, d, J = 7.8 Hz, 1H), 7.54
(ArH, d, J = 7.4 Hz, 2H), 7.40–7.28 (phenyl, m, 4H), 7.13 (ArH, t, J = 7.4 Hz, 1H); 13C NMR (100 MHz,
CDCl3) δ 149.1, 142.5, 139.7, 132.2, 131.9, 131.8, 129.0, 128.1, 127.7, 127.5, 125.6, 124.5.
Benzo[b]tellurophen-2-ylmethanol (1b). Yield: 50%; IR (neat, cm−1) 3224, 2918, 2848, 1444; 1H
NMR (400 MHz, CDCl3)
δ 7.89 (ArH, d, J = 7.6 Hz, 1H), 7.70 (ArH, d, J = 7.6 Hz, 1H), 7.63 (tellurophene,
s, 1H), 7.34 (ArH, td, J = 7.6, 1.2, 1H), 7.10 (ArH, td, J = 7.6, 1.2, 1H), 4.87 (CH2, d, J = 0.8 Hz, 2H),
2.37 (s, br OH); 13C NMR (100 MHz, CDCl3)
δ 148.0, 146.2, 132.1, 132.0, 131.3, 127.5, 125.3, 124.1, 65.9;
HRMS(ESI): m/z 261.9622 [M+H]+ (calcd for C9H9OTe+ 261.9637).
The tert-Butyl benzo[b]tellurophen-2-ylmethylcarbamate (1c). Yield: 56%; IR (neat, cm−1) 3298,
1
2970, 1661, 1523, 1288; H NMR (400 MHz, CDCl3)
δ 7.83 (ArH, d, J = 7.8 Hz, 1H), 7.66 (ArH, d,
J = 7.8 Hz, 1H), 7.55 (tellurophene, s, 1H), 7.31 (ArH, t, J = 7.6 Hz, 1H), 7.06 (ArH, t, J = 7.6 Hz, 1H),

Int. J. Mol. Sci. 2019, 20, 5908
10 of 14
5.20 (s, NH), 4.43 (CH2, d, J = 6.0 Hz, 2H), 1.48 (3XCH3, s, 9H); 13C NMR (100 MHz, CDCl3)
δ 156.1,
147.2, 141.9, 133.6, 133.3, 131.9, 127.3, 125.2, 124.3, 80.1, 46.4, 28.5; HRMS(ESI): m/z 384.0217 [M+Na]+
(calcd for C14H18NNaO2Te+ 384.0214).
Methyl benzo[b]tellurophen-2-ylmethylcarbamate (1d). Yield: 62%; IR (neat, cm−1) 3334, 2951,
1667, 1521, 1260; 1H NMR (400 MHz, CDCl3)
δ δ 7.84 (ArH, d, J = 7.8 Hz,
1H NMR (400 MHz, CDCl3)
1H), 7.67 (ArH, d, J = 7.8 Hz, 1H), 7.59 (tellurophene, s, 1H), 7.32 (ArH, t, J = 7.6 Hz, 1H), 7.09 (ArH,
t, J = 7.6 Hz, 1H), 5.33 (s, NH), 4.52 (CH2, d, J = 5.6 Hz, 2H), 3.71 (CH3, s, 3H); 13C NMR (100 MHz,
CDCl3)
δ 157.0, 147.3, 141.1, 133.9, 133.0, 132.0, 127.4, 125.3, 124.4, 52.5, 46.7; HRMS(ESI): m/z 341.9744
[M+Na]+ (calcd for C14H11NNaO2Te+ 342.9742).
Ethyl benzo[b]tellurophen-2-ylmethylcarbamate (1e). Yield: 49%; IR (neat, cm−1) 3318, 2914, 1673,
1522, 1253; 1H NMR (400 MHz, CDCl3)
δ 7.84 (ArH, d, J = 7.8 Hz, 1H), 7.68 (ArH, d, J = 7.8 Hz, 1H),
7.59 (tellurophene, s, 1H), 7.32 (ArH, t, J = 7.6 Hz, 1H), 7.09 (ArH, t, J = 7.6 Hz, 1H), 5.30 (s, 1H), 4.51
(CH2, d, J = 6.2 Hz, 2H), 4.17 (CH2, q, J = 7.0 Hz, 2H), 1.26 (CH2, t, J = 7.0 Hz, 3H); 13C NMR (100 MHz,
CDCl3)
δ 156.7, 147.2, 141.3, 133.8, 133.1, 132.0, 127.3, 125.3, 124.4, 61.3, 46.6, 14.7.; HRMS(ESI): m/z
355.9916 [M+Na]+ (calcd for C12H13NNaO2Te+ 355.9906).
