The hypopigmentary action of KI-063 (a new tyrosinase inhibitor) combined with terrein

Article abstract of DOI:10.1211/jpp.60.3.0009

Resorcinol derivatives are known to inhibit melanin synthesis. In this study, resorcinol derivatives were synthesized and screened for their activity on melanogenesis. KI-063 (a tyrosinase inhibitor) was examined for its effects on melanogenesis using a spontaneously immortalized mouse melanocyte cell line (Mel-Ab). In a cell-free system, KI-063 directly inhibited tyrosinase, the rate-limiting melanogenic enzyme. Moreover, in a cell system, it inhibited melanin synthesis in a concentration-dependent manner. In addition, KI-063 inhibited the activity of cellular tyrosinase. Thus, this study examined the effects of a combination of KI-063 with terrein, an agent that down-regulates microphthalmia-associated transcription factor. The data suggest that KI-063 has an additive effect in combination with terrein. Thus, the suppression of tyrosinase activity by KI-063 and the inhibition of tyrosinase production by terrein appear to be an optimal combination for skin whitening.

Full text of DOI:10.1211/jpp.60.3.0009

JPP 2008, 60: 343–348
© 2008 The Authors
Received June 3, 2007
Accepted November 13, 2007
DOI 10.1211/jpp.60.3.0009
ISSN 0022-3573
The hypopigmentary action of KI-063 (a new
tyrosinase inhibitor) combined with terrein
Dong-Seok Kim, Sangku Lee, Hyun-Kyung Lee, Seo-Hyoung Park,
In-Ja Ryoo, Ick-Dong Yoo, Sun-Bang Kwon, Kwang Jin Baek,
Jung-Im Na, Kyoung-Chan Park
Abstract
Department of Biochemistry,
College of Medicine, Chung-Ang
University, 221 Heukseok-Dong
Dongjak-Gu, Seoul 156-756,
Republic of Korea
Resorcinol derivatives are known to inhibit melanin synthesis. In this study, resorcinol deriva-
tives were synthesized and screened for their activity on melanogenesis. KI-063 (a tyrosinase
inhibitor) was examined for its effects on melanogenesis using a spontaneously immortalized
mouse melanocyte cell line (Mel-Ab). In a cell-free system, KI-063 directly inhibited tyrosinase,
the rate-limiting melanogenic enzyme. Moreover, in a cell system, it inhibited melanin synthesis
in a concentration-dependent manner. In addition, KI-063 inhibited the activity of cellular tyrosi-
nase. Thus, this study examined the effects of a combination of KI-063 with terrein, an agent that
down-regulates microphthalmia-associated transcription factor. The data suggest that KI-063 has
an additive effect in combination with terrein. Thus, the suppression of tyrosinase activity by KI-063
and the inhibition of tyrosinase production by terrein appear to be an optimal combination for skin
whitening.
Dong-Seok Kim, Kwang Jin Baek
National Cosmeceutical Research
Center, Korea Research Institute
of Bioscience and Biotechnology,
52 Oeun-Dong, Yuseong-Gu,
Daejeon 305-333, Korea
Sangku Lee, In-Ja Ryoo,
Ick-Dong Yoo
Department of Dermatology,
Seoul National University
College of Medicine,
Introduction
28 Yongon-Dong, Chongno-Gu,
Seoul 110-744, Republic of Korea
The production and distribution of melanin pigment is a major determinant of skin and
hair colour. Tyrosinase is a major melanosomal enzyme in melanogenesis, which catalyses
the rate-limiting reaction of the melanogenic process (Hearing & Jimenez 1989; Slominski
et al 2004). Therefore, melanin production depends mainly on the expression and activa-
tion of tyrosinase (Hearing & Tsukamoto 1991). Previous studies reported that resorcinol
(1,3-dihydroxybenzene) derivatives inhibit the activity of tyrosinase (Tasaka et al 1998).
