PAPER
Silylated organometals: a family of recyclable
homogeneous catalysts†
Cite this: DOI: 10.1039/c4gc01586j
Jian-Lin Huang,a Jun-Zhong Wang,a He-Xing Li,*b Haibing Guo*c and
George A. O’Dohertyd
A general strategy has been developed to synthesize a family of silylated organometals (M-PPh2-TS and
DPEN-Ru-PPh2-Ts, M = Pd2+, Rh+, Pt2+, Ir+, or Ru2+, PPh2-Ts = PPh2CH2CH2Si(OEt)3), DPEN = (1R,2R)-
1,2-diphenylethylenediamine). They can act as homogeneous catalysts with high efficiencies in various
organic reactions using THF, CH2Cl2 or toluene as the reaction medium. After reaction, they could be
thoroughly settled down by adding pentane and then used repeatedly owing to the complete catalyst
recovery and good preservation of the catalyst structure. This is particularly important due to the increas-
ing concerns regarding the cost, toxicity and limited availability of these nonrenewable transition metals.
Received 15th August 2014,
Accepted 14th November 2014
DOI: 10.1039/c4gc01586j
www.rsc.org/greenchem
Green chemistry requires chemical reactions to be conducted redox-,8 photo-9 and phase-switchable10 technologies.
with low cost, clean reactants, products and processes, recycl- However, their discovery and design are quite rare, which
able and environmentally friendly catalysts, and high activity greatly limits the number of catalysts and their practical appli-
and selectivity (i.e., economic reactions). Homogeneous cations. Obviously, a universal method for preparing recyclable
organometal catalysts have been widely used in organic syn- homogeneous catalysts is strongly desired.
thesis and have enjoyed great success as a result of their high
Herein, we reported a general way to synthesize a family of
activity, selectivity and stereoselectivity.1 However, they are silylated organometals using in situ coordinating metallic ions
difficult to be recycled and reused, leading to enhanced costs with the PPh2-ligand in PPh2CH2CH2Si(OEt)3, denoted as
and even environmental pollution from heavy metallic ions.2 M-PPh2-Ts, where M refers to Pd2+, Rh+, Pt2+, Ir+, or Ru2+,
Immobilized homogeneous catalysts on solid supports are while PPh2-Ts corresponds to PPh2CH2CH2Si(OEt)3. They
easily recycled and reused, but they usually display remarkably behaved as homogeneous catalysts with high activities and
decreased catalytic efficiencies due to the enhanced diffusion selectivities in various organic reactions using common sol-
limit, reduced dispersion degree and unmatchable chemical vents including THF, CH2Cl2 or toluene as the reaction media.
microenvironment of the active sites.3 There is always a dream After reaction, they could be completely precipitated by adding
of designing recyclable homogeneous catalysts combining the pentane and then used repeatedly without a significant decrease
merits of both homogeneous and heterogeneous catalysts. in the catalytic efficiencies. Moreover, we could further syn-
Such catalysts could be used homogeneously during reactions thesize the chiral catalyst DPEN-Ru-PPh2-Ts by further coordi-
and then easily recycled after reactions for subsequent reuse. nating Ru-PPh2-Ts with DPEN-ligand, where DPEN refers to
To date, only a few recyclable homogeneous catalysts have (1R,2R)-1,2-diphenylethylenediamine. DPEN-Ru-PPh2-Ts could
been reported, which can be settled down and recycled by act as a homogeneous chiral catalyst in CH2Cl2-medium organic
interphase,4 clathrate-enabled,5 ionic-6 and fluorous-tagged,7 reactions with high efficiencies and ee values. After each round
of reactions, it could also be totally recovered by adding pentane
and then used repeatedly many times. Obviously, these homo-
geneous silylated catalysts combine the advantages of both the
typical homogeneous and heterogeneous catalysts.
A general approach to prepare silylated organometals
(M-PPh2-Ts and DPEN-Ru-PPh2-Ts) is illustrated in Scheme 1
aKey Laboratory of Carbon Materials, Institute of Coal Chemistry, Chinese Academy
of Sciences, Taiyuan 030001, P. R. China. E-mail: jlhuang@sxicc.ac.cn
bThe Chinese Education Ministry Key Lab of Resource Chemistry, Shanghai
University of Electric Power, Shanghai 200090, P. R. China.
