Synthesis, biological evaluation, and docking studies of a novel sulfonamido-based gallate as pro-chondrogenic agent for the treatment of cartilage

Article abstract of DOI:10.3390/molecules22010003

Gallic acid (GA) and its derivatives are anti-inflammatory agents and are reported to have potent effects on Osteoarthritis (OA) treatment. Nonetheless, it is generally accepted that the therapeutic effect and biocompatibility of GA is much weaker than it

Full text of DOI:10.3390/molecules22010003

molecules
Article
Synthesis, Biological Evaluation, and Docking
Studies of a Novel Sulfonamido-Based Gallate as
Pro-Chondrogenic Agent for the Treatment
of Cartilage
Xiao Lin 1,2,†, Ling Chai 2,†, Buming Liu 2, Hailan Chen 2, Li Zheng 3, Qin Liu 3 and Cuiwu Lin 1,
*
1
School of Chemistry and Chemical Engineering, Guangxi University, Nanning 530005, China;
linxiaolegend@163.com
Guangxi Key Laboratory of Traditional Chinese Medicine Quality Standards,
2
Guangxi Institute of Traditional Medical and Pharmaceutical Sciences, Nanning 530022, China;
cicichai001@163.com (L.C.); liu_buming@163.com (B.L.); hlchen319@163.com (H.C.)
The Medical and Scientific Research Center, Guangxi Medical University, Nanning 530021, China;
3
zhengli224@163.com (L.Z.); liuqin_2001@163.com (Q.L.)
*
†
Correspondence: cuiwulin@163.com; Tel.: +86-771-3271189
These authors contributed equally to this work.
Academic Editor: Claudiu T. Supuran
Received: 9 October 2016; Accepted: 13 December 2016; Published: 23 December 2016
Abstract: Gallic acid (GA) and its derivatives are anti-inflammatory agents and are reported
to have potent effects on Osteoarthritis (OA) treatment. Nonetheless, it is generally accepted
that the therapeutic effect and biocompatibility of GA is much weaker than its esters due to the
high hydrophilicity. The therapeutic effect of GA on OA could be improved if certain structural
modifications were made to increase its hydrophobicity. In this study, a novel sulfonamido-based
gallate was synthesized by bonding sulfonamide with GA, and its biological evaluations on OA were
investigated. Results show that 5-[4-(Pyrimidin-2-ylsulfamoylphenyl)]-carbamoyl-benzene-1,2,3-triyl
triacetate (HAMDC) was able to reverse the effects induced by Interleukin-1 (IL-1) stimulation, and it
also had a great effect on chondro-protection via promoting cell proliferation and maintaining the
phenotype of articular chondrocytes, as well as enhancing synthesis of cartilage specific markers
such as aggrecan, collagen II and Sox9. Furthermore, a docking study showed that HAMDC fits
into the core of the active site of a disintegrin and metalloproteinase with thrombospondin motifs 5
(ADAMTS-5), which provides an explanation for its activity and selectivity.
Keywords: gallic acid; sulfadiazine sodium; pro-chondrogenic agent; molecular docking
1. Introduction
Osteoarthritis (OA), the most common form of arthritis, frequently occurring after middle age,
is usually characterized by progressive failure of the extracellular cartilage matrix (ECM) and changes
in the synovium and subchondral bone [
steroidal and non-steroidal anti-inflammatory drugs (NSAIDS), which merely provide symptomatic
relief of pain and inflammation but cannot alleviate or slow down the progression of the disease [ ].
1,2]. At the present time, the treatment of OA is limited to
3
For this reason, great efforts have been devoted to the discovery and development of new drugs to
reduce the progression of OA.
In OA patients and animal models, chondrocytes usually present changes of phenotype and gene
repertoire, which is fundamentally caused by abnormal excretion of biochemical factors, such as matrix
metalloproteases (MMPs), aggrecanases (ADAMTS-4 and ADAMTS-5), IL-1β and other cytokines [4,5].
Molecules 2017, 22, 3; doi:10.3390/molecules22010003
www.mdpi.com/journal/molecules

Molecules 2017, 22, 3
2 of 16
MMP-1 plays an important role in degrading the components of cartilage matrix, especially aggrecans
and collagens. Active stromelysin (MMP-3) serves as an activator of latent collagenases and also digests
proteoglycan aggregates in human articular cartilage [
(TIMPs) are inhibitors of MMPs and an increase of TIMP levels in OA cartilage possibly reflect an
endogenous adaptive response towards the increase of proteinase activity [ ]. Recently, a series
of new arylsulfonamido-based hydroxamates have been synthesized and several of them exhibit a
marked inhibiting effect on MMP-1, MMP-13 and MMP-14 [ ]. It was further reported that some
sulfonamido-based analogs show strong inhibitory activity on MMP-13 and aggrecanase [ 10]. These
6]. Tissue inhibitor of matrix metalloproteinases
7
8
9
,
synthetic compounds have several phenyl and sulfonamide groups, the unique structure of which
plays a leading role in the prevention of cartilage degradation. These studies shed light on the synthesis
of analogs to slow down or block cartilage degradation.
Gallic acid (GA) is a well-known polyphenol and ubiquitous in tea [11], grapes [12], berries [13],
and other plant species [14
in several pharmacological and biochemical pathways [16
exhibits strong pro-apoptotic and anti-inflammatory effects in the therapy of arthritis [13
chondroprotective and chondrogenic effect of GA has also been confirmed [21 22]. Sulfonamides are a
,
15]. GA has a wide range of pharmacological activity and takes part
19]. It has been reported that GA
20]. The
–
,
,
family of broad-spectrum synthetic bacteriostatic antibiotics. Due to their easy penetration across the
biological membranes and transfer to targeted cells or organs, sulfonamides have been widely applied
on human and animals for therapeutic and prophylactic purposes in the last century [23]. It has been
reported that several sulfonamides exhibited a significant effect on the treatment of degenerative joint
disorders and joint inflammation, such as osteoarthritis and rheumatism [24,25]. All these reported
compounds contain several phenyl groups and sulfonamide groups, which shed light on the synthesis
of derivatives by coupling GA with sulfonamides. The modification of GA with sulfonamide was
expected to enhance the pharmacological activity of GA.
Recently, we have reported a series of synthesized sulfonamido-based gallates and their
effectiveness on chondro-protection [26–30], which confirm the fact that coupling of the phenyl
ring with the sulfonamide group is critical for the activity of preventing cartilage degeneration. Herein,
another analog was synthesized and shown to be effective in biological evaluation, a docking study
was therefore performed to provide an explanation for its activity and selectivity.
2. Results
2.1. Chemistry
5-[4-(Pyrimidin-2-ylsulfamoylphenyl)]-carbamoyl-benzene-1,2,3-triyl triacetate (HAMDC, Figure 1)
was synthesized from GA and sulfadiazine sodium following the synthetic route (Scheme 1).
Figure 1. Chemical structure of HAMDC.
Scheme 1. Schematic of the HAMDC synthetic procedures. Reagents and conditions: (
oil bath, 120 C; (b) SOCl2, oil bath, 80 C; (c) sulfadiazine sodium, THF, pyridine, ice bath.
a
) acetyl oxide,
◦
◦

