1100 J . Org. Chem., Vol. 63, No. 4, 1998
Thompson and Hirsch
or reduced pressure, and the residue was vacuum-distilled
using a short-path distillation column, yielding the 1,2-bis-
(trimethylsiloxy)cycloalkene.
because one of their carbonyls is external to the ring. In
addition, Rhoads pointed out the possibility of their
working near the isokinetic temperature.
Gen er a l P r oced u r e for th e Syn th esis of 1, (n + 3)-
Bis(tr im eth ylsiloxy)bicyclo[n + 1.1.0]a lk a n es 5.5,6 A solu-
tion of diethylzinc (2.0-2.8 equiv) in toluene (Aldrich, 15 wt
% (1.1 M)) was added dropwise over 1 h to a mechanically
stirred solution of 1,2-bis(trimethylsiloxy)cycloalkene (4) and
diiodomethane (2.4-2.7 equiv) (Aldrich, 99%) in dried toluene
at 0 °C (ice bath) under a dried N2 atmosphere. After the
addition of the diethylzinc solution was complete, the reaction
mixture was stirred at rt for 2-2.5 h. Next, the reaction
mixture was slowly poured into 100 mL of cold saturated
aqueous NH4Cl. Quenching the excess diethylzinc in this
manner minimized bubbling resulting from the liberation of
ethane. The mixture was vacuum-filtered, and the white
precipitate was washed with 100 mL of n-hexane. The filtered
aqueous layer was extracted with the hexane wash from above
and was extracted twice more with 100 mL of n-hexane. The
combined organic layers were washed with 100 mL of satu-
rated aqueous NH4Cl and 100 mL of saturated aqueous brine.
The hexane layer was dried (anhyd Na2SO4), and after
filtration, the solvent was removed under reduced pressure.
The residue was vacuum-distilled using a short-path distilla-
tion column to afford the desired compound.
Gen er a l P r oced u r e for th e Syn th esis of Cycloa lk a n e-
1,3-d ion es 3.5,6,7j,15 Anhydrous FeCl3 (4 equiv) (MCB, sublimed,
reagent) was quickly transferred to a round-bottom flask under
an N2 atmosphere. Since anhyd FeCl3 dissolves exothermi-
cally, the dried DMF was added slowly with mechanical
stirring to the ice bath-cooled flask. A solution of the bicy-
cloalkane 5 in dried DMF was added to the stirred mixture,
and the reaction was stirred for 3-3.5 h at 60-70 °C. The
cooled reaction mixture was poured into 100 mL of cold 10%
aqueous HCl, and the mixture was extracted with 100 mL of
CHCl3 four times. The combined CHCl3 extracts were washed
with 100 mL of 10% aqueous HCl two to three times and then
with 100 mL of saturated aqueous brine. The organic layer
was dried over anhyd Na2SO4 or MgSO4 and suction-filtered
and the solvent removed under reduced pressure. If necessary,
the residue was reextracted with 50 mL of CHCl3 and 3 × 50
mL of aqueous HCl to remove residual DMF, followed by
washing with 50 mL of brine. The CHCl3 solution was dried
with anhyd Na2SO4 and filtered and the solvent removed
under reduced pressure. The crude dione was distilled (bulb-
to-bulb) under reduced pressure and then purified by chro-
matography.
Exp er im en ta l Section
The NMR spectra were obtained in solutions of deuterio-
chloroform (CDCl3) with 0.03% tetramethylsilane (TMS) except
for the trimethylsiloxy compounds, which were obtained in
CDCl3. Ultraviolet spectra were obtained in n-hexane (HPLC
grade) unless otherwise noted. GC-MS data were obtained
with a J &W DB-1 (30 m × 0.25 mm i.d., 0.25 µm film
thickness) column or a Hewlett-Packard HP1 (12 m × 0.2 mm
i.d., 0.33 µm film thickness) column. GC analyses were
performed with a J &W DB-1 (30 m × 0.53 mm i.d., 5 µm film
thickness) column, a J &W DB-1 (15 m × 0.555 mm i.d., 1.5
µm film thickness) column, or an XF1150 6 ft × 4 mm glass
column. Elemental analysis was performed by Analytische
Laboratorium, Elbach, Germany. Flash column chromatog-
raphy was performed utilizing E. M. Sciences silica gel 60
(particle size 0.040-0.063 mm) with suitable solvents in glass
columns with 1.5, 2, or 3 cm i.d. TLC analyses were performed
on Merck silica gel 60 F254 precoated glass plates (layer
thickness 0.25 mm) with detection by either shortwave UV,
vanillin spray, or iodine chamber. All syntheses were per-
formed using oven-dried glassware under a nitrogen atmo-
sphere. Both DME and THF were distilled from Na/benzophe-
none prior to use, while DMF was stored over BaO and was
distilled from either BaO or CaH2 under reduced pressure (20
mmHg) prior to use. The DMSO was stored over BaO, distilled
under reduced pressure, and further dried by refluxing over
CaH2 followed by distillation under reduced pressure. The
HMPA was refluxed over BaO under reduced pressure with
an N2 atmosphere followed by distillation. The HMPA was
then refluxed and distilled from Na under reduced pressure
with an N2 atmosphere. Toluene was refluxed and distilled
from either Na or CaH2 prior to use. Trimethylsilyl chloride
(TMSCl) (Aldrich, 98%) was distilled from CaH2 prior to use.
