Structure, antioxidant and anti-inflammatory activities of the (4R)-and (4S)-epimers of s-carboxymethyl-l-cysteine sulfoxide

Article abstract of DOI:10.3390/ph13100270

S-Carboxymethyl-L-cysteine (CMC) is an antioxidant and mucolytic commonly prescribed to patients with chronic obstructive pulmonary disease. In humans, CMC is rapidly metabolized to S-carboxymethyl-L-cysteine sulfoxide (CMCO). In this study, we assessed s

Full text of DOI:10.3390/ph13100270

pharmaceuticals
Article
Structure, Antioxidant and Anti-inflammatory
Activities of the (4R)- and (4S)-epimers of
S-Carboxymethyl-L-cysteine Sulfoxide
James K. Waters , Steven P. Kelley , Valeri V. Mossine * and Thomas P. Mawhinney 3
1
2
3,
1
Experiment Station Chemical Laboratories, University of Missouri, Columbia, MO 65211, USA;
WatersJ@missouri.edu
2
Department of Chemistry, University of Missouri, Columbia, MO 65211, USA; KelleySP@missouri.edu
Department of Biochemistry, University of Missouri, Columbia, MO 65211, USA;
3
MawhinneyT@missouri.edu
*
Correspondence: MossineV@missouri.edu; Tel.: +1-573-882-2608
ꢀ
ꢁꢂꢀꢃꢄꢅꢆꢇ
Received: 6 September 2020; Accepted: 23 September 2020; Published: 25 September 2020
ꢀ
ꢁꢂꢃꢄꢅꢆ
Abstract: S-Carboxymethyl-L-cysteine (CMC) is an antioxidant and mucolytic commonly prescribed
to patients with chronic obstructive pulmonary disease. In humans, CMC is rapidly metabolized to
S-carboxymethyl-L-cysteine sulfoxide (CMCO). In this study, we assessed structural and functional
similarities between CMC and CMCO. X-Ray diffraction analysis provided detailed structural
information about CMCO, which exists as a 1:1 mixture of epimers, due to the emergence of a new
chiral center at the sulfur atom. Both CMC and CMCO epimers protected model DNA from
copper-mediated hydroxyl free radical damage. Using an insulated transposable construct for
reporting activity of the cellular stress-responsive transcription factors Nrf2, p53, NF-κB, and AP-1, we
demonstrate that CMCO, especially its (4R)-epimer, is comparable to CMC in their ability to mitigate
the effects of oxidative stress and pro-inflammatory stimuli in human alveolar (A549) and bronchial
epithelial (BEAS-2B) cells. The results of these in vitro studies suggest that CMCO retains, at least
partially, the antioxidant potential of CMC and may inform pharmacodynamics considerations of
CMC use in clinics.
Keywords: COPD; carbocisteine; crystal structure; tumor necrosis factor; hydrogen peroxide;
hydroquinone; cigarette smoke extract
1
. Introduction
Chronic obstructive pulmonary disorder (COPD) is a serious life-threatening disease that
affects over 325 million people globally, with estimated 6% of all deaths due to this malady [1];
only cardiovascular disease, cancer, and stroke kill more. COPD is primarily caused by tobacco
smoke and is characterized by persistent pro-inflammatory responses in the respiratory tract, upon
which the airway cells are subjected to a chronic oxidative stress [2]. Though COPD is not curable,
a number of therapies, including treatment of exacerbations with mucolytic antioxidant agents,
were offered to attenuate damaging effects of the chronic inflammation in lungs of COPD patients.
S-Carboxymethyl-L-cysteine (CMC, carbocisteine) is an antioxidant and a mucolytic commonly
prescribed to patients with COPD [
use, CMC metabolism has been a subject of debate for a number of years [
believed to be one of the main metabolic transformations of CMC, with hepatic phenylalanine
-mono-oxygenase playing a major role in CMC oxidation [ ]. To the best of our knowledge,
3
]. Although CMC has a long history of a clinical drug
4
]. Sulfoxidation is
4
5
the functional properties of the sulfoxidation product, S-carboxymethyl-L-cysteine sulfoxide (CMCO),
related to mucolytic/antioxidant/anti-inflammatory activities of CMC have not been evaluated.
Pharmaceuticals 2020, 13, 270; doi:10.3390/ph13100270
www.mdpi.com/journal/pharmaceuticals

Pharmaceuticals 2020, 13, 270
2 of 16
Structure of CMCO has been deduced from an X-ray diffraction study in 1976 [
6]. The reported
structure represented only one out of two possible isomers that should form as a result of an emerging
new chiral center at the sulfur atom in CMCO, upon mild oxidation of CMC (Scheme 1). In addition,
one unusual feature of the reported structure was an assignment of the carboxylate proton to the
α
-carboxylic group, at an expense of deprotonated
δ-carboxylic group. Given that acidity of the
α
-carboxylic groups in acidic -amino acids, including CMC and CMC sulfone, is expected to be the
α
highest [7–11], the accuracy of the carboxylic proton assignment in CMCO needs to be re-assessed.
Scheme 1. Formation of S-carboxymethyl-L-cysteine sulfoxide (CMCO) through mild oxidation of
S-Carboxymethyl-L-cysteine (CMC).
Thus, the main objectives of this work were to re-investigate the structure of
S-carboxymethyl-L-cysteine sulfoxide and to compare the antioxidant and anti-inflammatory potential
of CMC and CMCO in an in vitro model of lower airways using established pathway reporter cell lines.
2
. Results
S-Carboxymethyl-L-cysteine sulfoxide was readily formed by oxidation of CMC with cold 30%
hydrogen peroxide (Scheme 1). The ion-exchange chromatographic analysis revealed the presence of
two products in a 1:1 ratio (Supplementary Figure S1). Fractional crystallization afforded three crops
of CMCO solid with different crystal parameters, all containing pure epimers of CMCO. The epimeric
purity of the crops has been established by chromatography and polarimetry, and the absolute
structures of the CMCO epimers were further confirmed by the X-ray diffraction analysis data,
which are presented below.
2
.1. Molecular and Crystal Structures of CMCO Epimers
2
.1.1. Polymorphs of the (2R,4R)-S-carboxymethylcysteine sulfoxide epimer
◦
Sequential crystallization of the CMCO epimeric mixture from warm (45 C) and cold
◦
(
(
0 C) aqueous solutions afforded crystal crops of the (2R,4R)-S-carboxymethylcysteine sulfoxide
(4R)-CMCO), which we determined as belonging to the triclinic P1 (structure referred to as
t-(4R)-CMCO) and orthorhombic P2 2 2 (structure referred to as o-(4R)-CMCO) space groups,
1
1 1
respectively (Supplementary Table S1), thus demonstrating existence of crystalline polymorphs for this
molecule. Further low-temperature X-ray diffraction analysis data (Supplementary Tables S2–S9) has
confirmed that, in these two types of crystals, (4R)-CMCO molecules assume different conformations
(Figure 1).