Molecules 2017, 22, 3
3 of 16
The molecular formula of HAMDC was confirmed to be C19H18N4O6S by the analysis of
MS-ESI (Shimadzu LC-MS 2010A) and NMR (Bruker AM-400 MHz) data (Supplementary Materials,
Figures S1–S3). MS-ESI: m/z: 527.0 [M
at : 11.75 (br s, 1H, -SO2-NH), 10.67 (s, 1H, -CO-NH), 8.49 (d, J = 4.9 Hz, 2H, Py-H), 7.95 (dd, J = 9.0 Hz,
4H, 4 Ar-H), 7.80 (s, 2H, 2 Ar-H), 7.03 (m, 1H, Py-H), 2.33 (s, 3H, -CO-CH3), 2.31 (s, 6H, -CO-CH3);
13C-NMR (100 MHz, DMSO) spectrum showed signals at
: 168.00, 166.95, 163.66, 158.38, 156.93,
−
H]−, 1H-NMR (400 MHz, DMSO) spectrum showed signals
δ
×
×
δ
143.17, 142.72, 137.62, 134.43, 132.43, 128.72, 120.74, 119.74, 115.85, 20.32, 19.88.
2.2. Cytotoxicity Assay
The cytotoxicity of different drugs on rabbit articular chondrocytes was investigated via MTT
assays. As shown in Figure 2, negligible cycotoxicity was observed when concentrations of HAMDC
between 1.950 and 15.625
between 18.750 and 37.500
µ
g/mL were used. However, when the concentration increased to a range
g/mL, the cell proliferation was partially inhibited. Comparatively, SD-Na
µ
and GA exhibited insignificant or certain level of inhibitive effect on chondrocytes growth depending
on the drug concentrations. It is possible to conclude from this experiment that concentrations
of HAMDC in the range of 3.125–12.500 µg/mL promoted cell growth, and thus concentrations
of HAMDC, SD-Na, and GA were chosen as 3.125–12.500, 2.344–9.375, and 3.125–12.500
respectively, and were adopted in the subsequent studies.
µg/mL,
Figure 2. Cont.

Molecules 2017, 22, 3
4 of 16
Figure 2. Cytotoxicity of chondrocytes treated with different concentrations of HAMDC, gallic acid
(GA) and SD-Na for three days (means ± SD, n = 3). (* p < 0.05; ** p < 0.01, *** p < 0.001).
2.3. Effect of HAMDC, SD-Na and GA on IL-1β Stimulated Chondrocytes
To investigate their effects on arthritis, chondrocytes were pre-incubated with HAMDC, SD-Na
and GA for 1 h before IL-1
drug treatment), the expressions of MMP-1 and MMP-3 were upregulated, while that of TIMP-1
was reduced (Figure 3). Pre-incubation with HAMDC inhibited the IL-1 -stimulated increase of
MMP-1 and MMP-3 gene expression and significantly enhanced the TIMP-1 expression. However,
pre-incubation with SD-Na and GA could not prevent the IL-1 stimulated MMP-1, MMP-3 and
TIMP-1 expression. The effect of IL-1 , HAMDC, SD-Na and GA on the secretion of MMP-1 and
TIMP-1 proteins from chondrocytes were tested subsequently. It was found that IL-1 stimulation
β stimulation. In the OA model group (with IL-1β stimulation but without
β
β
β
β
resulted in upregulation of MMP-1 secretion and downregulation of TIMP-1 secretion (Figure 4).
In agreement with the RT-PCR results, HAMDC was able to downregulate MMP-1 expression and
upregulate TIMP-1 expression, as demonstrated with increased positive staining of MMP-1 and
negative staining of TIMP-1 in the immunohistochemical images (Figure 4). These results indicated
that the MMPs induction and TIMP-1 downregulation that resulted from IL-1
effectively blocked by HAMDC but not SD-Na and GA.
β stimulation could be
Figure 3. Cont.

Molecules 2017, 22, 3
5 of 16
Figure 3. Quantitative analysis of ECM-related gene expressions by qRT-PCR, (
and ( ) TIMP-1. Chondrocytes were cultured with different concentrations of HAMDC, GA and
SD-Na for 2, 4 and 6 days. They were then stimulated with IL-1 for another 24 h. Control: cells
without any treatment; IL-1 : cells stimulated with IL-1 ; C-1 to C-3: cells pre-incubated with 3.125,
6.250, and 12.500 g/mL HAMDC, respectively; G-1 to G-3: cells pre-incubated with 3.125, 6.250, and
12.500 g/mL GA, respectively; H-1 to H-3: cells pre-incubated with 2.344, 4.688, and 9.375 g/mL
A) MMP-1; (B) MMP-3;
C
β
β
β
µ
µ
µ
SD-Na, respectively. The gene expressions of MMP-1, MMP-3,−a∆n∆dCtTIMP-1 in cells treated with
HAMDC, GA and SD-Na relative to control were analyzed by the 2
method using GAPDH as the
internal control. Each condition was repeated for three times, and data are presented as mean
(p < 0.05).
±
SD.
Figure 4. Immunohistochemical staining images of MMP-1 (
firstly pre-incubated with different concentrations of HAMDC, GA and SD-Na for 1 h, and further
stimulated with IL-1 for 1 days: ( ) 3.125 g/mL HAMDC; ( ) 6.250 g/mL HAMDC; ( ) 12.500 g/mL
HAMDC; ( ) 3.125 g/mL GA; ( ) 6.250 g/mL GA; ( ) 12.500 g/mL GA; ( ) 2.344 g/mL SD-Na;
) 4.688 g/mL SD-Na; ( ) 9.375 g/mL SD-Na; ( ) Control (no drug treatment and no stimulation);
a) and TIMP-1 (b). Chondrocytes were
β
A
µ
B
µ
C
µ
D
µ
E
µ
F
µ
G
µ
(
H
µ
I
µ
J
(K) IL-1β model (no drug treatment, but with IL-1β stimulation). Scale bar = 200 µm.
2.4. Cell Proliferation
In this study, the cell proliferation was analyzed by the DNA content after treatment with drugs
for 2, 4, and 6 days. From Figure 5A, significantly higher DNA content has been observed from
chondrocytes cultured with HAMDC comparing with control (p < 0.05), indicating that HAMDC was
able to promote cell proliferation. The optimal concentration was found to be 12.500
in agreement with MTT results.
µg/mL, which is

