Insight into GEBR-32a: Chiral Resolution,
Absolute Configuration and Enantiopreference
in PDE4D Inhibition
Valeria Cavalloro 1,2, Katia Russo 1, Francesca Vasile 3,
* ,
, Luca Pignataro 3
Archimede Torretta 4, Stefano Donini 4, Marta S. Semrau 5, Paola Storici 5 , Daniela Rossi 1,
Federica Rapetti 6, Chiara Brullo 6 , Emilio Parisini 4,7, Olga Bruno 6 and Simona Collina 1,
*
1
Department of Drug Sciences, University of Pavia, 27100 Pavia, Italy;
valeria.cavalloro01@universitadipavia.it (V.C.); katia.russo01@universitadipavia.it (K.R.);
daniela.rossi@unipv.it (D.R.)
Department of Earth and Environmental Sciences, University of Pavia, 27100 Pavia, Italy
2
3
Università degli Studi di Milano, Dipartimento di Chimica, via C. Golgi 19, 20133 Milano, Italy;
luca.pignataro@unimi.it
4
Center for Nano Science and Technology @PoliMi, Istituto Italiano di Tecnologia, Via Pascoli 70/3,
20133 Milano, Italy; archimede.torretta@iit.it (A.T.); stefano.donini@iit.it (S.D.); emilio.parisini@iit.it (E.P.)
Elettra-Sincrotrone Trieste S.C.p.A., SS 14-km 163.5 in AREA Science Park, 34149 Trieste, Italy;
5
marta.semrau@elettra.eu (M.S.S.); paola.storici@elettra.eu (P.S.)
Department of Pharmacy, Section of Medicinal Chemistry, School of Medical and Pharmaceutical Sciences,
6
University of Genoa, 16132 Genoa, Italy; federica.rapetti@edu.unige.it (F.R.); brullo@difar.unige.it (C.B.);
obruno@unige.it (O.B.)
Latvian Institute of Organic Synthesis, Aizkraukles 21, LV-1006 Riga, Latvia
7
*
Correspondence: francesca.vasile@unimi.it (F.V.); simona.collina@unipv.it (S.C.)
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 4 February 2020; Accepted: 16 February 2020; Published: 19 February 2020
Abstract: Alzheimer’s disease is the most common type of dementia, affecting millions of people
worldwide. One of its main consequences is memory loss, which is related to downstream effectors
of cyclic adenosine monophosphate (cAMP). A well-established strategy to avoid cAMP degradation
is the inhibition of phosphodiesterase (PDE). In recent years, GEBR-32a has been shown to possess
selective inhibitory properties against PDE type 4 family members, resulting in an improvement in
spatial memory processes without the typical side effects that are usually correlated with this
mechanism of action. In this work, we performed the HPLC chiral resolution and absolute
configuration assignment of GEBR-32a. We developed an efficient analytical and semipreparative
chromatographic method exploiting an amylose-based stationary phase, we studied the chiroptical
properties of both enantiomers and we assigned their absolute configuration by 1H-NMR (nuclear
magnetic resonance). Lastly, we measured the IC50 values of both enantiomers against both the PDE4D
catalytic domain and the long PDE4D3 isoform. Results strongly support the notion that GEBR-32a
inhibits the PDE4D enzyme by interacting with both the catalytic pocket and the regulatory domains.
Keywords: HPLC chiral resolution; NMR absolute configuration assignment; PDE4 inhibition
Molecules 2020, 25, 935; doi:10.3390/molecules25040935
www.mdpi.com/journal/molecules

Molecules 2020, 25, 935
2 of 14
1. Introduction
Nowadays, more than 30 million people live with dementia worldwide, and their number is
estimated to grow to 65.7 million in 2030 and 115.4 million in 2050 [ ]. As a result, dementia will
probably reach third place in terms of total healthcare costs, after cancer and cardiovascular diseases [ ].
Among all, Alzheimer’s disease (AD) represents the most common form of dementia and it can be
considered a challenge under both a medical and an economical point of view [ ]. AD is a polygenetic
neurodegenerative disorder characterized by neocortical atrophy that causes the loss of synapses and
neurons [ ]. One of its main consequences is memory loss, which is strictly related to downstream
effectors of cyclic adenosine monophosphate (cAMP) [ ]. Phosphodiesterase (PDE) inhibition has
long been considered a promising strategy to avoid the hydrolysis of cAMP and, therefore, to treat
memory deficits [ ]. Particularly, inhibitors of the PDE type 4 (PDE4) family have been identified
as effective pro-cognitive drugs [ ], and different drug discovery programs aim at developing an
1
2
3
4
5
6
7,8
effective PDE4 inhibitor to treat memory disorders. However, PDE4 inhibitors have been associated
with severe adverse effects, mainly emesis. Recently, it has been demonstrated that PDE4D is more
relevant to cognition enhancement than other PDE4 isoforms [9]. Thus, the quest for potent and
selective PDE4D inhibitors could open new avenues for memory performance enhancement. By
combining X-ray crystallography, molecular dynamic simulations and enzymatic assays, members
of our research team have recently provided a structural and functional characterization of several
PDE4D inhibitors from the well-established GEBR library [10]. Among them, GEBR-32a (Figure 1)
holds particularly good promises. Indeed, this PDE4D selective inhibitor is characterized by a good
toxicological and pharmacokinetic profile, and it is able to improve spatial memory processes without
undesired emetic-like side effects [7]. From a structural standpoint, we have shown previously that the
catechol portion of GEBR-32a binds the catalytic domain, while the tail of the molecule extends into
the S pocket, where it makes water-mediated contacts with the surrounding residues, and develops
toward the entrance of the active site (PDB 6FDC) [10]. Hence, when bound to the catalytic domain,
the protruding tail of GEBR-32a is expected to interact with the regulatory domains of the enzyme
(UCR1/UCR2 or CR3), which cap the catalytic pocket. Indeed, as the IC50 value measured against
the PDE4D catalytic portion alone is higher than the IC50 value against the full-length PDE4D3
isoform, we hypothesized that the tail of GEBR-32a contributes to its inhibitory mechanism [10]. Since
the tail portion of GEBR-32a is characterized by the presence of a stereogenic center, the absolute
configuration may also play a role in the interaction with the enzyme. Interestingly, despite the fact
that the structure of the PDE4D catalytic domain in complex with GEBR-32a has been determined
using the GEBR-32a racemic mixture, the crystallographic analysis provided evidence of a preferential
interaction of S-enantiomer with the enzyme (Figure 1B) (PDB 6FDC). This observation suggested that
(S)-GEBR-32a may be the eutomer and provided the rational for further careful investigation on the
resolved enantiomers.
