where h, kB, and T are Planck's constant, Boltzmann constant,
and temperature, respectively. The reorganization energies
upon intermolecular hole transfer (l) were obtained from l ¼
(E+* ꢀ E+) + (E* ꢀ E), where E, E+, E*, and E+* are the heat of
formations for an optimized neutral molecule, optimized cation
molecule, neutral state on cation structure, and cation state on
neutral structure, respectively, calculated at the B3LYP/6-31G(d)
level. Intermolecular hopping mobilities (m) were estimated
from the following eqn (3).
