COMMUNICATION
12/14/14-Helix Formation in 2:1 α/β-hybrid peptides containing bicyclo[2.2.2]octane ring
constraints
Baptiste Legrand[a], Christophe André[a],Laure Moulat[a], Claude Didierjean[b], Patrick Hermet[c], Jean-
Louis Bantignies[d], Jean Martinez[a], Muriel Amblard*[a], Monique Calmès*[a]
[a]
Dr. B. Legrand§, Dr C. André§,, L. Moulat, Prof. J. Martinez, Dr. M. Calmès, Dr. M. Amblard, Institut des Biomolécules Max Mousseron
(IBMM) UMR 5247 CNRS-Université Montpellier-ENSCM- 15 avenue Charles Flahault - 34093 Montpellier cedex 5, France
E-mail: muriel.amblard@univ-montp1.fr,
monique.calmes@univ-montp2.fr
Homepage: http://www.ibmm.univ-montp1.fr
[b]
Dr C. Didierjean, CRM2, UMR 7063 CNRS Université de Lorraine, Boulevard des Aiguilletes, 54506 Vandoeuvre-lès-Nancy Cedex,
France
[c]
Dr P. Hermet, Institut Charles Gerhardt Montpellier, UMR-5253, CNRS, Université de Montpellier, ENSCM, Place E. Bataillon, 34095
Montpellier Cédex 5, France
[d] Prof. J.L Bantignies, Laboratoire Charles Coulomb, UMR 5221 CNRS-Université de Montpellier, 34095 Montpellier, France
§
These authors contributed equally to this work
Supporting information for this article is given via a link at the end of the document
Abstract: The highly constrained β-amino acid ABOC induces different types of helices in β urea and 1:1 α/β amide oligomers. The latter can
adopt 11/9- and 18/16-helical folds depending on the chain length in solution. Here we showed that short peptides alternating proteinogenic
α-amino acids and ABOC in 2:1 α/β repeat pattern adopted an unprecedented and stable 12/14/14-helix established through extensive NMR,
molecular dynamics and IR studies. While the 1:1 α-AA/ABOC helices diverged from the canonical α-helix, the helix formed by the 9-mer 2:1
α/β-peptide allowed the projection of the α-amino acid side chains in a spatial arrangement according to α-helix. Such finding constitutes an
important step toward the conception of functional tools, using ABOC residue as a potent helix inducer, for biological applications.
Main text
The propensity of short amino acid sequences with heterogeneous backbones able to adopt helical conformations was first
described by the groups of Gellman and Reiser for /-hybrid peptides containing a 1:1 alternation of -amino acids and rigid cyclic
-amino acids, i.e. trans-ACPC and cis-ACC respectively.[1,2] Further studies involving 3-, 2,2- or alkyl and cyclic 2,3-amino acids
have significantly extended the chemical and structural diversity of this heterogeneous backbone foldamer family.[3–16] The use of
diverse -amino acids led to a range of helical structures that have been enlarged with α/β-hybrid peptides containing different mode
of combinations of  and  residues. However, in this last case a limited set of examples have been reported that can be divided in
two groups, i.e. oligomers with repetitive 2:1, 1:2 or 2:2 : patterns,[17–20] or oligomers with aperiodic / sequence.[21–23] Interestingly,
oligomers involving trans-ACPC residue with 2:1 or 1:2 / residue patterns adopted distinctive helical structures with the
coexistence in each case of two helical forms in solution, whereas in crystal structures only a 10/11/11- and a 11/11/12-helix were
observed, respectively.[17,18] More recently, following the proposed stereochemical patterning approach,[19] Martinek and Reiser
demonstrated that a 2:2 alternation of cis-ACPC and -amino acids motifs resulted in a stable 9/12/9/12-helical structure.[20] Quite
differently, the group of Balaram observed helical folding in short peptides containing only one or two consecutive acyclic 3-amino
acids in combination with -amino acid including the strong helix inducing Aib, in both the solid state and in solution.[21,22]
Incorporation of proteogenic or unnatural -amino acids constitutes a convenient way to generate well-structured hybrid peptides
with a large diversity of functional groups. In this context, we recently investigated the structural properties of short oligomers
containing both the constrained β2,3,3-trisubstituted bicyclic amino acid ABOC residue[24] that has showed to promote helical
conformations in homo- and mixed oligoureas,[25,26] and proteogenic -amino acid in a 1:1 alternating pattern.[16] We demonstrated
that these /-hybrid peptides adopt an 11/9-helix in the solid state, while a conformational polymorphism as a chain-dependent
phenomenon was observed in solution. In this study, we propose to extend the conformational analysis within the relatively
unexplored 2:1 /-hybrid peptides by using the ABOC building block as a potent helix inducer. For that purpose, three 2:1 /-hybrid
peptides of different lengths (1-3) containing the periodic trimer Ala-(S)-ABOC-Phe were synthesized and their progressive folding
evaluated using crystallographic structure analysis, NMR, FT-IR and CD spectroscopies.