Isobutyl benzo[b]tellurophen-2-ylmethylcarbamate (1f). Yield: 64%; IR (neat, cm−1) 3364, 1678,
1513, 1246, 1163; 1H NMR (400 MHz, CDCl3)
δ 7.84 (ArH, d, J = 7.8 Hz, 1H), 7.68 (ArH, d, J = 7.8 Hz,
1H), 7.60 (tellurophene, s, 1H), 7.32 (ArH, t, J = 7.6 Hz, 1H), 7.09 (ArH, t, J = 7.6 Hz, 1H), 5.31 (NH, 1H),
4.52 (CH2, d, J = 6.2 Hz, 2H), 3.90 (CH2, d, J = 6.6 Hz, 2H), 1.93 (CH, sep, 6.6 Hz, 1H), 0.92 (2XCH3, d,
J = 6.6 Hz, 6H); 13C NMR (100 MHz, CDCl3)
δ 156.9, 147.2, 141.3, 133.8, 133.1, 132.0, 127.3, 125.3, 124.4,
71.5, 46.6, 28.0, 19.1; HRMS(ESI): m/z 384.0208 [M+Na]+ (calcd for C14H17NNaO2Te+ 384.0214).
Neopentyl benzo[b]tellurophen-2-ylmethylcarbamate (1g). Yield: 71%; IR (neat, cm−1) 3296, 2955,
1667, 1533; 1H NMR (400 MHz, CDCl3)
δ
7.86 (ArH, d, J = 7.8 Hz, 1H), 7.70 (ArH, d, J = 7.8 Hz, 1H),
7.63 (tellurophene, s, 1H), 7.33 (ArH, t, J = 7.6 Hz, 1H), 7.10 (ArH, t, J = 7.6 Hz, 1H), 5.27 (NH, 1H),
4.56 (CH2, d, J = 6.2 Hz, 2H), 3.84 (CH2, s, 2H), 0.94 (2XCH3, s, 9H); 13C NMR (100 MHz, CDCl3)
δ
156.9, 147.2, 141.2, 133.8, 133.1, 131.9, 127.3, 125.2, 124.4, 74.6, 46.6, 31.5, 26.4; HRMS(ESI): m/z 378.0372
[M+Na]+ (calcd for C15H19NNaO2Te+ 378.0376).
The 2-Benzo[b]tellurophen-2-ylthiophene (1h). Yield: 54%; IR (neat, cm−1)1580,1497; 1H NMR
(400 MHz, CDCl3)
δ 7.86–7.81 (m, 2H), 7.73 (ArH, d, J = 7.8 Hz, 1H), 7.34 (ArH, t, J = 7.5 Hz, 1H),
7.26–7.23 (thiophene, m, 1H), 7.11 (ArH, t, J = 7.6 Hz, 1H), 7.05(thiophene, d, J = 2.8 Hz, 1H), 7.00
(thiophene, t, J = 3.9 Hz, 1H); 13C NMR (100 MHz, CDCl3)
δ 148.5, 143.6, 132.0, 131.8, 131.8, 131.7, 127.8,
127.5, 126.5, 125.7, 125.4, 124.6; HRMS(ESI): m/z 311.9402 [M+H]+ (calcd for C12H8STe+ 313.9409).