Compounds with a 4-substituted resorcinol skeleton are potent inhibitors of tyrosinase
(Shimizu et al 2000; Kim & Uyama 2005; Song et al 2007). Some of these polyphenols
can act as both inhibitors and substrates through a complex reaction involving tyrosinase
(Espin et al 1997; Fenoll et al 2003). Indeed, several polyphenols act as suicide substrates,
causing a mechanism-based inactivation of tyrosinase (Garcia Canovas et al 1987; Tudela
et al 1988; Haghbeen et al 2004; Chang 2007). Moreover, we have recently reported that
4-n-butylresorcinol strongly inhibits melanogenesis (Kim et al 2005), and this agent has
been useful as an experimental treatment for melasma (Khemis et al 2007). Thus, resorcinol
derivatives (including KI-063) were synthesized and screened for their inhibitory effects
on tyrosinase.
Microphthalmia-associated transcription factor (MITF) is known to regulate tyrosi-
nase expression and melanin synthesis at the transcription level (Yasumoto et al 1997;
Bertolotto et al 1998; Lin & Fisher 2007). Hence, mutations in the MITF gene cause
abnormal pigmentation of the skin and hair (Hughes et al 1994; Tassabehji et al 1994;
Tachibana 1997). Activation of the extracellular signal-regulated kinase (ERK) pathway
has been shown to decrease levels of MITF and to inhibit melanin synthesis (Englaro et al
1998; Kim et al 2002, 2003). We have shown that terrein, a bioactive fungal metabolite,
down-regulates MITF and tyrosinase through activation of ERK and thus reduces melanin
synthesis (Park et al 2004). We therefore hypothesized that the inhibition of tyrosinase
Hyun-Kyung Lee, Seo-Hyoung
Park, Jung-Im Na,
Kyoung-Chan Park
Welskin Co. Ltd,
28 Yongon-Dong, Chongno-Gu,
Seoul 110-744, Korea
Sun-Bang Kwon
Correspondence: Kyoung-Chan
Park, Department of
Dermatology, Seoul National
University Bundang Hospital,
300 Gumi-Dong, Bundang-Gu,
Seongnam-Si, Kyoungki-Do
463-707, Korea. E-mail:
gcpark@snu.ac.kr
Acknowledgements: This study
was supported by a grant
(A050432) from the Korea
Health 21 R&D Project, Ministry
of Health and Welfare, Republic
of Korea. We also wish to
acknowledge the support of the
Welskin Corporation (Seoul,
Republic of Korea).
343

344
Dong-Seok Kim et al
production by terrein might strongly potentiate the inhibitory the cells were treated with KI-063 at various concentrations
effect of tyrosinase inhibitors on melanin synthesis.
for 4 days. The cell pellets were dissolved in 1 mL 1 m NaOH
This study examined the effects of KI-063 on melanin at 100ꢁC for 30 min and centrifuged for 20 min at 16,000 g.
synthesis and tyrosinase activity in a spontaneously immor- The optical density of the supernatants was measured at
talized mouse melanocyte cell line (Mel-Ab), alone and in
combination with terrein.
400 nm using an ELISA reader (TECAN). Before measuring
the melanin content, the cells were observed under a phase-
contrast microscope (Olympus Optical Co., Tokyo, Japan)
and photographed with a CoolSNAPcf digital video camera
system (Roper Scientific, Inc., Tucson, AZ, USA) supported
by RS Image software (Roper Scientific).
Materials and Methods
Materials
KI-063 and terrein were synthesized at the Korea Research
Institute of Bioscience and Biotechnology (Lee et al 2005).
Cholera toxin (CT), 12-O-tetradecanoylphorbol-13-acetate
(TPA), synthetic melanin, l-DOPA, and mushroom tyrosi-
nase were obtained from Sigma (St Louis, MO, USA).