In line with these considerations, herein we report on the chiral resolution of racemic GEBR-32a,
on the absolute configuration (AC) assignment and on the comparison of the inhibitory potency of the
two enantiomers against both the PDE4D catalytic domain and the full-length PDE4D3 isoform.

Molecules 2020, 25, 935
3 of 14
Figure 1. (A) Chemical structure of GEBR-32a and (B) crystal structure of S-GEBR-32a in complex with
the phosphodiesterase type 4 (PDE4D) catalytic domain (PDB 6FDC).
2. Results and Discussion
2.1. Chiral Chromatographic Resolution
Considering that both enantiomers are needed for biological testing, we synthesized racemic
GEBR-32a first (according to the previously reported procedure, Scheme SI) [ ] and solved the
7
enantiomers by chiral liquid chromatography, a time- and cost-effective approach for enantiomer
resolution at the discovery stage, commonly used both in Academia and the pharmaceutical
industry [7,11]. To find easily scalable chiral resolution analytical methods, our standard approach to
the analysis and separation of new chiral compounds consisted in the screening of polysaccharide-based
chiral stationary phases (CSPs) immobilized on silica gel chiral columns characterized by wide solvent
compatibility, versatility and robustness [11–18]. First, we tested a Regispack IA column containing a
dimethylphenyl-derivative of amylose. An initial mobile phase consisting of n-hexane (HEX)/isopropyl
alcohol (IPA)/diethylamine (DEA) (90:10:0.1) was used in order to assess the ability of the chiral
stationary phase (CSP) to resolve the GEBR-32a racemic mixture. Giving the encouraging resolution
thus obtained, a complete screening protocol (Table 1) in polar organic and reversed-phase mode was
applied under isocratic elution conditions. The best results in terms of peak resolution, peak shape
and enantioselectivity were achieved by eluting with isopropyl alcohol supplemented with 0.1% DEA
at a 0.5 mL/min flow rate. These chromatographic conditions allowed for very short retention times
and analysis time, adequate for scaling up (Figure 2).

Molecules 2020, 25, 935
4 of 14
Table 1. Analytical screening on Regispack IA (150 mm × 4.6 mm, 5 µm).
Mobile Phase a (v/v)
Flow
k1
k2
α
Rs
Hex/EtOH (90:10)
Hex/EtOH (80:20)
Hex/IPA (90:10)
Hex/IPA (80:20)
Hex/IPA (70:30)
Hex/IPA (50:50)
IPA
IPA/EtOH (50:50)
EtOH
EtOH/ MeOH (50:50)
MeOH
1 mL/min
1 mL/min
1 mL/min
1 mL/min
1 mL/min
1 mL/min
0.5 mL/min
0.5 mL/min
0.5 mL/min
0.5 mL/min
0.5 mL/min
3.05
2.47
8.24
3.10
1.78
1.07
0.87
3.10
2.63
2.24
0.48
3.07
3.02
8.71
3.55
2.07
1.23
1.56
3.38
2.89
2.42
0.53
N/A
1.22
1.06
1.15
1.16
1.15
1.79
1.09
1.10
1.08
1.10
N/A
N/A
N/A
0.77
0.89
N/A
2.61
1.27
1.34
1.09
N/A
a
0.1% DEA added. k1: retention factor of the first eluted enantiomer, k2: retention factor of the second eluted
enantiomer, α: resolution and Rs: factors.
200,000
100,000
0
0.0
2.0
4.0
6.0
8.0
10.0
12.0
W avelenght[nm ]
Figure 2. Analytical profile of racemic GEBR-32a: Regispack IA (150 mm
IPA plus 0.1% DEA at a flow rate of 0.5 mL/min (λ = 280 nm). N/A: not applicable due to the low
×
4.6 mm, 5
µ
m) and 100%
poor resolution.
In Table 1, the results expressed as retention (k), selectivity (
are reported.
α) and resolution (Rs) factors
This method was transferred to a (semi)preparative scale using the Chiralpak IA, ID of 10 mm,
characterized by the same CSP of the analytical column used. The good solubility of the racemate in
the mobile phase allowed the fast separation of the enantiomers. About 70 mg of racemic GEBR-32a
were processed in seven runs, and both enantiomers obtained with high enantiomeric excess (ee)
and in suitable amount for further studies (more than 30 mg for each enantiomer). As evidenced by
the analytical control of the collected fractions (Figure S1), the first eluted enantiomer has an ee of
99.5%, and the second one of 99.9%. The recovery is reported in Table 2 and the (semi)preparative
chromatographic profile in the supplementary material (Figure S1).