Molecules 2017, 22, 3
6 of 16
Figure 5. Quantification of cell proliferation (DNA) and matrix production (glycosaminoglycan (GAG))
by biochemical assays: ( ) the proliferation of chondrocytes cultured with different concentrations
of HAMDC, GA and SD-Na for 2, 4 and 6 days. Control: cells without any treatment; IL-1 : cells
stimulated with IL-1 ; C-1 to C-3: cells pre-incubated with 3.125, 6.250, and 12.500 g/mL HAMDC,
respectively; G-1 to G-3: cells pre-incubated with 3.125, 6.250, and 12.500 g/mL GA, respectively;
H-1 to H-3: cells pre-incubated with 2.344, 4.688, and 9.375 g/mL SD-Na, respectively; ( ) Content
A
β
β
µ
µ
µ
B
of GAG (mg) normalized to DNA (mg). Each condition was repeated for four times, and data are
presented as mean ± SD. (p < 0.05).
2.5. Secretion of GAGs
Glycosaminoglycans (GAGs) are the building blocks of cartilage and joint fluid. It is thought
that the secretion of glycosaminoglycans in the cartilage inhibits the enzymes that destroy cartilage.
To examine the effect of HAMDC on the secretion of GAG, the chondrocytes were treated with
HAMDC, SD-Na or GA for 2, 4, and 6 days and then subjected to biochemical assays. Under the same
conditions, GAG production was gradually increased over time (Figure 5B). It was found that HAMDC
treatment dramatically enhanced the GAG production compared to controls. In contrast, SD-Na and
GA treatment reduced the GAG production. In line with the cell proliferation results, a concentration
of HAMDC at 12.5 µg/mL exhibited the strongest effect on promoting GAG synthesis among the three
tested concentrations.
The safranin O-positive stain (Figure 6a) shows that GAGs were abundant and homogeneously
distributed around the chondrocytes which have been treated with HAMDC. In contrast, fewer GAGs
have been observed in condrocytes treated with SD-Na and GA compared to the control.
2.6. Cell Morphology
The morphology of articular chondrocytes treated with HAMDC (3.125, 6.250 and 12.500
µg/mL),
SD-Na (2.344, 4.688 and 9.375 g/mL) and GA (3.125, 6.250 and 12.500 g/mL) for 2, 4, and 6 days
µ
µ
were observed under an invert microscope (Figure 6b, here shows cells treated for 6 days). The number
of condrocytes in the HAMDC group was obviously larger than the SD-Na, GA, and control groups.
Cells with all tested concentrations of HAMDC-grown confluent were observed for 2 days with healthy
morphology (data not shown), and the largest number of cells was obtained when a concentration
of 12.500
µg/mL was used. In contrast, the above phenomenon was not observed in SD-Na and
GA groups.
Figure 7a showed the actin filaments of chondrocytes stained with rhodamine phalloidin/Hoechst
33258. A higher density and larger covered area of filaments was observed from the HAMDC groups
compared with other conditions, which was in agreement with the HE analysis (Figure 6b).

Molecules 2017, 22, 3
7 of 16
Figure 6. Inverted phase contrast microscopy images showing the GAG production (
morphology ( ) of chondrocytes treated with different concentrations of HAMDC, GA and SD-Na
for 6 days: ( ) 3.125 g/mL HAMDC; ( ) 6.250 g/mL HAMDC; ( ) 12.500 g/mL HAMDC;
g/mL GA; ( ) 6.250 g/mL GA; ( ) 12.500 g/mL GA; ( ) 2.344 g/mL SD-Na;
g/mL SD-Na; ( ) 9.375 g/mL SD-Na; ( ) Control (no drug treatment and no stimulation).
a) and cellular
b
A
µ
B
µ
C
µ
(
D
) 3.125
) 4.688
µ
E
I
µ
F
J
µ
G
µ
(
H
µ
µ
Scale bar = 200 µm.
Figure 7. Confocal laser scanning microscopy images showing the actin filaments (
) of chondrocytes treated with different concentrations of HAMDC, GA and SD-Na for 6 days:
(A) 3.125 µg/mL HAMDC; (B) 6.250 µg/mL HAMDC; (C) 12.500 µg/mL HAMDC; (D) 3.125 µg/mL
GA; ( ) 6.250 g/mL GA; ( ) 12.500 g/mL GA; ( ) 2.344 g/mL SD-Na; ( ) 4.688 g/mL SD-Na;
a) and viability
(
b
E
µ
F
µ
G
µ
H
µ
(I) 9.375 µg/mL SD-Na; (J) Control (no drug treatment and no stimulation). Scale bar = 200 µm.
2.7. Cell Viability Assay
The viable and dead cells were determined by the calcein/PI staining method (Figure 7b). It seems
that the number of live cells in the HAMDC groups was much larger than that of the SD-Na, GA group,
and control groups, which consistent with the cell proliferation results. These findings suggest that

