Synthesis and antiplasmodial activity of streptocyanine/peroxide and
streptocyanine/4-aminoquinoline hybrid dyes†
Marie-Pierre Maether,a Virginie Bernat,a Marie Maturano,a Christiane Andre´-Barre`s,a Sonia Ladeira,b
Alexis Valentin,c Henri Viald and Corinne Payrastre*a
Received 29th June 2011, Accepted 21st July 2011
DOI: 10.1039/c1ob06048a
Two series of streptocyanine dyes incorporating cyclic peroxide or 4-aminoquinoline moieties are
prepared and X-ray diffraction structures for three compounds are determined. All hybrid dyes show
good antiplasmodial activity (0.06 to 0.66 mM) and are not or are slightly cytotoxic, except 10a.
Introduction
Malaria is one of the most serious infectious diseases in tropical
and subtropical regions. Every year, 300 million people are afflicted
leading to 880 000 deaths, especially among young children.1 An
urgent need exists to develop new classes of antimalarial drugs that
operate, or not, by novel mechanisms of action because malaria
parasites develop resistance to clinically used chemotherapeutic
Fig. 1 5C- (n = 1),5 7C- (n = 2)6 and 9C-7 chain streptocyanine dyes.
agents and prophylactic drugs such as chloroquine, mefloquine or
sulfadoxine–pyrimethamine, and recently to artemisinin.2 Nowa-
days, drug combinations are recommended to avoid the emergence
of resistant parasite strains. But the two independent drugs may
present different pharmacokinetics profiles which hamper the full
benefit of the drug combinations. A recent rational approach
involves “covalent bitherapy”. This new strategy is based on
using hybrid molecules with a dual mode of action. The two
active entities are covalently linked. These drugs allow bypassing
the development of resistance, enhancing patient compliance and
reducing drug–drug interactions.3
We previously described the synthesis of streptocyanine dyes
as a potential new class of antimalarial drugs.4 SAR studies have
shown the influence of the polymethine chain length (5C-, 7C- or
9C-) and also the great importance of the structural modifications
at the nitrogen end groups (Fig. 1). The most active compounds
displayed sub-micromolar in vitro activities against P. falciparum
and the best selectivity was obtained for 5C-streptocyanines with
morpholino end groups.
Here we report our results on the synthesis and in vitro
antiplasmodial activities of two series of new hybrid molecules.
Firstly, a cyclic peroxide moiety and secondly, a 4-aminoquinoline
moiety, were chosen to be tagged on the streptocyanines with the
aim to induce a synergic effect and/or to create molecules with
a dual mode of action. We are also interested in antiplasmodial
agents acting in a similar way to artemisinin and we focused on
the syntheses of modified bicyclic peroxide G-factors (G1, G2,
G3). These natural bicyclic peroxides are easily extracted from the
leaves of Eucalyptus grandis8 (Fig. 2). We have previously reported
the crucial role of the peroxyketal function for this activity.9 But
the most significant differences were those observed between the
natural product G3 (IC50 30 mM) and the methyl ether analogue
G3Me (IC50 0.28 mM). The latter compound was found to be
one hundred times more active than G3, indicating the crucial
role of the ether function compared to the hydroxyl one. Some
of the previously synthesised a-spiro derivatives present moderate
aLaboratoire de Synthe`se et Physico-Chimie de Mole´cules d’Inte´reˆt Bi-
ologique (UMR 5068), Universite´ de Toulouse (Universite´ Paul Sabatier),
31062 Toulouse Cedex 9, France. E-mail: payrastr@chimie.ups-tlse.fr;
Fax: (+)330561556011; Tel: (+)330561558392
bUniversite´ de Toulouse, UPS, Structure Fe´de´rative Toulousaine en Chimie
Mole´culaire, FR2599, 118 Route de Narbonne, F-31062 Toulouse, France
cUPS and IRD, Pharma-DEV, UMR 152, Universite´ de Toulouse, 118 route
de Narbonne, 31062 Toulouse cedex 9, France
dDynamique des Interactions Membranaires Normales et Pathologiques
(UMR 5235), Universite´ Montpellier; 2, cc 107, Place E. Bataillon, 34095
Montpellier cedex 5, France
† CCDC reference numbers 805391–805393. For crystallographic data in
CIF or other electronic format see DOI: 10.1039/c1ob06048a
Fig. 2 Natural G-factors and a-spirobicyclic peroxide analogues of
G3-factor.
7400 | Org. Biomol. Chem., 2011, 9, 7400–7410
This journal is
The Royal Society of Chemistry 2011
©

View Article Online
to good antiplasmodial activities.10 We decided to synthesise the
a-spiropiperidine analogue allowing the tag of the streptocyanine
and obtaining only one compound, avoiding the presence of two
diastereoisomers.
The 4-aminoquinoline moiety11 was introduced to the strepto-
cyanine dyes via cyclic or acyclic linkers (Fig. 3).
on the peroxyhemiketal position, using butyllithium solution then
methyl triflate at low temperature. Methylated bicyclic peroxide
5 is obtained in 65% yield after purification by silica gel column
chromatography. Then BOC is cleaved using trifluoroacetic acid
at room temperature furnishing peroxide 6 in 92% yield, which is
used in the next coupling without further purification.
The synthesis of functionalized 4-aminoquinoline 7a, b (Fig. 3)
was achieved by the nucleophilic substitution of the 4-Cl atom of
4,7-dichloroquinoline with ethylenediamine or piperazine accord-
ing to Chauhan’s procedures.11
Hybrid peroxo-streptocyanine dyes 10a, b, 11b and 12b were
synthesised by the synthetic procedures as shown in Scheme 2.