Pharmaceuticals 2020, 13, 270
3 of 16
Figure 1.
Atom numbering and displacement ellipsoids at 50% probability level for
2R,4R)-S-carboxymethylcysteine sulfoxide polymorphs crystallized in: ( ) the triclinic space group;
b) the orthorhombic space group. An intramolecular hydrogen bond is shown as a thin dotted line.
(
(
a
In both structures, the amino acid molecules exist as zwitterions, with the deprotonated
-carboxylic group and the protonated -amino- and -carboxylic groups; a similar arrangement was
found for both CMC [10] and CMC sulfone [ ] molecules in the crystalline state. The main difference
α
α
δ
9
in the conformations of t-(4R)-CMCO and o-(4R)-CMCO is due to a rotation around the C2–C3 bond.
Thus, in t-(4R)-CMCO, atoms S1 and C1 are in the antiperiplanar conformation, with the torsion angle
◦
S1-C3-C2-C1 at 170.34 , while in o-(4R)-CMCO, the conformation around the C2–C3 bond is gauche
◦
in respect to the atoms S1 and C1, with the corresponding torsion angle at 66.36 . The conformation
displayed by CMC sulfone in crystallo [9] is nearly similar to t-(4R)-CMCO, while structure of the CMC
molecules [10] differs from o-(4R)-CMCO by a single rotation around the S1–C3 bond. In addition,
t-(4R)-CMCO features a suspected intramolecular hydrogen bond between the amino group and the
sulfoxide oxygen atom O3 (Supplementary Table S5). A weak intramolecular H-bond including one
ammonium hydrogen and S1 is assumed in the crystalline CMC as well. In o-(4R)-CMCO, there is
an indication of a strong hydrogen bond between the δ-carboxylate O5 and the α-carboxylate O2,
with an unusually short distance between proton H5 and its acceptor O2, such that the O5–H5 bond in
o-(4R)-CMCO is considerably longer than a similar bond in CMC and other CMCO molecules (1.15 Å
in o-(4R)-CMCO versus 0.89 Å in t-(4R)-CMCO, 0.82 Å in m-(4S)-CMCO, and 0.98 Å in CMC, Table 1).
In addition, delocalization of the π-bonding in the α-carboxylic group at C5 is higher in o-(4R)-CMCO,
as compared to the similar reference structures, so that the length difference between C5–O4 and
C5–O5 bonds in o-(4R)-CMCO is significantly shorter (0.055 Å in o-(4R)-CMCO versus 0.08–0.1 Å in the
rest). These parameters are in agreement with the previously published orthorhombic (4R)-CMCO [6]
structure, as well (Table 1).
◦
Table 1. Comparative geometries (Å, ) of carboxylate-carboxylate hydrogen bonds in CMCO and
related structures.
Space
Group
1
2
Molecule
D–H ··· A
D–H
H ··· A
D ··· A
D–H ··· A
∆
∆
C5–O
C1–O
0.89 (2) 3
1.15 (3)
1.15 (3)
0.82 (4)
0.98 (3)
1.04 (4)
0.96 (5)
t-(4R)-CMCO
o-(4R)-CMCO
Triclinic
O5–H ··· O1
O5–H ··· O1
O5–H ··· O2
O5–H ··· O2
O5–H ··· O2
1.64 (3)
2.44 (3)
1.32 (3)
1.67 (4)
1.58 (3)
1.41 (4)
1.54 (5)
2.500 (1)
3.247 (2)
2.450 (2)
2.489 (3)
2.548 (2)
2.449 (3)
2.504 (5)
163 (2)
126 (2)
168 (3)
176 (4)
169 (3)
176 (4)
175 (5)
0.018
0.039
0.083
0.055
Orthorhombic
m-(4S)-CMCO
CMC [10]
Monoclinic
Monoclinic
Orthorhombic O2–H ··· O5
Orthorhombic O5–H ··· O2
0.010
0.008
0.032
0.048
0.083
0.102
0.058
0.098
(
4R)-CMCO [6]
CMCO2 [9]
1
Length difference between C1–O1 and C1–O2 bonds, Å. 2 Length difference between C5–O4 and C5–O5 bonds, Å.
The estimated standard deviation of the last digit.
3
2
.1.2. The (2R,4S)-S-carboxymethylcysteine sulfoxide epimer
Although (2R,4S)-S-carboxymethylcysteine sulfoxide ((4S)-CMCO) was initially identified in
a crop of a co-crystallized mixture of the (4S)- and (4R)-CMCO epimers, crystals containing this
molecule and suitable for X-ray diffraction studies were obtained in a course of fractional crystallization.

Pharmaceuticals 2020, 13, 270
4 of 16
These have been identified as crystals of pure (4S)-CMCO belonging to the monoclinic P2 space group,
1
structure referred to as m-(4S)-CMCO. Similarly to t-(4R)-CMCO and o-(4R)-CMCO, the molecule
of m-(4S)-CMCO (Figure 2, Supplementary Tables S10–S12) exists as a zwitterion, with charged
α
-carboxylic and α-amino groups. The conformation of m-(4S)-CMCO is close to the conformation
of o-(4R)-CMCO, less position of the sulfoxide oxygen O3. In addition, m-(4S)-CMCO features
an intramolecular heteroatom interaction between O2 and N1, which may qualify for a weakly
◦
directional hydrogen bond, with H1C ··· O2 distance 2.57(3) Å and N1–H1C···O2 angle 95.1(4) .
Figure 2.
Atom numbering and displacement ellipsoids at 50% probability level for
(2R,4S)-S-carboxymethylcysteine sulfoxide crystallized in the monoclinic space group. A suspected
intramolecular hydrogen bond is shown as a thin dotted line.
2
.1.3. Crystal Packing and Intermolecular Hydrogen Bonding
The crystal packing in t-(4R)-CMCO, o-(4R)-CMCO, and m-(4S)-CMCO is shown in Supplementary
Figures S2–S4. Since CMC, its sulfoxides, and sulfone are heteroatom-rich, zwitterionic molecules,
the contacts involving electronegative heteroatom O dominate in the crystal structures of these
molecules, as summarized in Table 2. The H ··· O contacts are responsible for an extensive
three-dimensional hydrogen bonding network in all three crystal structures (Supplementary Tables S5,
S9, S13; Supplementary Figures S2–S4).
Table 2. Contributions (%) of the intermolecular contacts to the Hirshfeld surfaces [12] of
S-carboxymethyl-L-cysteine and its oxidation products.
Molecule
H ··· O
H ··· H
H ··· S H ··· C
O ··· O
O ··· S O ··· C C ··· C S ··· C
CMC [10]
t-(4R)-CMCO
o-(4R)-CMCO
m-(4S)-CMCO
CMCO2 [9]
58.5
68.8
77.6
68.4
78.4
22.2
18.1
10.3
18.2
11.2
9.1
4.6
4.9
4.9
0
2.2
0.6
2.9
0.4
1.4
2.5
2.4
2.0
2.8
5.8
2.9
2.6
0.7
2.0
0
0.6
2.9
1.6
2.4
3.2
0.6
0
0
0
0
1.5
0
0
0.9
0
Molecular modeling calculations, which were performed for these crystal structures,
have confirmed that the electrostatic interactions are pervasive and largely define energetics of
the crystal packing in CMC, S-carboxymethyl-L-cysteine sulfone (CMCO2), as well as all three CMCO
structures (Figure 3, Table 3, Supplementary Figures S5–S9).
Table 3. Contributions of intermolecular interactions to the packing energies
structures of S-carboxymethyl-L-cysteine and its oxidation products.
E (kJ/mol) in crystalline
Structure
E Electrostatic
E Polar
E Dispersion
E Repulsion
E Total
CMC [10]
t-(4R)-CMCO
o-(4R)-CMCO
m-(4S)-CMCO
CMCO2 [9]
−302.7
−309.6
−336.8
−323.4
−335.7
−124.6
−130.2
−148.7
−157.7
−142.4
−103.4
−118.8
−117.3
−118.7
−126
277.3
319.2
350.2
318.4
319.7
−331.1
−329.9
−351.8
−365.6
−372.6