Molecules 2020, 25, 935
5 of 14
Table 2. GEBR-32a enantiomers.
[α]2D0 (c 0.2%, MeOH)
Cmpd
Rt
ee
Isolated Amount
Yield
(–)-GEBR-32a
(+)-GEBR-32a
6.0 min
8.4 min
99.5%
99.9%
−18.6
+19.4
30 mg
34 mg
43%
48%
Rt = retention time and ee = enantiomeric excess.
Both enantiomers have been characterized by nuclear magnetic resonance (NMR) (1H-NMR
and 13C-NMR) by measuring the specific rotations ([α]2D0) and recording electronic circular dichroism
spectra (Table 2 and Figure 3).
Figure 3. Circular dichroism spectra of (+)-GEBR-32a (green line) and (
Analysis are performed in methanol at c: 1.37 × 10−4 M.
−)-GEBR-32a (blue line).
The electronic circular dichroism (ECD) spectra of GEBR-32a showed two cotton effects (CEs)
between 215 and 300 nm corresponding to the characteristic 1La and 1Lb transitions of the benzene
chromophore. The first eluted enantiomer, (–)-GEBR-32a, showed negative cotton effects, and, as
expected, the second eluted enantiomer exhibited an identical ECD profile but of opposite sign
(Figure 3).
2.2. Assignment of the Absolute Configuration (AC)
The absolute configuration (AC) assignment of enantiomeric GEBR-32a was performed by
nuclear magnetic resonance (NMR) spectroscopy. The strategy is based on the derivatization of the
substrate with unknown configuration using both the enantiomers of a chiral reagent, leading to two
diastereoisomeric derivatives. The assignment of the AC is obtained from the difference in chemical
shifts observed in the 1H-NMR spectra of the two species [19].
The presence of a hydroxy group directly connected to the stereocenter of GEBR-32a makes
this molecule a suitable candidate for being derivatized by reaction with methoxy-
α-trifluoromethyl-
α
-phenylacetic acid chloride (MTPA-Cl), also known as Mosher’s reagent and usually employed for
the AC assignment of secondary alcohols and amines [20]. This methodology is well-established and
has been exploited to assign the absolute configuration of a large number of different compounds [21].
Its rationale is based on the assumption that the diastereoisomeric esters obtained by derivatization
adopt a s-cis conformation with the C=O and the CF3 group laying in the same plane [20
,22,23]. In this
conformation, the OMe and the Ph substituent of the MTPA moiety perturbate the signals of L1 and L2

Molecules 2020, 25, 935
6 of 14
groups belonging to the alkoxy residue (Figure 4): the aromatic ring will cause a high field shift of
the substituent sitting on its side, while the substituent on the OMe side will remain unaffected or
undergo an opposite change of δ
. In the (S)-MTPA ester, the L1 group is close to the phenyl ring and
so it resonates at higher field than in the (R)-MTPA derivative. At the same time, the chemical shift
of L2 is larger in the (S)-MTPA ester (in which this residue is closed to the OMe moiety) than in the
(R)-MTPA ester (in which it is close to the Ph ring). Thus, the chemical shift differences of all protons of
the (S)- and (R)-MTPA derivatives are calculated, and, considering the projections shown in Figure 4,
the stereocenter substituents are assigned as L1 and L2 depending on the sign of ∆δ (defined as δS −
δR). Following this general procedure, we derivatized the two enantiomeric alcohols as esters of both
(S)-MTPA and (R)-MTPA (Scheme 1). To obtain the diastereomeric esters, small amounts of both (+)
and (–)-GEBR-32a were reacted in parallel with (R) and (S)-α-methoxy-α-trifluoromethylphenylacetyl
chloride (MTPA-Cl) [24]. The reactions were performed in dichloromethane (DCM) in the presence of
triethylamine (4 equiv.) and of a catalytic amount of 4-dimethylaminopyridine (DMAP). It should
be noted that—as illustrated in Figure 4—upon ester formation, the stereochemical descriptor of the
MTPA-Cl stereocenter changes, because the COCl group has a CIP priority different from COOR.
Figure 4. Generic (S)- and (R)-methoxy-α-trifluoromethyl-α-phenylacetic acid (MTPA) esters in their
assumed preferred conformation, with the typical signs of ∆δ = δS − δR.
Scheme 1.
Synthesis of the four possible diastereosomeric forms of GEBR-32a Mosher’s
esters. DCM: dichloromethane, DMAP: dimethylaminopyridine, MTPA: methoxy-α-trifluoromethyl-
α-phenylacetic acid.

Molecules 2020, 25, 935
7 of 14
1
Next, H-NMR experiments were performed on both the nonderivatized and the derivatized
alcohols. The ∆δ values of the protons involved in the interaction with MTPA are reported in Table 3.
The absolute configurations of the Mosher’s esters were assigned based on the ∆δ signs, as
described above. Considering that the absolute configurations and the stereochemical descriptors
of GEBR-32a did not change upon derivatization, these results lead to conclude that the first eluted
enantiomer is (R)-(–)-GEBR-32a and the second is (S)-(+)-GEBR-32a.
