Generation of Blue Light-Emitting Zinc Complexes by Band-Gap Control
of the Oxazolylphenolate Ligand System: Syntheses, Characterizations,
and Organic Light Emitting Device Applications of 4-Coordinated
Bis(2-oxazolylphenolate) Zinc(II) Complexes
Ho-Jin Son, Won-Sik Han, Ji-Yun Chun, Byoung-Kook Kang, Soon-Nam Kwon, Jaejung Ko,*
Su Jung Han, Chongmok Lee, Sung Joo Kim, and Sang Ook Kang*
Department of Materials Chemistry, Korea UniVersity, 208 Seochang, Chochiwon, Chung-nam
339-700, South Korea, Department of Chemistry, Ewha Womans UniVersity, Seoul 120-750, South
Korea, and Department of Materials Science and Engineering, Columbia UniVersity, New York 10027
Received December 24, 2007
Color-tunable Zn(II) complexes of the type Zn(N,O-OPhOxZArX)2 (5), where the ligand consists of an oxazolylphenolate
ion connected at the 4-position by a 2,4-substituted aryl functional group with X ) NMe2 a, OMe b, Ph c, Cl d,
F2 e, and CN f, were prepared. X-ray structural studies of 5a, 5b, and 5e showed that a zinc atom was positioned
in a distorted tetrahedral coordination environment created by two oxazolylphenolate ligands with N,O-chelation.
Hammet plots of absorption and emission maxima, respectively, in UV and photoluminescence (PL) spectra with
respect to electron-donating and electron-withdrawing groups of the substituents indicate a direct correlation between
the highest occupied molecular orbital (HOMO)-lowest unoccupied molecular orbital (LUMO) band gaps and
electronic alterations at the ligand sites. A similar correlation was also observed for the reduction and oxidation
potentials in cyclic voltammograms (CVs). A gradual increase in the HOMO-LUMO band gap is seen from electron-
donating to electron-withdrawing functional groups, NMe2 < OMe < Ph < Cl < F2 < CN. An emission peak with a
maximum at 455 nm was achieved when the most electron-withdrawing group (cyano) was applied to the
oxazolylphenolate ligand system. Density-functional theory (DFT) calculations on the HOMOs and LUMOs for this
series lead to a conclusion similar to that arrived at from a blue-shift trend observed in UV data and trends in the
CVs. The 4-coordinated zinc complex (5c) was shown to be a potential blue-emitting material, exhibiting a maximum
efficiency of 1720 cd/m2 at 17 V with 0.3 cd/A in a multilayered device structure of ITO/NPB/5c/BCP/Alq3/LiF/Al.
On the basis of the low HOMO level of this series, 5a was tested as a hole-transporting material; this resulted in
the successful fabrication of a multilayered device of ITO/5a/DPVBI/Alq3/LiF/Al with an efficiency of 7000 cd/m2 at
13 V with 2.0 cd/A.
Introduction
focused on small organic molecules and polymers. However,
for the successful fabrication of full-color OLEDs, issues
related to efficiency and lifetime of blue emitting materials
need to be resolved. Major research on blue luminescent
materials has been carried out mainly using aromatic organic
molecules3 and organic polymers.4 Blue EL materials derived
from organometallic complexes are rare and limited to late
transition-metal complexes (Ir,5 Pt,6 Os7) and main group
metal complexes8,9 based on hydroquinoline-type ligands.
For this reason, new types of organometallic EL materials
utilizing main group metals (Al,10 Be,11 Cu,12 Zn13) with
N,O- and N,N-chelate ligands have been actively studied.
Since the discovery of organic light emitting devices
(OLEDs) by C. W. Tang1 and J. H. Burroughes,2 unrelenting
efforts have been made to develop highly efficient electrolu-
minescent (EL) materials. In particular, methods to construct
blue light-emitting materials with large band gaps have long
been sought; studies aimed at producing such materials have
* To whom correspondence should be addressed. E-mail: sangok@
korea.ac.kr. Tel: +82-41-860-1334. Fax: +82-41-867-5396.
(1) Tang, C. W.; VanSlyke, S. A. Appl. Phys. Lett. 1987, 51, 913.
(2) Burroughes, J. H.; Bradley, D. D. C.; Brown, A. R.; Marks, R. N.;
Mackay, K.; Friend, R. H.; Burns, P. L.; Homes, A. B. Nature 1990,
347, 539.
5666 Inorganic Chemistry, Vol. 47, No. 13, 2008
10.1021/ic702491j CCC: $40.75  2008 American Chemical Society
Published on Web 06/11/2008

Blue Light-Emitting Zinc Complexes
Among them, zinc complexes have received much attention
because of their many advantageous EL properties, such as
electron transporting ability, light emitting efficiency, high
thermal stability, ease of sublimation, and great diversity of
tunable electronic properties resulting from ligand
substitution.13l–n,14 Because the electronic structure of metal
chelate luminescent materials is determined by the coordina-
tion of a ligand, the coordination geometry as well as the
highest occupied molecular orbital (HOMO) and the lowest
unoccupied molecular orbital (LUMO) contributions from
the ligand need to be examined. Indeed, the coordination
mode of the ligand relates to the photophysical properties
of the resulting metal complexes, and the bulkiness of the
ligand alters the bonding around the metal center; a bulky
ligand tends to form monomeric species while less bulky
ligands encourage the formation of dimeric or trimeric metal
complexes. Furthermore, modification of the chelating ligand
in Alq3 and Bq (q: hydroquinoline) with electron-donating
or electron-withdrawing groups proves to be an effective
method for the tuning of the optical properties of Alq38 and
Bq.9b However, until recently very few studies have been
performed on the systematic tuning of the luminescence of
zinc complexes. In an effort to investigate the efficacy of
the substituent effect and its possible use in color tuning in
zinc(II) complexes, a series of electron-rich and electron-
poor oxazolylphenol ligands was prepared, and the resulting
4-coordinated Zn(oxazolylphenolate)2 complexes were in-
vestigated for their electronic and photophysical properties.
Here, we report the full details of the syntheses and
characterizations of various electron-donating and electron-
withdrawing aryl-substituted Zn oxazolylphenolate com-
plexes (5). The photophysical and electrochemical properties
of these Zn complexes were estimated by means of UV and
photoluminescence (PL) spectroscopy, as well as cyclic
voltammetry (CV). The corresponding EL properties for 5a
and 5c were studied through device fabrication by applying
them respectively as hole-transporting and emitting materials
in multilayer devices, depending on the HOMO and LUMO
energy levels. In addition, theoretical calculations were
performed to account for the change in the electronic
structure as a result of the inductive and mesomeric effects
on aryl substituents (ArX), as shown in Chart 1.