Chemistry - A European Journal
10.1002/chem.201602746
COMMUNICATION
Figure 1. Structure of (Ala-(S)-ABOC-Phe)n /β-hybrid peptides.
Each of the α/β-hybrid peptides was prepared in solution by stepwise assembly, using the standard N-Boc protected peptide
synthesis strategy (Figure 1, see SI). A N-benzhydrylglycolamide ester group (OBg)[27] was introduced at the C-terminal part of
oligomers for crystallization trials and an isobutyryl group was used as capping at the N-terminal part.
Figure 2 XRD and NMR studies of the trimer 1, hexamer 2 and nonamer 3. (a) HN/Hα and HN/HN-Haro regions of the ROESY spectrum of 3 recorded in CD3OH at 298 K. (b) Typical non-
sequential NHi/NHi+2 (plain arrows), NHi/Hαi-2, NHi/Hαi-3 (dashed arrows) and NHi/Hαi+3 (dotted arrows) backbone NOE cross-peaks of the (Ala-(S)-ABOC-Phe)n peptides. (c) Crystal structure
of 1. (d) and (e) superimposition of the 20 lowest energy NMR solution structures of 2 and 3. (f) Superimposition of the crystal structure of 1 and NMR solution structures of 3. (g)
Characteristic hydrogen-bond pattern stabilizing the (Ala/(S)-ABOC/Phe)n structures. For the NMR structures, the disordered C-terminal OBg ester and protons were omitted for clarity
(hydrogen bonds are represented by dotted lines).
Attempts to crystallize oligomers 2 and 3 failed, despite the screening of a broad range of solvent conditions and variation of the
capping groups such as a C-terminal benzyl ester and a N-terminal Boc or iPrCO groups. However, suitable crystals of the trimer 1
were generated by slow evaporation of a methanol solution (Figure 2c and S1). In the solid state, the trimer 1 exhibited a C11/12 turn
stabilized by two hydrogen bonds between the CO(iPr) and the NH(Phe), and between the CO(OBg) and the NH(Ala) forming a C11
and a C12 pseudocycle, respectively. As previously found,[24] ABOC residue displayed a drastically reduced conformational freedom
with a θ2 torsional angle locked around 60° that is favorable for the design of helical foldamers. Other backbone torsional angles for
ABOC, Ala and Phe residues are reported in Table 1.
To gain detailed structural information, NMR studies were carried out in CD3OH for the compounds 1, 2 and 3. NMR signals were
sharps and well-dispersed and all resonances could be assigned using 2D homonuclear COSY, TOCSY, ROESY and heteronuclear
15N- and 13C-HSQC experiments (Figures S3, S4 and Tables S2-S5). It is noteworthy that NOE correlations detected on the ROESY
spectra of 1 in CD3OH (Figure S4A) were fully compatible with the crystal structure (Figure 2c). Moreover, although trimer 1 was too
short to achieve an helix, its crystal structure superimposed well with the lowest energy NMR solution structures of 3 highlighting the
high propensity of short sequences containing ABOC to initiate the folding (Figure 2f). Four characteristic non-sequential backbone
NOE correlations NHi/NHi+2, NHi/Hi-2, NHi/Hi-3 and NHi/Hi+3 (Figures 2, S4B and S4C), were detected for the 2:1 /-hybrid
peptides 2 and 3 all along the sequences, providing strong evidences of a conformational preference. Simulated annealing
calculations under NOE-derived distance restraints were carried out with AMBER 11 to generate an ensemble of the 20-lowest
energy structures for both compounds 2 and 3 (Figure 2). When the flexible C-terminal OBg capping group was omitted, well-defined

Chemistry - A European Journal
10.1002/chem.201602746
COMMUNICATION
structures with low RMSD values were obtained (0.06 and 0.18 for 2 and 3, respectively) (Table S6). These NMR structure
calculations showed the ability of α-AA/ABOC/α-AA oligomers to display a right-handed 12/14/14-helix with 3 residues per turn and a
pitch of 5.3 Å. This helix was stabilized by hydrogen bonds with opposite directionality, forming intramolecular 12- and 14-membered
pseudocycles. The 12-membered ring involved the COi(Ala) and the NHi-2(ABOC) with backward hydrogen-bond orientation, while
the two 14-membered rings involved the COi(ABOC and Phe) and the NHi+4(Phe and Ala) with forward hydrogen-bond orientation.