As already stated above, this assignment can be considered to be reliable only if the Mosher’s
esters’ conformations in solution are actually those shown in Figure 4. In order to confirm this, we
performed 2D-NOESY experiments, which can provide information on the relative position of their
structural elements [25,26]. For compound 1a ((S)-MTPA ester of (R)-GEBR-32a), we observed two
important NOE contacts between the Ph ring of MTPA with protons 5 and 6 of GEBR-32a (Figure S2)
and the OMe group of MTPA with proton 9 of GEBR-32a (see Scheme in Table 3 for atom numbering).
On the contrary, in the NOESY spectrum of compound 1b ((R)-MTPA ester of (R)-GEBR-32a), the OMe
group of MTPA shows cross peaks with protons 5 and 6 of (R)-GEBR-32a (Figure S3), while the Ph
ring of MTPA has interactions with protons 10 and 11. In Figure 5, the most significant NOE contacts
are shown for compounds 1a and 1b. The NOESY spectra of the Mosher’s esters of (S)-GEBR-32a
featured the following interactions: (a) for compound 2a ((S)-MTPA ester of (S)-GEBR-32a), NOE
contacts between the OMe group of MTPA and protons 5 and 6 of (S)-GEBR-32a (Figures S4 and S6),
and (b) for compound 2b ((R)-MTPA ester of (S)-GEBR-32a), NOE contacts between the Ph group of
MTPA and proton 5 and 6 (S)-GEBR-32a (Figures S5 and S6).
Table 3. Nuclear magnetic resonance (NMR) analysis of derivatized and nonderivatized alcohols.
Proton
(–)-GEBR-32a
a
1a
1b
∆δ = δ − δ
R
S
H5
H6
H7
6.28
6.99
4.30–4.23
6.40
7.28
4.45–4.32
−0.12
−0.29
−0.15/0.09
H9
H10
H11
2.50
2.61–2.34
3.57
2.53
2.52–2.34
3.60
−0.03
0.09
−0.03
Proton
(+)-GEBR-32a
2a
2b
∆δ = δ − δ
R
S
H5
H6
H7
6.40
7.36
4.42–4.30
6.29
6.99
4.31–4.23
0.11
0.37
0.09/0.07
H9
H10
H11
2.48
2.51–2.34
3.59
2.51
2.62–2.36
3.61
−0.03
−0.11/−0.02
−0.02
a
δS = chemical shift of the (S)-methoxy-
α-trifluoromethyl-α-phenylacetic acid (MTPA) ester and δR = chemical shift
of the (R)-MTPA ester.

Molecules 2020, 25, 935
8 of 14
Figure 5. The most interesting NOE contacts observed for compounds Mosher’s esters 1a and 1b.
Therefore, overall, the NOE data collected for these compounds are compatible with the assumed
ester s-cis conformation with the C=O and CF3 groups eclipsed (Figure 4), suggesting that the latter is
effectively populated in the solution.
2.3. Enzymatic Activity
With the enantiomers of GEBR-32a in hand, we evaluated their inhibitory activity on both the
catalytic domain alone and the full-length enzyme. Results are shown in Table 4 and in Figure 6.
Table 4. Inhibitory activity on both the catalytic domain and the full-length enzyme of racemic and
enantiomers of GEBR-32a. PDE: phosphodiesterase.
IC50 (µM) PDE4 cat
IC50 (µM) PDE4D3
(R)-(-)-GEBR-32a
(S)-(+)-GEBR-32a
31.8 ± 6.7
19.5 ± 1.8
15.5 ± 2.7
2.1 ± 0.3
Figure 6. Cont.

Molecules 2020, 25, 935
9 of 14
Figure 6. IC50 curves for the two GEBR-32a enantiomers relative to the catalytic domain only (
against the long PDE4D3 isoform ( ). The experimental conditions are reported in the Materials and
Methods section. The reported data are the mean values of three replicates SD (standard deviation).
A) and
B
±
Results clearly show that inhibitory activity of GEBR-32a is significantly influenced by the
configuration of the stereogenic center that is present in the tail portion. In fact, the (S)-configured
enantiomer is approximately seven times more active than the (R)-configured one when measured
against the full-length protein, whereas this fold-difference reduces to less than two when measured
against the catalytic domain. This data confirms our hypothesis that the tail portion of GEBR-32a
contributes significantly to the inhibition of the full-length PDE4D enzyme. In addition, enzymatic
assays clearly indicate that (S)-GEBR 32a is the eutomer, in accordance with the crystallographic
analysis, which evidenced a preferential interaction of S-enantiomer with the enzyme.
3. Materials and Methods
3.1. General
HPLC grade-solvents were supplied by Honeywell (Seelze, Germany), while analytical
grade-solvents by PanReac (Darmstadt, Germany). The evaporation procedures were performed under
reduced pressure using a Heidolph Laborota 4000 instrument (Heidolph Instruments GmbH & Co.,
Schwabach, Germany).
Analytical thin-layer chromatography (TLC) was carried out on silica gel precoated glass-backed
plates (Fluka Kieselgel 60 F254, Merck, Darmstadt, Germany). The detection was conducted with UV
light (λ = 254 nm).
Flash chromatography was performed with silica gel 60 (particle size 230–400 mesh) purchased
from Nova Chimica (Cinisello Balsamo, Italy).
Deuterated solvent and all the reactants were purchased from Sigma Aldrich (Milan, Italy).
3.2. Chromatographic Resolution
Chromatographic resolution was carried out at room temperature on a Jasco (Tokyo, Japan) system
consisting of a PU-1580 pump and MD-1510 photo diode array (PDA) detector.