E-mail: Hexing-Li@shnu.eud.cn
cThe College of Nuclear Technology, Chemistry and Biology, Hubei University of
Science and Technology, Xianning, Hubei 437100, P. R. China.
E-mail: haibingguojj@yahoo.com
dDepartment of Chemistry and Chemical Biology, Northeastern University, Boston,
Massachusetts 02115, United States. E-mail: G.O'Doherty@neu.edu
†Electronic supplementary information (ESI) available. See DOI: 10.1039/
c4gc01586j
(see ESI† for experimental details). It is noteworthy that when
the resulting complex was treated with pentane, it was precipi-
tated out and a pure product was obtained after washing with
pentane without using chromatography. This implies that the
silylated complex can indeed be easily purified and potentially
recycled. To determine the catalyst compositions, the metal
This journal is © The Royal Society of Chemistry 2014
Green Chem.

View Article Online
Paper
Green Chemistry
DPEN-Ru-PPh2-Ts displayed three signals at around 20, 35,
and 47 ppm, corresponding to three kinds of P-Ru coordi-
nation models.15 Meanwhile, according to the FTIR spectra
(Fig. S2†), all the M-PPh2-Ts samples displayed absorbance
bands at around 695, 2897, 2973, 1439, and 1083 cm−1 due to
the asymmetric and symmetric stretching vibrations of C–H,
P–CH2, Si–O bonds, and the -H out-of-plane deformation of
the monosubstituted benzene ring.16 The DPEN-Ru-PPh2-Ts
exhibited a new absorption band at 1641 cm−1 owing to the
N–H stretching vibration.17 Furthermore, the TG curves
(Fig. S3†) revealed a total weight loss of around 60.2% at
around 250 °C for all the M-PPh2-Ts samples, which could be
attributed to the subsequent combustion of the PPh2-CH2-
CH2- and the C2H5-groups, in good accordance with theoretical
values. The DPEN-Ru-PPh2-Ts showed 10% more weight loss
resulting from the removal of the additional DPEN ligand. In
addition, the XPS spectra (Fig. S4†) revealed that all the Pd
and Ru species were present in the +2 oxidation state while the
Rh species were present in the +1 oxidation state, corres-
ponding to binding energies (BE) of 338.0, 280.6 and 307.7 eV
in the Pd3d5/2, Ru3d5/2 and Rh3d5/2 levels, respectively.18 One
could see that the metallic ions in either M-PPh2-Ts or M
(PPh3)xCly (M = Pd2+ and Rh+) displayed slightly lower BE than
the corresponding ones in M(COD)Cl2, which confirmed the
coordination between metallic ions with the PPh2 or the PPh3
ligand instead of the COD ligand, making metallic ions more
electron-enriched owing to the stronger electron-donating
ability of PPh2 or PPh3 than that of COD. Moreover, the met-
allic ions in the M-PPh2-Ts (M = Pd2+, Rh+, and Ru2+) exhibited
slightly lower BE than the corresponding ones in M(PPh3)xCly,
implying the weaker electron-donation ability of the PPh3-
ligand than PPh2-CH2-CH2-ligand. This could be easily under-
stood by considering the conjugated system between one
P atom with three Ph groups. The PPh2-CH2-CH2-ligand con-
tains a conjugated system between one P atom and two Ph
rings, while the PPh3-ligand contains a bigger conjugated
system between one P atom and three Ph rings, which might
dilute the electron density on the P atom, leading to the lower
electron-donating ability.19 In comparison with the Ru-PPh2-
Ts, no significant BE shift was observed in the DPEN-Ru-PPh2-
Ts, suggesting the similar electron-donating ability of the
DPEN-ligand to that of the PPh2-CH2-CH2-ligand.
