zinc species when using 4-fluorostyrene (50 mol%).[17] Mod-
erate yields of 4a (13–18%) were obtained using N,N,N’,N’-
tetramethylethane-1,2-diamine (TMEDA, 30 mol%) as
ortho,ortho’ substituents present in the diarylzinc species
(2a) did not disturb the cross-coupling and most of the
reactions were complete within 6 h at 08C. Primary alkyl
bromides have also been used successfully coupled, but with
somewhat lower yields (entries 2–4). Functional groups such
as an ester or a nitrile are well-tolerated in such cross-
coupling reactions. Interestingly, secondary alkyl iodides
reacted smoothly to provide the alkylation products 4a and
4e–j in 55–79% yield (entries 4–10). In no case did we
observe rearrangement products (branched to unbranched;
see entry 5 and Table 3).[20] When an oxygen substituent was
present in position 2 to the carbon–iodine bond, excellent
diastereoselectivities were observed (up to d.r. = 99:1, see
entries 8–10) and the products were isolated in 55–69% yield.
Additionally, this cross-coupling can also be performed with
heterocyclic alkyl iodides, thereby leading to the expected
products 4g and 4j in 79% and 55% yield, respectively (see
entries 7 and 10).
a
ligand (entries 1–4). Switching to cobalt(II) chloride
(20 mol%) and 4-fluorostyrene (50 mol%) or TMEDA
(30 mol%) in THF at 08C furnished the desired cross-
coupling product 4a in 42% and 84% yield, respectively
(entries 5 and 6). Significant improvements were achieved by
using the THF-soluble CoCl2·2LiCl (20 mol%)[18] and
TMEDA (30 mol%),[19] which afforded the coupling product
4a in 87% yield of the isolated product (entry 7). Further
variation of the ligand[5b] or lowering the amount of the cobalt
catalyst from 20 mol% to 10 mol% led only to a decrease in
the yield (entries 7–10).
With these optimized reaction conditions in hand, we have
performed a range of alkylations using primary alkyl iodides,
which led to the polyfunctional alkylated benzoates (4b–d) in
58–77% yield (Table 2, entries 1–3). Remarkably, the
The reaction scope of this Co-catalyzed alkylation is quite
broad and a range of diarylzinc reagents prepared by
a directed deprotonation using TMP2Zn·2MgCl2·2LiCl (1,
0.6 equiv) provided the isolated alkylated products 5a–o in
51–88% yield (Table 3). Thus, this sequential one-pot metal-
ation/cross-coupling procedure could be extended to various
1,2- and 1,3-disubstituted aromatic compounds. The zincation
of 2-fluorobenzonitrile or 3-fluorobenzonitrile using
1 (0.6 equiv) proceeds within 12 h at 258C, and the subse-
quent coupling reactions with secondary alkyl iodides pro-
vides the desired products 5a–e in 52–86% yield (entries 1–
4). Remarkably, diheteroarylzinc reagents generated by
directed zincation using 1 undergo the alkylation reactions
in good yields to afford the expected products 5a–o (51–88%
yield, entries 6–14). Thus, zincated benzofurans or benzothio-
phenes reacted with secondary alkyl iodides such as cHex-I,
iPr-I, or nBu-I to furnish the corresponding cross-coupling
products 5 f–i in 61–76% yield (entries 6–9). The metalation
of benzofuran with TMP2Zn·2MgCl2·2LiCl (1, 0.6 equiv) was
complete within in 12 h at 258C, thereby providing the
corresponding zinc reagent. This species undergoes the Co-
catalyzed cross-coupling with nBu-I to afford the substituted
benzofuran 5h in 63% yield (entry 8). This alkylated
benzofuran (5h) is a key intermediate for the synthesis of
amiodarone, an active antiarrhythmic agent.[21,22] Similarly,
3,6-dimethoxypyridazine was zincated using 1 (0.6 equiv, 4 h,
RT), and the cross-coupling with 2-iodopropane or cHex-I
afforded the desired polyfunctional hetereocycles 5j, k in 69
and 61% yield, respectively (entries 10 and 11). Coumarin is
also an excellent substrate, with its zincation complete within
1 h at 258C. After alkylation with various primary and
secondary alkyl iodides, the substituted coumarins 5l–
n were obtained in up to 88% yield (entries 12–14) Similarly,
the regioselective zincation of thiochromone (À408C, 1 h)[23]
at the a-position to sulfur followed by a Co-catalyzed
alkylation with 2-iodobutane led to the desired product 5o
in 51% yield (entry 15).
Table 2: Scope of various primary and secondary alkyl iodides or
bromides.
Entry
1
Product/yield [%]
Entry
6
Product/yield [%]
4b: 63% (X=I)
4 f: 79% (X=I, d.r. =
50:50)[d]
2
3
4
5
7
4c: 58% (X=I)
38% (X=Br)
4g: 79% (X=I)
8
4d: 71% (X=I)
51% (X=Br)
4h: 68% (X=I, d.r.=
99:1)[e]
9
4a: 61% (X=Br)
2% (X=Cl)[b]
4i: 69% (X=I, d.r.=99:1)[f]
10
4e: 70% (X=I, d.r.=
4j: 55% (X=I, d.r.=99:1)[g]
50:50)[c]
[a] MgCl2 and LiCl are omitted for the sake of clarity. [b] The yield was
determined by GC. [c] The starting material was 99:1 syn/anti. [d] The
starting material was 75:25 cis/trans. [e] The starting material was 75:25
cis/trans. [f] The starting material was 99:1 trans/cis. [g] The starting
material was 99:1 trans/cis. TBS=tert-butyldimethylsilyl.
In summary, we have reported a new Co-catalyzed cross-
coupling of polyfunctional diaryl- and diheteroarylzinc
reagents with primary and secondary alkyl iodides (or
bromides) using the highly soluble cobalt salt CoCl2·2LiCl.