Molecules 2020, 25, 935
10 of 14
Chromatogram acquisitions and elaborations were performed using the ChromNAV software
(Tokyo, Japan). The resolution factor was directly given by the software, while selectivity (
calculated using Equation (1):
α
) was
k2
α =
k1
(1)
where k1 and k2 are the retention factors of the two enantiomers calculated as the ratio between the
retention time (tr) and the solvent front (t0) in (Equation (2)):
tr − t0
k =
(2)
t0
The best enantiomeric resolution was achieved exploiting a Regispack IA (250 mm
5 µm) column from Daicel Chemical Industries (Tokyo, Japan), a chiral stationary phase composed by
×
4.6 mm,
amylose tris(3,5-dichlorophenylcarbamate). The elution was performed in an isocratic mode using
100% IPA + 0.1% DEA at a flow rate of 0.5 mL/min (injection volume = 10 µL).
A Hamilton (Reno, NV, USA) syringe (syringe volume: 2.5 mL; loop: 2 mL) was employed for
(semi)-preparative chiral resolutions. In detail, the scale-up of the analytical conditions allowed us to
set up the following method: Regispack IA (1 cm
injection volume of 1 mL (concentration: 10 mg/mL).
×
25 cm, 5 µm) as column and flow rate of 2 mL/min
3.3. Specific Rotation
The optical rotatory power was recorded using a Jasco photoelectric polarimeter DIP 1000 (Tokyo,
Japan). The analysis was conducted using a 0.5 dm cell, methanol as solvent and a sodium lamp (
λ =
589 nm).
3.4. Circular Dichroism
Electronic circular dichroism (ECD) spectra were recorded on a Jasco J-1500 circular dichroism
spectrophotometer (Tokyo, Japan) from 315 to 215 nm. The methanolic solutions of (–)-GEBR-32a (c:
1.09
×
10−4 M) and (+)-GEBR-32a (c: 1.37
×
10−4 M) were analyzed in a nitrogen atmosphere with an
optical pathway of 1 cm. ECD spectra were scanned at 200 nm/min with a spectral band width of 1 nm
and a data resolution of 1 nm. For each measurement, 10 scans were taken and averaged, considering
both enantiomers. ECD spectra of the solvent in the same experimental conditions were subtracted.
Data are reported in ∆ε versus λ (nm) from knowledge of the cell pathlength and solution concentration.
3.5. Absolute Configuration Assignment
Under nitrogen, (R or S)-MTPA-Cl (7.1 mg, 1 eq) was added to an ice-chilled solution of (+)- or
(–)-GEBR-32a, TEA (6.6 mg, 4 eq) and DMAP (cat) in dry DCM (0.2 mL). After 15 min, the ice bath
was removed, and the mixture was stirred at r.t. (30 ◦C) overnight. The volatiles were removed at
rotavapor and the products purified by flash chromatography (eluent: 97:3 DCM/EtOAc).
3.6. NMR Analysis
NMR experiments were performed at 298 K on a Bruker Avance III 400 MHz spectrometer (Milan,
Italy). The NMR experiments were carried out in 500 µL of CDCl3. All proton and carbon chemical
shifts were assigned unambiguously using bi-dimensional experiments (COSY, NOESY and HSQC),
and the assignments are reported in Table S1. Edited 1H-13C HSQC experiments were performed to
confirm and follow the resonances of carbons. Phase sensitive 2D-NOESY experiments with gradient
pulses in mixing time were performed with a mixing time of 700 ms in order to observe homonuclear
correlation via dipolar coupling.

Molecules 2020, 25, 935
11 of 14
3.7. Expression and Purification of PDE4D Catalytic Domain and PDE4D3
The PDE4D catalytic domain and the PDE4D3 isoform were expressed and purified, as described
previously [10]. Briefly, the PDE4D catalytic domain (residues 244–578) featuring a C-terminal 6His-tag
was cloned into a pET-3a vector (Merck Millipore, Darmstadt, Germany) and transformed into
Escherichia coli BL21(DE3) pLysS cells (Thermo Fisher Scientific, Waltham MA, USA). Transformed
◦
cells were cultured at 37 C in LB broth supplemented with 50 mg/L ampicillin until OD600 =
◦
0.6. Protein expression was carried out overnight at 25 C after induction with 0.5 mM isopropyl
1-thio-β-D galactopyranoside (IPTG). Cells were harvested by centrifugation and resuspended in
20 mM Tris-HCl pH 7.5 and 150 mM NaCl. After sonication, the soluble fraction was first purified by
affinity chromatography using a preequilibrated Ni-NTA (Qiagen, Hilden, Germany) column. Elution
of the His-tagged protein was carried out using the same buffer supplemented with 400 mM imidazole.
The eluted sample was further purified by size-exclusion chromatography using a Sephacryl 100 HR
HiPrep 26/60 column (GE Healthcare, Chicago, IL, USA) and by anion exchange chromatography
using a HiPrep Q HP 16/10 column (GE Healthcare, Chicago, IL, USA). The final protein sample was
dialyzed against 20 mM Tris-HCl pH 7.5 and 150 mM NaCl and its purity assessed by SDS-PAGE.
The codon-optimized gene-encoding human PDE4D3 was purchased from GenScript (Piscataway,
NJ, USA). The construct, featuring a C-terminal 6His-tag and cloned into the pFastBac dual vector, was
designed to include the PKA phosphomimetic Ser54Asp mutation and the Ser579Ala mutation, the latter
preventing a known inactivating phosphorylation [27]. The bacmid was generated by transposition
in E. coli DH10EMBacY (strain kindly provided by I. Berger, University of Bristol, Bristol, UK) [28].
