4
Tetrahedron
selective allylic alcohol reduction using a fluoroarylborane
SilaFlash P60 40-63 ꢀm (230-400 mesh). Thin layer
chromatography (TLC) was performed on SiliCycle Silica Gel 60
F254 plates and was visualized with ceric ammonium molybdate
(CAM) stain. All NMR spectra were recorded on a Bruker
Avance 600 MHz spectrometer at standard temperature and
pressure. All deuterated solvents were used as received from
Cambridge Isotope Laboratories, Inc. The residual solvent
protons (1H) or the solvent carbons (13C) were used as internal
standards. The following abbreviations are used in reporting
NMR data: s, singlet; d, doublet; dd, doublet of doublets; dt,
doublet of triplets; td, triplet of doublets; ddd, doublet of doublet
of doublets; and m, multiplet. Where necessary, 2D COSY, and
HSQC data were used for peak assignment. High Resolution
Mass spectra were obtained on Q ExactiveTM HF-X Hybrid
Quadrupole-OrbitrapTM Mass spectrometer.
catalyst and silane (Scheme 3(b)). Silyl protected diene 4 was
prepared via a previously reported procedure in 64% yield from
gibberellic acid.[13] Under B(C6F5)3-catalyzed hydrosilylative
deoxygenation conditions, 32% of reduced allylic alcohol 2 was
obtained after 24 h, with only trace amounts of 2 being formed
when BAr3,5-CF3 was the catalyst. Few examples of
hydrosilylative allylic alcohol reductions with fluoroarylborane
catalysts are known although several examples of C–O
reductions on cyclic ethers have been reported.[18,19]
Unlike B(C6F5)3 catalyzed reactions, in situ spectroscopic
studies of the BAr2,4,6-F and BAr3,5-CF3 reactions provided no clear
evidence for how the borane speciated. In an attempt to observe a
difference in the behavior of the catalysts an additional 20 mol%
of an external Lewis base (PPh3) was added, which can promote
the heterolysis of the silane into a borohydride/silylphosphonium
ion pair.[20] In the case of BAr2,4,6-F the rate of forming 1 and 3
slowed and resonances for H−BAr2,4,6-F– were observed in the 19F
NMR (-100.2 ppm for o-F, and -120.1 ppm for p-F) along with
All chemicals were used as received, or otherwise described
on how it was treated before use. Me2EtSiH and Et3SiH were
purchased from Gelest, and degassed via three freeze-pump-thaw
cycles and stored over molecular sieves in the glovebox.
Catecholborane was purchased from Sigma-Aldrich, distilled
prior to use, taken into a nitrogen filled glovebox, and stored at -
48 oC. B(C6F5)3 was purchased from Strem and used as received.
BAr2,4,6-F and BAr3,5-CF3 were synthesized via known
methods.[10,24]
its cation Me2EtSi-PPh3 (-3.29 ppm) by 31P NMR.[20,21] By
+
contrast, addition of 20 mol% PPh3 to the BAr3,5-CF3 catalyzed
reaction completely shut down its reduction to 2, and instead
provided only partial conversion of Si-Gibb to 3. As discussed in
Figure 1, despite having a similar net hydride affinity, both the
borohydrides and borane Lewis acids have different electrostatic
potential surfaces. In addition to these electrostatic differences,
the lack of ortho-F groups in BAr3,5-CF3 makes it more sterically
accessible to both the hydride source (Piers mechanism) and
other competing Lewis bases.[9,22–24] The balance of these
forces is especially complex in a multi-functional structure like
gibberellic acid and so the diverging reactivity patterns is
difficult to pin down to a specific feature of the catalysts.
4.2. B(C6F5)3 catalyzed reaction with Si-Gibb and silane
In a N2-filled glove box, B(C6F5)3 (4.9 mg, 0.010 mmol, 0.10
equiv) was placed in a 1 dram vial and dissolved in 0.2 mL of
CH2Cl2. To the catalyst solution was added Me2EtSiH (32 µL,
0.241 mmol, 2.50 equiv) and mixed. In a separate vial, Me2EtSi-
Gibb (50 mg, 0.096 mmol, 1.00 equiv) was diluted with 0.3 mL
of CH2Cl2. The catalyst and borane mixture was then added to the
substrate solution in one portion. The reaction mixture was
transferred to an NMR tube and sealed with a septum cap. After
24 h, the mixture was transferred to a vial and rinsed three times
with 0.5 mL of MeOH. After concentrating the resulting solution
in vacuo, the crude residue was purified by silica gel
chromatography (30:1 CH2Cl2/MeOH to 20:1 to 10:1 to 5:1) to
yield 1 (83%, 28 mg) and 2 (16%, 5.0 mg).