Pharmaceuticals 2020, 13, 270
5 of 16
Figure 3. Interaction energies in crystal structures. (a) A view of interactions between a central
molecule of (4R)-CMCO in t-(4R)-CMCO, shown as its Hirshfeld surface, and 14 molecules that
share the interaction surfaces with the central molecule. ) Calculated energies (electrostatic,
polarization, dispersion, repulsion, and total) of pairwise interactions in t-(4R)-CMCO between
the central molecule and those indicated by respective colors. ( ) Energy framework for total pairwise
interaction energies in t-(4R)-CMCO. The cylinders link molecular centroids, and the cylinder thickness
is proportional to the magnitude of the energies, such as those shown in ( ). For clarity, the cylinders
corresponding to energies <5 kJ/mol are not shown. ( ) The total pairwise interaction energy framework
(
b
c
b
d
in o-(4R)-CMCO. For interaction energies in o-(4R)-CMCO and m-(4S)-CMCO, also see Supplementary
Figures S5–S6. For energy frameworks depicting electrostatic and dispersion energies in crystals of
CMCO, see Supplementary Figures S7–S9.
2
.2. CMC and CMCO Protect DNA from Copper-Catalyzed Degradation by Hydroxyl Free Radicals
Redox-active metals, such as copper, and aromatic molecules, such as hydroquinone, from cigarette
smoke can promote cellular nucleic acids damage by reactive oxygen species (ROS) and are thought to
contribute to development of COPD and other pulmonary disorders in smokers [ 13 15]. We have
2, –
compared the protective effects of CMC and CMCO as antioxidants in a conventional in vitro
model of DNA degradation by hydroxyl free radicals generated in the copper-catalyzed Fenton
reaction. Both epimeric forms of CMCO, along with CMC and their decarboxylated structural
analogues, S-methyl-L-cysteine and S-methyl-L-cysteine sulfoxide, protected DNA from oxidative
degradation by hydroxyl free radicals in the copper(II)/hydrogen peroxide/ascorbate system (Figure 4).
In contrast, N-acetyl-L-cysteine and L-2-aminohexanedioic acid (L-α-aminoadipic acid), a structural
analogue of CMC lacking the thioether atom, were not effective. Moreover, CMCO inhibited the
oxidative degradation of DNA in the copper(II)/hydroquinone system somewhat more efficiently
than CMC. Likewise, S-methyl-L-cysteine sulfoxide appeared to act as a better DNA protector than
S-methyl-L-cysteine in this system (Figure 4).

Pharmaceuticals 2020, 13, 270
6 of 16
Figure 4. CMC and CMCO protect dsDNA degradation in presence of (a) 50 µM copper/2 mM
ascorbate/2 mM H O ; (b) 50 µM copper/4 mM hydroquinone ROS generating systems. Abbreviations:
2
2
Ctrl, no ROS; DTPA, diethylenetriaminepentaacetic acid; Erdo, erdosteine; GSH, reduced glutathione;
NAC, N-acetyl-L-cysteine; SMC, S-methyl-L-cysteine; SMCO, S-methyl-L-cysteine sulfoxide; Ahd,
L-2-aminohexanedioic acid. Concentrations of inhibitors—1 mM; DMSO—0.5% v/v. For each treatment,
n = 3. The differences of means were probed by the one-way ANOVA; ø indicates no statistically
significant difference between a treatment and “no inhibitor” control; otherwise, p < 0.001.
2
.3. Effects of CMC and CMCO on Activation of Oxidative Stress and Pro-inflammatory Signalling Pathways
in Human Bronchial Epithelial and Alveolar Cell Lines
To ascertain potential inhibitory activities of CMCO against COPD-relevant inducers of
inflammation and oxidative stress in respiratory cells, we have generated a series of reporters
of transcriptional activity of the following four stress-inducible transcriptional factors: p53, Nrf2,
NF-κB, and AP-1 [16,17]. A reporter, schematized in Figure 5, represents a DNA sequence containing
5-8 concatenated binding sites for a specific transcription factor, followed by the minimal CMV
promoter, a luciferase gene, the EF1 promoter, and the copepod GFP and a selector antibiotic resistance
gene. This assembly is flanked by a pair of insulator sequences, which deter epigenetic silencing of
the reporter sequence within the cellular host DNA; furthermore, a pair of the piggyBac transposon
sequences outside of the insulators provides for an efficient integration of the reporter sequence into
the host chromatin within regions of enhanced transcriptional activity. Such constructs provided for
exceptional stabilities and high functional activities of the transgenes [16]. For this work, we have
stably transfected human bronchial epithelial BEAS-2B and human alveolar A549 cell lines with the
reporter plasmids; the resulting reporter cell lines thus allowed for conducting the testing experiments
in a medium-throughput format.
Figure 5. The construct for a transcriptional activity reporter. Abbreviations: TRE, transcriptional
response elements; mCMV, minimal CMV promoter; EF1, elongation factor 1
α promoter; GFP, green
fluorescent protein; Puro, puromycin resistance gene; Ins, insulators; ITR, inverted terminal repeats.

