Tyrosine–chlorambucil conjugates facilitate cellular uptake through L-type amino acid transporter 1 (LAT1) in human breast cancer cell line MCF-7

Article abstract of DOI:10.3390/ijms21062132

l-type amino acid transporter 1 (LAT1) is an amino acid transporter that is overexpressed in several types of cancer and, thus, it can be a potential target for chemotherapy. The objectives of this study were to (a) synthesize LAT1-targeted chlorambucil d

Full text of DOI:10.3390/ijms21062132

International Journal of
Molecular Sciences
Article
Tyrosine–Chlorambucil Conjugates Facilitate Cellular
Uptake through L-Type Amino Acid Transporter 1
(LAT1) in Human Breast Cancer Cell Line MCF-7
Piman Pocasap 1,2, Natthida Weerapreeyakul 1,2,
*
, Juri Timonen 3, Juulia Järvinen 3,
Jukka Leppänen 3, Jussi Kärkkäinen 3 and Jarkko Rautio 3,
*
1
Division of Pharmaceutical Chemistry, Faculty of Pharmaceutical Sciences, Khon Kaen University,
Khon Kaen 40002, Thailand; piman.pocasap@kkumail.com
Human High Performance and Health Promotion Research Institute, Khon Kaen University,
Khon Kaen 40002, Thailand
School of Pharmacy, Faculty of Health Sciences, University of Eastern Finland, P.O. Box 1627,
FI-70211 Kuopio, Finland; juri.timonen@uef.fi (J.T.); juulia.jarvinen@uef.fi (J.J.); jukka.leppanen@uef.fi (J.L.);
jussi.karkkainen@uef.fi (J.K.)
2
3
*
Correspondence: natthida@kku.ac.th (N.W.); jarkko.rautio@uef.fi (J.R.)
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 20 February 2020; Accepted: 19 March 2020; Published: 20 March 2020
Abstract: l-type amino acid transporter 1 (LAT1) is an amino acid transporter that is overexpressed
in several types of cancer and, thus, it can be a potential target for chemotherapy. The objectives
of this study were to (a) synthesize LAT1-targeted chlorambucil derivatives and (b) evaluate their
LAT1-mediated cellular uptake as well as antiproliferative activity in vitro in the human breast cancer
MCF-7 cell line. Chlorambucil was conjugated to l-tyrosine—an endogenous LAT1 substrate—via
either ester or amide linkage (compounds
1 and 2, respectively). While chlorambucil itself did
not bind to LAT1, its derivatives and bound to LAT1 with a similar affinity as with l-tyrosine
1
2
and their respective cellular uptake was significantly higher than that of chlorambucil in MCF-7.
The results of our cellular uptake study are indicative of antiproliferative activity, as a higher
intracellular uptake of chlorambucil derivatives resulted in greater cytotoxicity than chlorambucil
by itself. LAT1 thus contributes to intracellular uptake of chlorambucil derivatives and, therefore,
increases antiproliferative activity. The understanding gained from our research can be used in
the development of LAT1-targeted anticancer drugs and prodrugs for site-selective and enhanced
chemotherapeutic activity.
Keywords: AT1; cancer; chlorambucil; cellular uptake; antiproliferative; MCF-7
1. Introduction
l-type amino acid transporter 1 (LAT1), commonly referred to as the large neutral amino acid
transporter 1, is a Na+-independent amino acid transporter responsible for the transport of mainly
large and neutral amino acids from extracellular fluids into cells. LAT1 substrates include several
essential amino acids, e.g., leucine, isoleucine, valine, tryptophan, methionine, histidine, tyrosine,
and phenylalanine [1]. In addition, LAT1 is also known to mediate the transport of thyroid hormones
and prescription drugs (e.g., melphalan, gabapentin, and l-dopa). LAT1 has also been demonstrated to
transport amino acid-containing prodrugs, in which amino acids as promoieties have been linked with
non-substrate parent drugs. The prodrug strategy has been exploited, for example, to utilize LAT1 as a
drug carrier to increase drug permeability through the blood–brain barrier by conjugating various
drugs (e.g., dopamine, ketoprofen, and valproic acid) to various amino acids [2–4].
Int. J. Mol. Sci. 2020, 21, 2132; doi:10.3390/ijms21062132
www.mdpi.com/journal/ijms

Int. J. Mol. Sci. 2020, 21, 2132
2 of 15
High levels of LAT1 are expressed in many cancerous tissues [
5], the overexpression being a result
of the higher amounts of essential amino acids needed to support the growth and development of
the malignancy [ ]. LAT1 is thus an intriguing target for improved and targeted tumor therapy [ ].
Some LAT1 inhibitors have, on the other hand, been developed to thwart the supply of amino acids,
impeding protein synthesis and cancer cell proliferation [ 10]. Recently, a LAT1 inhibitor JPH203
displayed promising results in a clinical phase I study, especially in patients with advanced solid
tumors expressing high levels of LAT1 [11 12]. The results emphasized LAT1 as a potential target for
6
7
8–
,
cancer treatment. On the other hand, only a very few anticancer agents have been modified to take
advantage of LAT1-targeted cancer cell uptake [13].
The chemotherapeutic agent chlorambucil is mainly used in the treatment of chronic lymphocytic
leukemia as well as some types of lymphoma; however, the cancer resistance mechanisms, i.e., efflux
by MRP1 as well as drug metabolism by glutathione (GSH) conjugation and
β-oxidation, reduce
chlorambucil intracellular levels and hinder its effectiveness [14 15]. The objective of the present study
,
was to modify the structure of chlorambucil so that it resembles LAT1 substrates, thereby enhancing
its intracellular uptake through LAT1-mediated transport, and thus increasing its efficacy against
cancer cells. Based on the LAT1 model [16], chlorambucil derivatives
1 and 2 (Figure 1) were designed:
chlorambucil was linked from its carbonyl group with an endogenous LAT1 substrate, l-tyrosine,
or its amine derivative by either an ester or amide bond, respectively. The affinity of chlorambucil
and its derivatives to LAT1, their cellular uptake, and antiproliferative activity were determined in
a LAT1-expressing human breast adenocarcinoma cell line (MCF-7). The obtained results support
rational drug/prodrug design to increase drug uptake into cancer cells via a specific transporter and,
thereby, enhance chemotherapeutic efficiency.
Figure 1. Structures of chlorambucil derivatives 1 and 2.
2. Results
2.1. Synthesis of Chlorambucil Derivatives
Compounds
through either an ester or an amide bond, respectively. Compound
chlorambucil, 3, to commercially available Boc-l-tyrosine-OtBu, 5, using EDC/DMAP and then
removing of the protecting groups (Boc and OtBu) by trifluoroacetic acid. In compound synthesis,
the amino acid part (Boc-4-amino-l-phenylalanine methyl ester, ) was first synthesized as previously
1
and
2
were designed to link chlorambucil with tyrosine or its amine derivative
1
was synthesized by conjugating
2
6
described [16] with methyl esterification of Boc-4-nitro-l-phenylalanine, 4, using dimethyl sulfate in
the presence of K2CO3. The reduction of the nitro group was done by hydrogenation in the presence
of 10% Pd-C. Then, peptidic coupling of chlorambucil with amino derivative
6 was catalyzed by