High-titer recombinant baculovirus was obtained by transfecting Sf9 cells grown in suspension at
a density of 0.8
The protein was expressed in Sf9 cells (1.5
centrifugation and resuspended in 50 mMHepes pH 7.5, 500 mM NaCl, 10 mM MgCl2, 10% glycerol,
5 mM imidazole, 10 g/mL DNaseI, 1 mM TCEP and a protease inhibitor cocktail (Roche, Mannheim,
×
106 cell/mL with PEI MAX (Polysciences Europe GmbH, Hirschberg, Germany).
106 cells/mL) for 72 h at 27 ◦C. Cells were harvested by
×
µ
Germany). After mild cell disruption by the Avestin homogenizer, the lysate was incubated for 5 min
with benzonase nuclease (Merck Millipore, Darmstadt, Germany) and then clarified by centrifugation.
The supernatant was loaded on Ni-NTA resin (Qiagen, Hilden, Germany) pre-equilibrated in 50 mM
Hepes pH 7.5, 150 mM NaCl, 10% glycerol, 5 mM imidazole and 1 mM TCEP and incubated for 1 h.
After extensive washing with wash buffer containing 20 mM imidazole, the protein was eluted with
the 50 mM Hepes pH 7.5, 150 mM NaCl, 10% glycerol, 400 mM imidazole and 1 mM TCEP. The protein
was later diluted in 100 mM Hepes pH 7.5, 10% glycerol and 1 mM DTT and immediately purified on
HiTrap HP Q column (GE Healthcare, Chicago, IL, USA) over linear gradient with buffer containing
1 M NaCl. The final purity of the sample was assessed by SDS-PAGE.
3.8. PDE4 Activity and Inhibition Assays
To measure enzyme activity, we used a coupled assay in which the adenosine monophosphate
(AMP) generated from the hydrolysis of cAMP was detected by a NADH-coupled enzyme system [29].
The assay was adapted to support a high-throughput format in 96 transparent polystyrene plates from
Greiner Bio (Kremsmünster, Austria). The 250 µL reaction mixture consisted of 100 mM Hepes pH 7.5,
10 mM MgCl2, 10 mM KCl, 0.3 mM ATP, 0.6 mM PEP, 0.9 unit of pyruvate kinase, 0.90 unit of lactate
dehydrogenase, 0.8 unit of myokinase and the PDE4 enzyme at an estimated final concentration of
10 nM. A preincubation step was carried out at 25 ◦C for 20 min. Then, the reaction was started by
adding cAMP at a final concentration of 0.04 mM. The oxidation of NADH to NAD+ was monitored
over time at 340 nm (NADHε340 = 6220 M−1 cm−1) in a Spark10M instrument (Tecan, Männedorf,
Switzerland). One unit (U) is defined as the amount of enzyme required to hydrolyze 1 µmol of cAMP
to 50-AMP per minute, and specific activity was expressed as units per milligram of enzyme. Inhibition
assays using the two enantiomers of GEBR-32a were done following the same protocol and by varying
the compound concentrations from 0.1
µM to 1 mM. Each enantiomer was dissolved in DMSO and
diluted in the assay buffer to a final concentration of 1%. Finally, the IC50 values of both enantiomers

Molecules 2020, 25, 935
12 of 14
relative to the PDE4 catalytic domain and to the PDE4D3 isoform were determined by plotting the
enzyme fractional activity against the logarithm of compound concentration. Curve fitting was done
with a dose
Equation (3):
−
response curve from OriginLab (OriginLab Corporation, Northampton MA, USA) using
max − min
y = min +
(3)
1 + 10ˆ(logIC50 − x)
where y is the fractional activity of the enzyme in the presence of the inhibitor at concentration [I], max
is the maximum value of y observed at [I] = 0 and min is the minimum limiting value of y at a higher
inhibitor concentration. All data points were collected in triplicate.
4. Conclusions
GEBR-32a is a promising phosphodiesterase type 4 family inhibitor. The recently obtained
GEBR-32a crystal structure [10] evidenced that the long tail of the molecule (bearing the hydroxypropyl
chain, with the chiral center and the morpholine end) extends toward the entrance of the enzyme
active site. This feature may allow it to interact with the UCR2 or the CR3 regulatory domains that
cap the catalytic pocket in the intact protein, thus possibly contributing to its inhibitory mechanism.
To corroborate this hypothesis, we studied the relationship between the absolute configuration of
GEBR-32a and its PDE4D inhibition. Therefore, we solved the two enantiomers via chiral HPLC and
assigned their absolute configuration via 1H-NMR, using Mosher’s reagent, as chiral derivatizing
agents. The enantiomers showed different potency against both the PDE4D catalytic domain and the
long PDE4D3 isoform of the enzyme, providing evidence of the difference in the contacts that they
may likely form with the regulatory domains of the enzyme.
Here, we show that the enantiomers of GEBR-32a interact with different potency with PDE4D
and that (S)-GEBR 32a is the eutomer, in accordance with the crystallographic analysis. These results
provide useful insights to guide improvements in binding potency and possible new avenues for the
development of more potent and selective homochiral PDE4D inhibitors.
Supplementary Materials: The following are available online. Figure S1. Chromatographic profile at (λ = 254 nm)
of racemic GEBR-32a in semi-preparative scale and chromatographic analysis of the pure enantiomers; Figure S2.