Molecules 2017, 22, 3
8 of 16
HAMDC might benefit from the chondrocyte survival and growth, and the optimal concentration is
12.500 µg/mL.
2.8. Secretion of Type I and Type II Collagen
The cartilaginous intracellular matrix deposition was evaluated by immunohistochemical assay
of type I and type II collagen. From Figure 8, a large area of positive stained cartilage-specific type II
collagen was observed in the HAMDC groups after 2, 4, and 6 days. In contrast, sparse and light stained
type I collagen was observed, indicating the inhibition of chondroncyte dedifferentiation. For SD-Na
and GA groups, type II collagen staining was weaker and collagen I staining was stronger compared
to the control. These results imply that HAMDC possesses greater ability to inhibit chondrocyte
dedifferentiation in vitro compared to SD-Na and GA.
Figure 8. Immunohistochemical staining images showing the presence of type I (a) and type II (b)
collagens. Chondrocytes treated with different concentrations of HAMDC, GA and SD-Na for 6 days:
(A) 3.125 µg/mL HAMDC; (B) 6.250 µg/mL HAMDC; (C) 12.500 µg/mL HAMDC; (D) 3.125 µg/mL
GA; (E) 6.250 µg/mL GA; (F) 12.500 µg/mL GA; (G) 2.344 µg/mL SD-Na; (H) 4.688 µg/mL SD-Na;
(I) 9.375 µg/mL SD-Na; (J) Control (no drug treatment and no stimulation). Scale bar = 200 µm.
2.9. Gene Expression
The effect of HAMDC, SD-Na and GA on chondrocyte ECM synthesis was further investigated by
detecting the gene expression of collagen I, collagen II, collagen X, Sox9, and aggrecan (a proteoglycan
composed of GAGs). Figure 9 showed that the transcription of aggrecan, collagen II, and Sox9 were
notably promoted by HAMDC but significantly suppressed by SD-Na and GA. Compared to the
control, lower collagen I expression was observed from the HAMDC group but higher or similar levels
of collagen I expression were found from the SD-Na and GA groups. Particularly, cells treated with
12.500 µg/mL of HAMDC showed the best performance with highest levels of collagen II, aggrecan,
and Sox9 expression. Meanwhile, collagen X could hardly be detected under all conditions, suggesting
the absence of cell hypertrophy. These results indicate that HAMDC was able to upregulate the
expression of collagen II, aggrecan, and Sox9 and downregulate that of collagen type I, indicating that
HAMDC might be able to delay or prevent the chondrocyte dedifferentiation.

Molecules 2017, 22, 3
9 of 16
Figure 9. Quantitative comparison of ECM-related gene expression by qRT-PCR: (
were pre-incubated with different concentrations of HAMDC, GA and SD-Na for 2 days, 4 days and 6 days, and then stimulated by 10 ng/mL IL-1
without any treatment; IL-1 : cells stimulated with IL-1 ; C-1 to C-3: cells pre-incubated with 3.125, 6.250, and 12.500 g/mL HAMDC, respectively; G-1 to G-3: cells
pre-incubated with 3.125, 6.250, and 12.500 g/mL GA, respectively; H-1 to H-3: cells pre-incubated with 2.344, 4.688, and 9.375
A
–
C) aggrecan; (D–F
) collagen II; (
G
–
I) Sox9; and (
J–
L) collagen I. The chondrocytes
β. Control: cells
β
β
µ
µ
µ
g/mL SD-Na, respectively. The gene
−∆∆Ct
expressions of aggrecan, collegen II, Sox9 and collagen I in cells treated with HAMDC, GA and SD-Na relative to control were analyzed by the 2
method using
GAPDH as the internal control. Each condition was repeated for three times, and data are presented as mean ± SD (p < 0.05).

Molecules 2017, 22, 3
10 of 16
2.10. Molecular Docking Studies of Sulfonamido-Based Gallates
It is envisaged that the sulfonamido-based gallates that have been demonstrated to be effective
might owe this to their binding interaction with the ADAMTS-5 L-shaped S1’ subsite. In light of this
hypothesis, we performed molecular docking to find out whether this proposal is reliable. The catalytic
site in ADAMTS-5 structure has an L-shaped funnel, opening up at the zinc site at its widest point,
the hydrophobic channel through the S1’-site and out to the solvent at its distalend. In our docking
result (Figure 10), HAMDC is in the lowest energy docked conformation, the acetyl group of gallic
acid moiety coordinates the catalytic zinc atom in a chelation fashion with H410, H414, and H420, and
establishes three hydrogen bonds with the H414, L379, and L438 side chain. Meanwhile, the benzyl
ring of benzsulfamide establishes a pi-pi interaction with the imidazole ring of H410. Furthermore,
other lipophilic contacts are detectable between HAMDC and the side chain of H373, T378, S440, S445,
and R437 as seen in Figure 11. Clearly, all these interactions endowed HAMDC with a inhibitory
activity toward ADAMTS-5.
Figure 10. Docked pose of HAMDC with ADAMTS-5 (PDB code: 3B8Z).
Figure 11. The interaction between HAMDC and ADAMTS-5 (PDB code: 3B8Z) on a 2D Diagram.