Int. J. Mol. Sci. 2020, 21, 2132
3 of 15
EDC/DMAP. Finally, deprotection of the protecting groups, i.e., methyl ester and Boc, using LiOH and
trifluoroacetic acid, respectively, afforded chlorambucil derivative 2 (Scheme 1).
Scheme 1. Synthetic pathway for chlorambucil derivatives. Reagents and conditions: (
(CH3O)2SO2, acetone, overnight, and ( ) 10% Pd-C, H2, MeOH, overnight; ( ) EDC, DMAP, CH2Cl2,
overnight; ( ) TFA, CH2Cl2, 6 h; (For ) ( ) LiOH, THF, 1.5 h, and ( ) TFA, CH2Cl2, 2 h; all conditions
a) K2CO3,
b
c
d
2
e
f
were conducted at room temperature.
2.2. In Vitro Conversion
The in vitro conversion of compounds
(pH 7.4) and in human liver microsomes. Both compounds released the parent drug, chlorambucil,
in both experiments. The respective chemical conversion profiles of compounds and resulted
1 and 2 was determined both in aqueous buffer solution
1
2
in half-lives (T1/2) of 167 and 179 min (Figure 2A), suggesting no difference in the non-enzymatic
conversion rate between the ester and amide derivatives. By contrast, the enzymatic conversion in
human liver microsomes resulted in more rapid conversion of compound
1 (T1/2: 5 min) compared to
compound 2 (T1/2: 52 min) (Figure 2B).
Figure 2. Time courses (mean, n = 2) for chlorambucil derivatives
1
and
2
during chemical conversion
) at 37 ◦C.
in phosphate buffer (pH 7.4) ( ) and enzymatic conversion in human microsomes (pH 7.4) (
A
B

Int. J. Mol. Sci. 2020, 21, 2132
4 of 15
2.3. LAT1 Binding Affinity
The binding abilities of compounds
1 and 2 to LAT1 were investigated in MCF-7 cells at 10 µM in
a competitive inhibition assay with the endogenous LAT1 substrate, l-leucine. Chlorambucil, which is
not a LAT1 substrate, displayed no binding affinity to LAT1 as it does not have the physicochemical
facets to inhibit [14C]-l-leucine uptake. The chlorambucil derivatives
1
and
2, however, exhibited
binding affinity to LAT1, evidenced by the significantly decreased cellular uptake of [14C]-l-leucine to
61.5%
±
2.7% and 49.6%
±
5.3%, respectively. The endogenous LAT1 substrate, l-tyrosine, was able to
decrease the cellular uptake of [14C]-l-leucine to 48.6% ± 7.9% (Figure 3).
Figure 3. Ability of chlorambucil and its derivatives
(0.157
compared to untreated control.
1
and
±
2
(10
µ
M) to inhibit uptake of [14C]-l-leucine
µ
M) in MCF-7 cells. All data presented as mean
SD (n = 3). * p < 0.05, significant difference
2.4. In Vitro Cellular Uptake
The respective cellular uptake of compounds
1
and
2
as well as the parent drug, chlorambucil,
were evaluated in MCF-7 cells to determine the exposure effect of both time and concentration on
cellular uptake. Chlorambucil and its derivatives
time- and concentration-dependent manner.
1 and 2 were all taken up into MCF-7 cells in both a
In the time-dependent study, the uptake of compound
chlorambucil at all five time points between 5 and 45 min. Compound
greater cellular uptake than chlorambucil after 10 min of incubation (Figure 4A). The cellular
uptake of compounds varied as follows: chlorambucil 0.16–0.29 mol/mg of protein; compound
1 0.27–0.45 µmol/mg of protein, and compound 2 0.18–0.47 µmol/mg of protein.
According to time-dependent data, the uptake of both compounds and reached their maximum
at 15 min. Therefore, 15 min was selected for the concentration-dependent uptake study as it displayed
1
was significantly greater than that of
2
showed significantly
µ
1
2
unsaturated uptake with maximum values. The respective uptakes of compounds
1
and
2
±
(2.5
0.14
±
0.35 and
µmol/mg
2.61 0.10 mol/mg of protein) were significantly higher than that of chlorambucil (1.61
±
µ
of protein) at concentrations of 80 µM and higher, at 15 min incubation time (Figure 4B).

Int. J. Mol. Sci. 2020, 21, 2132
5 of 15
(A)
(B)
Figure 4. Cellular uptake of chlorambucil and its derivatives
1
and
2
at different incubation times
SD
(20 M) ( ) and different concentrations (15 min) ( ) in MCF-7 cells. Values expressed as mean
µ
A
B
±
(n = 3). * p < 0.05, significant difference compared to chlorambucil at relevant times and concentrations.
2.5. Antiproliferative Activity
The antiproliferative activity of chlorambucil and its derivatives 1 and 2 were studied in MCF-7
cells in vitro. The cell cytotoxicity was determined after treatment with all compounds at various
concentrations for 24, 48, and 72 h. All compounds displayed time-dependent cell cytotoxicity
(Figure 5A). There was no cell death in any of the treatment groups at 24 h incubation. At 48 h,
compounds
death was detected in the chlorambucil-treated cells (6.7%
cell cytotoxicity for , and chlorambucil at 120 M, respectively). All compounds increased cell
cytotoxicity in a concentration-dependent manner at 72 h incubation with the highest cell cytotoxicity
observed at 120 M concentration. The respective cell cytotoxicity was 25.8% 3.2% for , 18.0% 2.5%
for , and 10.6% 1.3% for chlorambucil (Figure 5B). In summary, compounds and possessed higher
1
and
2
displayed cell cytotoxicity in a concentration-dependent manner, while no cell
±
2.0%, 15.5% 3.1%, and ( 1.1%) 2.5%
±
−
±
1
,
2
µ
µ
±
2
±
1
±
1
2
antiproliferative activity than chlorambucil in both a time- and concentration-dependent manner.
To investigate the contribution of LAT1 on the chlorambucil derivative activity, BCH, a standard
LAT1 inhibitor [17], was co-incubated with compound
inhibit the function of LAT1 around 80%–100% with no cytotoxicity at a minimum concentration
of 10 mM [18 19]. That means lower BCH concentrations (<10 mM) were not sufficient to inhibit
1 or 2 (Figure 5C). BCH was reported to
,
LAT1 function, while higher concentrations (>10 mM) could be cytotoxic to the cell and interfere
with the results. The reported data agreed with our study in that BCH had no significant cytotoxicity
to MCF-7 (4.3%
used in co-incubation with compounds
cytotoxicity of compound significantly, possibly due to the insensitivity of MCF-7 to the chlorambucil
±
3.4%) at the concentration used (10 mM, 72 h). Therefore, this concentration was
1
and . Our result showed that BCH was not able to reduce
2
1
derivative. A profound result was however demonstrated in the co-incubation of BCH with compound
2, since BCH significantly reduced its cytotoxicity (15.7% ± 2.7%).