Pharmaceuticals 2020, 13, 270
7 of 16
2
.3.1. The p53 Pathway
One of the main functions of the p53 transcription factor is to respond to cellular DNA damage
through regulation of the DNA repair and the cell fate [18]. When A549 and BEAS-2B cell reporters for
the p53 pathway were exposed to a diluted (2.5%) cigarette smoke extract for 18 h, the transcriptional
activity of the p53 increased by about 50% in both cell lines (Figure 6). Previous studies demonstrated
that hydroquinone, a major component of cigarette smoke, could be genotoxic in pulmonary cells [14
]
via induction of ROS, such as hydrogen peroxide. In our research, both hydroquinone and H O
2
2
promoted an increase in the p53 transcriptional activity in both A549 and BEAS-2B cells (Figure 6).
Figure 6. Induction of transcriptional activities of selected TFs in A549 and BEAS-2B cells by a cigarette
smoke extract (CSE), hydroquinone (HQ), hydrogen peroxide, and Tumor Necrosis Factor (TNF).
The response fold is measured as a ratio of luciferase activities in the treated and untreated cells after
1
8 h of exposure. The stressor concentrations are 2.5% CSE in both lines; 125 and 32
and BEAS-2B, respectively; 1000 and 125 M H O in A549 and BEAS-2B, respectively; 4 ng/mL TNF
in both lines. The error bars are SDs; n = 3.
µM HQ in A549
µ
2
2
In cultured alveolar and bronchial epithelial cells, both CMC and CMCO protected cellular DNA
from damage by hydroquinone or cigarette smoke extract, as evidenced by a decrease in activity of the
p53 pathway signaling in the antioxidant-treated cells. As demonstrated in Figure 7, CMC and the
(
4R)-CMCO epimer consistently inhibited p53 activation in CSE- and HQ-treated cells, although the
effect was less significant in the H O -treated cells. The (4S)-CMCO epimer, however, was ineffective
2
2
or less effective than CMC, in these experiments.

Pharmaceuticals 2020, 13, 270
8 of 16
Figure 7. Protection of A549 and BEAS-2B cells from stressors-activators of the p53 pathway by CMC
abbreviated as C), (4S)-CMCO (S), and (4R)-CMCO (R). The luciferase activities in the treated cells are
(
normalized for the reporter activity in wells receiving no inhibitor (N). The stressor concentrations are
indicated in Figure 6. The inhibitor concentrations were 1 mM in all experiments. The error bars are
SDs; n = 3. The differences of means were probed by the one-way ANOVA; * indicates a statistically
significant difference between an inhibitor treatment and “no inhibitor” control; # indicates a statistically
significant difference between CMC and CMCO treatments, p < 0.05.
2
.3.2. The Nrf2 Pathway
Widely acknowledged as a master regulator of cellular stress, the Nrf2 transcription factor normally
responds to an increase in intracellular concentrations of thiol-reactive species, such as ROS, heavy
metals, hydroquinones, and unsaturated or carbonyl intermediates [19]. Cigarette smoke contains
a large number of these potential inducers for Nrf2 [20]. In most cells, the SH-sensor is represented
by the Kelch-like ECH-associated protein 1 (KEAP1), which, in its native state, binds to Nrf2 and
directs it to degradation. Electrophiles dysfunction KEAP1 and thus promote survival of Nrf2 and its
translocation from the cytoplasm to the nucleus, where it becomes transcriptionally active. A549 cells
represent a line with mutated KEAP1 and thus with enhanced basal Nrf2 activity and resistance to
oxidative stress [21]. Indeed, as shown in Figure 6, the Nrf2 reporter is considerably more responsive
to CSE in BEAS-2B cells, as compared to A549.
In the presence of CMC and CMCO, there was a significant decrease in the Nrf2 activity in A549
cells treated with H O or hydroquinone (Figure 8). In addition, CMCO, rather than CMC, inhibited
2
2
Nrf2 activation in A549 cells treated with CSE or TNF. In BEAS-2B cells, the protective effect of CMC
and CMCO was the most pronounced against the H O stress, while there was no significant influence
2
2
on the Nrf2 activation by HQ and TNF by any of the inhibitors.

Pharmaceuticals 2020, 13, 270
9 of 16
Figure 8. Effects of CMC (C), (4S)-CMCO (S), and (4R)-CMCO (R) on activation of the Nrf2 pathway by
stressors in A549 and BEAS-2B cells. The luciferase activities in the treated cells are normalized for
the reporter activity in wells receiving no inhibitor (N). The stressor concentrations are indicated in
Figure 6. The inhibitor concentrations were 1 mM in all experiments. The error bars are SDs; n = 3.
The differences of means were probed by the one-way ANOVA; * indicates a statistically significant
difference between an inhibitor treatment and “no inhibitor” control; # indicates a statistically significant
difference between CMC and CMCO treatments, p < 0.05.
2
.3.3. The NF-κB Pathway
In both A549 and BEAS-2B cells, this pro-inflammatory pathway was, as expected, significantly
activated by pro-inflammatory cytokine TNF (Figure 6). In both cell lines, treatment with CSE resulted
in a moderate (about 50%) increase of the NF-κB activation, as well, while HQ in BEAS-2B and H O
2
2
in both lines were not inducing this pathway.
Both CMC and CMCO could reduce NF-κB activation in cells treated with either CSE or HQ
(
Figure 9) but had no effect on cells receiving H O . Interestingly, there was a small but significant
2
2
increase in the NF-κB transcriptional activity in both A459 and BEAS-2B cells treated simultaneously
with TNF and CMC, but no interaction between TNF and CMCO was detected in these cells.
Figure 9. Effects of CMC (C), (4S)-CMCO (S), and (4R)-CMCO (R) on activation of NF-κB pathway by
stressors in A549 and BEAS-2B cells. The luciferase activities in the treated cells are normalized for
the reporter activity in wells receiving no inhibitor (N). The stressor concentrations are indicated in
Figure 6. The inhibitor concentrations were 1 mM in all experiments. The error bars are SDs; n = 3.
The differences of means were probed by the one-way ANOVA; * indicates a statistically significant
difference between an inhibitor treatment and “no inhibitor” control; # indicates a statistically significant
difference between CMC and CMCO treatments, p < 0.05.