Molecules 2017, 22, 3
11 of 16
3. Discussion
In Nuti’s report [
8], the phenyl ring adjacent to the sulfonamide group is important for the
pharmacological activity of arylsulfonamide hydroxamate, since it allows the perfect docking of
sulfonamides onto ADAMTS-5 and then inhibits ADAMTS-5 activity on the native aggrecan substrate.
In this study, a novel compound (HAMDC) was synthesized from GA and sulfonamide. Its effect on
IL-1
β
stimulated rabbit articular chondrocytes has been studied. It was found that HAMDC effectively
-stimulated induction of MMP-1 and MMP-3 but enhanced the expression of
inhibited the IL-1
β
TIMP-1. However, a negligible effect has been observed when GA and SD-Na were used. These
results confirm the fact that coupling of phenyl ring with the sulfonamide group is critical for the
activity of the compound and the GA modification is helpful to improve its pharmacological activity.
It can be concluded form this study that HAMDC has great potential to be developed as a potent
anti-inflammatory agent for the OA treatment.
On the other hand, our research indicates that HAMDC was able to promote chondrocyte growth,
showing better results compared to the control and its raw materials (Figure 2). Biochemical assays
have shown that HAMDC could greatly promote GAG deposition around cultured chondrocytes
(Figure 5). Further, HAMDC possesses the ability to upregulate the expression of aggrecan, collagen II,
and Sox9 (Figure 9). All these results suggest that HAMDC can benefit chondrocyte proliferation and
stimulate exuberant cartilage matrix secretion. In contrast, the expression of collagen type I, a marker
of chondrocyte dedifferentiation, was effectively inhibited by HAMDC. Moreover, collagen type X,
a protein specifically reflecting hypertrophic chondrocytes and regulating the onset of endochondral
ossification, was nearly undetectable in the HAMDC groups. Therefore, the reduced transcription
of collagen I and undetectable collagen X demonstrate that HAMDC might be able to prevent the
chondrocyte dedifferentiation and hypertrophy.
Meanwhile, Molecular docking was conducted. With its acetyl moiety coordinating the catalytic
zinc atom, three established hydrogen bonds, and a pi-pi interaction with the imidazole ring,
the HAMDC presented a good docking result with the ADAMTS-5 L-shaped S1’ subsite. The deacetylation
derivative of HAMDC was also acquired in an acid hydrolysis experiment after HAMDC was
purified and scored a high affinity in the docking study. However, it exhibited an inhibitive effect
on chondrocytes growth in the concentration between 0 and 40
therefore the subsequent experiments were not performed in this way. Nevertheless, other synthesized
sulfonamido-based gallate analogues we had investigated previously [26 30] presented great effect on
µg/mL in a cytotoxicity assay, and
–
promoting chondrocyte growth and upregulating the expression of aggrecan, collagen II and Sox9,
which confirm the fact that coupling of the phenyl ring with the sulfonamide group is critical for the
pro-chondrogenic activity of these compounds and this docking model would provide us with a quick
method to screen out the effective compounds. More docking studies should be performed in our
further investigation to optimize their structures.
4. Materials and Methods
4.1. Synthesis and Preparation of HAMDC
HAMDC was synthesized from GA and sulfadiazine sodium following the synthetic route which
was reported previously [27]. Five grams of GA was dissolved in 20 mL acetyl oxide and refluxed for
8 h. Subsequently, 300 mL distilled water was added to produce recipitates. The precipitates were
filtrated and dried, then 20 mL SOCl2 was added and refluxed for 6 h. The solution was evaporated in
vacuo and mixed with 8 g sulfadiazine sodium in THF and stirred in an ice bath for 2 h. Upon the
end of the reactions, an appropriate volume of distilled water (~10 times to the volume of reaction
system) was added to the mixture. The obtained product was precipitated and filtered. It was then
recrystallized in a THF-methanol solvent system and dried in a vacuum oven at 80 ◦C. The obtained
product exhibited a pale yellow color in a powder form. The yield of HAMDC was 61% (3.05 g).

Molecules 2017, 22, 3
12 of 16
To prepare the stock solution (20 mg/mL), 20 mg HAMDC was dissolved in 0.1 M sodium
hydroxide solution (NaOH, Sigma, Saint Louis, MO, USA), then the pH was adjusted to 7.0 with
0.1M HCl, and finally diluted with water to 1 mL. Aqueous stock solutions of GA (20 mg/mL) and
◦
sulfadiazine sodium (SD-Na) (20 mg/mL) were also prepared. All stock solutions were stored at
before being used.
−
4 C
4.2. Articular Chondrocyte Culture
The articular chondrocytes were harvested from knee joint cartilage slices of one-week-old New
Zealand rabbits by enzymatic digestion. The cartilage slices were first digested with 0.25% trypsin
(Solarbio, Beijing, China) for 30 min. They were then further digested with 2 mg/mL collagenase
type II (Gibco, Big Cabin, OK, USA) in alpha-modified Eagle’s medium (
were collected via centrifugation in 1000 rpm for 5 min, followed by resuspended in a complete culture
medium consisting of -MEM supplemented with 20% (v/v) fetal bovine serum (FBS) (Gibco) and 1%
α-MEM, Gibco) for 3 h. Cells
α
(v/v) antibiotics (100 U/mL penicillin and 100 U/mL streptomycin, Gibco). Cells were maintained at
37 ◦C in a saturated-humid atmosphere of 95% air and 5% CO2. The culture medium was replaced
every other day. The second passage of articular chondrocytes was used for the following experiments.
4.3. Cytotoxicity Assay
The cytotoxicity of HAMDC on chondrocyte was evaluated by the 3-(4,5-dimethylthiahiazol-2-
y1)-2,5-di-phenyltetrazolium bromide (MTT, Gibco) assay. Specifically, articular chondrocytes were
cultured in 96-well plates with 200
GA and SD-Na with defined concentrations. After 3 days cultured, 20
(5 mg/mL, Gibco) was added to each well and further incubated for 4 h. The supernatant was
carefully removed, the formazan crystals was dissolved in 150 L of dimethyl sulfoxide (DMSO,
µL culture medium in each well. Cells were treated with HAMDC,
µL of MTT stock solution
µ
Gibco), and the absorbance at 570 nm was measured using an enzyme-labeled meter (Thermo Fisher
Scientific, Hemel Hempstead, UK). The cytotoxicity results showed that HAMDC concentrations
ranging from 1.950 to 15.625 µg/mL did not have a negative effect on cell survival and proliferation.
Thus, final concentrations of HAMDC and GA ranging from 3.125 to 12.500 µg/mL, SD-Na from 2.344
to 9.375 µg/mL were chosen for further analysis.
4.4. Effect of HAMDC on IL-1 Stimulated Chondrocytes
To investigate the effect of HAMDC, SD-Na and GA on Interleukin-1 (IL-1) stimulated
chondrocytes, five groups were divided as following: (1) control group, chondrocytes without
any treatment; (2) OA model group, chondrocytes treated with IL-1
(3) HAMDC treatment groups, chondrocytes pre-incubated with three concentrations of HAMDC
(3.125, 6.250 and 12.500 g/mL) followed by stimulation with IL-1 for 24 h; (4) SD-Na treatment
groups, chondrocytes pre-incubated with three concentrations of SD-Na (2.344, 4.688 and 9.375 g/mL)
followed by stimulation with IL-1 for 24 h; (5) GA treatment groups, chondrocytes pre-incubated
with three concentrations of GA (3.125, 6.250 and 12.500 g/mL) followed by stimulation with IL-1
β (10 ng/mL, Gibco, USA);
µ
β
µ
β
µ
β
for 24 h. The concentrations of HAMDC, SD-Na and GA were determined by cytotoxicity assay results.
4.5. Cell Proliferation Analysis and Biochemical Assay
Cell proliferation and biochemical assays were carried out after treating with HAMDC, GA, and
SD-Na for 2, 4, and 6 days. For the cell proliferation assay, cells were first digested with proteinase
K (Sigma), and their DNAs were labeled with a fluorescent dye Hoechst 33258. The fluorescence
intensity at 460 nm indicating the total DNA content was measured. The total glycosaminoglycans
(GAGs) under each condition were measured by the 1,9-dimethylmethylene blue (DMMB; Sigma)
spectrophotometric assay following the manufacture’s instruction. Chondroitin sulfate (Sigma) was
used as control to plot the standard curve. The amount of GAGs in each group was normalized to the
total DNA content.