Int. J. Mol. Sci. 2020, 21, 2132
6 of 15
(A)
(B)
(C)
Figure 5. Antiproliferative activity of chlorambucil derivatives
(120 M) ( ), different concentrations (72 h) ( ), and different concentrations with BCH (10 mM) (
MCF-7 cells. Results expressed as mean SD (n = 3). * p < 0.05, significant difference compared to
chlorambucil (A), untreated control (B), and co-incubated with BCH (C).
1
and
2
at different incubation times
µ
A
B
C) in
±
3. Discussion
Structural features for LAT1 recognition are prone to resemble moieties belonging to endogenous
LAT1 substrates. The preferable features for LAT1 binding include (1) free amino and carboxylic acid
groups; (2) a large and neutral side group (referring to an amino acid side chain); and, (3) an H-bond
acceptor behind the amino acid side chain [20
derivatization or replacement of the functional groups can maintain some affinity to LAT1 [1,21].
To ensure adequate binding affinity, compounds and were designed according to our 3D
–22]. Nevertheless, the features are not obligatory as
1
2
quantitative relationship (3d-QSAR) model of the LAT1 binding site so as to contain: (1) free amino and
carboxylic acid groups; (2) an aromatic side chain; and, (3) an ester/amide linkage (H-bond acceptor).
While both the ester
1 and amide 2 bonds can undergo bioconversion, the chlorambucil derivatives
1
and were supposed to be active without bond cleavage because of the presence of the unconjugated
2
N,N-bis-(2-chloroethyl)-amine moiety. The moiety acts as the active functional group to interact with
DNA and exert its pharmacological activity. These compounds are, therefore, terminologically not
prodrugs that possess no pharmacological activity [23], even though they can release chlorambucil and
act like prodrugs.
Since the ability of the chlorambucil derivatives to bind to LAT1 depends on the amino acid
promoiety, the stability of the ester or amide bond significantly affects LAT1 binding properties. In our
results, there was no difference in the nonenzymatic conversion rates between the ester and amide

Int. J. Mol. Sci. 2020, 21, 2132
7 of 15
derivatives, as the two compounds displayed a comparable half-life. Both compounds displayed
chemical stability with a respective half-life being around 170 min, meriting further study; however,
they underwent faster bioconversion in human liver microsomes, resulting in a dramatic reduction
in half-life. The half-life of the bioconversion of the amide derivative
compared with that of the ester . As with other reports, the result indicates that the amide bond is less
sensitive to enzymatic hydrolysis than the corresponding ester bond [ 24]; the ester derivative is more
2 was up to 10 times higher
1
2
,
susceptible to enzymatic bioconversion, limiting its ability to reach the target site intact in vivo.
While chlorambucil demonstrated no binding affinity to LAT1 in MCF-7 cells, its derivatives 1 and
2
bound to LAT1 with an affinity comparable to the endogenous LAT1 substrate L-tyrosine. Nonetheless,
the high-binding affinity is not obligatory to the efficient LAT1-mediated cellular uptake [25]. Smaller
compounds seem to be taken up by LAT1 faster than the larger ones, at the expense of specificity
and affinity [26]. By contrast, the larger molecules with high lipophilicity can bind more efficiently
to LAT1, at the expense of transport capacity, resulting in compounds acting as inhibitors rather
than substrates [27]. Consequently, the cellular uptake profiles as well as binding affinity data are
crucial to determining whether the LAT-utilizing compound act as either an inhibitor or a substrate.
Chlorambucil derivatives
1 and 2 were taken up into the MCF-7 cells with a higher intracellular
concentration than chlorambucil itself in the time-dependent study. This result is consistent with the
concentration-dependent study. We hypothesize that carrier-mediated transport is participating in
improving the uptake of the designed derivatives via LAT1 into cancer cells. The computational analysis
(Table 1) of the physicochemical properties indicates that chlorambucil is a small lipophilic molecule with
a low polar surface area (PSA) that can effectively cross the cell membrane by passive diffusion [28
which has been demonstrated in the ascites sarcoma cell [30] and in situ rat intestine [31]. In contrast,
derivatives and are larger molecules (in both weight and size) with a high PSA, making these
derivatives less susceptible to passive diffusion across cell membranes. The higher cellular uptake of
chlorambucil derivatives and is, thus, more likely attributable to other transportation processes
,29],
1
2
1
2
than to passive diffusion. Taken together, the LAT1 binding study and the cellular uptake profile
indicate the roles of derivatives 1 and 2 as LAT1 substrates.
Table 1. Physicochemical properties of chlorambucil and its derivatives 1 and 2.
Compound
Computational Parameter
Chlorambucil
1
2
Log P
4.1
4.7
4.1
Molecular weight (g/mol)
Molecular accessible area (Å2)
Polar surface area (Å2)
304.2
558.3
40.5
467.4
798.7
92.8
466.4
802.6
95.7
Due to a more efficient cellular transport, compounds
1
and
2
accumulated in the MCF-7
cells more than did the parent drug, supporting the hypothesis that the antiproliferative activities
of derivatives and have higher cytotoxicity than those of chlorambucil in both a time- and
concentration-dependent manner. The incubation with BCH, a LAT1 inhibitor, could also decrease
the chlorambucil derivative cytotoxicity, especially compound , suggesting the contribution of
LAT1 in antiproliferative activity. Our results demonstrate that the increased intracellular uptake
attributed to LAT1 transport of derivatives and is positively related to their higher antiproliferative
activity. Derivative exhibited a higher intracellular concentration and cytotoxicity than derivative
The metabolic process in the MCF-7 cells was probably engaged; since the amide derivative was less
sensitive to enzymatic bioconversion than the ester form , the higher intracellular accumulation was
detected after the treatment of . The chlorambucil derivatives are pharmacologically active on their
1
2
2
1
2
2
1.
2
1
2
own and require no bioconversion, like a prodrug, so their intracellular concentrations relate directly
to their pharmacological activity (i.e., antiproliferation). In accordance with the antiproliferative study,
the MCF-7 cells were not as sensitive to chlorambucil, as cell cytotoxicities were not significantly