Pharmaceuticals 2020, 13, 270
10 of 16
2
.3.4. The AP-1 Pathway
The Activator Protein-1 pathway is a pro-inflammatory signaling pathway that is activated under
conditions of increased intracellular oxidative stress [22]. Indeed, all four stressors could induce
significant activation of this pathway in both A549 and BEAS-2B cells, as evidenced by data shown
in Figure 6. However, the reporter responses to particular stressors differed between these cell lines.
Thus, BEAS-2B was significantly more sensitive to CSE, as compared to A549, while the reporter lines
responses to H O were in the reverse order.
2
2
Both CMC and CMCO could reduce activation of the AP-1 pathway in A549 cells challenged with
the stressors, but in BEAS-2B cells, such effect was observed only against CSE (Figure 10). Surprisingly,
both CMC and CMCO did enhance the pro-inflammatory effect of HQ in BEAS-2B reporters of the
AP-1 pathway.
Figure 10. Effects of CMC (C), (4S)-CMCO (S), and (4R)-CMCO (R) on activation of AP-1 by stressors
in A549 and BEAS-2B cells. The luciferase activities in the treated cells are normalized for the
reporter activity in wells receiving no inhibitor (N). The stressor concentrations are indicated in Figure 6.
The inhibitor concentrations were 1 mM in all experiments. The error bars are SDs; n = 3. The differences
of means were probed by the one-way ANOVA; * indicates a statistically significant difference between
an inhibitor treatment and “no inhibitor” control; # indicates a statistically significant difference between
CMC and CMCO treatments, p < 0.05.
3
. Discussion
This work was aimed at establishing whether there are structural and functional similarities
between antioxidant drug CMC and its main product of metabolic oxidation in humans, CMCO,
because CMCO is considered functionally inactive due to a partial oxidation of the thioether sulfur [23].
This suggestion is based on an indirect observation of CMC efficacy that differed in patients with
higher and lower rates of CMC metabolism [4]. However, to the best of our knowledge, no previous
clinical, in vivo or in vitro laboratory studies compared efficacy of CMC and CMCO directly.
Non-enzymatic mild oxidation of CMC in vitro brought about a mixture of the (4R)- and
(
4S)-S-carboxymethyl-L-cysteine sulfoxide that were also detected in humans taking the CMC drug [24].
In vivo, oxidation of circulating CMC is believed to occur primarily in the liver, and no evidence is
available to suggest that the oxidation proceeds stereospecifically [4].
Fractional crystallization allowed for complete separation of the CMCO enantiomeric forms.
Both (4R)- and (4S)-CMCO molecules showed structural similarity with CMC, both by conformation and
charge distribution. Accordingly, the electrostatic forces defined the energetics of crystal packing in both
CMC and CMCO crystal structures. An unusually strong hydrogen bond between
groups was detected in the orthorhombic crystals of (4R)-CMCO, thus confirming an earlier report of
this phenomenon [ ]. Since we collected the X-ray diffraction data at much lower temperature (100 K)
than the previous study (295 K), it allowed us to determine the structure of (4R)-CMCO with higher
α- and δ-carboxylate
6

Pharmaceuticals 2020, 13, 270
11 of 16
confidence. Our data assigned the proton, which participates in the aforementioned H-bonding, to the
-carboxylate oxygen O5, as it would be expected for an aliphatic -aminodicarboxylic acid, based on
δ
α
considerations of the acid-base properties of this type of molecules [7,11].
Next, our data have demonstrated that CMCO, along with CMC, can protect polymeric nucleic
acid from degradation by hydroxyl free radicals. Because production of biologically relevant ROS
usually involves a process of biomolecules oxidation in presence of a redox-cycling catalyst, such as
transition metals copper or iron, successful antioxidants are represented by molecules that inhibit
the redox-cycling process. Alternatively, if production of ROS is sufficiently slow, strong reducing
agents can quench accumulating ROS, thus preventing oxidative damage to the target of the protection.
Both CMC and CMCO can chelate Cu2 ions [25
+
,
26] and act as reducing agents due to a presence
of the thioether group [27], although potential reducing capacity of the sulfur in CMCO is one-half
of that in CMC. Notably, a good copper(II) chelator but poor reducing agent, 2-aminohexanoic acid,
as well as an excellent reducing agent but poor copper(II) chelator, N-acetyl-L-cysteine, failed to
protect DNA from copper-mediated oxidative degradation, in our experiment. In contrast, a versatile
intracellular antioxidant, glutathione, which is well known for both its reducing power and copper
binding capabilities [28], potently inhibited oxidative degradation of DNA in our test. It should be
pointed out that since this experiment was performed outside of a biological milieu, its significance
can only be considered as a proof-of-principle for a hypothesis that CMCO can act likewise to CMC as
a chemical antioxidant. Biological relevance of similarities in functional activities of CMC and CMCO
was further examined in the cell culture.
Although CMC is considered a mucolytic, this molecule lacks free thiol groups that are needed to
break the S-S bonds in mucus proteins that stabilize the matrix. Rather, CMC is believed to relieve
inflammation and decrease mucus secretion in the lower airways [3]. Our study compared the ability
of CMC and CMCO to affect cell signaling pathways, which are sensitive to oxidative stress and
pro-inflammatory stimuli, in human bronchial epithelial and alveolar cells. As shown in Figure 11,
there is generally a good correlation between the activities (or non-activities) displayed by CMC and
CMCO in these experiments. However, one can notice (Figures 6, 8 and 9) that there is a substantial
difference between the activities of the (4R)- and (4S)-CMCO epimers, with the former providing
significantly more protection against the cell stressors. Such a pattern may hint at stereospecific
mechanisms of CMCO utilization by the cells, which could include its reduction to CMC, for example.
Figure 11. Summarized correlations between effects of: (a) CMC and (4S)-CMCO; (b) CMC and
(4R)-CMCO on activation of the four transcription factors in A549 (squares) and BEAS-2B (circles) cells,
as shown in Figures 7–10. Data points depicted below the diagonals signify stronger inhibitory effects
displayed by CMCO as compared to CMC. Color codes for the stressors: grey—CSE, green—HQ;
blue—H O , red—TNF.
2
2