Scheme 3. Divergent deoxygenation with fluoroarylboranes.
3. Conclusion
Selective activation and cleavage of C–O bonds in gibberellic
acid has been achieved employing different fluoroarylborane
Lewis acid catalysts. Although the precise mechanistic reasons
for the diverging behavior could not be unambiguously
disentangled, a number of differences were noted, including
changes in the electrostatic surfaces of the borane Lewis acid and
their conjugate hydrides. Experimental studies noted that
B(C6F5)3, which has the highest hydride affinity, rests as the
borohydride. The partially fluorinated catalysts have lower
hydride affinities and neither build up significant quantities of
borohydride during catalysis. However, when PPh3 is added to a
reaction the BAr2,4,6-F catalyst converts to the borohydride in situ
while BAr3,5-CF3 does not. It is tempting to ascribe the difference
in reaction selectivities to the propensity of the catalysts to form
borohydride versus borane resting states, however, it is still too
early to tell if this is the ultimate source of the divergent
behavior.
1
Compound 1: H NMR (600 MHz, Acetone-d6) δ 5.19 (br s,
1H), 5.06 (br s, 1H), 4.90 (br s, 1H), 4.04 (dd, J = 4.3, 2.0 Hz,
1H), 3.17 (d, J = 5.5 Hz, 1H), 3.16 – 3.12 (m, 1H), 2.77 (dt, J =
18.2, 3.5 Hz, 1H), 2.68 (dt, J = 16.3, 3.0 Hz, 1H), 2.49 (br s, 1H),
2.28 – 2.23 (m, 1H), 2.13 (m, 1H), 1.96 – 1.88 (m, 1H), 1.74 (dd,
J = 11.0, 2.9 Hz, 1H), 1.69 – 1.58 (m, 2H), 1.49 – 1.39 (m, 2H),
1.32 (s, 3H); 13C NMR (151 MHz, Acetone-d6) δ 177.5, 176.2,
156.6, 142.1, 111.0, 105.7, 79.3, 70.5, 50.5, 50.0, 49.8, 49.7,
48.8, 47.2, 46.6, 40.1, 38.8, 33.4, 22.2, 19.4. HRMS (EI)
calculated for C19H24O6Na [M+Na]+:371.1465; found 371.1459.
Compound 2: 1H NMR (600 MHz, Methanol-d4) δ 5.85 (d, J =
9.8 Hz, 1H), 5.51 (d, J = 9.8 Hz, 1H), 5.10 (t, J = 2.5 Hz, 1H),
3.15 – 3.01 (m, 1H), 2.98 – 2.81 (m, 2H), 2.75 – 2.64 (m, 1H),
2.60 – 2.42 (m, 2H), 2.31 – 2.12 (m, 1H), 2.06 (dd, J = 10.1, 2.6
Hz, 1H), 2.03 – 1.89 (m, 1H), 1.73 (td, J = 11.9, 6.4 Hz, 1H),
1.64 (ddd, J = 10.7, 7.0, 2.6 Hz, 1H), 1.59 (dd, J = 10.1, 2.5 Hz,
1H), 1.21 (s, 3H); 13C NMR (151 MHz, Methanol-d4) δ 178.2,
177.8, 156.0, 136.5, 132.4, 128.9, 127.8, 105.8, 80.0, 57.1, 55.9,
53.9, 52.4, 40.6, 40.5, 26.1, 24.5, 21.6. HRMS (EI) calculated for
C19H22O5Na [M+Na]+: 353.1360; found: 353.1370.
4. Experimental section
4.1. General information
4.3. B(C6F5)3 catalyzed reaction with HBCat
All reactions were performed at ambient temperature (25 ºC,
RT) unless otherwise specified. All workup procedures were
performed under air with reagent grade reagents unless otherwise
specified. Column chromatography was performed using
In a N2-filled glove box, B(C6F5)3 (3.6 mg, 0.007 mmol, 0.10
equiv) was placed in a 1 dram vial and dissolved in 0.2 mL of
CH2Cl2. To the catalyst solution was added HBCat (37 µL, 0.350