The 2,3-Trifluoromethylphenylbenzo[b]tellurophene (1i). Yield: 40%; IR (neat, cm−1) 132, 1171,
1110; 1H NMR (400 MHz, CDCl3)
δ 8.02 (phenyl, s, 1H), 7.90 (ArH, d, J = 7.8 Hz, 1H), 7.82 (ArH, d,
J = 7.8 Hz, 1H), 7.77 (tellurophene, s, 1H), 7.65 (phenyl, d, J = 7.6 Hz, 1H), 7.56 (phenyl, d, J = 7.6 Hz,
1H), 7.48 (phenyl, t, J = 7.6 Hz, 1H), 7.40 (t, J = 7.6 Hz, 1H), 7.16 (t, J = 7.6 Hz, 1H); 13C NMR (100 MHz,
CDCl3) δ 148.8, 141.0, 140.1, 133.2, 132.7, 131.9, 131.4 (q, J = 31.2 Hz), 130.9, 129.5, 128.1, 125.8, 125.0,
124.5 (q, J = 3.8 Hz), 123.9 (q, J = 271.0Hz), 123.7 (q, J = 3.8 Hz); HRMS(ESI): m/z 375.9791 [M+H]+
(calcd for C15H10F3Te+ 376.9797).
The 2-Benzo[b]tellurophen-2-ylpyridine (1J). Yield: 40%; IR (neat, cm−1) 2919, 1580, 1455, 1426;
1H NMR (400 MHz, CDCl3)
δ
8.48 (pyridine, d, J = 2.4 Hz 1H), 8.30 (tellurophene, s, 1H), 7.92 (ArH,
d, J = 7.8 Hz, 1H), 7.84–7.77 (m, 2H), 7.67 (pyridine, t, J = 7.6 Hz, 1H), 7.35 (ArH, t, J = 7.6 Hz, 1H),
7.19–7.10 (m, 2H); 13C NMR (100 MHz, CDCl3)
δ 156.4, 149.8, 146.6, 136.3, 133.5, 132.2, 131.6, 128.3,
125.3, 124.9, 122.6, 116.9; HRMS(ESI): m/z 309.9870 [M+H]+ (calcd for C13H10NTe+ 309.9875).
The 2-(4-Chlorophenyl)benzo[b]tellurophene (1k) [27]. Yield: 41%; IR (neat, cm−1) 1091; 1H NMR
(400 MHz, CDCl3)
1H), 7.46–7.40 (m, 2H), 7.40–7.29 (m, 3H), 7.12 (ArH, td, J = 7.9, 1.2 Hz, 1H); 13C NMR (100 MHz,
CDCl3) 149.0, 140.7, 138.3, 133.9, 132.4, 132.4, 131.9, 129.0, 128.6, 127.86, 125.7, 124.7; HRMS(ESI): m/z
341.9529 [M+H]+ (calcd for C14H10ClTe+ 342.9533).
δ 7.93 (tellurophene, s, 1H), 7.87 (ArH, d, J = 7.8 Hz, 1H), 7.78 (ArH, d, J = 7.8 Hz,
δ

Int. J. Mol. Sci. 2019, 20, 5908
11 of 14
The 2-Phenylbenzo[b]selenophene (1l). Yield: 63%; IR (neat, cm−1) 1442, 926; 1H NMR (400 MHz,
CDCl3) 7.85 (ArH, d, J = 8.0 Hz, 1H), 7.76 (ArH, d, J = 7.8 Hz, 1H), 7.69 (selenophene, s, 1H), 7.63 (ArH,
d, J = 7.6 Hz, 2H), 7.43–7.35 (m, 2H), 7.36–7.28 (m, 2H), 7.23 (ArH, t, J = 7.4 Hz, 1H); 13C NMR (100 MHz,
δ
CDCl3)
δ 147.7, 143.3, 140.9, 136.2, 128.9, 128.3, 126.9, 125.4, 125.4, 124.8, 124.5, 123.1; HRMS(ESI): m/z
259.0020 [M+H]+ (calcd for C14H11Se+ 259.0026).