Pharmaceuticals 2020, 13, 270
12 of 16
Another pattern noticeable in Figure 11 is that CMC performs better than CMCO when protecting
cells from CSE- or H O -induced stresses. In contrast, cellular responses to pro-inflammatory TNF in
2
2
presence of CMC were, in a number of cases, stronger, as compared to the CMCO treatments. In fact,
CMC did enhance the NF-κB activation in the TNF-treated cells.
In conclusion, results of this study have demonstrated an existence of some structural and
functional similarities between S-carboxymethyl-L-cysteine drug and two epimers of its metabolite,
S-carboxymethyl-L-cysteine sulfoxide. Precise structures of (4S)-CMCO and two polymorphs of
(4R)-CMCO, as well as their proton distribution, conformational and energetic similarities to CMC,
were determined. In a DNA oxidative degradation chemical model, CMCO exhibited antioxidant
activities that were comparable to CMC. In cell-based models of pulmonary inflammation and oxidative
stress, the CMCO protective effects correlated closely with those displayed by CMC, too. Because these
results were obtained in vitro only, their significance for clinical use of CMC could not be established.
However, these data might be informative for future pharmacodynamics studies of CMC and could
contribute methodologically to a wider use of cell signaling reporters to characterize pharmaceuticals,
nutraceuticals, or toxic agents.
4
. Materials and Methods
All commercial reagents and cell culture media were purchased from Fisher (Fair Lawn, New Jersey,
NJ, USA) or Sigma-Aldrich (St Louis, Missouri, MO, USA) companies. Cigarette smoke extract (CSE)
has been prepared following a simplified protocol [29] with some modifications: the mainstream
smoke from four unfiltered cigarettes was bubbled through 4 mL phosphate-buffered saline, pH 7,
using a 20 mL syringe pump. CSE was immediately sealed and kept on ice until use.
A549 (passage 81) human alveolar and BEAS-2B (passage 38) human bronchial epithelial cell lines
were purchased from the American Type Culture Collection. The cells were maintained in DMEM
media supplemented with 5% Newborn Calf Serum and 1% of the penicillin/streptomycin antibiotic
◦
cocktail, at 37 C, 100% humidity, and 5% CO .
2
Optical rotation data were collected using a Jasco P-1030 polarimeter (JASCO, Tokyo, Japan).
Chromatographic analyses were performed with Hitachi (L-8900) amino acid analyzer, using the
manufacturer’s lithium buffer system (Hitachi Group, Tokyo, Japan). All fluorescence and luminescence
measurements were done using a Synergy MX plate reader (BioTek Instruments, Winooski, Vermont,
VT, USA).
4
.1. Synthesis and Crystallization of S-carboxymethyl-L-cysteine sulfoxide
The synthetic CMCO preparation procedure generally followed a protocol originally developed
by Meese [30]. In one experiment, 35.8 g (0.2 moles) of S-carboxymethyl-L-cysteine were dissolved
in 134 mL water containing 16.8 g NaHCO and cooled in an ice bath. To the solution were added,
3
◦
dropwise, 40 mL cold 30% H O , and the reaction mixture was left for 20 h at 4 C. The completeness of
2
2
the oxidation reaction was confirmed chromatographically and the excess of H O was destroyed with
2
2
catalytic amounts of MnO . The reaction mixture was then filtered, acidified with 40 mL 5N HCl, and left
2
◦
for 2 days at 8 C. A crystalline mass had formed and was separated by filtration. Chromatography
and polarimetry data confirmed the formation of a 1:1 mixture of two CMCO epimers; [
c = 1.0, 0.2 N HCl); literature [30] [
for C H NO S: 7.82%. In another experiment, the crystallization step was carried at 45 C for 16 h.
2
3
◦
α
]D = +31.4
21
◦
(
α
]D = +28.2 (c = 1.0, 1 N HCl); nitrogen analysis: 7.74%, calcd
◦
5
9
4
The collected crystals, shaped as blocks and belonging to the triclinic space group, had a specific optical
2
3
◦
rotation value consistent with the (4R)-epimer of S-carboxymethyl-L-cysteine sulfoxide: [
α
]D = +59.4
21
◦
(
c = 1.0, 0.2 N HCl); literature [30] [
α
]D = +63.7 (c = 1.0, 1 N HCl). The mother liquor was cooled to
C and deposited an additional crop of the (4R)-epimer, [α]D = +53.5 (c 1, 0.2 N HCl), in the shape of
◦
23
◦
0
needles, the orthorhombic space group. The remaining mother liquor contained predominantly (>90%)
the (4S)-epimer, according to a chromatographic analysis of the sample. This solution was filtered,
◦
diluted with an equal volume of ethanol, and kept at 8 C for 3 days, to deposit monoclinic plates

Pharmaceuticals 2020, 13, 270
13 of 16
]D22 = +1.1 (c = 1.0, 0.2 N HCl); literature [30
◦
of chromatographically pure (>95%) (4S)-epimer, [α ]
21
◦
[
α]D = −4.2 (c = 1.0, 1 N HCl).
.2. X-ray Diffraction Studies
Crystal data, data collection, and structure refinement details are summarized in Table S1.
4
Oxygen-bound H atoms were located from the difference map and those bonded to carbon were placed
in calculated positions. The coordinates of all H atoms were refined freely while the thermal parameters
were constrained to ride on the carrier atoms, Uiso(H) = 1.2–1.5 Ueq(C,O). Structure refinement and
visualization was done with computer programs SHELXL [31], OLEX2 [32], Mercury [33].
4
.3. In Vitro DNA Protection
To a 200 L solution of 50
PBS, pH 7, were added, in order, CMCO or other antioxidants, CuCl (final concentration 50
µ
µ
g polymeric DNA (from calf thymus, Sigma) per mL of Chelex-treated
µ
M), H O
2
2
2
(
(
final concentration 2 mM), and ascorbic acid (final concentration 2 mM). Alternatively, hydroquinone
final concentration, 4 mM) was added instead of H O /ascorbate. The reaction was left to proceed at
2
2
room temperature for 2 h and then stopped by addition of DTPA to a final concentration of 5 mM.
Ethidium bromide was added at 20 g/mL, and the fluorescence of the solutions was measured at
08 nm excitation/590 nm emission wavelengths.
µ
5
4
4
.4. Signaling Pathway Reporters
.4.1. Reporter Vectors
Super piggyBac transposase expression vector PB210PA-1 was purchased from System Biosciences.
The preparation and validation of reporter plasmids carrying insulated piggyBac transposon constructs,
which contain transcriptional response element (TRE) and reporter genes, firefly or Brazilian click
beetle luciferase, and a copepod green fluorescent protein, as shown in Figure 5, were reported
earlier [16
,17,34]. Before transfections, the integrity of plasmids was verified by DNA electrophoresis
and sequence analysis.
4
.4.2. Stable Transfections
To generate stable reporter lines, the original A549 and BEAS-2B cells were seeded into wells of
4
a 96-well plate, at 2
5
×
10 cells per well in antibiotic-free DMEM/F12 medium supplemented with
% NCS and left to adhere for 6 h. The cells were then treated with a mixture of 100 ng of a reporter
plasmid and 33 ng of Super piggyBac transposase plasmid complexed with TransIT X2 transfection
reagent (Mirus) at 1:2 ( g DNA/ L) ratios. After 16 h, the regular media were added and the cells were
left to proliferate for next 48–72 h. The transfected cells were then treated with the selecting antibiotic
g/mL puromycin) for another week, and the surviving cells were expanded for cryopreservation
and activity validation.
µ
µ
(5 µ
4
.4.3. Transcriptional Activity Reporter Assay
4
In a typical experiment, reporter cells were seeded into wells of a 96-well plate, at 1
×
10 cells
per well in DMEM/F12 medium supplemented with 5% NCS and penicillin/streptomycin antibiotic
and left to proliferate for 48 h. The medium was changed to the experimental medium, Corning
Serum-free Medium, which is essentially a Phenol Red-free DMEM/F12 formulation with undisclosed
additions of RPMI-1640 and McCoy’s 5A, and is supplemented with 1 g/L BSA, 2 mg/L insulin, 2 mg/L
transferrin, and 2 µg/L selenite. After an 18 h adaptation period, the medium was replaced with fresh
experimental medium, now containing stressor and inhibitor agents. The experimental treatments
◦
lasted 18 h in standard conditions (37 C, 100% humidity and 5% CO ). The cells were then lysed in
2
7
0
µL of the Luciferase reporter lysing buffer (Promega). GFP content in the lysates was determined by
fluorescence at the 482(9)/512(17) nm wavelength (slit width) setup; this was followed by an addition of

