Amine-functionalized Metal-Organic Frameworks: An Efficient
and Recyclable Heterogeneous Catalyst for the Knoevenagel Con-
densation Reaction
R1
Abu Taher
O
Dong-Jin Lee
R2
Byoung-Ki Lee
+
Ik-Mo Lee*
NH2
X
CN
R1
DMF
80 °C
NH2
Department of Chemistry, Inha University,
Incheon 402-751, Korea
imlee@inha.ac.kr
CN
MOF
X
= Zn4O(CO2)6
R2
16 examples
up to 98% yield
100% selectivity
Catalyst
R1 = H, Me; R2 = H, Cl, Br, HO, Me, MeO, NO2; X = CN, COOEt
Received: 03.12.2016
Accepted after revision: 12.01.2016
Published online: 05.02.2016
es,7 solid-phase reactions,8 and methods using ionic liq-
uids,9 green solvents such as water,10 or grindstones under
solvent-free conditions have been developed.11 All these
protocols have drawbacks, such as use of expensive homo-
geneous catalysts, harsh thermal conditions, disposal of
toxic solvents and catalysts, or long reaction times. As a re-
sult, the development of heterogeneous catalytic systems
for chemical synthesis has attracted increasing attention,
and these systems can lead to novel environmentally be-
nign chemical procedures for academia and industry.12
The newly developed porous MOF structures are a
promising new generation of heterogeneous catalytic mate-
rials13 affording studies in the coordination space provided
by the 3D structure of the MOF due to (i) the well-ordered
size and shape of the pores, (ii) the flexible and dynamic be-
havior in response to guest molecules, and (iii) the design-
able channel surface functionalities. Porous MOFs can be
constructed rapidly from multidentate ligands through self-
assembly, where the ligand topology and coordination ten-
dencies depend on the metal ion. For the optimal catalytic
activity, two types of strategies are used: (a) introduction of
organic groups to provide guest-accessible functional or-
ganic sites14 and (b) formation of coordinatively unsaturat-
ed metal sites.15 If the metal is saturated coordinatively, the
organic moiety incorporating the functionality for non-co-
valent interactions can bind the reactant(s) through
H-bonding, or non-covalent stacking, leading to their acti-
vation. Herein, we report a highly active and recyclable cat-
alyst obtained by post-functionalization of MOF for Knoev-
enagel condensations between an aldehyde or ketone and
malononitrile or ethyl cyanoacetate, catalyzed by the pri-
mary amines embedded inside the well-known MOF [see
Scheme 1 in the Supporting Information (SI)]. The activities
DOI: 10.1055/s-0035-1561356; Art ID: st-2015-u0937-l
Abstract A highly efficient and reusable catalyst based on metal-or-
ganic frameworks (MOF) has been synthesized by post-functionaliza-
tion and applied in Knoevenagel condensations of various aldehydes
and ketones. The catalytic efficiency was demonstrated by the high
conversion (over 85−98%) of the reactants under mild conditions. The
catalyst maintained its unique framework after the reaction and could
be recycled and reused several times without significant loss of activity.
Key words Knoevenagel condensation, metal-organic frameworks,
heterogeneous catalysis, carbon–carbon bond, aldehyde, ketone
The Knoevenagel condensation1 is one of the most im-
portant and widely used methods for the formation of car-
bon–carbon bonds in organic synthesis.2 The condensation
reaction occurs between carbonyl compounds and activat-
ed methylene compounds. This carbon–carbon bond cou-
pling reaction is useful for the preparation of important in-
termediates in drug production. In addition, this reaction is
employed as a classic test reaction to analyze the activity of
a variety of solid base catalysts. The typical pKa values of
hydrogen atoms in β-dicarbonyl compounds are in the
range of 9–11.3 This makes them ideal substrates for test re-
actions utilizing Knoevenagel condensations. Active methy-
lene groups of compounds with different pKa values can be
reacted with benzaldehyde to test the activity of a basic
catalyst. Owing to their importance from an industrial and
synthetic point of view, a large number of methods for
Knoevenagel condensations has been reported employing
Lewis acids or bases,4 microwave assistance,5 or ultrasound
irradiation.6 Furthermore, biotechnology-based approach-
© Georg Thieme Verlag Stuttgart · New York — Synlett 2016, 27, A–E

B
A. Taher et al.
Letter
Synlett
were compared with those of the homogeneous counter-
parts benzylamine and aniline, and the heterogeneous IR-
MOF-3 catalyst.