Molecules 2017, 22, 3
13 of 16
4.6. Safranin O Staining
The secretion of glycosaminoglycan (GAG) was confirmed by Safranin-O/fast green-stain.
Specifically, cells were fixed with 95% alcohol for 30 min and then stained with 0.1% Safranin O
(Sigma) for 10 min. Subsequently, the cells were rinsed with water and sealed with neutral gum. They
were then observed under an inverted phase contrast microscope and photographed with adapted
camera (Zeiss Corporation, Oberkochen, Germany).
4.7. Morphological Examination
The cellular morphology of articular chondrocytes was observed with optical microscope and
fluorescent microscope. For optical microscope, cells were cultured for 2, 4, and 6 days, followed
by fixing in 95% alcohol. Cells were then subjected to Hematoxylin-eosin (HE) (Jiancheng Biotech,
China) staining, followed by washing with PBS, naturally dried, and sealed with neutral gum. After
that, cells were observed under an inverted phase contrast microscope and photographed with an
adapted camera.
Fluorescent microscope was employed to investigate the structure of cellular matrix. Firstly, cells
were fixed with 4% paraformaldehyde (PFA, Sigma) for 10 min at room temperature, rinsed with
PBS, and then treated with 0.5% Triton X-100 (Sigma Aldrich) for 5 min. Cells were then treated
with rhodamine phalloidin (Invitrogen, Carlsbad, CA, USA) for 30 min at room temperature in dark
followed by double-staining with Hoechst 33258 (Beyotime, Santa Cruz, CA, USA) for 5 min. Finally,
the labeled-articular chondrocytes were observed with a laser scanning confocal microscope (Nikon A1,
Tokyo, Japan).
4.8. Cell Viability Assay
The cell viability of articular chondrocytes cultured for 2, 4, and 6 days were studied using a
live-dead viability assay kit (Invitrogen). Briefly, calcein-AM and propidium iodide were added to
the cell cultures to a final concentration of 1 µmol/L for each. Cells were then incubated in dark at
37 ◦C for 5 min. Stained cells were observed and imaged with a laser scanning confocal microscope
(Nikon A1, Japan). Cell viability were measured and calculated from the fluorescent intensity of
obtained images.
4.9. Immunohistochemical Staining
The secretion of collagen type I and type II, MMP-1 and TIMP-1 were measured using
immunohistochemical staining kits (Bioss, Beijing, China) following the manufacture’s instructions.
Specifically, cells were firstly fixed in 4% (w/v) paraformaldehyde for 5 min and then treated with
Triton X-100 for 5 min. To exclude endogenous peroxidase activity, cells were incubated with 3%
H2O2 for 10 min and then blocked with goat serum for 10 min at room temperature. Cells were then
incubated with primary collagen type I and type II (rabbit anti-rabbit antibody, Boster, Wuhan, China)
for 2.5 h. They were then rinsed with PBS 3 times and incubated with second antibody attached with
biotin-labeled horseradish peroxidase for 30 min. Subsequently, the cells were counterstained with
hematoxylin and then analyzed using the 30-diaminobenzidine tetrahydrochloride (DAB) kit (Boster)
according to the manufacturer’s instructions. The cells were then gradually dehydrated by series
concentration of ethanol and sealed with neutral gum. An inverted phase contrast microscope was
used to evaluate and photograph the stained cells.
4.10. RNA Extraction, Real-Time Fluorescence Quantitative Reverse Transcription–Polymerase Chain
Reaction (qRT-PCR)
qRT-PCR was used to analyze the expression of type I, II and X collagen, aggrecan, Sox9, MMP-1,
MMP-3 and TIMP-1. The sequences of the specific primers were designed according to specific genes
and shown in Table 1. Total intracellular RNA was extracted using RNA isolation kits (Tiangen

Molecules 2017, 22, 3
14 of 16
Biotechnology; Beijing, China). Approximately 300 ng of total RNA was used as templates for the
reverse transcription into cDNA using reverse transcription kit (Fermentas Company, Waltham, MA,
USA). The qRT-PCR reactions were performed on a Quantitative PCR Detection System (Realplex 4,
Eppendorf Corporation, Hauppauge, NY, USA) with a FastStart Universal SYBR Green Master (Mix,
Roche Company, Grenzach, Germany) under the cycle conditions of 10 min at 95, 15 s at 95 ◦C and
1 min at 60 ◦C. The melting curve data were recorded to verify the PCR specificity. Each gene was
analyzed in triplicate to diminish operation errors. The relative gene expression levels were calculated
using the 2−∆∆Ct method according to glyceraldehyde-3-phosphate dehydrogenase (GAPDH).
Table 1. Sequences of the primers used in the qRT-PCR.
mRNA
Forward Primer
Reverse Primer
0
0
0
0
0
GAPDH
Aggrecan
type I collagen
type II collagen
type X collagen
Sox9
5 -GTCATCATCTCAGCCCCCTC-3
5 -GGATGCGTTGCTGACAATCT-3
0
0
0
5 -TTGCCTTTGTGGACACCAGT-3
5 -CCCAGCCACCTCAAGAGAAG-3
5 -TCCGGAAACCAGGACCAAAG-3
5 -GAGCCAAGGACGTAAACCCA-3
0
0
0
0
5 -CGGGGCTCTTGATGTTCTCA-3
0
0
0
CTTTGTCACCACGGTCACCT-3
0
0
0
0
0
5 -CTACGCTGAGCGGTACCAAA-3
5 -GGCTTCCCAGTGGCTGATAG-3
0
0
0
5 -GACGCACATCTCGCCCAAC-3
5 -TCTCGCTTCAGGTCAGCCTT-3
The results are presented as means
variance (ANOVA) followed by Dunnett’s post hoc test. The level of significance was set to p < 0.05.
±
SD. The statistical significance was determined using one way analysis of
4.11. Docking Setup
Molecular docking was performed with the aim of revealing the interaction between HAMDC and
ADAMTS-5 at an atomic level. The docking of HAMDC into ADAMTS-5 (PDB ID: 3B8Z) was carried
out by autodock program, The AutoDockTools 1.5.6 package was employed to generate the docking
input files, PyMOL 1.6 as the graphical user interface for 3D structure visualization, and Ligplus as the
2D structure-protein interaction visualizer to show the hydrogen bonds and hydrophobic contacts.
The docking centre has been defined as center_x: 12.695, center_y: 2.665, and center_z:
−
5.569. Grids
points of 56 20 26 with 0.375 Å spacing were calculated around the docking area for all the ligand
atom types using AutoGrid4. 100 separate docking calculations were performed using the Lamarckian
genetic algorithm local search (GALS) method. The docking results from each of the 100 calculations
were clustered on the basis of root-mean-square deviation (rmsd = 2.0 Å) between the Cartesian
coordinates of the ligand atoms and were ranked on the basis of the free energy of binding. In terms
of the above parameters, a re-docking process was performed as well and it presented an excellent
similarity to the ligand in 3B8Z Crystal Structure, revealing that the method we developed was reliable.
5. Conclusions
In conclusion, a new chemical compound was successfully synthesized by bonding sulfonamide
to the GA chemical structure in this study. It was demonstrated that HAMDC was able to relieve the
IL-1 stimulated chondrocyte destruction and thus lower the progression of OA. Further, HAMDC
possessed the ability to promote cell proliferation and maintain the phenotype of rabbit articular
chondrocytes. Summarizing the obtained results in our study, we believe that HAMDC has great
potential as a pro-chondrogenic agent for the treatment of cartilage problems.
Supplementary Materials: Supplementary materials can be accessed at: http://www.mdpi.com/1420-3049/22/
1/3/s1.
Acknowledgments: The work was supported by the Guangxi Key Laboratory of Traditional Chinese Medicine
Quality Standards (guizhongzhongkai201102), the Guangxi Natural Science Foundation (2014GXNSFBB118004),
and the National Natural Science Foundation of China (21362001).
Author Contributions: Xiao Lin, Buming Liu, Li Zheng and Cuiwu Lin designed the research; Xiao Lin, Li Zheng
and Qin Liu performed experiments; Xiao Lin and Ling Chai analyzed the data, Xiao Lin, Hailan Chen, and
Ling Chai wrote or contributed to the writing of the manuscript.

