Methane on Gasborne Nickel Nanoparticles
J. Phys. Chem. A, Vol. 105, No. 39, 2001 8959
3.1. Aerosol Particle Generation. Nickel nanoparticles are
generated with a spark discharge generator (SDG).6 In this
device, two Ni electrodes are placed in an inert gas stream
(99.99% N2). A capacitance of 20 nF parallel to the electrodes
is periodically charged by a constant current until the break-
through voltage is reached. The ensuing spark vaporizes small
but fairly constant amounts of metal, which then form Ni
nanoparticles of about 4 nm diameter by homogeneous nucle-
ation. These so-called primary particles undergo collisions
resulting in chainlike agglomerates in the size range of tens to
a few hundred nanometers (Figure 2a). The agglomerate number
concentration is controlled by the discharge frequency and was
in the range of 5 × 106 cm-3. On-line measurements with a
scanning mobility particle sizer (SMPS) give continuous data
on agglomerate size distribution and number concentration.
3.2. Structure Modification of the Agglomerates. As
illustrated in Figure 2a, the Ni agglomerates have a high
porosity, i.e., a large percentage of exposed surface area. One
can rearrange the primary particles to form more compact
agglomerates with only minor loss of overall BET-equivalent
surface area (Figure 3). This “restructuring” is induced thermally
by passing the aerosol through a heated tube furnace. Once
mobile enough to move, the primary particles rearrange into a
lower energy state, i.e., in a more compact agglomerate
structure,7 as illustrated in Figure 2b. Above about 450 °C, one
observes the onset of sintering accompanied by a rapid decrease
of BET surface area, followed by melting of the nickel, which
ultimately leaves solid spherical particles (see Figure 2c,d). At
the exit of the furnace, the aerosol is at room temperature.
The exposed surface area per average particle shown in Figure
3 is determined from its mobility equivalent size measured by
electrical mobility analysis (see below), which is known to be
a good representation of projected area.8,9
Figure 1. Schematic diagram of the experimental setup
2. Model Reaction CO + 3H2 f CH4 + H2O
The formation of methane from carbon monoxide and
hydrogen over a Ni catalyst, the so-called methanation reaction
was chosen as a simple and very well characterized system for
which the literature offers ample data on classical supported
catalysts. In addition, the rate of CH4 formation can be translated
directly into an overall turnover rate (TOR), defined as
number of product molecules
number of active sites‚time
TOR )
(1)
because methane is formed almost exclusively (>98%). The
TOR is related to the reaction rate r, i.e., the volume of methane
produced per mass of catalyst and time, in mL mg-1 s-1
rNA
TOR )
(2)
VMSBET
δ
3.3. Catalysis. After conditioning, the educt gases CO and
H2 are added to the aerosol immediately before entering the
flow reactor, which is heated, thereby initiating the catalytic
reaction. The point at which a constant maximum temperature
is reached is defined as t ) 0 for the reaction. Changing gas
composition and particle properties are monitored by a succes-
sion of sampling points which correspond to residence times
between a few seconds and a few minutes. At that point, the
reaction and any further growth processes within the aerosol
are quenched by dilution with a known flow of nitrogen, and
the aerosol sample is split for particle characterization and for
gas analysis. The aerosol characterization will be discussed
below. For the gas analysis, the particles are first removed by
filtration, and the gas composition is then determined on-line
with an FTIR spectrometer (Bruker Model Vector 22) equipped
with an 8.8 m cell. Stable concentrations in the optical cell were
obtained about 5 min after a change in input conditions,
corresponding to three exchanges of the cell volume.
where NA is the Avogadro number, VM the molar volume, SBET
the specific surface area of the catalyst, and δ the number of
active sites per unit surface area.
The reaction order for hydrogen is known to be close to unity,
while the reaction order for carbon monoxide is reported to vary
between -1 and 0.5, depending on CO partial pressure.5
However, by keeping the amount of produced methane low with
low educt concentrations and short reaction times, the initial
concentrations of CO and H2 remain virtually constant through-
out the reactor. Under these conditions, the reaction orders of
the individual educt gases need not be considered for the
determination of the TOR. They were determined nevertheless
in separate experiments by varying the educt initial concentra-
tions to establish a comparison with the classical route.
Moreover, the overall activation energy for the formation of
methane was determined from an Arrhenius-type plot.
3. Experimental Setup
4. Particle Characterization Techniques
As outlined above, the basic idea is to start with gasborne
nanoparticles produced freshly in a continuous process, thereby
guaranteeing constant and reproducible initial conditions. Im-
mediately after generation, the aerosol may undergo modifica-
tion steps to adjust particle structure and certain surface
conditions (for which an operational definition shall be given
later on) to have a broader range of variability than afforded
by the generator alone. These particle properties are all measured
and monitored as far as possible with on-line techniques, as
described in Section 4. In a third reactor, the actual catalytic
reaction is initiated and studied. A schematic diagram of the
experimental setup is shown in Figure 1.
The Ni particles were characterized by on-line and off-line
techniques. The latter include total surface area determination
by standard nitrogen adsorption (BET, Quantachrom Nova
2000), transmission electron microscopy (TEM, Zeiss Leo EM
109), and thermogravimetric analysis (TGA, Netsch TG 209)
coupled with an FTIR spectrometer to analyze adsorbates on
the particle surface qualitatively and quantitatively.
Aerosol particle size distributions and concentrations were
principally determined on-line by a scanning mobility particle
sizer (SMPS, combining TSI Models 3071 and 3022). This
technique is based on fractionating particles according to their