the azide groups of MOF-N3 were reduced to the primary
amine groups. The complete conversion of the azide groups
was also confirmed by the 1H NMR spectrum after digestion
of the reacted crystals (see Figure S3 in the SI). The signal of
the benzyl protons at 4.3 ppm was shifted to 3.8 ppm. The
XRD pattern of the MOF-NH2 crystals exhibited no appar-
ent changes compared to the XRD pattern of the starting
MOF-N3 as shown in Figure 1, a. The MOF-NH2 and the par-
ent compound showed identical thermal stability (see Fig-
ure S4 in the SI). The BET surface area and pore volume of
MOF-NH2 were 516.18 m2·g–1 and 0.29 cm3·g–1, respectively,
and the modified MOF showed type I N2-adsorption–de-
sorption isotherms (see Figure S5 in the SI), again suggest-
ing that the structure of the parent MOF remained intact af-
ter functionalization. To gain further insights, we also per-
formed XPS analysis. Careful analysis showed the presence
of a split peak with maxima at 400 and 401 eV for the azide
groups18 (Figure 1, c). Maxima at 398 and 399 eV for the
primary amine groups19 (Figure 1, d) suggested the com-
plete conversion of the azide functionalities to amines.
The Knoevenagel condensation of aldehydes with com-
pounds containing activated methylene groups is a robust
reaction often used to test the catalytic activities of basic
catalysts.20 This reaction is catalyzed by alkali metal hy-
droxides or by homogeneous organic bases, such as prima-
ry, secondary and tertiary amines.21 On the other hand, re-
cycling and catalyst recovery have been problems in their
use in the production of fine chemicals. Initially, the Knoeve-
nagel condensation of benzaldehyde was performed using
various amounts of the catalyst MOF-NH2 to screen the
loading. The yield of the reaction gradually increased with
increasing catalyst loading (0–0.15 mmol of –NH2 groups,
see Figure S7 in the SI). In addition, high catalytic activity
was still observed with a very low catalyst loading. Al-
though the reaction yield reached almost 100% with 0.10
mmol of –NH2 groups in MOF-NH2, 0.13 mmol and 0.15
mmol gave 100% yield in the reaction of benzaldehyde at
80 °C in DMF. Therefore, 0.13 mmol loading of –NH2 groups
in MOF-NH2 was determined to be the optimal loading un-
der such reaction conditions. Furthermore, solvents were
screened to reach higher efficiency in the condensations
(Figure 2, a). Water and toluene were poor solvents, and the
crystal structure of MOF-NH2 was deformed when water
was used as a solvent (see Figure S8 in the SI). The Knoeve-
nagel condensation of benzaldehyde reached only 55–65%
conversion in DMA, DME and ethanol. The results showed
that DMF proved the best solvent regarding the catalytic ac-
tivity. With the optimized conditions in hand, the reactions
of various aromatic substituted aldehydes or ketones with
malononitrile or ethyl cyanoacetate were investigated and
the results are listed in Table 1.24
The azide-functionalized MOF-N3 was prepared from an
azide-containing organic linker using zinc nitrate hexahy-
drate in N,N-diethylformamide (DEF) as described earlier.16
The XRD pattern of as-synthesized MOF-N3 (Figure 1, a)
was similar to the literature.16 In the FT-IR spectra, the crys-
tals showed a stretching band of the azide groups at 2100
cm–1 with the C–O stretching band of zinc carboxylate at
1400 cm–1 (Figure 1, b). These facts suggested that two
azide groups were introduced on each organic linker in the
frameworks of MOF-N3.17 Then, we tried reduction of the
azide groups by using triphenylphosphine (PPh3) as reduc-
ing agent in DEF. The optical microscope observation illus-
trated that there was no apparent damage to the shape and
the edges of the MOF crystals after modification (see Figure
S1a in the SI). The progress of the reducing reaction of MOF-
N3 was monitored by FT-IR as shown in Figure 1, b. After 10
hours, the azide stretching band at 2100 cm–1 disappeared
completely, an NH stretching band at 3300 cm–1 was ob-
served, and C=O stretching at ca. 1700 cm–1 showed no
changes (Figure 1, b). Therefore, the C–O band was still
maintained along with Zn (see Figure S2 in the SI) after
modification indicating that the MOF framework was con-
structed by zinc ions and carboxylate anions.
Figure 1 (a) XRD patterns, (b) FT-IR spectra, (c) and (d) XPS spectra of
the nitrogen N 1s peaks of MOF-N3 and MOF-NH2, respectively
Furthermore, the formation of amine functionalities in
the MOF crystals was qualitatively confirmed by a ninhy-
drin test according to a literature procedure.17 A red color
developed that the starting MOF-N3 did not display (see Fig-
ure S1b in the SI). This observation strongly suggested that
© Georg Thieme Verlag Stuttgart · New York — Synlett 2016, 27, A–E

C
A. Taher et al.
Letter
Synlett
Table 1 (continued)
Entry Product
Table 1 Knoevenagel Condensation of Various Aldehydes and Ketones