Int. J. Mol. Sci. 2020, 21, 2132
8 of 15
increased until the concentrations of compounds
1
and
2
reached 80
µM. Nonetheless, our result
demonstrated that the LAT1-targeting approach could increase cellular drug uptake, leading to the
improvement of drug efficiency, and thereby indicating the possibility of using this approach in other
LAT1-expressing cell lines.
The issues with drug stability, resistance, and selectivity limit clinical usage of chlorambucil [12].
The consequence of instability as well as drug resistance reduces chlorambucil intracellular levels,
leading to inefficient treatment. Our results demonstrate that the chlorambucil derivatives
1 and
2
accumulate inside cells at a higher level and display a greater efficiency than their parent drug.
In addition, the slow release of chlorambucil from its ester/amide derivatives could possibly retard
metabolic and/or resistance deactivation [32].
The lack of selectivity, a major concern, hinders the clinical usage of chlorambucil due to serious
adverse effects, i.e., myelosuppression and an increased risk of developing secondary neoplasm in
normal tissues [33,34]. We propose conjugating chlorambucil to LAT1 substrate so as to increase drug
selectivity. Whereas chlorambucil enters the cells nonspecifically by passive diffusion, its amino acid
conjugates bypass the cell membrane using more specific active transport. Since LAT1 is upregulated in
many cancers, specific transport using LAT1 as a carrier is conceivable to accumulate the chlorambucil
derivatives in cancer cells at a higher level than in normal cells. Therefore, the higher selectivity
could possibly lead to the reduction of nonselective side effects. In addition, the binding affinity to
LAT1 could also be enhanced by structural modifications. The meta-conjugation of l-phenylalanine
(or l-tyrosine) to a parent drug has been shown to display higher binding affinity to LAT1 than
para-conjugation [2,26]. In our experiment, chlorambucil conjugation to l-tyrosine derivatives at the
meta-position was highly acid sensitive, and both the ester and amide bonds were cleaved during the
deprotection process (unpublished data).
LAT1 has been reported to share its substrates with other transporters such as LAT2 [35],
monocarboxylate transporter 8 and 10 (MCT8/10) [36], and organic anions transporting polypeptides
(OATPs) [21]. Whereas the OATPs transport a broad range of amphipathic substrates and are not
specific to only amino acids, the MCT8/10 specifically uptakes thyroid hormone derivatives and
displays low affinity to aromatic amino acids such as tyrosine and tryptophan (Km ~ 5 mM in
Xenopus oocyte) [37]. On the other hand, LAT1 preferentially transports large and neutral amino
acids, while LAT2 displays a broader range of substrate selectivity including smaller amino acids.
In general, LAT1 binds to its substrates with higher affinity (Km ~ 10–20
µM in rat) than LAT2 to its
substrates (Km ~ 30-300 M in rat) [38]. Therefore, it is reasonable to target LAT1 for improved cancer
µ
drug uptake using aromatic amino acids, such as tyrosine, as the promoiety. Based on the results,
LAT1 contributed to cellular uptake of chlorambucil derivatives. However, the contribution of other
amino acid transporters (OATPs, MCTs, and LAT2) should not be ruled out as they share overlapping
substrates. While some of the other transporters can be found in normal tissues, the unspecific
binding among these transporters could complicate LAT1 utilization of compounds by impairing their
selectivity to cancer cells. The off-target effects are also possible and should be taken into consideration
in further in vivo studies.
In short, our study demonstrated a drug-design approach to increase the efficiency of chlorambucil,
as its derivatives displayed both higher intracellular accumulation and cytotoxicity against cancer,
which compensate for the issues of drug instability and resistance that reduce intracellular concentration
and efficiency. As LAT1 is overexpressed in several cancers, the structural modification of the drug
could possibly increase drug selectivity and reduce nonselective side effects. We suggest that the
(pro)drug design approach might be applied to other chemotherapeutic agents that contain available
functional group(s) to conjugate to the LAT1 substrate, rectifying permeability and selectivity issues.
Further studies are also needed to elucidate transporter selectivity and structural modifications for
enhancing the selectivity of chlorambucil derivatives. The pharmacokinetic profile using an animal
model should also be addressed since metabolism, unbound/bound factions, and distribution [39
]
could determine the efficiency of the derivatives in vivo.

Int. J. Mol. Sci. 2020, 21, 2132
9 of 15
4. Materials and Methods
4.1. General Synthetic Procedure
The amino acid component of compounds
1
and
2
were synthesized from
Boc-l-tyrosine-OtBu (Combi-Blocks, San Diego, CA, USA) and Boc-4-nitro-l-phenylalanine
(Combi-Blocks), respectively.
Chlorambucil was obtained from TCI (Tokyo, Japan).
N-Ethyl-N0-(3-dimethylaminopropyl)carbodiimide (EDC), 4-(dimethylamino)pyridine (DMAP),
and Pd (10% on activated charcoal), potassium carbonate (K2CO3), dimethyl sulfate ((CH3O)2SO2),
and celite were purchased from Sigma-Aldrich (St. Louis, MO, USA).
Thin-layer chromatography (TLC) with aluminum sheets coated with silica gel 60 F245 (0.24
mm) (Merck, Darmstadt, Germany) was used with suitable visualization to monitor reactions. Flash
chromatography with the Sepacore Flash system, coupled with Sepacore flash cartridge (Buchi AG,
Flawil, Switzerland), was used for purification. Nuclear magnetic resonance (NMR) spectra were
recorded by Bruker Avance 500 spectrometer (Bruker Biospin, Fällanden, Switzerland), operating at
500.13 MHz for 1H and at 125.75 MHz for 13C using tetramethylsilane (TMS) as an internal standard.
Mass spectra were characterized using a Finnigan LCQ quadrupole ion trap mass spectrometer
(Finnigan MAT, San Jose, CA, USA) coupled with an electrospray ionization source. Purity of final
products was confirmed by quantitative 1H NMR (qHNMR) using maleic acid as an internal standard.
Boc-4-amino-l-phenylalanine methyl ester 6: Boc-4-nitro-l-phenylalanine
was dissolved in 10 mL acetone after which K2CO3 (884 mg, 6.4 mmol) and (CH3O)2SO2 (242
4
(400 mg, 1.28 mmol)
L, 2.56
µ
mmol) were added. The reaction was stirred at room temperature overnight. The reaction mixture was
subsequently evaporated under reduced pressure to get a dry residue of Boc-4-nitro-l-phenylalanine
1
methyl ester (378 mg). H NMR (MeOD):
δ ppm 1.38 (s, 9H), 3.03–3.07 (m, 1H), 3.27–3.31 (m, 1H), 3.74
(s, 3H), 4.46 (dd, J1 = 5.3 Hz, J2 = 9.2 Hz), 7.49 (d, J = 8.4 Hz, 2H), 8.18 (d, J = 8.4 Hz, 2H). Pd (10% on
activated charcoal) (10 mg) was carefully added to the solution of Boc-4-nitro-l-phenylalanine methyl
ester (378 mg, 0.58 mmol) in methanol (30 mL). The reaction was stirred in a H2-saturated atmosphere
(344.7 kPa (50 psi)) overnight. The mixture was then filtered through celite and evaporated under
reduced pressure. The residue was purified by flash chromatography in gradient mode (petroleum
1
ether/ethyl acetate=1:99 to 99:1) to get compound
6
(165 mg, 43%), a brown solid. H NMR (MeOD):
δ
ppm 1.41 (s, 9H), 2.79–2.83 (m, 1H), 2.94–2.98 (m, 1H), 3.69 (s, 3H), 4.27–4.30 (m, 1H), 6.67–6.69
(d, J = 8.2 Hz, 2H), 6.94–6.96 (d, J = 8.2 Hz. 2H).
Chlorambucil (Boc-OtBu-phenylalaninate) ester 7: Chlorambucil
dissolved in 5 mL dichloromethane (DCM) with DMAP (154 mg, 0.8 mmol) and Boc-l-tyrosine-OtBu
3
(200 mg, 0.66 mmol) was
5
(270 mg, 0.8 mmol). EDC (98 mg, 0.8 mmol) in 5 mL DCM was then added dropwise into the mixture
and the reaction stirred at room temperature overnight. Ethyl acetate (40 mL) was subsequently
added to the reaction mixture. The combined solvent was washed with 1 M hydrochloric acid (HCl)
(10 mL
×
2), saturated sodium bicarbonate (NaHCO3) (10 mL
×
2), and H2O (10 mL), respectively.
The organic solvent was dried over anhydrous sodium sulfate (Na2SO4), filtrated, and evaporated
under reduced pressure. The reaction yielded compound
(CDCl3):
1
7
(270 mg, 88%), an off-white solid. H NMR
δ
ppm 1.40 (s, 9H), 1.43 (s, 9H), 2.03 (quin, J = 7.5 Hz, 2H), 2.55 (t, J = 7.5 Hz, 2H), 2.64 (t,
J = 7.5 Hz, 2H), 3.04 (d, J = 5.7 Hz, 2H), 3.61-3.72 (m, 8H), 4.43 (m, 1H), 5.00 (d, J = 8.5 Hz, 1H), 6.65
(d, J = 8.4 Hz, 2H), 6.99 (d, J = 8.4 Hz, 2H), 7.11 (d, J = 8.4 Hz, 2H), 7.17 (d, J = 8.4 Hz, 2H). 13C NMR
(CDCl3):
(2 C), 54.80 (1
134.07 (1×C), 144.37 (1×C), 149.54 (1×C), 170.80 (1×C), 172.01 (1×C).
Chlorambucil (Boc-methyl-phenylalaninate) amide 8: Chlorambucil
dissolved in 5 mL DCM with DMAP (77 mg, 0.4 mmol) and compound
δ
ppm 26.73 (1
×
C), 27.96 (3
×
C), 28.33 (3
×
C), 33.67 (1
×
C), 33.94 (1
×
C), 40.49 (2
×
C), 53.66
C),
×
×
C), 79.75 (1
×
C), 82.20 (1
×
C), 112,29 (2
×
C), 121.39 (2
×
C), 129.77 (2
×
C), 130.47 (2
×
3
(100 mg, 0.33 mmol) was
6
(130 mg, 0.4 mmol). EDC
(49 mg, 0.4 mmol) in 5 mL DCM was then added dropwise into the mixture and the reaction stirred
at room temperature overnight. Ethyl acetate (40 mL) was then added into the reaction mixture.
The combined solvent was washed with 1 M HCl (10 mL
×
2), saturated NaHCO3 (10 mL
×
2), and H2O

