6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid

Base Information

• Chemical Name: 6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid
• CAS No.: 1560834-87-8
• Molecular Formula: C₂₄H₃₁N₅O₇
• Molecular Weight: 501.539
• Mol file: 1560834-87-8.mol

Synonyms:6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid

Chemical Property of 6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of 6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid

There total 2 articles about 6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 79.0%

methyl 6-(2-(2-(ethyl(4-((4-nitrophenyl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoate → 6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid (1560834-87-8)

Guidance literature:

methyl 6-(2-(2-(ethyl(4-((4-nitrophenyl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoate; With potassium hydroxide; In methanol; toluene; for 3h; Reflux;

With hydrogenchloride; In methanol; water; toluene; pH=5;

DOI:10.1039/c3ob41421c

Reference yield:

2-(2-(ethyl(4-((4-nitrophenyl)diazenyl)phenyl)amino)ethoxy)acetic acid (253426-53-8) → 6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid (1560834-87-8)

Guidance literature:

Multi-step reaction with 2 steps

1.1: O-(1H-benzotriazol-1-yl)-N,N,N',N'-tetramethyluronium hexafluorophosphate; benzotriazol-1-ol / N,N-dimethyl-formamide / 1 h

1.2: 20 °C

2.1: potassium hydroxide / toluene; methanol / 3 h / Reflux

2.2: pH 5

With benzotriazol-1-ol; O-(1H-benzotriazol-1-yl)-N,N,N',N'-tetramethyluronium hexafluorophosphate; potassium hydroxide; In methanol; N,N-dimethyl-formamide; toluene;

DOI:10.1039/c3ob41421c

Reference yield: 79.0%

4-nitro-phenol (100-02-7,78813-13-5,89830-32-0) + 6-(2-(2-(ethyl(4-((4-nitrocyclohexa-1,3-dien-1-yl)diazenyl)phenyl)amino)ethoxy)acetamido)hexanoic acid (1560834-87-8) → 4-nitrophenyl 3-(4-((4-nitrophenyl)diazenyl)phenyl)-8-oxo-6,9-dioxa-3,10-diazahexadecan-16-oate (1560834-88-9)

Guidance literature:

With pyridine; trichlorophosphate; at -15 ℃;

DOI:10.1039/c3ob41421c

upstream raw materials:

2-(2-(ethyl(4-((4-nitrophenyl)diazenyl)phenyl)amino)ethoxy)acetic acid

Downstream raw materials:

4-nitrophenyl 3-(4-((4-nitrophenyl)diazenyl)phenyl)-8-oxo-6,9-dioxa-3,10-diazahexadecan-16-oate