Tyrosinase activity
The tyrosinase activity was assessed using a slight modifica-
tion of the method described by Busca et al (1996). Briefly,
Mel-Ab cells were cultured in six-well plates and incubated
with KI-063 at various concentrations for 4 days. The cells
were then washed with ice-cold phosphate-buffered saline
and lysed with 0.1 m phosphate buffer (pH 6.8) containing
1% Triton X-100. Cells were then disrupted by freezing and
thawing, and the lysates clarified by centrifugation at 10 000 g
for 5 min. After quantifying protein levels and adjusting
the concentrations with lysis buffer, 90ꢃL of each lysate
containing the same amount of protein was placed in each
well of a 96-well plate and 10ꢃL 10mm l-DOPA added to
each well. The control wells contained 90ꢃL 0.1 m phosphate
buffer (pH 6.8) and 10ꢃL 10mm l-DOPA. After incuba-
tion at 37ꢁC, the absorbance at 475 nm was measured every
10 min for at least 1 h using an ELISA plate reader.
Synthesis of KI-063
KI-063 was synthesized through the esterification of
dihydrocaffeic acid with 4-n-butylresorcinol using NꢀNꢀ-
dicyclohexylcarbodiimide and 4-di(methylamino)pyridine.
NꢀNꢀ-dicyclohexylcarbodiimide (720 mg, 3.49 mm) and
4-di(methylamino)pyridine (60 mg, 0.49 mm) were added to
a solution of dihydrocaffeic acid (500 mg, 2.75 mm) and 4-
n-butylresorcinol (450 mg, 2.71 mm) in ethyl acetate (30 mL)
at room temperature. The reaction mixture was stirred for
24 h, concentrated, and purified by silica gel column chro-
matography (2:1 hexane/ethyl acetate) to give KI-063. Its
chemical structure was analysed by NMR as follows: 1H
NMR (CDCl3, 300 MHz), ꢁ (ppm) 7.04 (d, J = 8ꢂ4Hz, 1H),
6.78 (d, J = 8ꢂ4Hz, 1H), 6.76 (d, J = 3ꢂ0Hz, 1H), 6.68 (dd,
J = 8ꢂ1, 1.8 Hz, 1H), 6.62 (dd, J = 8ꢂ1, 2.7 Hz, 1H), 6.41 (d,
J = 2ꢂ4Hz, 1H), 5.19 (br s, 3H), 2.96 (t, J = 6ꢂ6Hz, 2H),
2.84 (t, J = 6ꢂ6Hz, 2H), 2.33 (t, J = 7ꢂ8Hz, 2H), 1.45 (m,
2H), 1.26 (m, 2H), 0.88 (t, J = 7ꢂ5Hz, 3H).
A cell-free assay system was used to examine the direct
effects of KI-063 on tyrosinase activity. Phosphate buffer
ꢄ70ꢃLꢅ containing various concentrations of KI-063 was
combined with 20ꢃL 10ꢃg mL−1 mushroom tyrosinase, and
10ꢃL 10mm l-DOPA was added to each well. After incu-
bation at 37ꢁC, the absorbance was measured at 475 nm.
Statistical analysis
Cell cultures
Differences between groups were assessed using the Kruskal–
Wallis test followed by Dunnett’s test. P values below 0.01
were considered significant.
The Mel-Ab cell line is a mouse-derived spontaneously
immortalized melanocyte cell line that produces large
amounts of melanin (Dooley et al 1994). Mel-Ab cells were
cultured in Dulbecco’s modified Eagle’s medium (DMEM)
supplemented with 10% fetal bovine serum, 100 nm TPA,
1 nm CT, 50ꢃg mL−1 streptomycin, and 50U mL−1 peni-
cillin at 37ꢁC in 5% CO2.
Results
Cytotoxicity of KI-063 in Mel-Ab cells
Cell viability
KI-063 is a resorcinol derivative prepared from 4-n-
butylresorcinol and dihydrocaffeic acid (Figure 1). To deter-
mine whether KI-063 can be used safely as a skin-whitening
agent, Mel-Ab cells were treated with 0ꢂ01–50ꢃm KI-063,
and the cell viability measured using a crystal violet assay.
