COMMUNICATION
Table 1. Reaction of dialkylzincs on b-(propargyloxy)enoates 1a–e.
for the E isomers, as for the non-substituted case (entries 3–
4).
Functionalization of the intermediate vinylzinc species
was thus considered with substrates affording high degrees
of Z selectivity. The intermediate gem Si/Zn bimetallated
alkene resulting from the addition of Bu2Zn or Et2Zn on 1b
was trapped with iodine to afford iodo vinylsilane (E)-15 in
72% as a single diastereomer or allylated with allyl bromide
following transmetallation with CuCN·2LiCl to give trisub-
stituted vinylsilane (Z)-16 (entries 6–7). As confirmed by
NOE experiments on 15 (Scheme 2), full retention of con-
figuration was observed.[15] Likewise, electrophilic trapping
of the intermediate vinyl zinc was also possible starting from
enoate 1c bearing a phenylacetylene moiety (Table 2, en-
tries 8–9). Reaction with Bu2Zn followed by iodolysis af-
forded 17 in 79% yield in a 93:07 E/Z ratio, whereas reac-
tion with Et2Zn followed by transmetallation and trapping
with allyl bromide gave tetrasubstituted alkene 18 in 42%
as a single Z diastereomer. Here again, as evidenced by the
slight increase in diastereoselectivity with respect to simple
acidic quench (Table 1, entries 6–7) the alkenyl intermediate
leading to the Z product seems to be fully metallated but
not the one leading to the E product.
Entry Substrate R1
R2Zn (equiv) Product Yield [%][a] dr[b]
Z/E
1
2
3
4
5
6
7
8
9
1a
1a
1b
1b
1b
1c
1c
1d
1e
H
H
TMS
TMS
TMS
Ph
Bu2Zn (3)
Et2Zn (3)
Bu2Zn (5)
Et2Zn (3)
iPr2Zn (3)
Bu2Zn (5)
Et2Zn (3)
2
3
4
5
6
7
8
9
54
55
67
91
49[c]
81
79
59
64
–
–
>95:05
>95:05
>95:05
88:12
90:10
>95:05
64:36
Ph
1-Cx[d] Bu2Zn (3)
Et
Bu2Zn (3)
10
[a] Combined yield of isolated diastereomers. [b] Determined by NMR
analysis of the crude material. [c] 40% of 3-(trimethylsilyl)prop-2-yn-1-ol
was isolated. [d] 1-Cx/ 1-cyclohexenyl.
reochemical assignment for products 4 and 8 arouse from
NOE experiments (Scheme 2).[15]
The observed transformations are believed to follow a
radical-polar crossover mechanism similar to the one we evi-
denced for the related reactions involving (N-allyl)amino-
enoates and b-(allyloxy)enoates (Scheme 3).[9a,b,e] Initial oxi-
dation of the organometallic species by traces of oxygen
produces a radical that undergoes 1,4-addition onto the Mi-
chael acceptor 1a–e to afford an enoxy radical 19.[17] Subse-
quent 5-exo-dig cyclization on the alkyne moiety and reduc-
tion of the resulting vinyl radical 20 by the organometallic
species gives the (tetrahydofuranylalkenyl)zinc intermediate
21 and a new radical that propagates the chain. The forma-
tion of the non-metallated compounds 2 and (E)-10 is unex-
pected. In the case of 1a (R1 =H), we initially considered a
possible deprotonation of the starting terminal alkyne by
the formed vinylzinc 21.[18] To be consistent with the ob-
served yields higher than 50%, this possibility would imply
the formation of a gem-Zn,Zn bimetallated species which
was not detected after a deuterium quench.[19] Moreover,
such a possibility would not account for the formation of the
reduced product even with internal alkynes. It therefore
seems reasonable to consider that non-metallated com-
pounds 2 and (E)-10 arise from reduction of the intermedi-
ate vinyl radicals by hydrogen abstraction. Since a possible
intramolecular hydrogen shift was ruled out by the fact that
Scheme 2. Selected NOE signals for products (Z)-4, (Z)-8 and (E)-15.
Reaction with alkyl substituted alkynes is also possible as
evidenced by the addition of Bu2Zn on 1e (entry 9). Howev-
er, in this case, a significant drop in diastereoselectivity is
observed as a mixture of alkylidene furans 10 is obtained in
a 64:36 Z/E ratio.
The domino sequence is not limited to primary dialkyl-
zincs. For example, salt free iPr2Zn prepared from
iPrMgCl[16] reacts with 1b to afford diastereomerically pure
vinylsilane (Z)-6 in 49% yield (Table 1, entry 5). Neverthe-
less, as evidenced by the recovery of 40% of 3-TMS-prop-
argyl alcohol, a competitive addition/b-elimination process
hampers the overall efficiency in this case.
In order to develop a three-component approach, we next
investigated the subsequent functionalization of the vinyl-
zinc resulting from the 1,4 addition/cyclization sequence
(Table 2). Much to our surprise, deuteration of the inter-
mediate obtained from Bu2Zn and enoate 1a afforded 11 as
a mixture of two diastereomers in a 51:49 E/Z ratio but also
50% of non-deuterated methylene–tetrahydrofuran 2 (en-
tries 1–2). On the contrary, complete deuterium labeling was
observed starting with TMS-substituted enoate 1b and (Z)-
14 was isolated (entry 5). The case of substrate 1e bearing
an ethyl substituted internal alkyne lies between the two
previous cases. As expected, a mixture of diastereomers is
obtained, but whereas complete deuterium labeling is ob-
served for the Z isomers, only partial labeling is observed
2
no deuterium incorporation was detected by H-NMR else-
where in the molecule,[19] H abstraction must in consequence
occur intermolecularly, though the hydrogen donor still re-
mains unidentified.[20]
Vinyl zinc derivatives being known to be configurationally
stable,[21] the diastereoselectivity of the process arises from
the stereoselectivity of the kinetically controlled SH2 step.[22]
Building on models reported for reductive cyclization of
hexynyl radicals[23] and iodine atom transfer cyclization of
hex-5-ynyl iodides,[2b] we propose an interpretation of the
Chem. Eur. J. 2008, 14, 8784 – 8788
ꢀ 2008 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
8785