Aromatic region of the NOESY spectrum of compound 1a. The most important NOE contacts are evidenced;
Figure S3. Aromatic region of the NOESY spectrum of compound 1b. The most important NOE contacts are
evidenced; Figure S4. Aromatic region of the NOESY spectrum of compound 2a. The most important NOE
contacts are evidenced; Figure S5. Aromatic region of the NOESY spectrum of compound 2b. The most important
NOE contacts are evidenced; Figure S6. The most intesting NOE contacts observed for compounds Mosher’s
esters 2a and 2b; Table S1: NMR characterisation of non-derivatized GEBR-32a.
Author Contributions: O.B. and S.C.: conceptualization; V.C., F.V., L.P., A.T., S.D., M.S.S., P.S., D.R. and E.P.:
experimental design and methodology; V.C., K.R., F.V. and D.R.: investigation; C.B. and F.R.: racemate synthesis;
V.C., F.V., L.P. and S.C.: writing—original draft preparation; V.C., F.V., E.P. and S.C.: writing—review and editing;
C.B., O.B., P.S., E.P. and S.C.: supervision and O.B. and S.C.: project administration. All authors have read and
agreed to the published version of the manuscript.
Funding: This research received no external funding.
Conflicts of Interest: O.B. and C.B. declare an Intellectual Property interest on GEBR-32a.
References
1.
Prince, M.; Bryce, R.; Albanese, E.; Wimo, A.; Ribeiro, W.; Ferri, C.P. The global prevalence of dementia: A
systematic review and metaanalysis. Alzehimer’s Dement. 2013, 9, 63–75. [CrossRef] [PubMed]
Fillit, H.M. The pharmacoeconomics of Alzheimer’s disease. Am. J. Manag. Care 2000, 6, 1139–1148.
Colucci, L.; Bosco, M.; Fasanaro, A.M.; Gaeta, G.L.; Ricci, G.; Amenta, F. Alzheimer’s Disease Costs: What We
Know and What We Should Take into Account. J. Alzheimer’s Dis. 2014, 42, 1311–1324. [CrossRef] [PubMed]
Jahn, H. Memory loss in Alzheimer’s disease. Dialogues Clin. Neurosci. 2013, 15, 445–454. [PubMed]
Kandel, E.R. The molecular biology of memory: cAMP, PKA, CRE, CREB-1, CREB-2, and CPEB. Mol. Brain
2012, 5, 1–12. [CrossRef] [PubMed]
2.
3.
4.
5.

Molecules 2020, 25, 935
13 of 14
6.
7.
8.
9.
Nabavi, S.M.; Talarek, S.; Listos, J.; Nabavi, S.F.; Devi, K.P.; de Oliveirad, M.R.; Tewari, D.; Argüelles, S.;
Mehrzadi, S.; Hosseinzadeh, A.; et al. Phosphodiesterase inhibitors say NO to Alzheimer’s disease. Food
anche Chem. Toxicol. 2019, 134, 110822–110840. [CrossRef] [PubMed]
Ricciarelli, R.; Brullo, C.; Prickaerts, J.; Arancio, O.; Villa, C.; Rebosio, C.; Calcagno, E.; Balbi, M.; van
Hagen, B.T.J.; Argyrousi, E.K.; et al. Memory-enhancing effects of GEBR-32a, a new PDE4D inhibitor holding
promise for the treatment of Alzheimer’s disease. Sci. Rep. 2017, 7, 1–14. [CrossRef]
Gulisano, W.; Tropea, M.R.; Arancio, O.; Palmeri, A.; Puzzo, D. Sub-efficacious doses of phosphodiesterase 4
and 5 inhibitors improve memory in a mouse model of Alzheimer’s disease. Neuropharmacology 2018, 138,
151–159. [CrossRef]
Blokland, A.; Heckman, P.; Vanmierlo, T.; Schreiber, R.; Paes, D.; Prickaerts, J. Phosphodiesterase Type 4
Inhibition in CNS Diseases. Trends Pharmacol. Sci. 2019, 40, 971–985. [CrossRef]
10. Prosdocimi, T.; Mollica, L.; Donini, S.; Semrau, M.S.; Lucarelli, A.P.; Aiolfi, E.; Cavalli, A.; Storici, P.; Alfei, S.;
Brullo, C.; et al. Molecular Bases of PDE4D Inhibition by Memory-Enhancing GEBR Library Compounds.
Biochemistry 2018, 57, 2876–2888. [CrossRef]
11. Rossi, D.; Tarantino, M.; Rossino, G.; Rui, M.; Juza, M.; Collina, S. Approaches for multi-gram scale isolation
of enantiomers for drug discovery. Expert Opin. Drug Discov. 2017, 12, 1253–1269. [CrossRef] [PubMed]
12. Cosimelli, B.; Greco, G.; Laneri, S.; Novellino, E.; Sacchi, A.; Collina, S.; Rossi, D.; Cosconati, S.; Barresi, E.;
Taliani, S.; et al. Studies on enantioselectivity of chiral 4-acetylamino-6-alkyloxy-2-alkylthiopyrimidines
acting as antagonists of the human A3 adenosine receptor. Medchemcomm 2018, 9, 82–86. [CrossRef] [PubMed]
13. Rui, M.; Marra, A.; Pace, V.; Juza, M.; Rossi, D.; Collina, S. Novel enantiopure sigma receptor modulators:
Quick (semi-)preparative chiral resolution via hplc and absolute configuration assignment. Molecules 2016
21, 1210. [CrossRef] [PubMed]
,
14. Rossi, D.; Marra, A.; Rui, M.; Brambilla, S.; Juza, M.; Collina, S. “Fit-for-purpose” development of analytical
and (semi)preparative enantioselective high performance liquid and supercritical fluid chromatography for
the access to a novel σ 1 receptor agonist. J. Pharm. Biomed. Anal. 2016. [CrossRef] [PubMed]
15. Rossi, D.; Nasti, R.; Collina, S.; Mazzeo, G.; Ghidinelli, S.; Longhi, G.; Memo, M.; Abbate, S. The role
of chirality in a set of key intermediates of pharmaceutical interest, 3-aryl-substituted-γ-butyrolactones,
evidenced by chiral HPLC separation and by chiroptical spectroscopies. J. Pharm. Biomed. Anal. 2017
.