KI-063 had no cytotoxic effect in Mel-Ab cells at the concen-
trations used (data not shown).
Cell viability was determined using a crystal violet assay
(Dooley et al 1994). After incubating with KI-063 for 24 h,
the culture medium was removed and the cells were stained
with 0.1% crystal violet in 10% ethanol for 5 min at room
temperature, then rinsed four times with distilled water. The
crystal violet retained by the adherent cells was then extracted
with 95% ethanol. The absorbance was determined at 590 nm
using an ELISA reader (TECAN, Salzburg, Austria).
KI-063 decreased melanogenesis in Mel-Ab cells
To investigate the hypopigmentation effect, KI-063
ꢄ0ꢂ1–50ꢃmꢅ was added to cultured Mel-Ab cells for 4 days.
Measurement of melanin content and microscopy
The melanin content was measured using a slight modifica- The Mel-Ab cells were then photographed under a phase-
tion of the method described by Tsuboi et al (1998). Briefly, contrast microscope. Cells treated with KI-063 showed much

Inhibition of melanogenesis by KI-063
345
Combination of KI-063 with terrain
O
OH
OH
We have previously reported that terrein down-regulates
MITF and tyrosinase and thus reduces melanin synthesis
(Park et al 2004). KI-063 (10 or 20ꢃm) was used in combi-
nation with terrein (1, 10 or 20ꢃm) to examine the combined
effects of the tyrosinase inhibitor and the tyrosinase produc-
tion inhibitor. Terrein had no cytotoxic effect on Mel-Ab cells
at the concentrations used (Park et al 2004). After 4 days,
the Mel-Ab cells were photographed using phase-contrast
microscopy. Cells co-treated with KI-063 and terrein showed
much less pigmentation than cells treated with KI-063 or
terrein alone (Figure 3). Melanin content and tyrosinase
activity were measured after 4 days’ treatment with KI-063
and terrein. Consistent with the microscopic observations,
the combination of KI-063 and terrein had an additive effect
and significantly inhibited melanin synthesis and the tyrosi-
nase activity, respectively, at concentrations above 10ꢃm
(Figures 4 and 5). The addition of 1ꢃm terrein to KI-063
did not have any synergistic effects. This suggests that the
potent inhibition of tyrosinase activity by KI-063 works in
combination with the reduced level of tyrosinase induced by
terrein.
OH
O
O
OH
HO
H3C
KI-063
Figure 1 The structures of KI-063 and terrein.
Terrein
less pigmentation than untreated cells (Figure 2). Melanin
content was measured after 4 days’ treatment with KI-
063. Consistent with the microscopic observations, KI-063
ꢄ10–50ꢃmꢅ significantly inhibited melanogenesis (Table 1).
Tyrosinase is a critical enzyme in melanogenesis and is
involved in the rate-limiting step. We therefore measured
tyrosinase activity after treatment with KI-063 (same concen-
trations), which was found to decrease as a function of the
KI-063 dose (Table 1). This suggests that KI-063 inhibits
tyrosinase activity and subsequently suppresses melanin
synthesis in Mel-Ab cells.
Discussion
Tyrosinase is a key enzyme that regulates the rate-limiting
step of melanin synthesis (Ando et al 2007). In addition,
resorcinol derivatives have been reported to inhibit tyrosi-
nase activity (Tasaka et al 1998). KI-063 is a synthetic resor-
cinol derivative. In this study, KI-063 inhibited tyrosinase
activity and, as a result, significantly suppressed melanin
synthesis. Thus, it appears that a decrease in tyrosinase
activity may contribute to the lower pigment content in the
KI-063-treated cells.
