New lipophilic piceatannol derivatives exhibiting antioxidant activity prepared by aromatic hydroxylation with 2-iodoxybenzoic acid (IBX)

Article abstract of DOI:10.3390/molecules14114669

Piceatannol (E-3,5,3',4'-tetrahydroxystilbene) is a phytoalexin synthesized in grapes in response to stress conditions. It exhibits strong antioxidant and antileukaemic activities due to the presence of the catechol moiety. To modify some physical properties like solubility, and miscibility in non-aqueous media some new previously unreported piceatannol derivatives having lipophilic chains on the A-ring were prepared in good yields by a simple and efficient procedure. The key step was a chemo-and regioselective aromatic hydroxylation with 2-iodoxybenzoic acid (IBX). The new compounds showed antioxidant activity and seemed promising for possible applications as multifunctional emulsifiers in food, cosmetic and pharmaceutical fields.

Full text of DOI:10.3390/molecules14114669

Molecules 2009, 14, 4669-4681; doi:10.3390/molecules14114669
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
New Lipophilic Piceatannol Derivatives Exhibiting Antioxidant
Activity Prepared by Aromatic Hydroxylation with
2-Iodoxybenzoic Acid (IBX)
Roberta Bernini 1,*, Maurizio Barontini 1 and Carmela Spatafora 2
1
Agrobiology and Agrochemistry Department, University of Tuscia, Via S. Camillo De Lellis,
01100 Viterbo, Italy
2
Department of Chemical Sciences, University of Catania, Via A. Doria 6, I-95125 Catania, Italy;
E-Mail: cspatafo@unict.it (C.S.)
* Author to whom correspondence should be addressed; E-Mail: berninir@unitus.it.
Received: 2 October 2009; in revised form: 17 November 2009 / Accepted: 17 November 2009 /
Published: 17 November 2009
Abstract: Piceatannol (E-3,5,3’,4’-tetrahydroxystilbene) is a phytoalexin synthesized in
grapes in response to stress conditions. It exhibits strong antioxidant and antileukaemic
activities due to the presence of the catechol moiety. To modify some physical properties
like solubility, and miscibility in non-aqueous media some new previously unreported
piceatannol derivatives having lipophilic chains on the A-ring were prepared in good
yields by a simple and efficient procedure. The key step was a chemo- and regioselective
aromatic hydroxylation with 2-iodoxybenzoic acid (IBX). The new compounds showed
antioxidant activity and seemed promising for possible applications as multifunctional
emulsifiers in food, cosmetic and pharmaceutical fields.
Keywords: aromatic hydroxylation; 2-iodoxybenzoic acid (IBX); lipophilic piceatannol
derivatives; lipophilic antioxidants
1. Introduction
In the last few years, stilbene-based compounds have attracted the attention of many researchers
due to their wide range of positive biological effects [1–3]. One of the most relevant and extensively

Molecules 2009, 14
4670
studied compounds is resveratrol (E-3,5,4’-trihydroxystilbene 1, Figure 1), a phenolic compound
found mainly in grapes, where it is synthesized in response to stress conditions such as fungal infection
and trauma [4–5]. In red wines it is present at concentrations of mg/L and it is well known that a
moderate alcohol consumption has some protective effects against coronary heart disease [6]. Several
studies have demonstrated that resveratrol exhibits a wide range of biological and pharmacological
activities [7–8]. For example, it has been shown to have cancer preventive properties [9–11], anti-
inflammatory activities [12], and a role in the prevention of atherosclerosis and coronary diseases
[13–14].
Figure 1. Chemical structure of natural stilbenes 1 and 2.
OH
3'
OH
4'
OH
4'
B
B
HO
HO
5
A
A
O3H
O3H
2
1
Structurally similar to resveratrol is piceatannol (E-3,5,3’,4’-tetrahydroxystilbene 2) which differs
from 1 in that it possesses an extra hydroxyl group adjacent to the active 4’-OH of resveratrol. It is
present in low quantity in grapes [15], peanuts [16], Euphorbia lagascae [17] and Vaccinium berries
[18] and, like resveratrol, it is a phytoalexin. Piceatannol (2) shows many biological activities [19–21].
It has known anticancer and antileukaemic properties, inducing apoptosis in several cell lines and
animal models; it inhibits a variety of tyrosinase kinases involved in cell proliferation [22–23]. A
recent study has demonstrated that the cancer preventative properties of resveratrol (1) are related to
its natural conversion into metabolite piceatannol (2) in living cells by the enzyme CYP1B1 (belongs
to the cytochrome P450 enzyme family) that is over-expressed in a wide variety of human tumors [24].
Other experimental evidences showed that piceatannol has a higher level of antioxidant activity
compared to resveratrol [25]. This result is according to the evidence that a catechol moiety present in
a compound increases the cytotoxic and antioxidant activity in vitro [26–27].
As all naturally occurring phenolic antioxidants, stilbene derivatives 1 and 2 are hydrophilic and
thus scarcely soluble in aprotic solvents, oils and emulsions. Consequently, their application in the
food, pharmaceutical and cosmetic fields is strongly limited.
In recent times, more attention has been turned on the development of possible strategies to modify
and to enhance the functional properties of natural antioxidants without altering the functionality
responsible for the biological activities. For example, the hydrophobicity of antioxidant phenolic acids
has been enhanced by esterifying the carboxylic acid moiety of the phenolic acid with a fatty alcohol
by chemical and enzymatic procedures [28]. In a similar way, phenethyl alcohols have been
lipophilized by esterifying the alcoholic function with acid chlorides or acid anhydrides [29]. In this
way amphiphilic phenolic compounds that are able to distribute between the aqueous phase and the
lipophilic phase and interact with an emulsifier at the interface were obtained. Recently, it has been
reported that these compounds are potentially interesting for possible applications in nanotechnology

