Published on Web 11/11/2009
Spin-Selective Charge Transport Pathways through
p-Oligophenylene-Linked Donor-Bridge-Acceptor Molecules
Amy M. Scott, Tomoaki Miura, Annie Butler Ricks, Zachary E. X. Dance,
Emilie M. Giacobbe, Michael T. Colvin, and Michael R. Wasielewski*
Department of Chemistry and Argonne-Northwestern Solar Energy Research (ANSER) Center,
Northwestern UniVersity, EVanston, Illinois 60208-3113
Received September 8, 2009; E-mail: m-wasielewski@northwestern.edu
Abstract: A series of donor-bridge-acceptor (D-B-A) triads have been synthesized in which the donor,
3,5-dimethyl-4-(9-anthracenyl)julolidine (DMJ-An), and the acceptor, naphthalene-1,8:4,5-bis(dicarboximide)
(NI), are linked by p-oligophenylene (Phn) bridging units (n ) 1-5). Photoexcitation of DMJ-An produces
DMJ+•-An-• quantitatively, so that An-• acts as a high potential electron donor, which rapidly transfers an
electron to NI yielding a long-lived spin-coherent radical ion pair (DMJ+•-An-Phn-NI-•). The charge transfer
properties of 1-5 have been studied using transient absorption spectroscopy, magnetic field effects (MFEs)
on radical pair and triplet yields, and time-resolved electron paramagnetic resonance (TREPR) spectroscopy.
The charge separation (CS) and recombination (CR) reactions exhibit exponential distance dependencies
with damping coefficients of ꢀ ) 0.35 Å-1 and 0.34 Å-1, respectively. Based on these data, a change in
mechanism from superexchange to hopping was not observed for either process in this system. However,
the CR reaction is spin-selective and produces the singlet ground state and both 3*An and 3*NI. A kinetic
analysis of the MFE data shows that superexchange dominates both pathways with ꢀ ) 0.48 Å-1 for the
singlet CR pathway and ꢀ ) 0.35 Å-1 for the triplet CR pathway. MFEs and TREPR experiments were
used to measure the spin-spin exchange interaction, 2J, which is directly related to the electronic coupling
matrix element for CR, V2CR. The magnitude of 2J also shows an exponential distance dependence with a
damping coefficient R ) 0.36 Å-1, which agrees with the ꢀ values obtained from the distance dependence
for triplet CR. These results were analyzed in terms of the bridge molecular orbitals that participate in the
charge transport mechanism.
Introduction
has inspired the design of organic donor-bridge-acceptor (D-
B-A) systems that exhibit efficient, controlled energy and charge
Charge transport plays an integral role in many fields
including physics, chemistry, and biology and has revolutionized
how simple molecular systems with unique photochemical and
electronic properties can be utilized as photofunctional materials
for solar energy conversion,1 photocatalysis,2,3 and optoelec-
tronic nanodevices.4,5 In particular, there is a great need to
develop new, tunable materials that efficiently use light to
separate charge and demonstrate distance-independent charge
transport. The multistep electron transfer pathway in photosyn-
thetic reaction centers converts photon energy into chemical
energy with near unity efficiency using highly ordered as-
semblies of chromophores to separate charge over distances of
35 Å within these membrane-bound proteins.6,7 The photoge-
neration of radical ion pairs (RPs) within reaction center proteins
transport as a means of capturing solar energy.8 Charge transport
has been studied in covalently linked D-B-A systems with
modified bridge molecules, such as proteins,9 DNA,10-12
chromophores,13 saturated14 and unsaturated phenylene spac-
ers,15-19 but, often, multiple charge transport pathways exist
and the factors that influence them still remain poorly under-
stood. There is a growing effort to understand how the electronic
structure and composition of the bridge governs the charge
transport mechanism and thus influences the lifetimes of
photogenerated RPs (D+•-B-A-•).20-25
The utilization of rigid donors and acceptors with varying
bridge lengths allows for the measurement of distance dependent
electron transfer rates with the aim of elucidating the superex-
change and hopping charge transfer regimes within molecular
(1) Baik, C.; Kim, D.; Kang, M. S.; Kang, S. O.; Ko, J.; Nazeeruddin,
M. K.; Gratzel, M. J. Photochem. Photobiol., A 2009, 201 (2-3),
168–174.
(2) Kunkely, H.; Vogler, A. Angew. Chem., Int. Ed. 2009, 48 (9), 1685–
1687.
(8) Wasielewski, M. R. J. Org. Chem. 2006, 71 (14), 5051–5066.
(9) Gray, H. B.; Winkler, J. R. Proc. Natl. Acad. Sci. U.S.A. 2005, 102
(10), 3534–3539.
(3) Barber, J. Chem. Soc. ReV. 2009, 38 (1), 185–196.
(4) Straight, S. D.; Andreasson, J.; Kodis, G.; Bandyopadhyay, S.;
Mitchell, R. H.; Moore, T. A.; Moore, A. L.; Gust, D. J. Am. Chem.
Soc. 2005, 127 (26), 9403–9409.
(10) Jortner, J.; Bixon, M.; Langenbacher, T.; Michel-Beyerle, M. E. Proc.
Natl. Acad. Sci. U.S.A. 1998, 95, 12759–12765.