[CrossRef]
16. Rossi, D.; Nasti, R.; Marra, A.; Meneghini, S.; Mazzeo, G.; Longhi, G.; Memo, M.; Cosimelli, B.; Greco, G.;
Novellino, E.; et al. Enantiomeric 4-Acylamino-6-alkyloxy-2 Alkylthiopyrimidines As Potential A3 Adenosine
Receptor Antagonists: HPLC Chiral Resolution and Absolute Configuration Assignment by a Full Set of
Chiroptical Spectroscopy. Chirality 2016, 28, 434–440. [CrossRef]
17. Gaggeri, R.; Rossi, D.; Christodoulou, M.S.; Passarella, D.; Leoni, F.; Azzolina, O.; Collina, S. Chiral Flavanones
from Amygdalus lycioides Spach: Structural Elucidation and Identification of TNFalpha Inhibitors by
Bioactivity-guided Fractionation. Molecules 2012, 1665–1674. [CrossRef]
18. Gaggeri, R.; Rossi, D.; Collina, S.; Mannucci, B.; Baierl, M.; Juza, M. Quick development of an analytical
enantioselective high performance liquid chromatography separation and preparative scale-up for the
flavonoid naringenin. J. Chromatogr. A 2011, 1218, 5414–5422. [CrossRef]
19. Seco, J.M.; Quiño
17–118. [CrossRef]
20. Dale, J.A.; Mosher, H.S.
á, E.; Riguera, R. The Assignment of Absolute Configuration by NMR. Chem. Rev. 2004, 104,
α
-Methoxy-α-trifluoromethylphenylacetic acid, a versatile reagent for the
determination of enantiomeric composition of alcohols and amines. J. Org. Chem. 1969, 34, 2543–2549.
[CrossRef]
21. Fadia, Y.S.; Ashour, M.L.; Singa, A.N.B.; Wink, M. A Comprehensive Review of Bioactive Peptides from
Marine Fungi and Their Biological Significance. Mar. Drugs 2019, 17, 559–583.
22. Hub, L.; Mosher, H.S. α-Methoxy-α-trifluoromethylphenylacetic acid. Configuration by asymmetric synthesis.
J. Org. Chem. 1970, 35, 3691–3694. [CrossRef]
23. Sullivan, G.R.; Dale, J.A.; Mosher, H.S. Correlation of configuration and fluorine-19 chemical shifts of
α-methoxy-α-trifluoromethylphenyl acetate derivatives. J. Org. Chem. 1973, 38, 2143–2147. [CrossRef]
24. Peterson, J.R.; Bickford, L.C.; Morgan, D.; Kim, A.S.; Ouerfelli, O.; Kirschner, M.W.; Rosen, M.K. Chemical
Inhibition of N-WASP by stablization of a native autoinhibited conformation. Nat. Struct. Mol. Biol. 2004, 11,
747–755. [CrossRef]

Molecules 2020, 25, 935
14 of 14
25. Vasile, F.; Civera, M.; Belvisi, L.; Potenza, D.; Tiana, G. Thermodynamically–weighted conformational
ensemble of cyclic RGD peptidomimetics from NOE data. J. Phys. Chem. B 2016, 120, 7098–7107. [CrossRef]
[PubMed]
26. Vasile, F.; Panigada, M.; Siccardi, A.; Potenza, D.; Tiana, G. A Combined NMR-Computational Study of the
Interaction between Influenza Virus Hemagglutinin and Sialic Derivatives from Human and Avian Receptors
on the Surface of Transfected Cells. Int. J. Mol. Sci. 2018, 19, 1267. [CrossRef] [PubMed]
27. Burgin, A.B.; Magnusson, O.T.; Singh, J.; Witte, P.; Staker, B.L.; Bjornsson, J.M.; Thorsteinsdottir, M.;
Hrafnsdottir, S.; Hagen, T.; Kiselyov, A.S.; et al. Design of phosphodiesterase 4D (PDE4D) allosteric
modulators for enhancing cognition with improved safety. Nat. Biotechnol. 2010, 28, 63–70. [CrossRef]
28. Bieniossek, C.; Imasaki, T.; Takagi, Y.; Berger, I. MultiBac: Expanding the research toolbox for multiprotein
complexes. Trends Biochem. Sci. 2012, 37, 49–57. [CrossRef]
29. Chock, S.P.; Huang, C.Y. An optimized continuous assay for cAMP phosphodiesterase and calmodulin. Anal.
Biochem. 1984, 138, 34–43. [CrossRef]
Sample Availability: Samples of the compounds GEBR-32a are available from the authors.
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