KI-063 directly inhibited tyrosinase in a cell-free system
To determine whether KI-063 inhibits tyrosinase activity
directly, its effect on mushroom tyrosinase was measured
in a cell-free system. These results showed that KI-063
had a strong concentration-dependent inhibitory effect on
tyrosinase activity (Table 1). This indicates that KI-063 can
inhibit melanogenesis, possibly through direct inhibition of
tyrosinase.
MITF is known to regulate the expression of tyrosinase
(Busca & Ballotti 2000; Tachibana 2000; Lin & Fisher 2007).
0.1 µM
1 µM
control
10 µM
20 µM
50 µM
Figure 2 Phase-contrast photomicrographs showing the effects of KI-063 on melanin synthesis in Mel-Ab cells (cultured with 0ꢂ1–50ꢃm KI-063
for 4 days).

346
Dong-Seok Kim et al
Table 1 The effects of KI-063 on melanin synthesis and tyrosinase activity in Mel-Ab cells
KI-063 concn ꢄꢃmꢅ
0
0.01
–
0.1
1
10
20
50
Melanin content
Tyrosinase activity
Mel-Ab cells
100ꢂ0 3ꢂ6
108ꢂ5 3ꢂ7
98ꢂ8 6ꢂ7
85ꢂ2 2ꢂ2∗
76ꢂ6 3ꢂ9∗
47ꢂ7 2ꢂ9∗
100ꢂ0 6ꢂ0
100ꢂ0 5ꢂ7
–
94ꢂ7 9ꢂ7
70ꢂ2 5ꢂ3∗
79ꢂ4 12ꢂ3
65ꢂ6 3ꢂ3∗
60ꢂ8 11ꢂ1∗
50ꢂ2 10ꢂ5∗
34ꢂ4 10ꢂ7∗
40ꢂ5 15ꢂ6∗
14ꢂ5 17ꢂ2∗
40ꢂ9 2ꢂ3∗
Cell-free system
79ꢂ4 1ꢂ6∗
Values are % of control activity, mean s.d. of three replicates. ∗P < 0ꢂ01vs untreated control.
KI-063
10
µ
M
20 µM
control
1
10
20
µ
µ
µ
M
M
M
Terrein
Figure 3 Phase-contrast photomicrographs showing the effects of KI-063 and terrein on melanin synthesis in Mel-Ab cells (cultured with 10 or
20ꢃm KI-063 without or with 1, 10, or 20ꢃm terrein for 4 days).
Previous studies suggest that ERK is an important kinase the structure of KI-063 suggests that it may act as a compet-
involved in melanin synthesis, as ERK activation induces itive inhibitor.
the phosphorylation and subsequent degradation of MITF
Many studies have focused on tyrosinase inhibitors for the
(Hemesath et al 1998; Wu et al 2000; Xu et al 2000). In addi- development of skin-whitening agents. Many such inhibitors
tion, ERK activation by terrein down-regulates MITF, which have been developed from studies using model enzymes
results in reduced tyrosinase levels and reduced melanogen- such as mushroom and plant tyrosinases (Kim & Uyama
esis (Park et al 2004). However, terrein does not inhibit the 2005; Chang 2007). Although these inhibitors have hypopig-
activity of tyrosinase directly. In this study, it was found that menting effects in-vitro, only a few substances were found
KI-063 directly inhibits tyrosinase (Figure 5). Although the to have effective hypopigmenting activity in clinical trials.
mechanism by which KI-063 inhibits tyrosinase is unclear, Moreover, they often induce skin irritation or permanent

Inhibition of melanogenesis by KI-063
347
P<0.01
P<0.01
P<0.01
P<0.01
Conclusions
These results showed that a combination of KI-063 and
terrein acted synergistically, indicating that the strong tyrosi-
nase inhibitory activity of KI-063 works in combination
with the reduced level of tyrosinase due to terrein. Because
melanogenesis in the skin is complex and involves different
stages of regulation, this combination suggests a new concept
for skin-whitening agents. Future studies should consider a
combination of KI-063 and MITF regulators to maximize the
hypopigmentary effect.
