Synthesis of Six-Component Metallodendrimers
via [3 + 3] Coordination-Driven Self-Assembly
Hai-Bo Yang,*,† Brian H. Northrop,‡ Yao-Rong Zheng,‡
Koushik Ghosh,‡ Matthew M. Lyndon,§
David C. Muddiman,§ and Peter J. Stang*,‡
Shanghai Key Laboratory of Green Chemistry and Chemical
Processes, Department of Chemistry, East China Normal
UniVersity, 3663 North Zhongshan Road, Shanghai, China
200062, Department of Chemistry, UniVersity of Utah, 315
South 1400 East, Room 2020, Salt Lake City, Utah 84112,
and W. M. Keck FT-ICR Mass Spectrometry Laboratory and
Department of Chemistry, North Carolina State UniVersity,
Raleigh, North Carolina 27695
Coordination-driven self-assembly8 has been demonstrated
to be a powerful and facile approach to the construction of
polygons and polyhedra9 with well-designed shapes, sizes, and
symmetry. By employing such a strategy, we have previously
constructed a series of functionalized metallacycles10 including
well-defined metallodendrimers11 with various sizes and shapes.
For example, by combining predesigned 120° angular dendritic
hbyang@chem.ecnu.edu.cn; stang@chem.utah.edu
ReceiVed January 12, 2009
(3) (a) Newkome, G. R.; Moorefield, F.; Vo¨gtle, F. Dendritic Molecules:
Concepts, Synthesis, Properties; VCH: Weinheim, Germany, 1996. (b) Constable,
E. C. Chem. Commun. 1997, 1073–1080. (c) Zeng, F.; Zimmerman, S. C. Chem.
ReV. 1997, 97, 1681–1712. (d) Newkome, G. R.; He, E.; Moorefield, C. N. Chem.
ReV. 1999, 99, 1689–1746. (e) Bosman, A. W.; Janssen, H. M.; Meijer, E. W.
Chem. ReV. 1999, 99, 1665–1688. (f) Balzani, V.; Campagna, S.; Denti, G.;
Juris, A.; Serroni, S.; Venturi, M. Acc. Chem. Res. 1998, 31, 26–34. (g) Gorman,
C. B.; Smith, J. C. Acc. Chem. Res. 2001, 34, 60–71. (h) Astruc, D. Acc. Chem.
Res. 2000, 33, 287–298. (i) Crooks, R. M.; Zhao, M.; Sun, L.; Chechik, V.;
Yeung, L. K. Acc. Chem. Res. 2001, 34, 181–190. (j) Selby, H. D.; Roland,
B. K.; Zheng, Z. Acc. Chem. Res. 2003, 36, 933–944. (k) Huck, W. T. S.; van
Veggel, F. C. J. M.; Reinhoudt, D. N. Angew. Chem., Int. Ed. Engl. 1996, 35,
1213–1215. (l) Enomoto, M.; Aida, T. J. Am. Chem. Soc. 1999, 121, 874–875.
(m) Hwang, S.-H.; Shreiner, C. D.; Moorefield, C. N.; Newkome, G. R. New
J. Chem. 2007, 119, 2–1217. (n) Constable, E. C. Chem. Soc. ReV. 2007, 36,
246–253.
A new class of 120° dendritic di-Pt(II) acceptor subunits has
been designed and synthesized, from which six-component
hexagonal metallodendrimers were easily formed with 120°
dendritic dipyridine donors via [3 + 3] coordination-driven
self-assembly. The structures of all metallodendrimers are
confirmed by multinuclear NMR, ESI-TOF-MS/ESI-FTMS,
and elemental analysis. MMFF force-field simulations indi-
cates that all metallodendrimers have a hexagonal ring with
an internal radius of approximately 1.4 nm.
(4) (a) Astruc, D.; Chardac, F. Chem. ReV. 2001, 101, 2991–3023. (b) Becker,
J. J.; Gagne´, M. R. Acc. Chem. Res. 2004, 37, 798–804. (c) Astruc, D.; Ornelas,
C.; Ruiz, J. Acc. Chem. Res. 2008, 41, 841–856. (d) Bonomi, R.; Selvestrel, F.;
Lombardo, V.; Sissi, C.; Polizzi, S.; Mancin, F.; Tonellato, U.; Scrimin, P. J. Am.
Chem. Soc. 2008, 130, 15744–15745.
(5) (a) Enomoto, M.; Aida, T. J. Am. Chem. Soc. 1999, 121, 874–875. (b)
Percec, V.; Dulcey, A. E.; Peterca, M.; Ilies, M.; Sienkowska, M. J.; Heiney,
P. A. J. Am. Chem. Soc. 2005, 127, 17902–17909.
(6) (a) Adronov, A.; Fre´chet, J. M. J. Chem. Commun. 2000, 1701–1710.
(b) Jiang, H.; Lee, S. J.; Lin, W. Org. Lett. 2002, 4, 2149–2152. (c) Choi, M.-
S.; Yamazaki, T.; Yamazaki, I.; Aida, T. Angew. Chem., Int. Ed. 2004, 43, 150–
158. (d) Mo, Y.-J.; Jiang, D.-L.; Uyemura, M.; Aida, T.; Kitagawa, T. J. Am.
Chem. Soc. 2005, 127, 10020–10027. (e) Maury, O.; Bozec, H. L. Acc. Chem.
Res. 2005, 38, 691–704. (f) Hwang, S.-H.; Moorefield, C. N.; Newkome, G. R.
Chem. Commun. 2008, 37, 2543–2557.
