958
A. Ali et al.
LETTER
(2) (a) Shutske, G. M. J. Org. Chem. 1984, 49, 180.
(Table 4, entries 1, 2, and 4). Similarly, benzophenone
oxime (5b) cross-coupled poorly with 4-chlorophenylbo-
ronic acid (2a, Table 4, entry 5), although the O-arylation
of 5b with phenylboronic acid (2d) was somewhat more
efficacious (Table 4, entry 6). Moreover, in both cases
significant deoximation of benzophenone oxime (5b) oc-
curred under the reaction conditions [the deoximation of
oximes by Cu(II) salts has been reported previously].7,15
(b) Shutske, G. M.; Kapples, K. J. J. Heterocycl. Chem.
1989, 26, 1293.
(3) Johnson, S. M.; Petrassi, H. M.; Palaninathan, S. K.;
Mohamedmohaideen, N. N.; Purkey, H. E.; Nichols, C.;
Chiang, K. P.; Walkup, T.; Sacchettini, J. C.; Sharpless,
K. B.; Kelly, J. W. J. Med. Chem. 2005, 48, 1576.
(4) (a) Meyer, A. G.; Winzenberg, K. N.; Sawutz, D. G.; Liepa,
A. J. US 7 312 248, 2007. (b) Ali, A.; Altamore, T. M.;
Bliese, M.; Fisara, P.; Liepa, A. J.; Meyer, A. G.; Nguyen,
O.; Sargent, R. M.; Sawutz, D. G.; Winkler, D. A.;
Winzenberg, K. N.; Ziebell, A. Bioorg. Med. Chem. Lett.
2008, 18, 252.
(5) Ãbele, E.; Lukevics, E. Org. Prep. Proced. Int. 2000, 32,
235.
(6) (a) Mooradian, A.; DuPont, P. E. J. Heterocycl. Chem. 1967,
4, 441. (b) Jacob, B. B. Synthesis 1975, 782.
(7) A copper-catalyzed cross-coupling of aromatic oximes with
iodoarenes has recently been reported. See: De Nonappa,
P.; Pandurangan, K.; Maitra, U.; Wailes, S. Org. Lett. 2007,
9, 2767.
(8) Chan, D. M. T.; Monaco, K. L.; Wang, R.-P.; Winters, M. P.
Tetrahedron Lett. 1998, 39, 2933.
(9) Evans, D. A.; Katz, J. L.; West, T. R. Tetrahedron Lett.
1998, 39, 2937.
(10) (a) Petrassi, H. M.; Sharpless, K. B.; Kelly, J. W. Org. Lett.
2001, 3, 139. (b) Wang, Z.; Zhang, J. Tetrahedron Lett.
2005, 46, 4997. (c) Singh, B. K.; Appukkuttan, P.;
Claerhout, S.; Parmar, V. S.; Van der Eycken, E. Org. Lett.
2006, 8, 1863.
Table 4 Cu(OAc)2-Mediated O-Arylation of Benzaldehyde Oxime
(5a) or Benzophenone Oxime (5b) with Phenylboronic Acids
2a,b,d,e11
OH
N
R1
B(OH)2
Cu(OAc)2
DCE
O
R1
N
+
py, 4 Å MS
air, 72 h, r.t.
R2
R2
5a, R1 = H
2a,b,d,e
6a–f
5b, R1 = Ph
Entry
R1
R2
Product
6a
Yield (%)a
1
H
4-Cl
3-Cl
H
28
30
43
29b
32
51
2
H
6b
3
H
6c
4
H
3-MeO
4-Cl
H
6d
(11) All products showed analytical and spectral characteristics
consistent with their structure.
5
Ph
Ph
6e
Representative Pocedure for the Copper-Mediated
Cross-Coupling of Aromatic Oximes and Phenylboronic
Acids
6
6f
a See Table 1.
To a mixture of acetophenone oxime (1a, 200 mg, 1.48
mmol), Cu(OAc)2 (269 mg, 1.48 mmol) and 4-chloro-
phenylboronic acid (2a, 463 mg, 2.96 mmol) in DCE (12
mL) was added pyridine (239 mL, 2.96 mmol). This resulted
in a light green colored solution to which freshly activated,
and partially crushed, 4 Å MS (ca. 350 mg) were added. The
reaction was open to the atmosphere. The progress of the
reaction was followed by TLC. The color of the reaction
mixture changed from light to deep green as the reaction
proceeded. After stirring at r.t. for 72 h the reaction mixture
was filtered through a small pad of silica gel (eluting with
CH2Cl2) and the solvent removed under reduced pressure.
The resulting brown oil was purified by radial
chromatography (eluting with 5–10% CH2Cl2–PE) to afford
(E)-O-(4-chlorophenyl)acetophenone oxime (3a, 215 mg,
59%) as a white solid; mp 69–71 °C (lit.7 54–56 °C). 1H
NMR (400 MHz, CDCl3): d = 7.76 (m, 2 H), 7.43 (m, 3 H),
7.29 (d, J = 9.2 Hz, 2 H), 7.23 (d, J = 9.2 Hz, 2 H), 2.45 (s,
3 H). 13C NMR (100 MHz, CDCl3): d = 158.2 (C), 158.1 (C),
135.7 (C), 129.9 (CH), 129.1 (CH), 128.5 (CH), 126.9 (C),
126.5 (CH), 116.0 (CH), 13.4 (CH3). HRMS: m/z calcd for
C14H12ClNO: 245.0607; found: 245.0599.
b Slowly isomerizes in CDCl3 to give a mixture of E- and Z-isomers.
In summary, we report a concise method to prepare O-aryl-
oxime ethers by means of the first copper-mediated cross-
coupling of aromatic oximes and phenylboronic acids us-
ing stoichiometric Cu(OAc)2 with pyridine as base. In
most cases the O-arylation of acetophenone oximes with
phenylboronic acids furnished O-aryloxime ethers in
good to moderate yields, although when the phenylboron-
ic acid coupling partner contained a highly electron-defi-
cient moiety the reaction did not proceed as smoothly. It
was also found that the cross-coupling was not greatly in-
fluenced by the electronic nature of the acetophenone
oxime. Studies to optimize and improve the scope of this
method are being actively investigated within our labora-
tories and will be reported in due course.
Acknowledgment
Data for Selected Compounds
The authors wish to thank Dr. Craig Forsyth, School of Chemistry,
Monash University, for X-ray crystallographic analysis.
(E)-O-(3-Chlorophenyl)acetophenone Oxime (3b)
Colorless oil. 1H NMR (400 MHz, CDCl3): d = 7.77 (m,
2 H), 7.43 (m, 3 H), 7.35 (m, 1 H), 7.24 (m, 1 H), 7.15 (m,
1 H), 7.01 (m, 1 H), 2.45 (s, 3 H). 13C NMR (100 MHz,
CDCl3): d = 160.2 (C), 158.5 (C), 135.6 (C), 134.7 (C), 130.0
(CH), 129.9 (CH), 128.5 (CH), 126.5 (CH), 122.2 (CH),
115.2 (CH), 113.0 (CH), 13.4 (CH3). HRMS: m/z calcd for
C14H12ClNO: 245.0607; found: 245.0606.
References and Notes
(1) (a) Sheradsky, T. Tetrahedron Lett. 1966, 43, 5225.
(b) Castellino, A. J.; Rapoport, H. J. Org. Chem. 1984, 49,
4399. (c) Takeda, N.; Miyata, O.; Naito, T. Eur. J. Org.
Chem. 2007, 1491.
Synlett 2009, No. 6, 955–959 © Thieme Stuttgart · New York