120
100
80
60
40
20
0
∗∗
∗∗
∗∗
∗∗
KI-063 ( M)
µ
0
10 20
0
10 20
0
10 20
0
10 20
Terrein 1
µ
M
Terrein 10
µ
M
Terrein 20 M
µ
Figure 4 Effects of KI-063 and terrein on melanin content of Mel-Ab
cells cultured with 10 or 20ꢃm KI-063 without or with 1, 10, or 20ꢃm
terrein for 4 days. Data are mean s.d. of three replicate experiments.
∗P < 0ꢂ01vs untreated control.
References
Ando, H., Kondoh, H., Ichihashi, M., Hearing, V. J. (2007)
Approaches to identify inhibitors of melanin biosynthesis via
the quality control of tyrosinase. J. Invest. Dermatol. 127:
751–761
Bertolotto, C., Busca, R., Abbe, P., Bille, K., Aberdam, E., Ortonne,
J. P., Ballotti, R. (1998) Different cis-acting elements are involved
in the regulation of TRP1 and TRP2 promoter activities by cyclic
AMP: pivotal role of M boxes (GTCATGTGCT) and of microph-
thalmia. Mol. Cell Biol. 18: 694–702
Busca, R., Ballotti, R. (2000) Cyclic AMP a key messenger in the
regulation of skin pigmentation. Pigment Cell Res 13: 60–69
Busca, R., Bertolotto, C., Ortonne, J. P., Ballotti, R. (1996) Inhibi-
tion of the phosphatidylinositol 3-kinase/p70(S6)-kinase pathway
induces B16 melanoma cell differentiation. J. Biol. Chem. 271:
31824–31830
Chang, T. S. (2007) Two potent suicide substrates of mush-
room tyrosinase: 7ꢀ8ꢀ4ꢀ-trihydroxyisoflavone and 5ꢀ7ꢀ8ꢀ4ꢀ-
tetrahydroxyisoflavone. J. Agric. Food Chem. 55: 2010–2015
Dooley, T. P., Gadwood, R. C., Kilgore, K., Thomasco, L. M. (1994)
Development of an in vitro primary screen for skin depigmentation
and antimelanoma agents. Skin Pharmacol 7: 188–200
Englaro, W., Bertolotto, C., Busca, R., Brunet, A., Pages, G.,
Ortonne, J. P., Ballotti, R. (1998) Inhibition of the mitogen-
activated protein kinase pathway triggers B16 melanoma cell
differentiation. J. Biol. Chem. 273: 9966–9970
P<0.01
P<0.01
P<0.01
120
100
80
60
40
20
0
P<0.01
∗∗
∗∗
∗∗
∗∗
KI-063 ( M)
µ
0
10 20
0
10 20
0
10 20
0
10 20
Terrein 1
µ
M
Terrein 10
µ
M
Terrein 20
µ
M
Figure 5 Effects of KI-063 and terrein on tyrosinase activity in Mel-Ab
cells cultured with 10 or 20ꢃm KI-063 without or with 1, 10, or 20ꢃm
terrein for 4 days. Data are mean s.d. of three replicate experiments.
∗P < 0ꢂ01vs untreated control.
Espin, J. C., Varon, R., Tudela, J., Garcia-Canovas, F. (1997) Kinetic
study of the oxidation of 4-hydroxyanisole catalyzed by tyrosinase.
Biochem. Molec. Biol. Int. 41: 1265–1276
Fenoll, L. G., Garcia-Ruiz, P. A., Varon, R., Garcia-Canovas, F.
(2003) Kinetic study of the oxidation of quercetin by mushroom
tyrosinase. J. Agric. Food Chem. 51: 7781–7787
Garcia Canovas, F., Tudela, J., Martinez Madrid, C., Varon, R.,
Garcia Carmona, F., Lozano, J. A. (1987) Kinetic study on the
suicide inactivation of tyrosinase induced by catechol. Biochim.