Molecules 2017, 22, 3
15 of 16
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
Goldring, M.B.; Goldring, S.R. Osteoarthritis. J. Cell. Physiol. 2007, 213, 626–634. [CrossRef] [PubMed]
Aigner, T.; Sachse, A.; Gebhard, P.M.; Roach, H.I. Osteoarthritis: Pathobiology-targets and ways for
therapeutic intervention. Adv. Drug Deliv. Rev. 2006, 58, 128–149. [CrossRef] [PubMed]
3.
4.
5.
Fajardo, M.; di Cesare, P.E. Disease-modifying therapies for osteoarthritis: Current status. Drugs Aging 2005
22, 141–161. [CrossRef] [PubMed]
Goldring, S.R.; Goldring, M.B. The role of cytokines in cartilage matrix degeneration in osteoarthritis.
Clin. Orthop. Relat. Res. 2004, S27–S36. [CrossRef]
Aida, Y.; Maeno, M.; Suzuki, N.; Namba, A.; Motohashi, M.; Matsumoto, M.; Makimura, M.; Matsumura, H.
The effect of IL-1beta on the expression of inflammatory cytokines and their receptors in human chondrocytes.
Life Sci. 2006, 79, 764–771. [CrossRef] [PubMed]
,
6.
7.
8.
Okada, Y.; Shinmei, M.; Tanaka, O.; Naka, K.; Kimura, A.; Nakanishi, I.; Bayliss, M.T.; Iwata, K.;
Nagase, H. Localization of matrix metalloproteinase 3 (stromelysin) in osteoarthritic cartilage and synovium.
Lab. Investig. 1992, 66, 680–690. [PubMed]
Hembry, R.M.; Bagga, M.R.; Reynolds, J.J.; Hamblen, D.L. Immunolocalisation studies on six matrix
metalloproteinases and their inhibitors, TIMP-1 and TIMP-2, in synovia from patients with osteo- and
rheumatoid arthritis. Ann. Rheum. Dis. 1995, 54, 25–32. [CrossRef] [PubMed]
Nuti, E.; Santamaria, S.; Casalini, F.; Yamamoto, K.; Marinelli, L.; la Pietra, V.; Novellino, E.; Orlandini, E.;
Nencetti, S.; Marini, A.M.; et al. Arylsulfonamide inhibitors of aggrecanases as potential therapeutic agents
for osteoarthritis: Synthesis and biological evaluation. Eur. J. Med. Chem. 2013, 62, 379–394. [CrossRef]
[PubMed]
9.
Noe, M.C.; Natarajan, V.; Snow, S.L.; Mitchell, P.G.; Lopresti-Morrow, L.; Reeves, L.M.; Yocum, S.A.; Carty, T.J.;
Barberia, J.A.; Sweeney, F.J.; et al. Discovery of 3,3-dimethyl-5-hydroxypipecolic hydroxamate-based
inhibitors of aggrecanase and mmp-13. Bioorg. Med. Chem. Lett. 2005, 15, 2808–2811. [CrossRef] [PubMed]
10. Noe, M.C.; Natarajan, V.; Snow, S.L.; Wolf-Gouveia, L.A.; Mitchell, P.G.; Lopresti-Morrow, L.; Reeves, L.M.;
Yocum, S.A.; Otterness, I.; Bliven, M.A.; et al. Discovery of 3-OH-3-methylpipecolic hydroxamates: Potent
orally active inhibitors of aggrecanase and MMP-13. Bioorg. Med. Chem. Lett. 2005, 15, 3385–3388. [CrossRef]
[PubMed]
11. Gil, D.M.A.; Falé, P.L.V.; Serralheiro, M.L.M.; Rebelo, M.J.F. Herbal infusions bioelectrochemical polyphenolic
index: Green tea—The gallic acid interference. Food Chem. 2011, 129, 1537–1543. [CrossRef]
12. Liu, Y.; Pukala, T.L.; Musgrave, I.F.; Williams, D.M.; Dehle, F.C.; Carver, J.A. Gallic acid is the major
component of grape seed extract that inhibits amyloid fibril formation. Bioorg. Med. Chem. Lett. 2013, 23,
6336–6340. [CrossRef] [PubMed]
13. Jean-Gilles, D.; Li, L.; Ma, H.; Yuan, T.; Chichester, C.O.; Seeram, N.P. Anti-inflammatory effects of
polyphenolic-enriched red raspberry extract in an antigen-induced arthritis rat model. J. Agric. Food Chem.
2012, 60, 5755–5762. [CrossRef] [PubMed]
14. Bhadoriya, U.; Sharma, P.; Solanki, S.S. In vitro free radical scavenging activity of gallic acid isolated from
caesalpinia decapetala wood. Asian Pac. J. Trop. Dis. 2012, 2, S833–S836. [CrossRef]
15. Soong, Y.-Y.; Barlow, P.J. Quantification of gallic acid and ellagic acid from longan (Dimocarpus longan lour.)
seed and mango (Mangifera indica L.) kernel and their effects on antioxidant activity. Food Chem. 2006, 97,
524–530. [CrossRef]
16. Hsiang, C.-Y.; Hseu, Y.-C.; Chang, Y.-C.; Kumar, K.J.S.; Ho, T.-Y.; Yang, H.-L. Toona sinensis and its major
bioactive compound gallic acid inhibit lps-induced inflammation in nuclear factor-κb transgenic mice as
evaluated by in vivo bioluminescence imaging. Food Chem. 2013, 136, 426–434. [CrossRef] [PubMed]
17. Chandramohan Reddy, T.; Bharat Reddy, D.; Aparna, A.; Arunasree, K.M.; Gupta, G.; Achari, C.; Reddy, G.V.;
Lakshmipathi, V.; Subramanyam, A.; Reddanna, P. Anti-leukemic effects of gallic acid on human leukemia
k562 cells: Downregulation of COX-2, inhibition of BCR/ABL kinase and NF-κB inactivation. Toxicol. Vitro
2012, 26, 396–405. [CrossRef] [PubMed]

