229467-26-9

Basic information

• Product Name: Methyl 4-(naphthalen-1-yl)benzoate
• Synonyms: Methyl 4-(naphthalen-1-yl)benzoate
• CAS NO: 229467-26-9
• Molecular Formula: C₁₈H₁₄O₂
• Molecular Weight: 262.30256
• Mol File: 229467-26-9.mol

Chemical Properties

• Appearance: /
• Storage Temp.: 2-8°C
• CAS DataBase Reference: Methyl 4-(naphthalen-1-yl)benzoate(CAS DataBase Reference)
• NIST Chemistry Reference: Methyl 4-(naphthalen-1-yl)benzoate(229467-26-9)
• EPA Substance Registry System: Methyl 4-(naphthalen-1-yl)benzoate(229467-26-9)

Safety Data

• Hazardous Substances Data: 229467-26-9(Hazardous Substances Data)

Upstream product

• 619-42-1 4-methoxycarbonylphenyl bromide
• 13922-41-3 1-Naphthylboronic acid
• 1144-13-4 naphthalen-1-yl N,N-dimethylsulfamate
• 99768-12-4 4-methoxycarbonylphenylboronic acid
• 905966-40-7 methyl 4-(5,5-dimethyl-1,3,2-dioxaborinan-2-yl)benzoate
• 619-44-3 methyl 4-iodobenzoate
• 90-13-1 1-Chloronaphthalene
• 54806-25-6 chloro(1-naphthyl)bis(triphenylphosphine)nickel(II)
• 51207-43-3 methyl 4-(tosyloxy)benzoate
• 86-56-6 N,N-dimethyl-1-naphthalenamine
• 90-11-9 1-Bromonaphthalene
• 1351445-39-0 N,N,N-trimethyl-1-naphthalenaminium trifluoromethanesulfonate
• 171364-80-0 methyl 4-(4,4,5,5-tetramethyl-1,3,2-dioxaborolan-2-yl)benzoate
• 1126-46-1 Methyl 4-chlorobenzoate

Downstream Products

• 106359-69-7 4-(naphthalen-1-yl)benzoic acid
• 106359-61-9 N-hydroxy-4-(naphthalene-1-yl)benzamide

Relevant articles and documents

C(sp2)-C(sp2) Suzuki cross-coupling of arylammonium salts catalyzed by a stable Pd–NHC complex

We have developed the Suzuki-Miyaura cross-coupling of aryl ammonium salts via C–N bond activation catalyzed by an easily prepared and bench-stable palladium-N-heterocyclic carbene complex. The reaction proceeded well under mild conditions with phenylboronic acid, pinacol ester or anhydride and provided yields of products up to 97% with good functional group compatibility. The direct arylation of arylamine can be performed by a two-step one-pot process and the protocol can be performed on the gram scale.

Cobalt-catalyzed C(sp2)?CN bond activation: Cross-electrophile coupling for biaryl formation and mechanistic insight

Herein, we report a cross-electrophile coupling of benzonitrile derivatives and aryl halides with a simple cobalt-based catalytic system under mild conditions to form biaryl compounds. Even though the cobalt catalyst is able to activate the C(sp2)?CN bond alone, the use of the AlMe3 Lewis acid enhances the reactivity of benzonitriles and improves the cross-selectivity with barely any influence on the functional group compatibility. X-ray structure determination of an original low-valent cobalt species combined with catalytic and stoichiometric reactions reveals a catalytically active cobalt(I) species toward the aryl halide partner. On the other hand, experimental insights, including cyclic voltammetry experiments, suggest the involvement of a cobalt complex of a lower oxidation state to activate the benzonitrile derivative. Finally, density functional theory calculations support the proposed mechanistic cycle involving two low-valent cobalt species of different oxidation states to perform the reaction.

Generation of Organozinc Reagents by Nickel Diazadiene Complex Catalyzed Zinc Insertion into Aryl Sulfonates

The generation of arylzinc reagents (ArZnX) by direct insertion of zinc into the C?X bond of ArX electrophiles has typically been restricted to iodides and bromides. The insertions of zinc dust into the C?O bonds of various aryl sulfonates (tosylates, mesylates, triflates, sulfamates), or into the C?X bonds of other moderate electrophiles (X=Cl, SMe) are catalyzed by a simple NiCl2–1,4-diazadiene catalyst system, in which 1,4-diazadiene (DAD) stands for diacetyl diimines, phenanthroline, bipyridine and related ligands. Catalytic zincation in DMF or NMP solution at room temperature now provides arylzinc sulfonates, which undergo typical catalytic cross-coupling or electrophilic substitution reactions.

Nickel-Catalyzed Stille Cross Coupling of C-O Electrophiles

Aryl sulfamates, tosylates, and mesylates undergo efficient Ni-catalyzed cross coupling with diverse organostannanes in the presence of relatively unhindered alkylphosphine ligands and KF. The coupling is valuable for difficult bond constructions, such as aryl - heteroaryl, aryl - alkenyl, and aryl - alkynyl, using nontriflate phenol derivatives. A combination of experimental and computational studies implicates an unusual mechanism for transmetalation involving an 8-centered cyclic transition state. This reaction is inhibited by chloride sources due to slow transmetalation of organostannanes at a Ni(II) - chloride intermediate. These studies help to explain why prior efforts to achieve Ni-catalyzed Stille coupling of phenol derivatives were unsuccessful.