The φ, θ and ψ average values in compounds 2 and 3 for ABOC were 61°, 50°, and -100° respectively, whereas φ = -130° and ψ
= 157° for the Ala residue, and φ = -61° and ϕ = -41° for the Phe residue (Table 1). Such dihedral angle values were similar to those
measured on the trimer 1 solid-state structure, except for the φ angle value of the first residue (Tables 1 and S7).
Table 1. Backbone torsion angle values
α/β-hybrid
Residue
φ
θ
ψ
peptides

-AA
-90 ± 21
75 ± 16
113 ± 15
-119 ± 23
Predicted
H12/14/14*
β
-AA
64 ± 14
(average values)

-AA
-AA
-83 ± 31
-24 ± 35

-130 ± 24
61 ± 9
157 ± 10
-100 ± 5
2 and 3
NMR structures
(average values)
β
-AA
50 ± 7
63
-AA
-61 ± 14
-41 ± 18
-AA
-59
75
-87
148
-82
-66
Trimer 1
XRD structure
β

-AA
-AA
[a] Calculated at the HF/6-31G* level of Ab Initio MO Theory for
hydrid octamers.[28]
//-
We then recorded mid infrared absorption spectra (4000-400 cm-1) of the compounds 1, 2 and 3 in CHCl3 to assess their ability to
establish intramolecular hydrogen bond networks monitoring the vibrational frequencies of both amide A (3600-3100 cm-1) and amide
I (1800-1600 cm-1). As expected, the three oligomers showed similar infrared active bands (Figures 3b and 3c). They exhibited three
main contributions in the amide A region at high (3504 cm-1 and 3399 cm-1) and low frequencies (from 3348 to 3306 cm-1)
corresponding to free and hydrogen bonded amide, respectively. In the amide I region, while the high frequency band around 1742
cm-1 was assigned to the ester C=O group,[29] the large band centred around 1660 cm-1 corresponded to the free and H-bonded
amide I features. In both amide A and amide I regions, the main band intensities increased with the oligomer size according to the
typical hydrogen bonds pattern stabilizing the 12/14/14-helix solved by NMR.
Figure 3. (a) CD spectra in CH3OH (100 µM) at 20°C and (b-c) FT-IR spectra (2 mM) in CHCl3 at 20°C (b) Amide A and (c) Amide I region. Compounds 1, 2
and 3 are indicated by plain, dashed and dotted lines, respectively.
Interestingly, we could notice a significant downshift of the H-bonded amide A and amide I vibrations to the lower frequencies
(from 3348 to 3306 cm-1 and 1666 to 1658 cm-1) with the oligomers length. These data supported the progressive strengthening of
the hydrogen bonds network with the extension of the oligomers (Figures 3b and 3c). We also performed DFT calculations starting
from the optimized lowest energy NMR structure of compound 3 to calculate the FT-IR spectrum of the 12/14/14 helical fold of the
hexamer (see SI). A good correlation between the experimental and the calculated vibrational features was obtained, validating the

Chemistry - A European Journal
10.1002/chem.201602746
COMMUNICATION
helical conformational preference of 3 and allowing us to identify the amide modes from the different residues (Figure S6 and Table
S8).
At last, according to their similar folds, the three oligomers 1, 2 and 3 shared comparable CD profiles with a strong maximum at
around 205 nm and a shoulder at 220 nm (Figures 3a and S7). The positive Cotton effects observed were consistent with a right-
handed helical fold.