Pharmaceuticals 2020, 13, 270
14 of 16
the luciferase substrate (Promega) and luminescence readings in the wells. The GFP fluorescence values
were used for both evaluation of relative cell transcriptional activity/proliferation and normalization of
the reporter luciferase activities in respective wells [16].
4
.5. Molecular Modeling and Statistical Analysis
The Hirshfeld surfaces analyses and DFT calculations, at the B3LYP/6-31G(d,p) theory level,
were performed using CrystalExplorer software (version 17.5) [12,35]. Statistical tests and plots were
done by using SigmaPlot (version 11.0).
Supplementary Materials: The following are available online at http://www.mdpi.com/1424-8247/13/10/270/
s1, Figure S1: Ion-exchange chromatograms of CMCO crystalline forms; Figure S2: The molecular packing
in t-(4R)-CMCO; Figure S3: The molecular packing in o-(4R)-CMCO; Figure S4: The molecular packing in
m-(4S)-CMCO; Figure S5: Interaction energies in crystal structure of o-(4R)-CMCO; Figure S6: Interaction energies
in crystal structure of m-(4S)-CMCO; Figure S7: Energy framework for pairwise interactions in t-(4R)-CMCO;
Figure S8: Energy framework for pairwise interactions in o-(4R)-CMCO; Figure S9: Energy framework for pairwise
interactions in m-(4S)-CMCO; Table S1: Crystal data, data collection, and structure refinement details; Table S2:
Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters for t-(4R)-CMCO; Table
S3: Atomic displacement parameters for t-(4R)-CMCO; Table S4: Bond distances and angles for t-(4R)-CMCO; Table
S5: Hydrogen-bond geometry t-(4R)-CMCO; Table S6: Fractional atomic coordinates and isotropic or equivalent
isotropic displacement parameters for o-(4R)-CMCO; Table S7: Atomic displacement parameters for o-(4R)-CMCO;
Table S8: Bond distances and angles for o-(4R)-CMCO; Table S9: Hydrogen-bond geometry o-(4R)-CMCO;
Table S10: Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters for
m-(4S)-CMCO; Table S11: Atomic displacement parameters for m-(4S)-CMCO; Table S12: Bond distances and
angles for m-(4S)-CMCO; Table S13: Hydrogen-bond geometry m-(4S)-CMCO. The complete crystallographic
data for the structural analysis have been deposited with the Cambridge Crystallographic Data Centre, CCDC
#
# 2027234, 2027235, 2027236. Copies of this information may be obtained free of charge from the Director,
Cambridge Crystallographic Data Centre, 12 Union Road, Cambridge, CB2 1EZ, UK. (Fax: +44-1223-336033,
e-mail: deposit@ccdc.cam.ac.uk or via: www.ccdc.cam.ac.uk).
Author Contributions: J.K.W., project conceptualization, chemical synthesis, and analysis; S.P.K., structural
data collection and interpretation; V.V.M., project conceptualization, methodology, biological data collection and
interpretation, writing the manuscript; T.P.M., project conceptualization, administration, and funding acquisition.
All authors have read and agreed to the published version of the manuscript.
Funding: This research was supported, in part, by the University of Missouri Experiment Station Chemical
Laboratories and by the USDA National Institute of Food and Agriculture, Hatch project 1023929.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
L
ó
pez-Campos, J.L.; Tan, W.; Soriano, J.B. Global burden of COPD. Respirology 2016, 21, 14–23. [CrossRef]
[PubMed]
Aoshiba, K.; Zhou, F.; Tsuji, T.; Nagai, A. DNA damage as a molecular link in the pathogenesis of COPD in
smokers. Eur. Respir. J. 2012, 39, 1368–1376. [CrossRef] [PubMed]
Maccio, A.; Madeddu, C.; Panzone, F.; Mantovani, G. Carbocysteine: Clinical experience and new perspectives
in the treatment of chronic inflammatory diseases. Expert Opin. Pharmacother. 2009, 10, 693–703. [CrossRef]
[PubMed]
4
5
.
.
Mitchell, S.C.; Steventon, G.B. S-Carboxymethyl-L-cysteine. Drug Metab. Rev. 2012, 44, 129–147. [CrossRef]
Mitchell, S.C.; Steventon, G.B. Phenylalanine 4-monooxygenase: The “sulfoxidation polymorphism”.
Xenobiotica 2020, 50, 51–63. [CrossRef]
6.
7.
8.
9.
Staffa, J.A.; Zervos, C.; Mighell, A.D.; Hubbard, C.R. S-Carboxymethyl-L-cysteine sulfoxide (configuration
2
R:4R). Acta Crystallogr. 1976, B32, 3132–3135. [CrossRef]
Hirayama, N.; Shirahata, K.; Ohashi, Y.; Sasada, Y. Structure of the
α form of L-glutamic acid. The α-β
transition. Bull. Chem. Soc. Jpn. 1980, 53, 30–35. [CrossRef]
Lehmann, M.S.; Nunes, A.C. A short hydrogen bond between near identical carboxyl groups in the
α-modification of L-glutamic acid. Acta Crystallogr. 1980, B36, 1621–1625. [CrossRef]
Hubbard, C.R.; Mighell, A.D.; Staffa, J.A.; Zervos, C.; Konopelski, J.P. S-Carboxymethyl-L-cysteine sulfone.
Acta Crystallogr. 1976, B32, 2723–2725. [CrossRef]