The tert-Butyl benzo[b]selenophen-2-ylmethylcarbamate (1m). Yield: 59%; IR (neat, cm−1) 3416,
2976, 1681, 1499, 1158; H NMR (400 MHz, CDCl3)
1
δ 7.83 (ArH, d, J = 8.0 Hz, 1H), 7.68 (ArH, d,
J = 7.8 Hz, 1H), 7.37–7.23 (m, 2H), 7.22 (ArH, t, J = 7.6 Hz, 1H), 5.01 (s, NH), 4.56 (CH2, d, J = 5.2 Hz,
2H), 1.48 (3XCH3, s, 9H); 13C NMR (100 MHz, CDCl3)
δ 155.6, 147.1, 141.8, 141.4, 125.5, 125.2, 125.0,
124.6, 124.4, 79.9, 42.6, 28.4; HRMS(ESI): m/z 334.0312 [M+Na]+ (calcd for C14H17NNaO2Se+ 334.0317).
1
The 2-Benzo[b]selenophen-2-ylpyridine (1n). Yield: 23%; IR (neat, cm−1) 2919, 1457, 1426; H
NMR (400 MHz, CDCl3)
δ 8.58 (pyridine, d, J = 4.8 Hz, 1H), 7.97 (s, 1H), 7.90 (ArH, d, J = 8.0 Hz, 1H),
7.82–7.76 (m, 2H), 7.69 (ArH, td, J = 7.6, 1.6 Hz, 1H), 7.29–7.24 (m, 1H), 7.17 (ArH, ddd, J = 7.2, 5.2,
0.8, 1H); 13C NMR (100 MHz, CDCl3)
δ 153.9, 149.7, 149.0, 143.3, 142.0, 136.4, 125.9, 125.7, 125.1, 124.7,
124.1, 122.6, 118.6; HRMS(ESI): m/z 259.9969 [M+H]+ (calcd for C13H9NSe+ 259.9973).
The 2-(4-Chlorophenyl)benzo[b]selenophene (1o). Yield: 70%; IR (neat, cm−1) 2918, 1091; 1H NMR
(400 MHz, CDCl3)
δ 7.86 (ArH, d, J = 8.0 Hz, 1H), 7.76 (ArH, d, J = 8.0 Hz, 1H), 7.67 (selenophene, s,
1H), 7.55 (phenyl, d, J = 8.6 Hz, 2H), 7.39–7.33 (m, 3H), 7.29–7.22 (m, 1H); 13C NMR (100 MHz, CDCl3)
δ
146.1, 143.1, 141.0, 134.7, 134.1, 129.1, 128.0, 125.5, 125.4, 125.0, 124.7, 123.5; HRMS(ESI): m/z 291.9632
[M+H]+ (calcd for C14H10ClSe+ 292.9636).
3.1.6. Procedure for the Preparation of Benzo[b]furans (1p, 1q)
The 2-Phenylbenzofuran (1p). Ethynylbenzene (366 mg, 3.5 mmol), PdCl2(Ph3P)2 (123 mg,
0.2 mmol), and CuI (34 mg, 0.2 mmol) were added to a solution of 2-iodophenol (773 mg, 3.5 mmol) in
toluene (4 mL). The reaction mixture was stirred at 45 ◦C for 4 hours. After the mixture was cooled,
water was added and the resulting mixture was extracted with methylene chloride. The combined
organic layers were washed with water and brine, then dried over MgSO4, filtered, and concentrated
in vacuo. The residue was purified by flash column chromatography using n-hexane as the eluent.
Yield: 85%; IR (neat, cm−1) 1603, 1452; 1H NMR (400 MHz, CDCl3)
δ 7.86 (ArH, d, J = 8.0 Hz, 2H),
7.58 (ArH, d, J = 7.6 Hz, 1H), 7.52 (ArH, d, J = 8.0 Hz, 1H), 7.44 (ArH, t, J = 7.6 Hz, 2H), 7.35 (ArH, t,
J = 7.4 Hz, 1H), 7.30-7.19 (m, 2H), 7.02 (furan, s, 1H);13C NMR (100 MHz, CDCl3)
δ 155.9, 154.9, 130.5,
129.2, 128.8, 128.5, 124.9, 124.2, 122.9, 120.9, 111.2, 101.3.