Reagents were generally used as obtained from the supplier.
Details on individual experiments are found in the Supporting
Information.
3-Eth oxy-2-cycloh ep ten -1-on e (1, n ) 3, R ) Et). Modi-
fying the procedure of Pirrung and Webster,6 15.5 mL (15.5
mmol) of potassium tert-butoxide (1.0 M in THF) was added
to a solution of 1.56 g (12.4 mmol) of cycloheptane-1,3-dione
(3, n ) 3) in 35 mL of dried THF at 0 °C. After the yellow-
orange suspension was stirred for 1 h at 0 °C, 20 mL (20 mmol)
of triethyloxonium tetrafluoroborate (TEO) (1.0 M in CH2Cl2,
Aldrich) was added to the reaction. The reaction was stirred
for 30 min at 0 °C. The potassium tert-butoxide and TEO
solutions were added to the reaction a second (8 mmol each)
and third (10 mmol each) time to drive the reaction toward
completion. The reaction mixture was diluted with 40 mL of
diethyl ether and then filtered through a 20 g plug of neutral
alumina. The solvents were removed under reduced pressure
to give a dark yellow liquid, which was dissolved in 10 mL of
ether and filtered through a 5 g plug of neutral alumina. After
removal of solvents and purification by flash chromatography
(95 CH2Cl2/5 ether), the residue was distilled (bulb-to-bulb,
80-100 °C, 5 mmHg) to yield 0.89 g (47%, GC purity 88%) of
a colorless liquid: GC-MS m/z 156, 155, 154 (M+), 126, 125,
109, 98, 97 (base), 84, 82, 81, 69, 67, 55, 41, 39. Repeated flash
chromatography (same conditions) resulted in 0.65 g (34%) of
pure product (GC purity 99%): IR (neat) 3450, 3230, 3040,
Gen er a l P r oced u r e for th e Syn th esis of 1,2-Bis(tr i-
m eth ylsiloxy)cycloa lk en es 4.5,7j,13 A solution of the dimeth-
ylalkanediester in dried toluene was slowly added, dropwise,
to a stirred solution of cleaned Na sand and TMSCl in dried
toluene at the temperature specified in the individual proce-
dure. The cleaned Na was prepared14 by heating pieces of Na
in toluene until melted and pouring the molten Na into dried
toluene. The clean Na balls were easily separated from the
oxidized Na residues. The Na sand14 was prepared in the
reaction flask by vigorously stirring (5-10 min) the weighed,
clean Na balls in refluxing toluene until a fine suspension of
Na was obtained. A Hershberg-type wire paddle was utilized
to stir the Na. The heat was removed with continued stirring
until the Na suspension solidified. After addition of the diester
was complete, the stirred mixture was refluxed until the
reaction was complete and then cooled to room temperature.
Generally, the reaction turned deep purple upon addition of
the diester. The mixture was vacuum-filtered using a sintered
glass funnel, and the purple precipitate was rinsed with 100-
200 mL of dried toluene. The precipitate, containing excess
Na, was carefully treated with 2-propanol. The toluene was
removed from the combined toluene filtrates at atmospheric
1
1625, 1590, 1441, 1368, 1230, 1174 cm-1; H NMR (CDCl3) δ
(13) Ruhlmann, K. Synthesis 1971, 236.
(14) Fieser, L. F.; Fieser, M. Reagents for Organic Synthesis; J ohn
Wiley and Sons: New York, 1967; pp 1022-1023. preparation of a fine
and clean Na sand is critical.
(15) Lewicka-Piekut, S.; Okamura, W. H. Synth. Commun. 1980,
10, 415.