(7) (a) Gorman, C. B.; Smith, J. C. J. Am. Chem. Soc. 2000, 122, 9342–
9343. (b) Wang, P.; Moorefield, C. N.; Newkome, G. R. Org. Lett. 2004, 6,
1197–1200.
Since the pioneering work by Newkome et al.1 and Balzani
et al.2 in the early 1990s, metallodendrimers3 have evolved to
be one of the most attractive fields within supramolecular
chemistry. Compared to the synthesis of conventional dendrim-
ers that rely heavily on carbon-carbon or carbon-heteroatom
bond formation, metal-donor interactions have been shown to
function as the key growth steps in the construction of
metallodendrimers. The highly efficient formation of coordina-
tion bonds offers considerable synthetic advantages such as
fewer steps, fast and facile construction of the final products,
and inherently self-correcting, defect-free assembly. More
(8) (a) Stang, P. J.; Olenyuk, B. Acc. Chem. Res. 1997, 30, 502–518. (b)
Leininger, S.; Olenyuk, B.; Stang, P. J. Chem. ReV. 2000, 100, 853–908. (c)
Seidel, S. R.; Stang, P. J. Acc. Chem. Res. 2002, 35, 972–983. (d) Schwab,
P. F. H.; Levin, M. D.; Michl, J. Chem. ReV. 1999, 99, 1863–1934. (e) Caulder,
D. L.; Raymond, K. N. Acc. Chem. Res. 1999, 32, 975–982. (f) Gianneschi,
N. C.; Masar, M. S., III.; Mirkin, C. A. Acc. Chem. Res. 2005, 38, 825–837. (g)
Cotton, F. A.; Lin, C.; Murillo, C. A. Acc. Chem. Res. 2001, 34, 759–771. (h)
Fujita, M.; Tominaga, M.; Hori, A.; Therrien, B. Acc. Chem. Res. 2005, 38,
369–378. (i) Fiedler, D.; Leung, D. H.; Bergman, R. G.; Raymond, K. N. Acc
2005, 38, 349–358. (j) Steel, P. J. Acc. Chem. Res. 2005, 38, 243–250.
(9) (a) Fujita, M.; Oguro, D.; Miyazawa, M.; Oka, H.; Yamaguchi, K.; Ogura,
K. Nature (London) 1995, 378, 469–471. (b) Olenyuk, B.; Levin, M. D.;
Whiteford, J. A.; Shield, J. E.; Stang, P. J. J. Am. Chem. Soc. 1999, 121, 10434–
10435. (c) Olenyuk, B.; Whiteford, J. A.; Fechtenkotter, A.; Stang, P. J. Nature
(London) 1999, 398, 796–799. (d) Takeda, N.; Umemoto, K.; Yamaguchi, K.;
Fujita, M. Nature (London) 1999, 398, 794–794. (e) Fujita, M.; Fujita, N.; Ogura,
K.; Yamaguchi, K. Nature (London) 1999, 400, 52–55. (f) Davis, A. V.;
Raymond, K. N. J. Am. Chem. Soc. 2005, 127, 7912–7919. (g) Hiraoka, S.;
Sakata, Y.; Shionoya, M. J. Am. Chem. Soc. 2008, 130, 10058–10059. (h)
Hiraoka, S.; Harano, K.; Shiro, M.; Ozawa, Y.; Yasuda, N.; Toriumi, K.;
Shionoya, M. Angew. Chem., Int. Ed. 2006, 45, 6488–6491.
† East China Normal University.
‡ University of Utah.
§ North Carolina State University.
(1) Newkome, G. R.; Moorefield, F.; Vo¨gtle, F.; Baker, G. R.; Johnson, A. L.;
Behara, R. K. Angew. Chem., Int. Ed. Engl. 1991, 30, 1176–1178.
(2) Denti, G.; Serroni, S.; Campagana, S.; Ricevuto, V.; Balzani, V. Inorg.
Chim. Acta 1991, 182, 127–129.
3524 J. Org. Chem. 2009, 74, 3524–3527
10.1021/jo900067v CCC: $40.75 2009 American Chemical Society
Published on Web 04/03/2009

organic donors with 180° di-Pt(II) acceptors, “snowflake-
shaped” [6 + 6] metallodendrimers11b were prepared via
coordination-driven self-assembly. More recently, a new family
of metallodendritic squares has been synthesized from 4,4′-
bipyridines funtionalized with Fre´chet-type dendrons and (dp-
pp)Pt(II) or Pd(II) triflate by Schalley et al.12
According to the “symmetry interaction” model,8a,e 120°
anglular building units are required for hexagonal assemblies
whereas 108° anglar units lead to the production of pentagonal
structures. As supramolecular structures increase in size they
also tend toward increasing flexibility. For large, complex
supramolecular hexagons, small distortions away from the ideal
bond angles of the subunits can occur and make up for the
necessary 12° difference per corner between a hexagon and a
pentagon. Although no evidence for any other species, such as
pentagonal assemblies, was found in multinuclear NMR or mass
spectroscopy studies during the formation of [6 + 6] hexagonal
metallodendrimers,11b it is necessary to find alternative means
to prepare six-component hexagonal metallodendrimers that rule
out the possibility of forming pentagonal structures entirely.
In general, the shape of an individual two-dimensional
polygon is determined by the value of the turning angle within
its angular components. According to the “directional bonding”
and “symmetry interaction” models,8a,e discrete hexagonal
entities can be self-assembled via the combination of two
complementary ditopic building blocks A2 and X2, each
incorporating 120° angles between their coordination sites,
allowing for the formation of hexagonal structures of type
A2 X2 .13 This strategy, in contrast to the use of six 120° angular
FIGURE 1. Schematic and molecular structure of 120° dendritic donor