Int. J. Mol. Sci. 2020, 21, 2132
10 of 15
(10 mL), respectively. The organic solvent was dried over anhydrous Na2SO4, filtrated, and evaporated
1
under reduced pressure. The reaction yielded compound
(CDCl3):
3.00–3.11 (m, 2H), 3.61–3.72 (m, 11H), 4.55 (m, 1H), 4.95 (d, J = 7.7 Hz, 1H), 6.63 (d, J = 8.5 Hz, 2H),
7.04–7.10 (m, 4H), 7.42 (d, J = 8.5 Hz, 2H). 13C NMR (MeOD):
ppm 19.44 (1 C), 27.25 (3 C), 33.34
C), 79.23 (1 C), 112,16 (2 C), 119.83
C), 144.62 (1 C), 172.78 (1 C), 173.00 (1 C).
(255 mg, 0.55 mmol) was dissolved in DCM
8
(118 mg, 77%), a brown solid. H NMR
δ
ppm 1.42 (s, 9H), 2.02 (quin, J = 7.3 Hz, 2H), 2.33 (t, J = 7.5 Hz, 2H), 2.62 (t, J = 7.3 Hz, 2H),
δ
×
×
(1
(2
×
C), 35.91 (1
C), 129.17 (2
Chlorambucil phenylalanine ester 1: Compound
×
C), 40.29 (2
×
C), 51.19 (1
×
C), 53.17 (2
×
C), 60.12 (1
×
×
×
×
×
C), 129.26 (2
×
C), 130.31 (1
×
C), 132.62 (1
×
×
×
×
7
(4 mL) and trifluoroacetic acid (2 mL) was added dropwise. The reaction was stirred for 6 h at room
temperature and the solvent evaporated. The residue was purified by flash chromatography in gradient
mode (DCM/MeOH=1:99 to 99:1) to get compound
1, an off-white solid in trifluoroacetic salt (2X)
form (134 mg, 35%). 1H NMR (MeOD):
δ
ppm 2.00 (quin, J = 7.2 Hz, 2H), 2.58 (t, J = 7.3 Hz, 2H),
2.64 (t, J = 7.4 Hz, 2H), 3.10–3.14 (dd, J1 = 8.2 Hz, J2 = 14.8 Hz, 1H), 3.32–3.34 (m, 1H), 3.65–3.75 (m,
8H), 4.08 (dd, J1 = 8.2 Hz, J2 = 5.1 Hz, 1H), 6.71 (d, J = 8.7 Hz, 2H), 7.06 (d, J = 8.5 Hz, 2H), 7.11 (d,
J = 8.6 Hz, 2H), 7.17 (d, J = 8.5 Hz, 2H). 13C NMR (MeOD):
δ
ppm 26.43, 32.88, 33.55, 35.58, 40.30 (2
C), 129.99, 130.22 (2 C), 132.61, 144.75, 150.34,
170.72, 172.80. MS: calcd. for C23H28Cl2N2O4 466.14 [M]+, found 467.12 [M+H]+, 97% purity.
Chlorambucil phenylalanine amide 2: Compound (100 mg, 0.21 mmol) was dissolved in
×
C),
53.17 (2
×
C), 54.69, 112.17 (2
×
C), 122.01 (2
×
C), 129.30 (2
×
×
8
tetrahydrofuran (5 mL) and lithium hydroxide (20 mg, 0.8 mmol) in H2O (5 mL) added dropwise.
The reaction was stirred for 1.5 h and the solvent evaporated. The intermediate compound was then
dissolved in DCM (4 mL) and trifluoroacetic acid (2 mL) was added dropwise. The reaction was
stirred for 2 h at room temperature and the solvent evaporated. The residue was purified by flash
chromatography in gradient mode (DCM/MeOH=1:99 to 99:1) and recrystallized using MeOH to get
1
compound
2
, a light-brown solid in trifluoroacetic salt (2X) form (24 mg, 16%). H NMR (MeOD):
δ
ppm 1.98 (quin, J = 7.4 Hz, 2H), 2.38 (t, J = 7.5 Hz, 2H), 2.61 (t, J = 7.4 Hz, 2H), 2.98–3.02 (dd, J1 = 14.4
Hz, J2 = 8.8 Hz, 1H), 3.28–3.33 (dd, J1 = 4.1 Hz, J2 = 14.9 Hz, 1H), 3.65–3.75 (m, 8H), 3.77–3.79 (dd,
J1 = 4.1 Hz, J2 = 8.4 Hz, 1H), 6.70 (d, J = 8.6 Hz, 2H), 7.10 (d, J = 8.6 Hz, 2H), 7.27 (d, J = 8.4 Hz, 2H), 7.52
(d, J = 8.4 Hz, 2H). 13C NMR (MeOD):
δ
ppm 27.34, 33.82, 35.86, 36.24, 40.28 (2
×
C), 53.17 (2
×
C), 56.10,
112.17 (2
×
C), 120.48 (2
×
C), 129.24 (2
×
C), 129.39 (2
×
C), 130.28, 131.43, 137.72, 144.65, 172.28, 173.19. MS:
calcd. for C23H29Cl2N3O3 465.16 [M]+, found 466.09 [M+H]+, 95% purity.
4.2. HPLC Analysis
The analytical and biological samples were injected into a reversed-phase C18 analytical column
Zorbax SB-C18 (3
×
150 mm, 3.5 µm) coupled with guard-column Zorbax SB-C18 (Agilent Technologies,
Little Falls Wilmington, DE, USA). The solutions were eluted in isocratic mode with 50% acetonitrile
and deionized water (with 0.1% formic acid) as eluents at a flow rate of 0.8 mL/min. The sample
peaks were monitored by Agilent 1100 series HPLC (Agilent Technologies, Waldbronn, Karlsruhe,
Germany) with UV detection at 254 nm. The retention time of chlorambucil derivatives (1 and 2) and
chlorambucil (3) were 2.4, 1.6, and 5.0 min, respectively.
4.3. In Vitro Conversion
The rates of chemical conversion of compounds
buffer solutions (50 mM, pH 7.4) at 37 ◦C. The solutions of the chlorambucil derivatives were prepared
by adding 80 L of stock solution (0.5 mg/mL in 5% HP- -cyclodextrin (Carvasol, Wacker Chemie,
Munich, German) in phosphate buffer) to 720 L of the preheated buffer. At predetermined time
L) were sampled, mixed with MeOH (50 L), and analyzed for the remaining
1 and 2 were studied in aqueous phosphate
µ
β
µ
intervals, aliquots (50
compound by HPLC.
µ
µ
Compounds
susceptibility to bioconversion in the liver. The reactions were initiated by adding 3.0
(10 mM in DMSO) to a preheated solution consisting of 747 L phosphate buffer (20 mM, pH 7.4),
1
and
2
were incubated with the human liver microsomes as an indication of the
µL of compounds
µ