The tert-Butyl benzofuran-2-ylmethylcarbamate (1q). Di-tert-butyl dicarbonate (362 mg,
1.66 mmol) was slowly added to a solution of propagyl amine (257 mg, 1.66 mmol) in piperidine
(4 mL) at 0 ◦C. After the reaction mixture was stirred at room temperature for 3 hours, water was
added to the mixture, and the resulting mixture was extracted with methylene chloride. The combined
organic layers were washed with water and brine, then dried over MgSO4, filtered, and concentrated in
vacuo. Without purification, the resulting mixture was dissolved with toluene (10 mL) and mixed with
piperidine (2 mL) 2-iodophenol (365 mg, 1.66 mmol), PdCl2(Ph3P)2 (58 mg, 0.08 mmol), and CuI (15 mg,
0.08 mmol) Then the reaction mixture was stirred at 45 ◦C for 4 hours. After the mixture was cooled,
water was added and the resulting mixture was extracted with methylene chloride. The combined
organic layers were washed with water and brine, then dried over MgSO4, filtered, and concentrated
in vacuo. The residue was purified by flash column chromatography using n-hexane: ethyl acetate =
6:1 as the eluent. Yield: 90%; IR (neat, cm−1) 3371, 2984, 1681, 1508, 1453; 1H NMR (400 MHz, CDCl3)
δ
7.51 (ArH, d, J = 7.6 Hz, 1H), 7.43 (ArH, d, J = 7.6 Hz, 1H), 7.25 (ArH, td, J = 7.3, 1.3 Hz, 1H), 7.20 (ArH,
td, J = 7.3, 0.8 Hz, 1H), 6.57 (furan, s, 1H), 5.20 (s, NH), 4.44 (CH2, d, J = 5.6 Hz, 2H), 1.47 (3XCH3, s,
9H); 13C NMR (100 MHz, CDCl3)
δ
155.7, 154.9, 154.9, 128.3, 124.0, 122.7, 120.9, 111.1, 103.6, 79.8, 38.2,
28.4; HRMS(ESI): m/z 247.1260 [M]+ (calcd for C14H17NO3+ 247.1208).

Int. J. Mol. Sci. 2019, 20, 5908
12 of 14
3.2. Biology
3.2.1. Acid Extraction of Histones
Acid extraction of histones was performed as described previously [28]. Briefly, HeLa cell pellets
were suspended in 10 volumes of PBS and centrifuged at 200 g for 10 min. Cells were then suspended
×
with five volumes of hypotonic lysis buffer (10 mM Tris-Cl (pH 8.0), 1.5 mM MgCl2, 1 mM KCl, 1 mM
DTT, and 1 mM phenylmethylsulfonyl fluoride) and 0.4 N H2SO4 at a final concentration of 0.2 M
and subsequently lysed on ice for 30 min. After centrifugation at 16,000
g for 10 min at 4 ◦C, the cell
×
supernatant fraction that contained acid-soluble proteins was retained. Trichloroacetic acid was added
to the supernatant up to 33% and the samples were incubated on ice overnight. Proteins were pelleted
◦
by centrifugation at 16,000
×
g for 10 min at 4 C and washed 4 times with ice cold acetone with
centrifugations at 16,000
×
g for 5 min at 4 ◦C. Each histone pellet was air-dried for 20 min at room
temperature and dissolved in an appropriate volume of ddH2O.
3.2.2. Western Blot Analysis
Acid extracted proteins were analyzed by sodium dodecyl sulfate-polyacrylamide gel
electrophoresis (SDS-PAGE)/immunoblotting with antibodies recognizing methylated histones
H3K9 and histone H3. Protein samples were separated along with molecular weight markers
(Bio-Rad, Hercules, CA, USA) in 15% polyacrylamide gels. Gels were transferred onto 0.45-µm
nitrocellulose membranes (Schleicher and Schuell). Species-specific immunoglobulin G-horseradish
peroxidase (IgG-HRP) secondary antibodies were purchased from Bio-Rad. Blots were developed
with chemiluminescent substrate (Amersham International, Buckinghamshire, England), and
autoradiography was performed utilizing X-OMAT film (Kodak, Rochester, NY, USA). The blots were
semi-quantified using FusionCapt software version 16.08a (Viber Lourmat Sté, Collégien, France).