A highly efficient and recyclable NiCl2(dppp)/PEG-400 system for Suzuki-Miyaura reaction of aryl chlorides with arylboronic acids

NiCl2(dppp) in PEG-400 is shown to be a highly efficient catalyst for Suzuki-Miyaura coupling of aryl chlorides with arylboronic acids. The reaction could be conducted at 100 °C using K3PO4 as base, yielding a variety of biaryls in good to excellent yields. The isolation of the products was readily performed by extraction with petroleum ether and NiCl2(dppp)/PEG-400 system could be easily recycled and reused up to five times without significant loss of activity. Our system not only avoids the use of easily volatile and toxic dioxane or toluene as a solvent but also solves the basic problem of nickel catalyst reuse.

An efficient class of bis-NHC salts: Applications in Pd-catalyzed reactions under mild reaction conditions

This study describes an efficient class of bis-N-heterocyclic carbene (bis-NHC) salts that can be easily made from commercially available and inexpensive starting materials. The application of these salts to Pd-catalyzed reactions is described. The palladium (Pd) catalyst generated in situ was highly effective under mild reaction conditions.

Synthesis of 3-Arylbenzofuran-2-ylphosphines via Rhodium-Catalyzed Redox-Neutral C-H Activation and Their Applications in Palladium-Catalyzed Cross-Coupling of Aryl Chlorides

A new class of aryl-heteroarylphosphines, 3-arylbenzofuran-2-ylphosphines, was synthesized by [Cp?Rh(III)]-catalyzed redox-neutral cyclization of N-phenoxyacetamides with 1-alkynylphosphine sulfides and oxides followed by reduction. This step-economic reaction proceeds in excellent regioselectivity with a broad substrate scope. The application of the resulting air-stable trivalent-phosphine containing dicyclohexylphosphino moiety in palladium-catalyzed Suzuki-Miyaura coupling and Buchwald-Hartwig amination of aryl chlorides is also described.

An Indefinitely Air-Stable σ-NiII Precatalyst for Quantitative Cross-Coupling of Unreactive Aryl Halides and Mesylates with Aryl Neopentylglycolboronates

Three classes of Ni precatalysts based on π-NiII, π-Ni0 and σ-NiII complexes have been elaborated and employed in different laboratories for the functionalization and cross-coupling of otherwise inert aryl C-O, C-Cl, and C-F electrophiles. Various Ni precatalysts, ligands, boron sources, and reaction conditions that were developed in various research groups, necessitated the selection of the most suitable conditions for desired cross-coupling partners. Here a universal, bench-stable, easily prepared NiIICl(1-naphthyl)(PCy3)2/PCy3 σ-complex, for efficient and quantitative cross-coupling of aryl chlorides, bromides, iodides, mesylates, and fluorides with aryl neopentylglycolboronates is reported. This precatalyst will most probably help to advance the applications of Ni catalysis in organic, supramolecular, and macromolecular synthesis and will provide an easier access to the selection of reaction conditions for various transformations.

Air-stable nickel precatalysts for fast and quantitative cross-coupling of aryl sulfamates with aryl neopentylglycolboronates at room temperature

A library containing 10 air-stable NiIIX(Aryl)(PCy3)2 complexes as precatalysts (X = Cl, Br, OTs, OMs, aryl = 1-naphthyl, 2-naphthyl; X = Cl, 1-acenaphthenyl, 1-(2-methoxynaphthyl), 9-phenanthrenyl, 9-anthracyl) was synthesized and demonstrated to quantitatively cross-couple 2-methoxyphenyl dimethylsulfamate with methyl 4-(5,5-dimethyl-1,3,2-dioxaborinane-2-yl)benzoate at 23 °C in dry THF in the presence of K3PO4(H2O)3.2 in less than 60 min. Lower or higher amounts of H2O in K3PO4 and as received THF mediate the same transformation in a maximum three times longer reaction time.

An efficient suzuki-miyaura coupling of aryl sulfamates and boronic acids catalyzed by NiCl2(dppp)

The Suzuki-Miyaura cross-coupling of aryl sulfamates and boronic acids was investigated by using [1,3-bis(diphenylphosphanyl)propane]nickel(II) chloride {NiCl2(dppp)} as the catalyst. The results showed that NiCl 2(dppp) is a highly active and general catalyst that allows effective Suzuki-Miyaura cross-coupling of aryl sulfamates with a slight excess amount of the boronic acid (1.2 equiv.) in the presence of a low catalyst loading (generally 1.0-1.5 mol-%). The method also displays broad generality not only to various aryl sulfamates, but also to an array of boronic acids. Furthermore, various functional groups are tolerated. These apparent advantages make NiCl2(dppp) a practical and reliable catalyst system for the Suzuki-Miyaura coupling of aryl sulfamates.