Int. J. Mol. Sci. 2020, 21, 2132
11 of 15
200
µ
L NADPH (1 mM), and 50
µ
L human liver microsomes (20 mg/mL). The mixture was incubated
thermostatically at 37 ◦C, and the 50
µL aliquots were withdrawn at predetermined time intervals.
The aliquots were then immediately mixed with 100
µ
L of ice cold MeOH and centrifuged at 14,000
×
g
for 5 min to precipitate proteins. The clear supernatants were analyzed for the remaining compound
by HPLC. The respective pseudo-first-order half-lives (T1/2) for the conversion rate of the compounds
were calculated from the slope of the linear portion of the remaining compound logarithm plots
against time.
4.4. Cell Line and Culture Condition
The human breast adenocarcinoma cell line MCF-7 was purchased from the American Type
Culture Collection (ATCC#HTB-22) (Manassas, VA, USA). The MCF-7 cells were cultured in Dulbecco’s
Modified Eagle Medium (DMEM) supplemented with 2 mM l-glutamine, 10% fetal bovine serum
(FBS), 50 units/mL penicillin, and 50% streptomycin. The cell line was incubated in a humidified
incubator at 37 ◦C with 5% CO2, and the cells were used after reaching approximately 80% confluency.
4.5. LAT1 Binding Affinity
The expression and function of LAT1 and LAT2 in MCF-7 cells was characterized in our recent
study [26]. The study indicated that LAT1 is predominant in both expression and function compared to
LAT2, implying its role as a major transporter responsible for the uptake of LAT1 substrates. The ability
of compounds to bind to LAT1 was determined as previously described [40]. In brief, MCF-7 cells
were seeded into collagen-coated, 24-well plates at a density of 1.5
cells were incubated overnight in the incubator before the affinity experiment. The cells were then
pre-incubated in 500 L of warm HBSS (Hank’s balance salt solution) for 10 min. After the removal
of HBSS, the cells were incubated for 5 min in 250 L of 5% HP- -cyclodextrin in HBSS, containing
0.157 M of compound: chlorambucil,
M of [14C]-l-leucine (PerkinElmer, Waltham, MA, USA) and 10
its derivatives ( and ), or l-tyrosine (Fluka, Buchs, Switzerland). The cells were washed twice
with ice-cold HBSS (500 L) on an ice bath and lysed by 250 L of 0.1 M sodium hydroxide (NaOH)
×
105 cells/well. The seeded
µ
µ
β
µ
µ
1
2
µ
µ
for 1 h at room temperature. The lysate was then mixed with 1 mL of an emulsifier-safe cocktail
(PerkinElmer) and the radioactivity recorded by liquid scintillation counter (Wallac 1450 MicroBeta,
Wallac Oy, Finland).
4.6. In Vitro Cellular Uptake
Determination of the intracellular concentration of compounds was performed following a
previous report [25]. Briefly, MCF-7 cells were seeded and treated as in LAT1 affinity studies.
The uptake of chlorambucil and its derivatives was studied in 250
HBSS by incubating the MCF-7 cells for varying incubation times (5–45 min, 20
(10–120 M, 15 min). The cells were washed twice with ice-cold HBSS (500 L) in an ice bath, then lysed
by 1% perchloric acid (250 L) for 0.5 h at room temperature. The suspension was removed to an
Eppendorf tube and centrifuged at 14,000 L) was analyzed
g, 4 ◦C, for 5 min. The supernatant (200
by HPLC. The respective standard curve for the intracellular concentration of compounds ( , or
) was performed by spiking known amounts of the compounds into cell lysate of untreated cells.
µL of 5% HP-β-cyclodextrin in
µM) or concentrations
µ
µ
µ
×
µ
1, 2
3
For protein determination, the cells were lysed using 250 µL of 0.1 M NaOH for 0.5 h instead of 1%
perchloric acid and were determined using Bio-Rad protein assay (Bio-Rad, CA, USA) as described by
the manufacturer, using serum albumin (Sigma-Aldrich) as the standard. The protein concentrations
in samples were recorded using an EnVision multimode plate reader (PerkinElmer). The final results
were expressed as the intracellular concentration normalized by its protein content.
4.7. Antiproliferative Activity
Cell cytotoxicity was assessed using MTT (3-(4,5-Dimethylthiazol-2-yl)-2,5-diphenyltetrazolium
bromide) assay as previously described [41]. MCF-7 cells were seeded at a density of 6 × 103 cells/well

Int. J. Mol. Sci. 2020, 21, 2132
12 of 15
into a 96-well plate and incubated overnight in an incubator. Thereafter, chlorambucil and its
derivatives were added and incubated for 24, 48, and 72 h with a final concentration ranging from 10
to 120
saline, was added to each well to achieve a final concentration of 0.5 mg/mL. The cells were then
incubated for 3 h in an incubator before discarding the media, after which 100 L of DMSO were
µM. At predetermined times, MTT (Amresco, Solon, OH, USA) solution, in phosphate buffer
µ
added to each well to solubilize the formazan. The absorbance of solubilized formazan was measured
at 570 nm (reference wavelength: 650 nm) using an EnSight multimode plate reader (PerkinElmer).
BCH (2-aminobicyclo-[2,2,1]-heptane-2-carboxylic acid) (Sigma-Aldrich) was used as a standard LAT1
inhibitor in the co-incubation assay. DMSO in 5% HP-β-cyclodextrin was used as the dispersing agent,
which had no cytotoxicity at the respective concentrations at any of the predetermined time points.
4.8. Computational Analysis
The chemical structures were analyzed using CS ChemBio3D Ultra (version 12.0; Cambridge
Soft Corporation, Waltham, MA, USA). For each molecule, energy minimization was performed by
molecular mechanics (MM2) with a root-mean-square of 0.001. The property server was used to
compute the log P, molecular weight, molecular accessible area (Å2) (as per the Connolly method),
and polar surface area (PSA) (Å2).
4.9. Statistical Analysis
The data were analyzed for normality of distribution (Shapiro–Wilk test) and homogeneity of
variance (Levene’s test) (p > 0.05). Differences among treatments were assessed using a one-way
ANOVA followed by a Tukey’s multiple comparison post hoc tests using SPSS 19.0 software for
Windows® (SPSS Inc, Chicago, IL, USA). Respective data were presented as a mean
differences with a p value < 0.05 were considered statistically significant.
±
SD and any
5. Conclusions
Structural modifications of a chemotherapeutic drug by conjugating it to LAT1 substrate can
increase its effectiveness against cancer. A synthetic method for conjugating chlorambucil and tyrosine
via either an ester or amide bond was developed to obtain derivatives 1 and 2. The MCF-7 cell line was
used as a cancer cell model to determine binding ability, intracellular uptake, and antiproliferative
activity in vitro. The chlorambucil derivatives bound to LAT1 in a manner comparable to l-tyrosine.
The respective intracellular concentration after treatment with derivatives
respective antiproliferative activity had a higher cytotoxicity than that of chlorambucil. By exploiting
LAT1 as a carrier-mediated transporter, derivatives and efficiently permeated the cell membrane,
1 and 2 was higher and their
1
2
accumulated, and exerted their cytotoxicity in vitro more efficiently than did chlorambucil. Our results
support rational drug design to elevate the intracellular drug level using a specific transporter as well
as enhancing its chemotherapeutic efficiency.
Author Contributions: Conceptualization, P.P., N.W., J.R; methodology, P.P., J.T., J.J., J.L., J.K., J.R., N.W.; formal
analysis, P.P., J.T., J.J., J.L., J.K., J.R., N.W.; investigation, P.P.; validation, P.P., J.T., J.J., J.L., J.K., J.R., N.W.;
resources, N.W., J.R.; data curation, P.P., J.R., N.W.; visualization, P.P., J.R., N.W.; writing—original draft, P.P., N.W.;
writing—review and editing, P.P., J.R., N.W.; funding acquisition, N.W., J.R.; project administration, N.W., J.R.;
All authors have read and agreed to the published version of the manuscript.
Funding: This work has received funding under the Post-Doctoral Training Program (Grant No. PD2563-09)
from Khon Kaen University, Thailand, for financial support to P.P. and N.W., and the Academy of Finland
(Grant No. 308329) for financial support to J.R.
Acknowledgments: The authors thank Tarja Ihalainen for technical assistance with the in vitro conversion studies
and Bryan Roderick Hamman for assistance with the English-language presentation.
Conflicts of Interest: The authors declare no conflict of interest.