3.2.3. Histone Demethylase Assay
Histone demethylase activity assay was performed according to the manufacturer’s instruction
(Cayman’s demethylase (JumonJi-type) activity assay kit, 700390) and used to determine demethylase
activity and to select potent inhibitors. All compounds were dissolved in dimethyl sulfoxide (DMSO)
at various concentrations and added to the mixture such that the final DMSO concentration was 1%.
All solutions were kept on ice until being mixed and incubated at 37 ◦C. Recombinant enzyme KDM4A,
cofactor mixture (2-oxoglutarate, ascorbate, Fe(II)), H3K9me3 peptide as substrate, and compound
were incubated for 60 min at 37 ◦C; the final volume was 50
and 10
L of detector were added to all of the wells and incubated for 15 min at 25 ◦C. The resulting
µL. Then, 40 µL of ammonium acetate
µ
fluorescent production was analyzed using an excitation wavelength 370 and an emission wavelength
470 nM. All data were processed with GraphPad Prism 5.0™.
3.2.4. MTT Assay
Cell viability was assessed by 3-(4,5-dimethylthiazol-2-yl)-2, 5-diphenyltetrazo-lium bromide
(MTT) assay. Briefly, 8
with a compound for 72 h. After adding 20
another 2 h. Supernatants were then removed and the formazan crystals were dissolved in 100
×
104 of cells were seeded into 96-well plates for 24 h, followed by incubation
µL/well of MTT solution, the cells were incubated for
µL/well
DMSO. The absorbance at 570/630 nm of each sample was measured using multimode microplate
reader (Teckan, Switzerland). Three independent triplicate experiments were performed.
3.2.5. Statistical Analysis
Statistical analyses were performed using GraphPad Prism software (GraphPad Software 5.0, Inc.,
La Jolla, CA, USA). All data are presented as the mean
±
SD from three independent experiments.

Int. J. Mol. Sci. 2019, 20, 5908
13 of 14
Statistical significances were determined by one-way analysis of variance with post hoc analysis using
Tukey’s multiple comparison test. p < 0.05 was considered to indicate a statistically significant difference.
4. Conclusions
In conclusion, benzo[b]tellurophene, benzo[b]selenophene, and benzo[b]furan compounds were
efficiently synthesized and evaluated for their histone demethylase inhibition activity. In particular,
carbamate derivatives of benzo[b]tellurophene are newly synthesized novel compounds, and novel
carbamate derivative compound 1c exhibited a specific KDM4 inhibitory activity, without affecting the
activity of other histone modifying enzymes. We also confirmed that compound 1c induced selective cell
death in cancer cells, but it is not cytotoxic to normal human cells. Compound 1c is therefore valuable
for further biological investigation, particularly with regard to KDM4 inhibition, and it has potential
to be an anticancer agent. This is the first report on the biological activity of benzo[b]tellurophene
derivatives and the study of the mechanism of benzo[b]tellurophene inhibition of KDM4 is ongoing.
The newly synthesized benzo[b]tellurophene or benzo[b]selenophene can be provided as a novel
molecular framework that is similar to but distinct from benzofuran or benzothiophene.
Supplementary Materials: Supplementary materials can be found at http://www.mdpi.com/1422-0067/20/23/
5908/s1.
Author Contributions: Y.-J.K. designed and performed the experiments, analyzed the data, and drafted the
manuscript. D.H.L. and Y.-S.C. performed the experiments and analyzed the data. S.H.K. and J.-H.J. conceived
the general design of the study, wrote the initial draft of the manuscript, extensively edited the manuscript, and
supervised the work. All authors read and approved the final manuscript.
Funding: This research was supported by Basic Science Research Program through the National
Research Foundation of Korea (NRF) funded by the Ministry of Education (NRF-2016R1A6A3A11932164,
NRF-2017R1A6A3A11034603, 2018R1A6A1A03023718, and 2019R1A2C1008619).
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
5.
6.