Overall, these results showed the ability of 2:1 /β-hybrid peptides to adopt a well-defined secondary structure. Interestingly, the
12/14/14-helix characterized in this study has been previously predicted to be favored by theoretical calculations[28] among the //-
hydrid octamers, but never obtained before (Table 1). NMR structures of 3 superimposed well with the predicted structure of //-
hydrid peptides (Figure S5). In addition, it could be noticed that the ABOC backbone torsional angles were nearly similar to those
previously observed within the 12/14 helix of the ABOC-based oligoureas[25,26] and also within the 11/9- and 18/16-helices of the 1:1
α-AA/ABOC oligoamides[16] emphasizing its high conformational restriction. The 1:1 and 2:1 α-AA/ABOC-peptide helices exhibited
different helical parameters which affect their stability and the relative distribution of the ABOC and α residues along the helices axis
(Figure 4). Unlike the 1:1 α-AA/ABOC alternating pattern[16] but also the 2:1 α/β-peptides reported by the group of Gellman,[17] no
helical polymorphism was observed in solution among the 2:1 α-AA/ABOC-hybrid peptides. While the 11/9-helix the 18/16-helix have
a pitch of 6.2 and 5.0 and a diameter of 4.0 and 7.5 Å, respectively, the 12/14/14-helix possess properties closer than those of the α-
helix, with a rise per turn of ca 5.3 Å and a diameter of 5.5 Å. Thus, as shown in Figure 4, a good overlap was observed between the
central α-residues of peptides 3 and the corresponding residues of the model canonical α-helix (rmsd values on the Cα atoms of the
α-residues was 1.35 and dropped to 0.35 Å when the N- and C-terminal fraying residue were omitted). Both helices shared
comparable projection of their side chains with only small deviations at positions i+4 and i+7 (rmsd value on the Cα-Cβ atoms was
0.55 Å when the N and C terminal residues were omitted).
Figure 4. I) Comparison of 1:1 and 2:1 α-AA/ABOC-hybrid peptides structures: (a) X-ray crystal structure of the 11/9-helix in 1:1 octamer; (b) and (c) NMR
solution structures of the 18/16-helix in 1:1 octamer and the 12/14/14-helix in 2:1 nonamer, respectively. Except amides, protons were omitted for clarity
(Hydrogen bonds are represented by dotted lines); II) Superimposition of the 12/14/14 Ala/(S)-ABOC/Phe helix (in grey/yellow) and the poly-Ala α-helix (in green):
(a) transversal and axial views, b) linear sequences of the poly-Ala and 9-mer α/β/α peptide.
In conclusion, we established the conformational preference of 2:1 /β-hybrid peptides incorporating the ABOC motif as
constrained -residue and confirmed its strong ability to drive helical folding in peptide sequences. We demonstrated that the 2:1 α-
AA/ABOC displayed an original and predictable 12/14/14 helical fold that would match with the α-helix unlike the 1:1 α-AA/ABOC
helical folds. In particular, the 2:1 alternating pattern affords a helical scaffold projecting α-AA side chains in comparable positions as
certain side chains of the canonical α-helix. Thus, considering the distribution of the ABOC and the α-amino acids along the 12/14/14-
helix axis, we are currently focusing our attention on these new helical scaffolds for biological applications.

Chemistry - A European Journal
10.1002/chem.201602746
COMMUNICATION
Acknowledgements. We thank the CNRS, ANR-10-LABX-05-01 and the Université de Montpellier for financial support. We also
thank SIMS platform, LMP (Laboratoire de Mesures Physiques) for providing access to IR, NMR and CD facilities and Université de
Lorraine for XRD facilities.
References
[1] A. Hayen, M. A. Schmitt, F. N. Ngassa, K. A. Thomasson, S. H. Gellman, Angew. Chem.-Int. Ed. 2004, 43, 505–510.
[2] S. De Pol, C. Zorn, C. D. Klein, O. Zerbe, O. Reiser, Angew. Chem.-Int. Ed. 2004, 43, 511–514.
[3] W. S. Horne, S. H. Gellman, Acc. Chem. Res. 2008, 41, 1399–1408.
[4] P. G. Vasudev, S. Chatterjee, N. Shamala, P. Balaram, Chem. Rev. 2011, 111, 657–687.
[5] T. A. Martinek, F. Fulop, Chem. Soc. Rev. 2012, 41, 687–702.
[6] G. V. M. Sharma, P. Nagendar, P. Jayaprakash, P. R. Krishna, K. V. S. Ramakrishna, A. C. Kunwar, Angew. Chem.-Int. Ed. 2005, 44,
5878–5882.
[7] G. V. M. Sharma, T. A. Yadav, M. Choudhary, A. C. Kunwar, J. Org. Chem. 2012, 77, 6834–6848.
[8] D. Seebach, B. Jaun, R. Sebesta, R. I. Mathad, O. Flögel, M. Limbach, H. Sellner, S. Cottens, Helv. Chim. Acta 2006, 89, 1801–1825.