Biophys. Acta 912: 417–423
Haghbeen, K., Saboury, A. A., Karbassi, F. (2004) Substrate share
in the suicide inactivation of mushroom tyrosinase. Biochim.
Biophys. Acta 1675: 139–146
Hearing, V. J., Jimenez, M. (1989) Analysis of mammalian pigmen-
tation at the molecular level. Pigment Cell Res 2: 75–85
Hearing, V. J., Tsukamoto, K. (1991) Enzymatic control of pigmen-
tation in mammals. FASEB J. 5: 2902–2909
Hemesath, T. J., Price, E. R., Takemoto, C., Badalian, T.,
Fisher, D. E. (1998) MAP kinase links the transcription factor
Microphthalmia to c-Kit signalling in melanocytes. Nature 391:
298–301
Hughes, A. E., Newton, V. E., Liu, X. Z., Read, A. P. (1994)
A gene for Waardenburg syndrome type 2 maps close to the
human homologue of the microphthalmia gene at chromosome
3p12–p14.1. Nat. Genet. 7: 509–512
depigmentation. In addition, some inhibitors require unac-
ceptably high doses to produce visible effects. The skin
is a very complex organ, containing various types of cells
such as keratinocytes, melanocytes and fibroblasts. Thus,
the development of an effective hypopigmenting agent will
require further testing of potential candidates for their effects
in melanocyte–keratinocyte co-culture models, melanocyte-
containing skin-equivalent models, and in-vivo models. Two
or more agents that act through different mechanisms are
likely to have synergistic hypopigmenting effects (Solano
et al 2006). Thus, regulators of signalling pathways have been
investigated, and several molecules, such as terrein, have been
found to suppress the activity of tyrosinase indirectly.
The current study showed that a combination of KI-063 and
terrein dramatically decreased melanin synthesis. This combi-
nation allows a reduction in the effective dose of each agent,
and is therefore likely to decrease the number of unwanted
adverse effects (Solano et al 2006). Hence, a combination of
these agents might be a new strategy for the treatment of
hyperpigmentory skin diseases.

348
Dong-Seok Kim et al
Khemis, A., Kaiafa, A., Queille-Roussel, C., Duteil, L., Ortonne, Song, S., Lee, H., Jin, Y., Ha, Y. M., Bae, S., Chung, H. Y., Suh, H.
J. P. (2007) Evaluation of efficacy and safety of rucinol serum
in patients with melasma: a randomized controlled trial. Br. J.
Dermatol. 156: 997–1004
Kim, Y. J., Uyama, H. (2005) Tyrosinase inhibitors from natural and
synthetic sources: structure, inhibition mechanism and perspective
for the future. Cell. Mol. Life Sci. 62: 1707–1723
(2007) Syntheses of hydroxy substituted 2–phenyl-naphthalenes
as inhibitors of tyrosinase. Bioorg. Med. Chem. Lett. 17: 461–464
Tachibana, M. (1997) Evidence to suggest that expression of
MITF induces melanocyte differentiation and haploinsufficiency
of MITF causes Waardenburg syndrome type 2A. Pigment Cell
Res. 10: 25–33
Kim, D. S., Kim, S. Y., Chung, J. H., Kim, K. H., Eun, H. Tachibana, M. (2000) MITF: a stream flowing for pigment cells.
