332
K. Mandai et al. / Tetrahedron Letters 53 (2012) 329–332
Figure 1. SEM images of (a) BIO, (b) BIO–IM, and (c) BIO–IM–Pd.
7. For recent reviews, see: (a) Marion, N.; Nolan, S. P. Acc. Chem. Res. 2008, 41,
1440; (b) Kantchev, E. A. B.; O’Brien, C. J.; Organ, M. G. Angew. Chem., Int. Ed.
2007, 46, 2768; (c) Kantchev, E. A. B.; O’Brien, C. J.; Organ, M. G. Aldrichim. Acta
2006, 39, 97.
8. Without TBAB, the reaction did not proceed sufficiently. For the enhancement
of Suzuki-Miaura cross coupling reaction in water by TBAB, see: (a) Schmöger,
C.; Szuppa, T.; Tied, A.; Schneider, F.; Stolle, A.; Ondruschka, B. ChemSusChem
2008, 1, 339; (b) Badone, D.; Baroni, M.; Cardamone, R.; Ielmini, A.; Guzzi, U. J.
Org. Chem. 1997, 62, 7170.
9. Typical procedure for the Suzuki–Miyaura coupling reactions with BIO-immobilized
palladium under solvent-free condition: In a test tube with a screw cap, BIO-
immobilized Pd, arylboronic acid, and K2CO3 were mixed well until
homogeneous. After the addition of aryl bromide, the mixture was heated
under the conditions of the temperature and reaction time that were indicated
without stirring. Organic materials were extracted with ethyl acetate (four
times) by using centrifugation and concentrated under reduced pressure.
10. For recent examples on silica-supported palladium catalysts for the Suzuki–
Miyaura coupling reactions, see: (a) Fukuya, N.; Ueda, M.; Onozawa, S.; Bando,
K. K.; Miyaji, T.; Takagi, Y.; Sakakura, T.; Yasuda, H. J. Mol. Catal. A: Chem. 2011,
342–343, 58; (b) Chen, W.; Li, P.; Wang, L. Tetrahedron 2011, 67, 318; (c) Yang,
H.; Han, X.; Li, G.; Ma, Z.; Hao, Y. J. Phys. Chem. C 2010, 114, 22221; (d) Feng, X.;
Yan, M.; Zhang, T.; Liu, Y.; Bao, M. Green Chem. 2010, 12, 1758.
dispersed well on the surface of modified BIO, and these palladium
nanoparticles promote the Suzuki–Miyaura coupling reactions. De-
tailed analysis of the catalyst and its role in the solvent-free Suzu-
ki–Miyaura coupling reactions will be further investigated.
In conclusion, we have prepared new types of BIO-immobilized
palladium catalysts and successfully applied them to the Suzuki–
Miyaura coupling reactions. Combination of the porous nanostruc-
ture of BIO and choice of suitable organic cross-linker notably en-
hanced the catalytic activity to promote the reaction even in a non-
solvent system as well as in a solid-state system. The catalyst could
be reused at least five times and was useful. Developing the func-
tional utility of naturally produced and ubiquitous materials such
as BIO will be an urgent subject for environmentally benign
synthesis.
Acknowledgments
11. The products 3a–h were identified by comparison with the spectroscopic data
in the literatures: For 3a, 3b, 3e, 3f, 3g, see: (a) Bandari, R.; Höche, T.; Prager,
A.; Dirnberger, K.; Buchmeiser, M. R. Chem. Eur. J. 2010, 16, 4650; For 3c, see:
(b) Hartmann, C. E.; Nolan, S. P.; Cazin, C. S. J. Organometallics 2009, 28, 2915;
For 3d, see: (c) Döbele, M.; Vanderheiden, S.; Jung, N.; Bräse, S. Angew. Chem.,
Int. Ed. 2010, 49, 5986.
12. For the solvent-free Suzuki–Miyaura coupling reactions with solid-supported
palladium catalysts, see: (a) Braga, D.; D’Addario, D.; Polito, M. Organometallics
2004, 23, 2810; (b) Basu, B.; Das, P.; Bhuiyan, Md. M. H.; Jha, S. Tetrahedron Lett.
2003, 44, 3817; (c) Kabalka, G. W.; Wang, L.; Pagni, R. M.; Hair, C. M.;
Namboodri, V. Synthesis 2003, 217; (d) Melucci, M.; Barbarella, G.; Sotgiu, G. J.
Org. Chem. 2002, 67, 8877; (e) Villemin, D.; Caillot, F. Tetrahedron Lett. 2001, 42,
639; (f) Kabalka, G. W.; Pagni, R. M.; Wang, L.; Namboodiri, V.; Hair, C. M. Green
Chem. 2000, 2, 120; (g) Kabalka, G. W.; Pagni, R. M.; Hair, C. M. Org. Lett. 1999, 1,
1423.