[9] K. Basuroy, V. Karuppiah, N. Shamala, P. Balaram, Helv. Chim. Acta 2012, 95, 2589–2603.
[10] K. Basuroy, V. Karuppiah, P. Balaram, Org. Lett. 2014, 16, 4614–4617.
[11] D. Balamurugan, K. M. Muraleedharan, Chem. – Eur. J. 2012, 18, 9516–9520.
[12] S. H. Choi, I. A. Guzei, L. C. Spencer, S. H. Gellman, J. Am. Chem. Soc. 2008, 130, 6544–6550.
[13] G. V. M. Sharma, T. Sridhar, B. Veena, P. P. Reddy, S. V. Reddy, C. Bruneau, A. C. Kunwar, New J. Chem. 2015, 39, 3295–3309.
[14] G. V. M. Sharma, T. Sridhar, P. P. Reddy, A. C. Kunwar, Eur. J. Org. Chem. 2013, 3543–3554.
[15] M. Lee, J. Shim, P. Kang, I. A. Guzei, S. H. Choi, Angew. Chem.-Int. Ed. 2013, 52, 12564–12567.
[16] B. Legrand, C. André, L. Moulat, E. Wenger, C. Didierjean, E. Aubert, M. C. Averlant-Petit, J. Martinez, M. Calmes, M. Amblard, Angew.
Chem. Int. Ed. 2014, 53, 13131–13135.
[17] M. A. Schmitt, S. H. Choi, I. A. Guzei, S. H. Gellman, J. Am. Chem. Soc. 2006, 128, 4538–4539.
[18] S. H. Choi, I. A. Guzei, L. C. Spencer, S. H. Gellman, J. Am. Chem. Soc. 2009, 131, 2917–2924.
[19] I. M. Mandity, E. Weber, T. A. Martinek, G. Olajos, G. K. Toth, E. Vass, F. Fulop, Angew. Chem.-Int. Ed. 2009, 48, 2171–2175.
[20] L. Berlicki, L. Pilsl, E. Weber, I. M. Mandity, C. Cabrele, T. A. Martinek, F. Fulop, O. Reiser, Angew. Chem.-Int. Ed. 2012, 51, 2208–2212.
[21] R. S. Roy, I. L. Karle, S. Raghothama, P. Balaram, Proc. Natl. Acad. Sci. U. S. A. 2004, 101, 16478–16482.
[22] K. Ananda, P. G. Vasudev, A. Sengupta, K. M. P. Raja, N. Shamala, P. Balaram, J. Am. Chem. Soc. 2005, 127, 16668–16674.
[23] G. V. Sharma, N. Chandramouli, S. J. Basha, P. Nagendar, K. V. Ramakrishna, A. V. Sarma, Chem Asian J 2011, 6, 84–97.
[24] C. André, B. Legrand, C. Deng, C. Didierjean, G. Pickaert, J. Martinez, M. C. Averlant-Petit, M. Amblard, M. Calmes, Org. Lett. 2012, 14,
960–963.
[25] B. Legrand, C. André, E. Wenger, C. Didierjean, M. C. Averlant-Petit, J. Martinez, M. Calmes, M. Amblard, Angew. Chem. Int. Ed. 2012,
51, 11267–11270.
[26] C. André, B. Legrand, L. Moulat, E. Wenger, C. Didierjean, E. Aubert, M. C. Averlant-Petit, J. Martinez, M. Amblard, M. Calmes, Chem.
– Eur. J. 2013, 19, 16963–16971.
[27] M. Amblard, M. Rodriguez, J. Martinez, Tetrahedron 1988, 44, 5101–5108.
[28] P. Schramm, G. V. M. Sharma, H. J. Hofmann, Biopolymers 2010, 94, 279–291.
[29] V. Martin, B. Legrand, L. L. Vezenkov, M. Berthet, G. Subra, M. Calmès, J.-L. Bantignies, J. Martinez, M. Amblard, Angew. Chem. Int.
Ed Engl. 2015, 54, 13966–13970.
Keywords: bicyclic β-amino acid • 12/14/14-helix • α/β-hybrid peptides • structural determination • helical structure
Table of Contents
/-hybrid peptides combining 2:1 / pattern of the highly constrained ABOC residue and proteogenic -amino acids adopted an
unprecedent 12/14/14-helix in solution. No helical polymorphism was observed for this helix. The 9-mer //α peptide showed some
similarities in α-AA side chain projection with that of α-helix.