Radadiya, A.; Shah, A. Bioactive benzofuran derivatives: An insight on lead developments, radioligands
and advances of the last decade. Eur. J. Med. Chem. 2015, 97, 356–376. [CrossRef] [PubMed]
Keri, R.S.; Chand, K.; Budagumpi, S.; Balappa Somappa, S.; Patil, S.A.; Nagaraja, B.M. An overview of
benzo[b]thiophene-based medicinal chemistry. Eur. J. Med. Chem. 2017, 138, 1002–1033. [CrossRef] [PubMed]
Majid, M.H.; Vahideh, Z. Recent Advances in the Synthesis of Biologically Active Compounds Containing
Benzo[b]Furans as a Framework. Curr. Org. Synth. 2016, 13, 780–833.
Khanam, H.; Shamsuzzaman. Bioactive Benzofuran derivatives: A review. Eur. J. Med. Chem. 2015, 97,
483–504. [CrossRef]
Tan, H.W.; Mo, H.-Y.; Lau, A.T.Y.; Xu, Y.-M. Selenium Species: Current Status and Potentials in Cancer
Prevention and Therapy. Int. J. Mol. Sci. 2018, 20, 75. [CrossRef]
Müller, A.; Cadenas, E.; Graf, P.; Sies, H. A novel biologically active seleno-organic compound—1: Glutathione
peroxidase-like activity in vitro and antioxidant capacity of PZ 51 (Ebselen). Biochem. Pharmacol. 1984, 33,
3235–3239. [CrossRef]
7.
8.
9.
Choi, Y.-S.; Kim, Y.-J.; Lee, J.; Lee, J.; Jeong, J.-H. Synthesis and Evaluation of Selenoflavones That Have
Potential Neuroprotective Effects. Heterocycles 2014, 89, 2794–2805.
Andersson, C.-M.; Hallberg, A.; Brattsand, R.; Cotgreave, I.A.; Engman, L.; Persson, J. Glutathione
peroxidase-like activity of diaryl tellurides. Bioorganic Med. Chem. Lett. 1993, 3, 2553–2558. [CrossRef]
Sredni, B.; Albeck, M.; Kazimirsky, G.; Shalit, F. The immunomodulator AS101 administered orally as a
chemoprotective and radioprotective agent. Int. J. Immunopharmacol. 1992, 14, 613–619. [CrossRef]
10. Sredni, B. Immunomodulating tellurium compounds as anti-cancer agents. Semin. Cancer Biol. 2012, 22,
60–69. [CrossRef]
11. Caracelli, I.; Vega-Teijido, M.; Zukerman-Schpector, J.; Cezari, M.H.S.; Lopes, J.G.S.; Juliano, L.; Santos, P.S.;
Comasseto, J.V.; Cunha, R.L.O.R.; Tiekink, E.R.T. A tellurium-based cathepsin B inhibitor: Molecular structure,
modelling, molecular docking and biological evaluation. J. Mol. Struct. 2012, 1013, 11–18. [CrossRef]

Int. J. Mol. Sci. 2019, 20, 5908
14 of 14
12. Angeli, A.; Tanini, D.; Capperucci, A.; Supuran, C.T. First evaluation of organotellurium derivatives as
carbonic anhydrase I, II, IV, VII and IX inhibitors. Bioorganic Chem. 2018, 76, 268–272. [CrossRef] [PubMed]
13. Singh, V.P.; Poon, J.-F.; Engman, L. Catalytic Antioxidants: Regenerable Tellurium Analogues of Vitamin E.
Org. Lett. 2013, 15, 6274–6277. [CrossRef] [PubMed]
14. Sekirnik, R.; Rose, N.R.; Thalhammer, A.; Seden, P.T.; Mecinovic, J.; Schofield, C.J. Inhibition of the histone
lysine demethylase JMJD2A by ejection of structural Zn(II). Chem. Commun. 2009, 42, 6376–6378. [CrossRef]
[PubMed]
15. Shi, Y.; Lan, F.; Matson, C.; Mulligan, P.; Whetstine, J.R.; Cole, P.A.; Casero, R.A.; Shi, Y. Histone Demethylation
Mediated by the Nuclear Amine Oxidase Homolog LSD1. Cell 2004, 119, 941–953. [CrossRef] [PubMed]