Pharmaceuticals 2020, 13, 270
15 of 16
1
0. Mighell, A.D.; Hubbard, C.R.; Harris, J.; Staffa, J.A.; Zervos, C. S-Carboxymethyl-L-cysteine. Acta Crystallogr.
979, B35, 1258–1261. [CrossRef]
1. Low, J.N.; Howie, R.A.; Scrimgeour, C.M.; Watt, P.W. The structure of L-
988, C44, 1762–1764. [CrossRef]
1
1
α
-aminoadipic acid. Acta Crystallogr.
1
1
1
2. Spackman, M.A.; Jayatilaka, D. Hirshfeld surface analysis. CrystEngComm 2009, 11, 19–32. [CrossRef]
3. Lapenna, D.; Mezzetti, A.; de Gioia, S.; Pierdomenico, S.D.; Daniele, F.; Cuccurullo, F. Plasma copper and
lipid peroxidation in cigarette smokers. Free Radic. Biol. Med. 1995, 19, 849–852. [CrossRef]
4. Peng, C.; Arthur, D.; Liu, F.; Lee, J.; Xia, Q.; Lavin, M.F.; Ng, J.C. Genotoxicity of hydroquinone in A549 cells.
Cell Biol. Toxicol. 2013, 29, 213–227. [CrossRef]
1
1
1
5. Yang, Q.; Hergenhahn, M.; Weninger, A.; Bartsch, H. Cigarette smoke induces direct DNA damage in the
human B-lymphoid cell line Raji. Carcinogenesis 1999, 20, 1769–1775. [CrossRef]
6. Mossine, V.V.; Waters, J.K.; Hannink, M.; Mawhinney, T.P. piggyBac Transposon plus insulators overcome
epigenetic silencing to provide for stable signaling pathway reporter cell lines. PLoS ONE 2013, 8, e85494.
[CrossRef]
1
7. Mossine, V.V.; Waters, J.K.; Chance, D.L.; Mawhinney, T.P. Transient proteotoxicity of bacterial virulence
factor pyocyanin in renal tubular epithelial cells induces ER-related vacuolation and can be efficiently
modulated by iron chelators. Toxicol. Sci. 2016, 154, 403–415. [CrossRef]
1
1
8. Meek, D.W. The p53 response to DNA damage. DNA Repair 2004, 3, 1049–1056. [CrossRef]
9. Suzuki, T.; Yamamoto, M. Stress-sensing mechanisms and the physiological roles of the Keap1-Nrf2 system
during cellular stress. J. Biol. Chem. 2017, 292, 16817–16824. [CrossRef]
2
2
0. Sekine, T.; Hirata, T.; Mine, T.; Fukano, Y. Activation of transcription factors in human bronchial epithelial
cells exposed to aqueous extracts of mainstream cigarette smoke in vitro. Toxicol. Mech. Methods 2016, 26,
2
2–31. [CrossRef]
1. Singh, A.; Misra, V.; Thimmulappa, R.K.; Lee, H.; Ames, S.; Hoque, M.O.; Herman, J.G.; Baylin, S.B.;
Sidransky, D.; Gabrielson, E.; et al. Dysfunctional KEAP1-NRF2 interaction in non-small-cell lung cancer.
PLoS Med. 2006, 3, e420. [CrossRef]
2
2
2
2
2. Park, H.S.; Kim, S.R.; Lee, Y.C. Impact of oxidative stress on lung diseases. Respirology 2009, 14, 27–38.
[CrossRef] [PubMed]
3. Hooper, C.; Calvert, J. The role for S-carboxymethylcysteine (carbocisteine) in the management of chronic
obstructive pulmonary disease. Int. J. Chronic Obstr. Pulm. Dis. 2008, 3, 659–669.
4. Waring, R.H.; Mitchell, S.C. The metabolism and elimination of S-carboxymethyl-L-cysteine in man.
Drug Metab. Dispos. 1982, 10, 61–62.
5. Nakon, R.; Beadle, E.M., Jr.; Angelici, R.J. Binding of copper(II), nickel(II), zinc(II), and cobalt(II) by
3-[(carboxymethyl)thio]-L-alanine and 3-[(-aminoethyl)thio]-L-alanine. J. Am. Chem. Soc. 1974, 96, 719–725.
[CrossRef] [PubMed]
2
6. Hermann, P.; Lemke, K. Ionization constants and stability constants of copper(II) complexes of some amino
acids and their sulfur-containing analogs. Hoppe-Seyler’s Z. Physiol. Chem. 1968, 349, 390–394. [CrossRef]
[PubMed]
2
2
2
7. Nishimura, H.; Higuchi, O.; Tateshita, K. Antioxidative activity of sulfur-containing compounds in Allium
species for human LDL oxidation in vitro. BioFactors 2004, 21, 277–280. [CrossRef] [PubMed]
8. Battin, E.E.; Brumaghim, J.L. Metal specificity in DNA damage prevention by sulfur antioxidants. J. Inorg. Biochem.
2
008, 102, 2036–2042. [CrossRef] [PubMed]
9. Su, Y.; Han, W.; Giraldo, C.; De Li, Y.; Block, E.R. Effect of cigarette smoke extract on nitric oxide synthase in
pulmonary artery endothelial cells. Am. J. Respir. Cell Mol. Biol. 1998, 19, 819–825. [CrossRef]
0. Meese, C.O. S-Carboxymethyl-L-cysteine (R)- and (S)-sulfoxide. Arch. Pharm. 1987, 320, 473–474. [CrossRef]
1. Sheldrick, G.M. Crystal structure refinement with SHELXL. Acta Crystallogr. 2015, C71, 3–8.
2. Dolomanov, O.V.; Bourhis, L.J.; Gildea, R.J.; Howard, J.A.K.; Puschmann, H. OLEX2: A complete structure
solution, refinement and analysis program. J. Appl. Crystallogr. 2009, 42, 339–341. [CrossRef]
3. Macrae, C.F.; Bruno, I.J.; Chisholm, J.A.; Edgington, P.R.; McCabe, P.; Pidcock, E.; Rodriguez-Monge, L.;
Taylor, R.; van de Streek, J.; Wood, P.A. Mercury CSD 2.0—New features for the visualization and investigation
of crystal structures. J. Appl. Crystallogr. 2008, 41, 466–470. [CrossRef]
3
3
3
3

Pharmaceuticals 2020, 13, 270
16 of 16
3
4. Mossine, V.V.; Chance, D.L.; Waters, J.K.; Mawhinney, T.P. Interaction of bacterial phenazines with
colistimethate in bronchial epithelial cells. Antimicrob. Agents Chemother. 2018, 62, e02349. [CrossRef]
PubMed]
[
3
5. MacKenzie, C.F.; Spackman, P.R.; Jayatilaka, D.; Spackman, M.A. CrystalExplorer model energies and energy
frameworks: Extension to metal coordination compounds, organic salts, solvates and open-shell systems.
IUCrJ 2017, 4, 575–587. [CrossRef] [PubMed]
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
CC BY) license (http://creativecommons.org/licenses/by/4.0/).
(