C., Park, K. C. (2002) Delayed ERK activation by ceramide Pigment Cell Res. 13: 230–240
reduces melanin synthesis in human melanocytes. Cell Signal. 14: Tasaka, K., Kamei, C., Nakano, S., Takeuchi, Y., Yamato, M. (1998)
779–785
Effects of certain resorcinol derivatives on the tyrosinase activity
and the growth of melanoma cells. Methods Find Exp. Clin. Phar-
macol. 20: 99–109
Kim, D. S., Hwang, E. S., Lee, J. E., Kim, S. Y., Kwon, S. B.,
Park, K. C. (2003) Sphingosine-1-phosphate decreases melanin
synthesis via sustained ERK activation and subsequent MITF Tassabehji, M., Newton, V. E., Read, A. P. (1994) Waardenburg
degradation. J. Cell. Sci. 116: 1699–1706
syndrome type 2 caused by mutations in the human microph-
Kim, D. S., Kim, S. Y., Park, S. H., Choi, Y. G., Kwon, S. B.,
thalmia (MITF) gene. Nat. Genet. 8: 251–255
Kim, M. K., Na, J. I., Youn, S. W., Park, K. C. (2005) Inhibitory Tsuboi, T., Kondoh, H., Hiratsuka, J., Mishima, Y. (1998) Enhanced
effects of 4-n-butylresorcinol on tyrosinase activity and melanin
synthesis. Biol. Pharm. Bull. 28: 2216–2219
Lee, S., Kim, W. G., Kim, E., Ryoo, I. J., Lee, H. K., Kim, J. N.,
melanogenesis induced by tyrosinase gene-transfer increases
boron-uptake and killing effect of boron neutron capture therapy
for amelanotic melanoma. Pigment Cell Res. 11: 275–282
Jung, S. H., Yoo, I. D. (2005) Synthesis and melanin biosyn- Tudela, J., Garcia Canovas, F., Varon, R., Jimenez, M., Garcia-
thesis inhibitory activity of ꢄ+/−ꢅ-terrein produced by Penicil-
lium sp. 20135. Bioorg. Med. Chem. Lett. 15: 471–473
Lin, J. Y., Fisher, D. E. (2007) Melanocyte biology and skin pigmen-
tation. Nature 445: 843–850
Park, S. H., Kim, D. S., Kim, W. G., Ryoo, I. J., Lee, D. H., Huh,
C. H., Youn, S. W., Yoo, I. D., Park, K. C. (2004) Terrein: a new
melanogenesis inhibitor and its mechanism. Cell. Mol. Life Sci.
61: 2878–2885
Carmona, F., Lozano, J. A. (1988) Kinetic study in the transient
phase of the suicide inactivation of frog epidermis tyrosinase.
Biophys. Chem. 30: 303–310
Wu, M., Hemesath, T. J., Takemoto, C. M., Horstmann, M. A.,
Wells, A. G., Price, E. R., Fisher, D. Z., Fisher, D. E. (2000)
c-Kit triggers dual phosphorylations, which couple activation and
degradation of the essential melanocyte factor Mi. Genes Dev. 14:
301–312
Shimizu, K., Kondo, R., Sakai, K. (2000) Inhibition of tyrosi-
nase by flavonoids, stilbenes and related 4-substituted resorcinols:
structure-activity investigations. Planta Med. 66: 11–15
Slominski, A., Tobin, D. J., Shibahara, S., Wortsman, J. (2004)
Melanin pigmentation in mammalian skin and its hormonal regu-
lation. Physiol. Rev. 84: 1155–1228
Solano, F., Briganti, S., Picardo, M., Ghanem, G. (2006) Hypopig-
menting agents: an updated review on biological, chemical and
clinical aspects. Pigment Cell Res. 19: 550–571
Xu, W., Gong, L., Haddad, M. M., Bischof, O., Campisi, J., Yeh,
E. T., Medrano, E. E. (2000) Regulation of microphthalmia-
associated transcription factor MITF protein levels by association
with the ubiquitin-conjugating enzyme hUBC9. Exp. Cell Res.
255: 135–143
Yasumoto, K., Yokoyama, K., Takahashi, K., Tomita, Y., Shiba-
hara, S. (1997) Functional analysis of microphthalmia-associated
transcription factor in pigment cell-specific transcription of the
human tyrosinase family genes. J. Biol. Chem. 272: 503–509