This study is financially supported by a Special Grant for Educa-
tion and Research from the Ministry of Education, Culture, Sports,
Science, and Technology, Japan. We are grateful to the SC-NMR
Laboratory of Okayama University for the measurement of NMR
spectra.
Supplementary data
Supplementary data associated with this article can be found, in
13. For the solvent-free Suzuki–Miyaura coupling reactions with nonimmobilized
palladium catalysts, see: (a) Li, J.-H.; Deng, C.-L.; Xie, Y.-X. Synth. Commun.
2007, 37, 2433; (b) Klingensmith, L. M.; Leadbeater, N. E. Tetrahedron Lett.
2003, 44, 765.
References and notes
1. Hashimoto, H.; Yokoyama, S.; Asaoka, H.; Kusano, Y.; Ikeda, Y.; Seno, M.;
Takada, J.; Fujii, T.; Nakanishi, M.; Murakami, R. J. Magn. Magn. Mater. 2007, 310,
2405.
2. (a) Ema, T.; Miyazaki, Y.; Kozuki, I.; Sakai, T.; Hashimoto, H.; Takada, J. Green
Chem. 2011, 13, 3187; (b) Sakai, T.; Miyazaki, Y.; Murakami, A.; Sakamoto, N.;
Ema, T.; Hashimoto, H.; Furutani, M.; Nakanishi, M.; Fujii, T.; Takada, J. Org.
Biomol. Chem. 2010, 8, 336.
3. Tsuji, J. Palladium Reagents and Catalysts New Perspective for the 21st Century;
Wiley: England, 2004.
4. For a recent example, see: Kawamorita, S.; Ohmiya, H.; Iwai, T.; Sawamura, M.
Angew. Chem., Int. Ed. 2011, 50, 8363.
5. For reviews on the Suzuki–Miyaura coupling reacions, see: (a) Kotha, S.; Lahiri,
K.; Kashinath, D. Tetrahedron 2002, 58, 9633; (b) Suzuki, A. J. Organomet. Chem.
1999, 576, 147; (c) Miyaura, N.; Suzuki, A. Chem. Rev. 1995, 95, 2457.
6. For recent reviews, see: (a) Molnár, Á. Chem. Rev. 2011, 111, 2251; (b) Lamblin,
M.; Nassar-Hardy, L.; Hierso, J.-C.; Fouquet, E.; Felpin, F.-X. Adv. Synth. Catal.
2010, 352, 33; (c) Alonso, F.; Beletskaya, I. P.; Yus, M. Tetrahedron 2008, 64,
3047; (d) Yin, L.; Liebscher, J. Chem. Rev. 2007, 107, 133; (e) Phan, N. T. S.; Sluys,
M. V. D.; Jones, C. W. Adv. Synth. Catal. 2006, 348, 609.
14. (a) Linares, N.; Sepúlveda, A. E.; Pacheco, M. C.; Berenguer, J. R.; Lalinde, E.;
Nájera, C.; Garcia-Martinez, J. New J. Chem. 2011, 35, 225; (b) Bernhardt, F.;
Trotzki, R.; Szuppa, T.; Stolle, A.; Ondruschka, B. Beilstein J. Org. Chem. 2010, 6.
No. 7; (c) Nun, P.; Martinez, J.; Lamaty, F. Synlett 2009, 1761; (d) Tao, L.; Xie, Y.;
Deng, C.; Li, J. Chin. J. Chem. 2009, 27, 1365; (e) Schneider, F.; Szuppa, T.; Stolle,
A.; Ondruschka, B.; Hopf, H. Green Chem. 2009, 11, 1894; (f) Schneider, F.;
Stolle, A.; Ondruschka, B.; Hopf, H. Org. Process Res. Dev. 2009, 13, 44; (g) Chang,
W.; Shin, J.; Oh, Y.; Ahn, B. J. J. Ind. Eng. Chem. 2008, 14, 423; (h) Schneider, F.;
Ondruschka, B. ChemSusChem 2008, 1, 622; (i) Kogan, V.; Aizenshtat, Z.;
Popovitz-Biro, R.; Neumann, R. Org. Lett. 2002, 4, 3529; (j) Nielsen, S. F.; Peters,
D.; Axelsson, O. Synth. Commun. 2000, 30, 3501.
15. Djakovitch, L.; Köhler, K.; de Vries, J. G. The Role of Palladium Nanoparticles as
Catalysts for Carbon–Carbon Coupling Reactions. In Nanoparicles and Catalysis;
Astruc, D., Ed., first ed.; Wiley-VCH: Weinheim, Germany, 2008; p 303.
16. Okumura, K.; Matsui, H.; Sanada, T.; Arao, M.; Honma, T.; Hirayama, S.; Niwa,
M. J. Catal. 2009, 265, 89.
