7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione

Base Information

• Chemical Name: 7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione
• CAS No.: 132533-69-8
• Molecular Formula: C₄₆H₆₀N₆O₁₂S₄
• Molecular Weight: 1017.28
• Mol file: 132533-69-8.mol

Synonyms:7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione

Chemical Property of 7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione

Chemical Property:

Purity/Quality:

Safty Information:

• Pictogram(s):
• Hazard Codes:

MSDS Files:

Useful:

Technology Process of 7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione

There total 4 articles about 7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione which guide to synthetic route it. The literature collected by LookChem mainly comes from the sharing of users and the free literature resources found by Internet computing technology. We keep the original model of the professional version of literature to make it easier and faster for users to retrieve and use. At the same time, we analyze and calculate the most feasible synthesis route with the highest yield for your reference as below:

synthetic route:

Reference yield: 82.0%

1-(p-toluenesulfonyl)-1,4,7-triazacyclononane (129422-96-4) + {2-[{2-[{2-[(2-Carboxymethoxy-ethyl)-(toluene-4-sulfonyl)-amino]-ethyl}-(toluene-4-sulfonyl)-amino]-ethyl}-(toluene-4-sulfonyl)-amino]-ethoxy}-acetic acid (132533-68-7) → 7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione (132533-69-8)

Guidance literature:

With diphenylphosphoranyl azide; triethylamine; In N,N-dimethyl-formamide; for 16h; Ambient temperature;

DOI:10.1016/S0040-4039(00)97093-X

Reference yield: 24.0%

1-(p-toluenesulfonyl)-1,4,7-triazacyclononane (129422-96-4) + {2-[{2-[{2-[(2-Chlorocarbonylmethoxy-ethyl)-(toluene-4-sulfonyl)-amino]-ethyl}-(toluene-4-sulfonyl)-amino]-ethyl}-(toluene-4-sulfonyl)-amino]-ethoxy}-acetyl chloride (132533-73-4) → 7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione (132533-69-8)

Guidance literature:

With triethylamine; In benzene;

DOI:10.1016/S0040-4039(00)97093-X

Reference yield:

6,9,12-triaza-3,15-dioxa-6,9,12-tritosylheptadecane-1,17-diol (83076-78-2) → 7,10,13,22-Tetrakis-(toluene-4-sulfonyl)-4,16-dioxa-1,7,10,13,19,22-hexaaza-bicyclo[17.5.2]hexacosane-2,18-dione (132533-69-8)

Guidance literature:

Multi-step reaction with 2 steps

1: 85 percent / Jones'reagent / acetone / Ambient temperature

2: 82 percent / Et₃N, diphenylphosphoryl azide (DPPA) / dimethylformamide / 16 h / Ambient temperature

With Jones'reagent; diphenylphosphoranyl azide; triethylamine; In N,N-dimethyl-formamide; acetone;

DOI:10.1016/S0040-4039(00)97093-X

upstream raw materials:

1-(p-toluenesulfonyl)-1,4,7-triazacyclononane

{2-[{2-[{2-[(2-Chlorocarbonylmethoxy-ethyl)-(toluene-4-sulfonyl)-amino]-ethyl}-(toluene-4-sulfonyl)-amino]-ethyl}-(toluene-4-sulfonyl)-amino]-ethoxy}-acetyl chloride

{2-[{2-[{2-[(2-Carboxymethoxy-ethyl)-(toluene-4-sulfonyl)-amino]-ethyl}-(toluene-4-sulfonyl)-amino]-ethyl}-(toluene-4-sulfonyl)-amino]-ethoxy}-acetic acid

6,9,12-triaza-3,15-dioxa-6,9,12-tritosylheptadecane-1,17-diol