Unsymmetrical compounds 10a, b and 11b were obtained in
respective yields of 22, 28 and 48% via a hemicarboxonium salt
which is isolated (13a) or not (9b). The symmetrical hybrid peroxo-
streptocyanine dye 12b was obtained by reacting peroxide 6 with
carboxonium salt 8b in 14% yield. To obtain the compounds 10a
and 12b, Hu¨nig’s base activation of 6 was necessary to achieve the
substitution of the second ethoxy group.
Nucleophilic substitution of the ethoxy group of hemicarbox-
onium salts 13b and 14b with 7a (quino) or 7b (pipequino) gives
unsymmetrical hybrid 4-aminoquinoline–streptocyanine dyes 15b,
16b and 18b, 19b in 26, 59, 30 and 50% yield, respectively
(Scheme 3).
Fig. 3 4-Amino-7-chloroquinolines 7a and 7b.11
Results and discussion
Synthesis
Because streptocyanine dyes are synthesised by reacting various
nitrogen nucleophiles with hemicarboxonium or carboxonium
salts,5 the functionalization of peroxide and 4-aminoquinoline
moieties by a reactive primary or secondary amino group has
been necessary (Scheme 1 and Fig. 3, respectively).
The functionalized cyclic peroxide
6 (peroxo) is ob-
To introduce two 4-aminoquinoline groups, the reaction was
carried out from the carboxonium salt 8b and the symmetrical
hybrid 4-aminoquinoline–streptocyanine dyes 17b and 20b were
obtained in 30 and 70% yield respectively, depending on the acyclic
or cyclic linker used (Scheme 4).
As was previously observed for streptocyanine dyes,6,7,12 X-ray
diffraction structures of 17b (Fig. 4), 18b (Fig. 5) and 19b (Fig. 6)
reveal “all trans” 5C carbon chains, with angles of about 120◦.
The polymethine chains are almost planar and the aryl groups
are roughly perpendicular to the chains, except for 17b. The C–C
and C–N bond lengths of the conjugated system have intermediate
tained by the following procedure (Scheme 1). 1-BOC-4-
hydroxymethylpiperidine is first oxidized to aldehyde 1 in quan-
titative yield. Then, modified Knoevenagel reaction between
syncarpic acid and the iminium obtained from aldehyde 1 and
piperidine leads to Mannich base 2, which after acidic treatment
and elimination of piperidine, furnishes the enone precursor 3 in
equilibrium with the dienol form in dichloromethane solution. The
solution is kept under air, and after twelve days at room tempera-
ture 1H NMR analysis indicates that auto-oxidation is complete.
Bicyclic peroxide 4 is obtained in 68% yield after purification by
silica gel column chromatography. The peroxide is then methylated
Scheme 1 Synthesis of peroxo compound 6. Reagents and conditions: (a) SO3–Py, Et3N, DMSO; (b) syncarpic acid, piperidine; (c) NH4Cl, HCl; (d) O2;
(e) BuLi, TfOMe; (f) TFA, CH2Cl2.
This journal is
The Royal Society of Chemistry 2011
Org. Biomol. Chem., 2011, 9, 7400–7410 | 7401
©

View Article Online
Scheme 2 Synthesis of hybrid peroxo-streptocyanine dyes 10a, 10b–12b. 8a, 8b and 13a were synthesised following previously described procedures.5
Reagents and conditions: argon, RT (a) CH3CN, iPr2NEt 2 eq., 6 2 eq., 10 d, (b) CH3CN, 6 1 eq., 24 h; (c) Et2NH or morpholine 1 eq., 24 h; (d) CH3CN,
Et2NH 1 eq., 15 min; (e) DMF, iPr2NEt 1 eq., 6 1 eq., 30 d.
Scheme 3 Synthesis of unsymmetrical hybrid 4-aminoquinoline–streptocyanine dyes 15b, 16b, 18b and 19b. Reagents and conditions: RT (a)
CH3CN/DMF, 7a 1 eq., 24 h; (b) CH3CN, 7b 1 eq., 24 h.
values between those of single and double bonds, expressing the
delocalisation of the positive charge of the 5C carbon chain.
(Vero cells), as described.16 These two cell lines were chosen for in
vitro culture ease and because one is a transformed cancerous cell
line (McF7) while the other (Vero) is not of cancerous origin, this
allowed comparisons of the two origins in the selectivity index. A
resistance index was also calculated as the ratio IC50 Fcb1/IC50 Nigerian
or IC50 FcM29/IC50 Nigerian. This ratio is 4.4 for chloroquine with the
FcB1 strain (K76T mutation at the PfCRT locus) and 8.7 for the
FcM29 strain (K76T mutation at the PfCRT locus, resistance-
associated mutations on the Pf-MDR gene) which has IC50
constantly higher than FcB1.17
All hybrid molecules exhibit good in vitro antiplasmodial activ-
ities (0.06 to 0.66 mM) similar to those of regular streptocyanines.
Moreover, they are not toxic or are slightly cytotoxic, except 10a.
Hemicarboxonium salts 13b and 14a are neither active nor toxic.
They are characterised by a less conjugated polymethine chain
Biological activity
All the biological results are summarized in Tables 1 and 2. The
antimalarial activity of the hybrid streptocyanines was evaluated
in vitro against P. falciparum on a chloroquine-sensitive (Nigerian)
strain13 and on chloroquine resistant strains (FcB1-Colombia and
FcM29),14 according to the procedures described by Desjardins
and co-workers.15 The antiplasmodial specificity of the drugs
was evaluated by comparing antiplasmodial activities toward
the mammalian MCF7 and Vero cell lines versus parasite (IC50
cells)/(IC50 P. falciparum). Two cell lines were used, the human
breast cancer cell line MCF7 and a normal cell line of simian origin
7402 | Org. Biomol. Chem., 2011, 9, 7400–7410