Int. J. Mol. Sci. 2020, 21, 2132
13 of 15
References
1.
Chien, H.C.; Colas, C.; Finke, K.; Springer, S.; Stoner, L.; Zur, A.A.; Venteicher, B.; Campbell, J.; Hall, C.;
Flint, A.; et al. Reevaluating the substrate specificity of the L-type amino acid transporter (LAT1). J. Med.
Chem. 2018, 61, 7358–7373. [CrossRef] [PubMed]
2.
Peura, L.; Malmioja, K.; Laine, K.; Leppanen, J.; Gynther, M.; Isotalo, A.; Rautio, J. Large amino acid
transporter 1 (LAT1) prodrugs of valproic acid: New prodrug design ideas for central nervous system
delivery. Mol. Pharm. 2011, 8, 1857–1866. [CrossRef] [PubMed]
3.
4.
Rautio, J.; Gynther, M.; Laine, K. LAT1-mediated prodrug uptake: A way to breach the blood-brain barrier?
Ther. Deliv. 2013, 4, 281–284. [CrossRef] [PubMed]
Gynther, M.; Peura, L.; Vernerova, M.; Leppanen, J.; Karkkainen, J.; Lehtonen, M.; Rautio, J.; Huttunen, K.M.
Amino acid promoieties alter valproic acid pharmacokinetics and enable extended brain exposure. Neurochem.
Res. 2016, 41, 2797–2809. [CrossRef]
5.
6.
7.
8.
Zhao, Y.; Wang, L.; Pan, J. The role of L-type amino acid transporter 1 in human tumors. Intractable Rare Dis.
Res. 2015, 4, 165–169. [CrossRef]
Hayashi, K.; Anzai, N. Novel therapeutic approaches targeting L-type amino acid transporters for cancer
treatment. World J. Gastrointest. Oncol. 2017, 9, 21–29. [CrossRef]
Häfliger, P.; Charles, R.P. The L-type amino acid transporter LAT1—An emerging target in cancer. Int. J. Mol.
Sci. 2019, 20, 2428.
Oda, K.; Hosoda, N.; Endo, H.; Saito, K.; Tsujihara, K.; Yamamura, M.; Sakata, T.; Anzai, N.; Wempe, M.F.;
Kanai, Y.; et al. L-type amino acid transporter 1 inhibitors inhibit tumor cell growth. Cancer Sci. 2010, 101,
173–179. [CrossRef]
9.
Huttunen, K.M.; Gynther, M.; Huttunen, J.; Puris, E.; Spicer, J.A.; Denny, W.A. A selective and slowly
reversible inhibitor of L-Type amino acid transporter 1 (LAT1) potentiates antiproliferative drug efficacy in
cancer cells. J. Med. Chem. 2016, 59, 5740–5751. [CrossRef]
10. Singh, N.; Scalise, M.; Galluccio, M.; Wieder, M.; Seidel, T.; Langer, T.; Indiveri, C.; Ecker, G.F. Discovery of
potent inhibitors for the large neutral amino acid transporter 1 (LAT1) by structure-based methods. Int. J.
Mol. Sci. 2019, 20, 27. [CrossRef]
11. Okano, N.; Kawai, K.; Yamauchi, Y.; Kobayashi, T.; Naruge, D.; Nagashima, F.; Endou, H.; Furuse, J.
First-in-human phaseIstudy of JPH203 in patients with advanced solid tumors. J. Clin. Oncol. 2018, 36, 419.
[CrossRef]
12. Kaira, K.; Sunose, Y.; Ohshima, Y.; Ishioka, N.S.; Arakawa, K.; Ogawa, T.; Sunaga, N.; Shimizu, K.;
Tominaga, H.; Oriuchi, N.; et al. Clinical significance of L-type amino acid transporter 1 expression as a
prognostic marker and potential of new targeting therapy in biliary tract cancer. BMC Cancer 2013, 13, 482.
[CrossRef]
13. Wu, W.; Dong, Y.; Gao, J.; Gong, M.; Zhang, X.; Kong, W.; Li, Y.; Zeng, Y.; Si, D.; Wei, Z.; et al.
Aspartate-modified doxorubicin on its N-terminal increases drug accumulation in LAT1-overexpressing
tumors. Cancer Sci. 2015, 106, 747–756. [CrossRef] [PubMed]
14. Millard, M.; Gallagher, J.D.; Olenyuk, B.Z.; Neamati, N. A Selective Mitochondrial-Targeted Chlorambucil
with Remarkable Cytotoxicity in Breast and Pancreatic Cancers. J. Med. Chem. 2013, 56, 9170–9179. [CrossRef]
15. Pathak, R.K.; Wen, R.; Kolishetti, N.; Dhar, S. A prodrug of two approved drugs, cisplatin and chlorambucil,
for chemo war against cancer. Mol. Cancer Ther. 2017, 16, 625–635. [CrossRef]
16. Ylikangas, H.; Malmioja, K.; Peura, L.; Gynther, M.; Nwachukwu, E.O.; Leppänen, J.; Laine, K.; Rautio, J.;
Lahtela-Kakkonen, M.; Huttunen, K.M.; et al. Quantitative insight into the design of compounds recognized
by the L-type amino acid transporter 1 (LAT1). ChemMedChem 2014, 9, 2699–2707. [CrossRef] [PubMed]
17. Kim, C.S.; Cho, S.H.; Chun, H.S.; Lee, S.Y.; Endou, H.; Kanai, Y.; Kim, D.K. BCH, an inhibitor of system L
amino acid transporters, induces apoptosis in cancer cells. Biol. Pham. Bull. 2008, 31, 1096–1100. [CrossRef]
18. Shennan, D.B.; Thomson, J.; Gow, I.F.; Travers, M.T.; Barber, M.C. L-leucine transport in human breast cancer
cells (MCF-7 and MDA-MB-231): Kinetics, regulation by estrogen and molecular identity of the transporter.
BBA Biomembr. 2004, 1664, 206–216. [CrossRef]
19. Van Geldermalsen, M.; Quek, L.E.; Turner, N.; Freidman, N.; Pang, A.; Guan, Y.F.; Krycer, J.R.; Ryan, R.;
Wang, Q.; Holst, J. Benzylserine inhibits breast cancer cell growth by disrupting intracellular amino acid
homeostasis and triggering amino acid response pathways. BMC Cancer 2018, 18, 689. [CrossRef]

