Photochemistry and Photobiology, 2014, 90 127
folded conformer of 2P would give a red side of the Qy band.
The spectral analysis indicated that 2P partially formed the
folded conformer mentioned above. The fact that a zinc porphy-
rin had less coordination ability than the corresponding zinc
chlorin also suppressed the folding of 2P. The Soret band of 2P
was largely shifted to a shorter wavelength than that of 3P (435
? 416 nm), and the face-to-face folding through H-type aggre-
gation may occur due to the extremely flat porphyrin planes.
photosynthetic apparatus and their synthetic models composing
of porphyrinoids.
Acknowledgements—We thank Mr. Katsunori Nishide of Ritsumeikan
University for his experimental assistance. This work was partially
supported by Grants-in-Aid for Scientific Research (A) (no. 22245030) as
well as on Innovative Areas “Artificial Photosynthesis (AnApple)” (no.
24107002) from the Japan Society for the Promotion of Science (JSPS).
Supramolecular structure of methanol-locked Chl dyad
conformer
SUPPORTING INFORMATION
Additional Supporting Information may be found in the online
version of this article:
Figure S1. Qy absorption spectra of monomer 3a and dyads
4(n) (ca. 10À5 M) in 1% (v/v) methanol and benzene.
Figure S2. Difference between 1H chemical shifts of 1bb in
C6D6 containing 1% (v/v) CD3OD and C5D5N.
In the folded conformer of zinc Chl derivative dyads, the central
zinc atoms were coordinated by a methanol molecule as an axial
ligand to give a five-coordinated species. It is known that the
chlorin p-plane of Chl derivatives has two faces, a- and b-faces
(25). In the folded conformer, the five-coordinated zinc took
either a- or b-ligation and four stereoisomers are proposed for the
coordination sites, a,a-, a,b-, b,a- and b,b-ligation (see Fig. 10,
upper). The stereochemistry in the folded conformer was identi-
fied by the following 1H NMR measurements. In 1% (v/v)
CD3OD–CDCl3, hetero-dyad 1ad was analyzed by 1D and 2D
REFERENCES
NMR spectroscopy and all the peaks were assigned. From H–1H
1
1. Melkozernov, A. N. and R. E. Blankenship (2006) Photosynthetic
functions of chlorophylls. In Chlorophylls and Bacteriochlorophylls:
Biochemistry, Biophysics, Functions and Applications, (Edited by B.
Grimm, R. J. Porra, W. R€udiger and H. Scheer), pp. 397–412.
Springer, The Netherlands.
ROESY spectrum of 1ad at À50°C, two nuclear Overhauser
effect (NOE) correlations between the 10-H of pyropheophor-
bide-a moiety and 12-CH3 of pyropheophorbide-d moiety and
between the former 12-CH3 and latter 10-H were clearly
observed. The result showed that the two chromophores were clo-
sely situated in a molecule to give the methanol-locked conformer
mentioned above. Moreover, the 132-Hb which was situated on
the same side of the 17-propionate residue in pyropheophorbide-a
moiety was apparently NOE correlated with the 132-Hb in
pyropheophorbide-d moiety, and other NOEs were invisible for
the 132-Ha/132-Ha, 132-Ha/132-Hb and 132-Hb/132-Ha in between
the different chromophores This observation indicated that
both the 132-Hb were closely situated in the folded conformer
and the b-face of pyropheophorbide-a macrocycle interacted with
the b-face of pyropheophorbide-d through the b-ligation of a
methanol oxygen atom with a zinc atom in each zinc chlorin. The
molecular structure of methanol-locked zinc Chl dyads is depicted
as shown in the lower of Fig. 10 (see also the space filling model
in Graphical Abstract).
€
2. Cogdell, R. J., A. Gall and J. Kohler (2006) The architecture and
function of the light-harvesting apparatus of purple bacteria: from
single molecules to in vivo membrane. Q. Rev. Biophys. 39, 227–
324.
3. Orf, G. S. and R. E. Blankenship (2013) Chlorosome antenna com-
plexes from green photosynthetic bacteria. Photosynth. Res. doi:10.
1007/s11120-013-9869-3.
4. Liu, Z. and W. Chang (2008) Structure of the light-harvesting
complex II. In Photosynthetic Protein Complexes:
A Structural
Approach, (Edited by P. Fromme), pp. 217–242. Wiley, Weinheim.
5. Tamiaki, H., R. Shibata and T. Mizoguchi (2007) The 17-propionate
function of (bacterio)chlorophylls: biological implication of their
long esterifying chains in photosynthetic systems. Photochem. Photo-
biol. 83, 152–162.
6. Tamiaki, H. and M. Kunieda (2011) Photochemistry of chlorophylls
and their synthetic analogs. In Handbook of Porphyrin Science, (Edi-
ted by K. M. Kadish, K. M. Smith and R. Guilard), Vol. 11, pp.
223–290. World Scientific, Singapore.
7. Ohashi, S., T. Iemura, N. Okada, S. Itoh, H. Furukawa, M. Okuda,
M. Ohnishi-Kameyama, T. Ogawa, H. Miyashita, T. Watanabe,
S. Itoh, H. Oh-oka, K. Inoue and M. Kobayashi (2010) An overview
on chlorophylls and quinones in the photosystem I-type reaction
centers. Photosynth. Res. 104, 305–319.
CONCLUSION
Two units of zinc (B)Chl-a/b/d derivatives were covalently
linked with a diester spacer to give homo/hetero-dyads 1xy, 2X
and 4(n). In a solution, the synthetic zinc Chl dyads were intra-
molecularly folded with bidentate species possessing coordinat-
ing and hydrogen-bonding abilities. The conformationally fixed
supramolecules showed redshifted Qy bands through exciton
coupling of the composite p-systems, compared with the corre-
sponding monomers 3z. The formation of such J-type aggre-
gates was regulated by D-ring (un)saturation, spacer length and
binder structure. The bathochromic shifts by the intramolecu-
larly folding formation were sterically and electronically con-
trolled by B-ring (un)saturation, spacer length and binder
structure as well as Qy energy levels of the composite chromo-
phores. The present supramolecules would help to understand
structures and functions of closely situated (B)Chls in natural
8. Gunderson, V. L. and M. R. Wasielewski (2012) Supramolecular
chlorophyll assemblies for artificial photosynthesis. In Handbook of
Porphyrin Science, (Edited by K. M. Kadish, K. M. Smith and
R. Guilard), Vol. 20, pp. 45–105. World Scientific, Singapore.
9. Boxer, S. G. and G. L. Closs (1976) A covalently bound dimeric
derivative of pyrochlorophyllide a. A possible model for reaction
center chlorophyll. J. Am. Chem. Soc. 98, 5406–5408.
10. Tamiaki, H., K. Fukai, H. Shimazu, K. Nishide, Y. Shibata, S. Itoh
and M. Kunieda (2008) Covalently linked zinc chlorophyll dimers as
a model of a chlorophyllous pair in photosynthetic reaction centers.
Photochem. Photobiol. Sci. 7, 1231–1237.
11. Wasielewski, M. R., U. H. Smith, B. T. Cope and J. J. Katz (1977)
A synthetic biomimetic model of special pair bacteriochlorophyll a.
J. Am. Chem. Soc. 99, 4172–4173.
12. Smith, K. M., D. A. Goff and D. J. Simpson (1985) Meso substitu-
tion of chlorophyll derivatives: direct route for transformation of
bacteriopheophorbides d into bacteriopheophorbides c. J. Am. Chem.
Soc. 107, 4946–4954.
