(3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester

Base Information

• Chemical Name: (3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester
• CAS No.: 223490-73-1
• Molecular Formula: C₂₃H₂₃ClN₂O₅S
• Molecular Weight: 474.965
• Mol file: 223490-73-1.mol

Synonyms:(3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester

Chemical Property of (3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of (3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester

There total 4 articles about (3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield:

{3-[(Pyridine-3-sulfonylamino)-methyl]-phenyl}-acetic acid methyl ester + 2-bromoethyl 3-chlorophenyl ether (6487-84-9) → (3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester (223490-73-1)

Guidance literature:

{3-[(Pyridine-3-sulfonylamino)-methyl]-phenyl}-acetic acid methyl ester; With sodium hydride; In DMF (N,N-dimethyl-formamide); at 0 - 20 ℃; for 0.5h;

2-bromoethyl 3-chlorophenyl ether; In DMF (N,N-dimethyl-formamide); at 0 - 20 ℃;

Reference yield:

Pyridine-3-sulfonyl chloride (16133-25-8) → (3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester (223490-73-1)

Guidance literature:

Multi-step reaction with 2 steps

1: hydrogenchloride; diisopropylamine / dichloromethane

2: methanol; dichloromethane; N,N-dimethyl-formamide; mineral oil

With hydrogenchloride; diisopropylamine; In methanol; dichloromethane; N,N-dimethyl-formamide; mineral oil;

Reference yield:

(3-(2-methoxy-2-oxoethyl)phenyl) methanaminium chloride (197792-60-2) → (3-(((2-(3-chloro-phenoxy)-ethyl)-(pyridine-3-sulfonyl)-amino)-methyl)-phenyl)-acetic acid methyl ester (223490-73-1)

Guidance literature:

Multi-step reaction with 2 steps

1: hydrogenchloride; diisopropylamine / dichloromethane

2: methanol; dichloromethane; N,N-dimethyl-formamide; mineral oil

With hydrogenchloride; diisopropylamine; In methanol; dichloromethane; N,N-dimethyl-formamide; mineral oil;

upstream raw materials:

2-bromoethyl 3-chlorophenyl ether

Pyridine-3-sulfonyl chloride

(3-(2-methoxy-2-oxoethyl)phenyl) methanaminium chloride

(3-cyano-phenyl)-acetic acid methyl ester