Int. J. Mol. Sci. 2020, 21, 2132
14 of 15
20. Ylikangas, H.; Peura, L.; Malmioja, K.; Leppanen, J.; Laine, K.; Poso, A.; Lahtela-Kakkonen, M.; Rautio, J.
Structure-activity relationship study of compounds binding to large amino acid transporter 1 (LAT1) based
on pharmacophore modeling and in situ rat brain perfusion. Eur. J. Pharm. Sci. 2013, 48, 523–531. [CrossRef]
21. Nagamori, S.; Wiriyasermkul, P.; Okuda, S.; Kojima, N.; Hari, Y.; Kiyonaka, S.; Mori, Y.; Tominaga, H.;
Ohgaki, R.; Kanai, Y. Structure-activity relations of leucine derivatives reveal critical moieties for cellular
uptake and activation of mTORC1-mediated signaling. Amino Acids. 2016, 48, 1045–1058. [CrossRef]
[PubMed]
22. Uchino, H.; Kanai, Y.; Kim, D.K.; Wempe, M.F.; Chairoungdua, A.; Morimoto, E.; Anders, M.W.; Endou, H.
Transport of amino acid-related compounds mediated by L-type amino acid transporter 1 (LAT1): Insights
into the mechanisms of substrate recognition. Mol. Pharmacol. 2002, 61, 729–737. [CrossRef] [PubMed]
23. Rautio, J.; Kumpulainen, H.; Heimbach, T.; Oliyai, R.; Oh, D.; Jarvinen, T.; Savolainen, J. Prodrugs: Design
and clinical applications. Nat. Rev. Drug Discov. 2008, 7, 255–270. [CrossRef] [PubMed]
24. Gynther, M.; Pickering, D.S.; Spicer, J.A.; Denny, W.A.; Huttunen, K.M. Systemic and brain pharmacokinetics
of perforin inhibitor prodrugs. Mol. Pharm. 2016, 13, 2484–2491. [CrossRef] [PubMed]
25. Huttunen, K.M.; Huttunen, J.; Aufderhaar, I.; Gynther, M.; Denny, W.A.; Spicer, J.A. L-type amino acid
transporter 1 (LAT1)-mediated targeted delivery of perforin inhibitors. Int. J. Pharm. 2016, 498, 205–216.
[CrossRef] [PubMed]
26. Kärkkäinen, J.; Gynther, M.; Kokkola, T.; Petsalo, A.; Auriola, S.; Lahtela-Kakkonen, M.; Laine, K.; Rautio, J.;
Huttunen, K.M. Structural properties for selective and efficient l-type amino acid transporter 1 (LAT1)
mediated cellular uptake. Int. J. Pharm. 2018, 544, 91–99. [CrossRef] [PubMed]
27. Augustyn, E.; Finke, K.; Zur, A.A.; Hansen, L.; Heeren, N.; Chien, H.C.; Lin, L.; Giacomini, K.M.; Colas, C.;
Schlessinger, A.; et al. LAT-1 activity of meta-substituted phenylalanine and tyrosine analogs. Bioorg. Med.
Chem. Lett. 2016, 26, 2616–2621. [CrossRef]
28. Hou, T.; Wang, J.; Zhang, W.; Wang, W.; Xu, X. Recent advances in computational prediction of drug
absorption and permeability in drug discovery. Curr. Med. Chem. 2006, 13, 2653–2667. [CrossRef]
29. Palm, K.; Luthman, K.; Ungell, A.L.; Strandlund, G.; Artursson, P. Correlation of drug absorption with
molecular surface properties. J. Pharm. Sci. 1996, 85, 32–39. [CrossRef]
30. Hill, B.T. Studies on the transport and cellular distribution of chlorambucil in the Yoshida ascites sarcoma.
Biochem. Pharmacol. 1972, 21, 495–502. [CrossRef]
31. Adair, C.G.; McElnay, J.C. Studies on the mechanism of gastrointestinal absorption of melphalan and
chlorambucil. Cancer Chemother. Pharmacol. 1986, 17, 95–98. [CrossRef] [PubMed]
32. Giraud, I.; Rapp, M.; Maurizis, J.C.; Madelmont, J.C. Synthesis and in vitro evaluation of quaternary
ammonium derivatives of chlorambucil and melphalan, anticancer drugs designed for the chemotherapy of
chondrosarcoma. J. Med. Chem. 2002, 45, 2116–2119. [CrossRef] [PubMed]
33. Singh, R.K.; Kumar, S.; Prasad, D.N.; Bhardwsaj, T.R. Therapeutic journery of nitrogen mustard as alkylating
anticancer agents: Historic to future perspectives. Eur. J. Med. Chem. 2018, 151, 401–433. [CrossRef]
[PubMed]
34. Reda, G.; Fattizzo, B.; Cassin, R.; Orofino, N.; Flospergher, E.; Iurlo, A.; Barcellini, W.; Cortelezzi, A. Secondary
malignancies in chronic lymphocytic leukemia: A single centre retrospective analysis of 514 cases. Blood
2015, 126, 5279. [CrossRef]
35. Wang, Q.; Holst, J. L-type amino acid transport and cancer: Targeting the mTORC1 pathway to inhibit
neoplasia. Am. J. Cancer Res. 2015, 5, 1281–1294.
36. Kinne, A.; Schülein, R.; Krause, G. Primary and secondary thyroid hormone transporters. Thyroid Res. 2011
4, S7. [CrossRef]
,
37. Kim, D.K.; Kanai, Y.; Chairoungdua, A.; Matsuo, H.; Cha, S.H.; Endou, H. Expression cloning of a
Na+-independent aromatic amino acid transporter with structural similarity to H+/monocarboxylate
transporters. J. Biol. Chem. 2001, 276, 17221–17228. [CrossRef]
38. del Amo, E.M.; Urtti, A.; Yliperttula, M. Pharmacokinetic role of L-type amino acid transporters LAT1 and
LAT2. Eur. J. Pharm. Sci. 2008, 35, 161–174. [CrossRef]
39. Puris, E.; Gynther, M.; Huttunen, J.; Petsalo, A.; Huttunen, K.M. L-type amino acid transporter 1 utilizing
prodrugs: How to achieve effective brain delivery and low systemic exposure of drugs. J. Control. Release
2017, 261, 93–104. [CrossRef]

Int. J. Mol. Sci. 2020, 21, 2132
15 of 15
40. Rautio, J.; Kärkkäinen, J.; Huttunen, K.M.; Gynther, M. Amino acid ester prodrugs conjugated to the
-carboxylic acid group do not display affinity for the L-type amino acid transporter 1 (LAT1). Eur. J. Pharm.
α
Sci. 2015, 66, 36–40. [CrossRef]
41. Pocasap, P.; Weerapreeyakul, N.; Barusrux, S. Cancer preventive effect of Thai rat-tailed radish (Raphanus
sativus L var. caudatus Alef). J. Funct. Foods 2013, 5, 1372–1381. [CrossRef]
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