Molecules 2017, 22, 3
16 of 16
18. Ho, H.-H.; Chang, C.-S.; Ho, W.-C.; Liao, S.-Y.; Wu, C.-H.; Wang, C.-J. Anti-metastasis effects of gallic acid on
gastric cancer cells involves inhibition of NF- b activity and downregulation of PI3K/AKT/small gtpase
κ
signals. Food Chem. Toxicol. 2010, 48, 2508–2516. [CrossRef] [PubMed]
19. Pal, C.; Bindu, S.; Dey, S.; Alam, A.; Goyal, M.; Iqbal, M.S.; Maity, P.; Adhikari, S.S.; Bandyopadhyay, U.
Gallic acid prevents nonsteroidal anti-inflammatory drug-induced gastropathy in rat by blocking oxidative
stress and apoptosis. Free Radic. Biol. Med. 2010, 49, 258–267. [CrossRef] [PubMed]
20. Yoon, C.-H.; Chung, S.-J.; Lee, S.-W.; Park, Y.-B.; Lee, S.-K.; Park, M.-C. Gallic acid, a natural polyphenolic
acid, induces apoptosis and inhibits proinflammatory gene expressions in rheumatoid arthritis fibroblast-like
synoviocytes. Jt. Bone Spine 2013, 80, 274–279. [CrossRef] [PubMed]
21. Shukla, M.; Gupta, K.; Rasheed, Z.; Khan, K.A.; Haqqi, T.M. Consumption of hydrolyzable tannins-rich
pomegranate extract suppresses inflammation and joint damage in rheumatoid arthritis. Nutrition 2008, 24,
733–743. [CrossRef] [PubMed]
22. Na, C.S.Y.; Sun, Y.; Kim, J.B.; Noh, H.J.; Eom, N.; Lee, J.M.; Nam, D.E.; Kim, O.K. Gyeong Rhus Verniciflua
Stokes Extracts for Preventing and Treating Degenerative Arthritis. KR Patent 2013083570, 23 July 2013.
23. Baran, W.; Adamek, E.; Ziemian´ska, J.; Sobczak, A. Effects of the presence of sulfonamides in the environment
and their influence on human health. J. Hazard. Mater. 2011, 196, 1–15. [CrossRef] [PubMed]
24. Marc, N.; Nis, H.; Friedemann, S.; Tilo, W.; Uwe, D. Armin Hofmeister N-[4-(1H-pyrazolo
[3,4-b]pyrazin-6-yl)-phenyl]-sulfonamides and Their Use as Pharmaceuticals. WO Patent 2013041119,
28 March 2013.
25. Taylor, S.; Hallett, D.J.; Townsend, R.J. Sulfonamide Compounds, Pharmaceutical Compositions and Uses
Thereof. WO Patent 2010130638, 18 November 2010.
26. Wei, S.; Lu, Z.; Zou, Y.; Lin, X.; Lin, C.; Liu, B.; Zheng, L.; Zhao, J. A novel synthesized sulfonamido-based
gallate-jez-c as potential therapeutic agents for osteoarthritis. PLoS ONE 2015, 10, e0125930. [CrossRef]
[PubMed]
27. Lin, X.; Zheng, L.; Liu, Q.; Liu, B.; Jiang, B.; Peng, X.; Lin, C. In vitro effect of a synthesized sulfonamido-based
gallate on articular chondrocyte metabolism. Bioorg. Med. Chem. Lett. 2014, 24, 2497–2503. [CrossRef]
[PubMed]
28. Liu, Q.; Li, M.-Y.; Lin, X.; Lin, C.-W.; Liu, B.-M.; Zheng, L.; Zhao, J.-M. Effect of a novel synthesized
sulfonamido-based gallate-szntc on chondrocytes metabolism in vitro. Chem. Biol. Interact. 2014, 221,
127–138. [CrossRef] [PubMed]
29. Xu, G.J.; Lu, Z.H.; Lin, X.; Lin, C.W.; Zheng, L.; Zhao, J.M. Effect of JJYMD-C, a novel synthetic derivative of
gallic acid, on proliferation and phenotype maintenance in rabbit articular chondrocytes in vitro. Braz. J.
Med. Biol. Res. Rev. 2014, 47, 637–645. [CrossRef]
30. Lu, Z.; Wei, S.; Wu, H.; Lin, X.; Lin, C.; Liu, B.; Zheng, L.; Zhao, J. A novel synthesized sulfonamido-based
gallic acid–LDQN-C: Effects on chondrocytes growth and phenotype maintenance. Bioorg. Chem. 2014, 57,
99–107. [CrossRef] [PubMed]
Sample Availability: Samples of the compounds HAMDC are available from the authors.
©
2016 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC-BY) license (http://creativecommons.org/licenses/by/4.0/).