16. Schneider, J.; Shilatifard, A. Histone Demethylation by Hydroxylation: Chemistry in Action. ACS Chem. Biol.
2006, 1, 75–81. [CrossRef]
17. Zhao, M.; Wang, Z.; Yung, S.; Lu, Q. Epigenetic dynamics in immunity and autoimmunity. Int. J. Biochem.
Cell Biol. 2015, 67, 65–74. [CrossRef]
18. Young, L.C.; Hendzel, M.J. The oncogenic potential of Jumonji D2 (JMJD2/KDM4) histone demethylase
overexpression. Biochem. Cell Biol. 2013, 91, 369–377. [CrossRef]
19. Berry, W.L.; Shin, S.; Lightfoot, S.A.; Janknecht, R. Oncogenic features of the JMJD2A histone demethylase in
breast cancer. Int. J. Oncol. 2012, 41, 1701–1706.
20. Ishimura, A.; Terashima, M.; Kimura, H.; Akagi, K.; Suzuki, Y.; Sugano, S.; Suzuki, T. Jmjd2c histone
demethylase enhances the expression of Mdm2 oncogene. Biochem. Biophys. Res. Commun. 2009, 389,
366–371. [CrossRef]
21. Luo, W.; Chang, R.; Zhong, J.; Pandey, A.; Semenza, G.L. Histone demethylase JMJD2C is a coactivator for
hypoxia-inducible factor 1 that is required for breast cancer progression. Proc. Natl. Acad. Sci. USA 2012
109, E3367–E3376. [CrossRef] [PubMed]
,
22. Westaway, S.M.; Preston, A.G.; Barker, M.D.; Brown, F.; Brown, J.A.; Campbell, M.; Chung, C.W.; Drewes, G.;
Eagle, R.; Garton, N.; et al. Cell Penetrant Inhibitors of the KDM4 and KDM5 Families of Histone Lysine
Demethylases. 2. Pyrido[3,4-d]pyrimidin-4(3H)-one Derivatives. J. Med. Chem. 2016, 59, 1370–1387.
[CrossRef] [PubMed]
23. Westaway, S.M.; Preston, A.G.; Barker, M.D.; Brown, F.; Brown, J.A.; Campbell, M.; Chung, C.W.; Diallo, H.;
Douault, C.; Drewes, G.; et al. Cell Penetrant Inhibitors of the KDM4 and KDM5 Families of Histone
Lysine Demethylases. 1. 3-Amino-4-pyridine Carboxylate Derivatives. J. Med. Chem. 2016, 59, 1357–1369.
[CrossRef] [PubMed]
24. Chen, Y.K.; Bonaldi, T.; Cuomo, A.; Del Rosario, J.R.; Hosfield, D.J.; Kanouni, T.; Kao, S.C.; Lai, C.; Lobo, N.A.;
Matuszkiewicz, J.; et al. Design of KDM4 Inhibitors with Antiproliferative Effects in Cancer Models. ACS Med.
Chem. Lett. 2017, 8, 869–874. [CrossRef]
25. Carter, D.M.; Specker, E.; Przygodda, J.; Neuenschwander, M.; von Kries, J.P.; Heinemann, U.; Nazare, M.;
Gohlke, U. Identification of a Novel Benzimidazole Pyrazolone Scaffold That Inhibits KDM4 Lysine
Demethylases and Reduces Proliferation of Prostate Cancer Cells. Slas Discov. Adv. Life Sci. R D 2017, 22,
801–812. [CrossRef]
26. Sashida, H.; Sadamori, K.; Tsuchiya, T. A Convenient One-Pot Preparation of Benzo[b]-tellurophenes,
-selenophenes, and -thiophenes from o-Bromoethynylbenzenes. Synth. Commun. 1998, 28, 713–727.
[CrossRef]
27. Okuma, K.; Yahata, S.; Nagahora, N.; Shioji, K. Reaction of Acetophenone Hydrazones with TeCl4: Novel
Formation of 2,5-Diaryltellurophenes and Benzotellurophenes. Chem. Lett. 2017, 46, 405–407. [CrossRef]
28. Shechter, D.; Dormann, H.L.; Allis, C.D.; Hake, S.B. Extraction, purification and analysis of histones.
Nat. Protoc. 2007, 2, 1445–1457. [CrossRef]
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