(11) Lewis, F. D.; Wu, T.; Zhang, Y.; Letsinger, R. L.; Greenfield, S. R.;
Wasielewski, M. R. Science 1997, 277 (5326), 673–676.
(12) Daublain, P.; Siegmund, K.; Hariharan, M.; Vura-Weis, J.; Wasielewski,
M. R.; Lewis, F. D.; Shafirovich, V.; Wang, Q.; Raytchev, M.; Fiebig,
T. Photochem. Photobiol. Sci. 2008, 7 (12), 1501–1508.
(5) Flood, A. H.; Stoddart, J. F.; Steuerman, D. W.; Heath, J. R. Science
2004, 306 (5704), 2055–2056.
(6) Wasielewski, M. R. Chem. ReV. 1992, 92, 435–461.
(7) Parson, W. W. Science 2007, 316 (5830), 1438–1439.
9
10.1021/ja907625k CCC: $40.75  2009 American Chemical Society
J. AM. CHEM. SOC. 2009, 131, 17655–17666 17655

A R T I C L E S
Scott et al.
systems.10,26-29 Superexchange is the virtual mediation of
charge transport from donor to acceptor by bridge orbitals
energetically well-separated from those of the donor and
acceptor. Charge transfer occurs in a single step with a rate
that decays exponentially with distance that is described by the
damping factor ꢀ. In contrast, sequential charge transport or
hopping occurs from the donor to the bridge, as well as between
bridge sites. Ultimately, charge trapping occurs at the acceptor
whose electron affinity is greater than that of the bridge. Charge
hopping by direct injection of charge from the donor to the
bridge, and/or between bridge sites, can occur by tunneling
through small potential barriers between successive sites,30-32
or by thermal activation, where the energy barrier between sites
is lowered by internal or solvent nuclear reorganization to allow
the system to surmount the barriers.30 Charge transport rates
for the hopping mechanism are only weakly distance dependent
(1/r) allowing charge to move efficiently at long distances, so
that systems exhibiting this mechanism are termed “molecular
wires”.33-35 Although molecular systems may display a com-
bination of charge transport mechanisms, there are certain
criteria that drive photoinduced charge transport in D-B-A
systems toward a particular mechanism, such as (1) the
magnitude of the donor-to-bridge charge injection barrier as
characterized by the energy levels of the system,36 (2) the energy
required for internal and solvent nuclear reorganization, and (3)
Figure 1. Charge transfer scheme for 1-5.
(13) Kobori, Y.; Yamauchi, S.; Akiyama, K.; Tero-Kubota, S.; Imahori,
H.; Fukuzumi, S.; Norris, J. R., Jr. Proc. Natl. Acad. Sci. U.S.A. 2005,
102 (29), 10017–10022.
Figure 2. Schematic of radical ion pair energy levels as a function of
magnetic field (2J > 0).
(14) Paulson, B. P.; Miller, J. R.; Gan, W. X.; Closs, G. J. Am. Chem.
Soc. 2005, 127 (13), 4860–4868.
the electronic coupling of the bridge to the donor and acceptor.
The overall electronic coupling matrix element, VDA, describes the
interaction between the donor and acceptor and is important for
determining rates of nonadiabatic charge transfer reactions.37-40
(15) Lembo, A.; Tagliatesta, P.; Guldi, D. M.; Wielopolski, M.; Nuccetelli,
M. J. Phys. Chem. A 2009, 113 (9), 1779–1793.
(16) Albinsson, B.; Mårtensson, J. J. Photochem. Photobiol., C 2008, 9
(3), 138–155.
(17) Wielopolski, M.; Atienza, C.; Clark, T.; Guldi, D. M.; Martin, N.
Chem.sEur. J. 2008, 14 (21), 6379–6390.
For charge recombination (CR), a fourth criterion must be
added, that of spin selectivity. The photogenerated singlet RP
may undergo electron-nuclear hyperfine coupling-induced
radical pair intersystem crossing (RP-ISC) to produce the triplet
(18) Martin, N.; Giacalone, F.; Segura, J. L.; Martin, N.; Guldi, D. M.
Synth. Met. 2004, 147 (1-3), 57–61.
(19) Guldi, D. M.; Luo, C.; Swartz, A.; Gomez, R.; Segura, J. L.; Martin,
N. J. Phys. Chem. A 2004, 108 (3), 455–467.
(20) Albinsson, B.; Eng, M. P.; Pettersson, K.; Winters, M. U. Phys. Chem.
Chem. Phys. 2007, 9 (44), 5847–5864.
1
3
RP, (D+•-B-A-•) f (D+•-B-A-•). The subsequent CR is spin
selective; i.e., the singlet RP recombines to the singlet ground
state, and the triplet RP recombines to yield the neutral local
triplet (Figure 1). Application of a static magnetic field causes
Zeeman splitting of the RP triplet sublevels, and varying the
field strength modulates the efficiency of RP-ISC by adjusting
the energies of triplet sublevels relative to that of the singlet
level (Figure 2). When the Zeeman splitting of the triplet RP
sublevels equals the intrinsic singlet-triplet splitting, 2J, of the
RP, there is an increase in the RP-ISC rate. This increase
translates into a maximum in triplet RP production and therefore
a maximum in neutral local triplet yield upon CR. By monitoring
the yield of local triplet production as a function of applied
magnetic field, the magnitude of 2J can be measured directly41,42