Scheme 1 Illustration of the catalyst preparation.
contents were determined by inductively coupled plasma
spectrometer (ICP, Varian VISTAMPX), while the C, N, and H
contents were detected by elemental analysis (Elementar Vario
ELIII, Germany). Some results are listed as follows (see the
structural formula of catalysts in Scheme S1†): (1) Pd-PPh2-Ts
= Pd(II)[PPh2CH2CH2Si(OEt)3]2Cl2: calculation values, C (51.64)
and H (6.28), experimental results, C (51.59) and H (6.22). (2)
Rh-PPh2-Ts
=
Rh(I)[PPh2CH2CH2Si(OEt)3]3Cl: calculation
values, C (56.84) and H (6.92), experimental results, C (56.64),
H (6.85). (3) Ru-PPh2-Ts = Ru(II)[PPh2CH2CH2Si(OEt)3]3Cl2:
calculation values, C (55.37), H (6.74), experimental results,
C (55.55) and H (6.74). (4) DPEN-Ru-PPh2-Ts = Ru(II)[(DPEN)/
PPh2CH2CH2Si(OEt)3]3Cl2: calculation value,
C (55.37), N
(1.85) and H (6.74), experimental results, C (55.31), N (1.81)
and H (6.75). The sample compositions and structures could
be further determined by NMR spectra (Fig. S1†). The 1H NMR
(CDCl3) spectra displayed characteristic peaks at 7.2–7.5,
7.6–7.7 (2 m, ArH), 3.71 (q, CH2CH2), 2.47 (m, CH2P), 1.13 (t,
CH3CH2), and 0.79 (m, SiCH2). The DPEN-Ru-PPh2-Ts dis-
played two new peaks around 4.1 and 5.2 ppm, indicative of
the H–N group.11 Meanwhile, the 13C NMR spectra exhibited
two peaks at 18 and 30 ppm, corresponding to two C atoms in
the ethyl group connecting with the PPh2 terminal. The peak
at 58 ppm was attributed to the Cb atom in the CaH3CbH2O–Si
group. An intense peak at 133 ppm was assigned to the
C atoms in the benzene ring.12 The DPEN-Ru-PPh2-Ts dis-
played two additional peaks around 29 and 62 ppm, character-
istic of two C atoms in the ethyl group connecting with the
NH2 terminal.13 The 29Si NMR spectra (Fig. S8†) of the PPh2-
Ts, and Pd-PPh2-Ts catalyst displayed an intense signal at
−47.1 ppm, which demonstrated that only one Si chemical
environment existed in the two samples. No obvious Qn peaks
were observed, where Qn = Si(OSi)n-(OH)4−n, n = 2–4, indicating
that the Pd-PPh2-Ts catalyst did not undergo hydrolysis and
condensation reactions under the present conditions. There is
a very small wide peak at about −110 ppm (Q4), which was
attributed to the hydrolysis and condensation of very few
Si(OEt)3 groups, as it is very difficult to completely exclude air
when conducting the NMR experiments. The 31P NMR spectra
further showed the intense signals around 21.2, 39.2 and
38.7 ppm indicative of the Pd-PPh2, Rh-PPh2 and Ru-PPh2
coordination bonds in the Pd-PPh2-Ts, Rh-PPh2-Ts, and
Ru-PPh2-Ts samples,14 respectively. The different peak posi-
tions could be attributed to the different chemical environ-
ments of the P atoms due to the change of metallic ions. The
The catalytic performances of the as-prepared organometals
were examined in various organic reactions including Pd-cata-
lyzed Suzuki coupling reactions (Table 1),20 Rh-catalyzed alde-
hyde methylenation reactions (Table 2),21 Ru-catalyzed
homoallylic alcohol isomerization reactions (Table 3),22 DPEN/
Ru-catalyzed asymmetric hydrogenations of acetophenone
(Table 4),23 Pt-catalyzed carboselenation of alkynes by seleno-
esters (Table S1†), and Ir-catalyzed transfer hydrogenation
reactions (Table S2†). In these reactions, all the M-PPh2-Ts cat-
alysts and the DPEN-Ru-PPh2-Ts chiral catalyst could be com-
pletely dissolved in the THF, CH2Cl2 or toluene used as the
reaction media and precipitated at the end of organic reactions
by adding fresh pentane. The catalytic performance of the
Pd-PPh2-Ts was examined for the Suzuki coupling reactions in
Green Chem.