Molecules 2009, 14
4671
[30]. To the best of our knowledge, lipophilic piceatannol derivatives have not been reported in the
literature and no chemical or enzymatic synthetic procedures are described.
In the last few years, our research has been devoted to the preparation of biologically active
catecholic compounds from naturally occurring phenols by oxidative procedures. For example, we
obtained in very good yields 2-(3’,4’-dihydroxyphenyl)ethanol (hydroxytyrosol) and its lipophilic
derivatives, useful molecules for cosmetic and pharmaceutical applications [31–35]; novel lignans
showing antioxidant activity [36]; endogenous catecholamines utilized for the treatment of many
clinical disorders, including hypertension and cardiovascular diseases [37]. The oxidant of choice was
1-hydroxy-1-oxo-1H-1λ5-benzo[d][1,2]iodoxol-3-one (2-iodobenzoic acid, IBX, Figure 2), the most
important representative of pentavalent iodine heterocycles first prepared by Hartmann and Mayer [38]
which has attracted increasing interest during the last decade because of its selective, mild and
environmentally friendly properties as an oxidant in organic synthesis [39-41]. Among its synthethic
potential, it is particularly interesting the ability to perform a regioselective oxidation of phenols into
ortho-quinones [42-44]. When the oxidative step was followed by in situ reduction, a catechol moiety
was produced with a selectivity similar to that of cytochrome P450 enzymes [45].
Figure 2. Chemical structure of 2-iodoxybenzoic acid (IBX).
In this paper we describe a simple and efficient route to prepare lipophilic piceatannol derivatives
displaying free-catecholic functionality in the B ring and long alkyl chains in the A ring by an
oxidative procedure using IBX and subsequent reduction with sodium dithionite (Na2S2O4). As
examples of chains with different length, we choose acetyl (C2), butanoyl (C4), octanoyl (C8) and
palmitoyl (C16). These new compounds were then evaluated for their radical-scavenging activity using
the DPPH method [46].
2. Results and Discussion
2.1. Preparation of 3,5-di-O-acyl resveratrol derivatives 4a-d
Firstly, we prepared 3,5-di-O-acyl resveratrol derivatives 4a-d by a two-step procedure (Scheme 1).
Peracylated derivatives [3,5,4’-tri-O-acetyl resveratrol (3a); 3,5,4’-tri-O-butanoyl resveratrol (3b);
3,5,4’-tri-O-octanoyl resveratrol (3c) and 3,5,4’-tri-O-palmitoyl resveratrol (3d)] were obtained in
90–95% yields from resveratrol (1) using acetic and butyric anhydride in pyridine and octanoyl and
palmitoyl chloride in pyridine, respectively (step a); then, compounds 3a-d were dispersed in t-butyl
methyl ether and n-butanol and subjected to enzymatic alcoholysis with Candida antarctica lipase to
isolate the corresponding 3,5-di-O-acetylated resveratrol derivatives 4a-d in 60–90% yields (step b)
[47–48].

Molecules 2009, 14
Scheme 1. Synthesis of 3,5-di-O-acetylresveratrol derivatives 4a-d.
4672
2.2. Aromatic hydroxylation of compounds 4a-d
The key reaction for the preparation of 3,5-di-O-acyl piceatannol derivatives 5a-d was the insertion
of an hydroxyl group in C-3’ (B ring) of compounds 4a-d (Scheme 2). The model substrate for the
optimization of the reaction conditions was 3,5-di-O-acetyl resveratrol (4a).
Scheme 2. Aromatic hydroxylation of 3,5-di-O-acyl resveratrol derivatives 4a-d.
OH
3'
OH
4'
OH
4'
ROCO
ROCO
IBX-oxidative procedure
Na2S2O4-reduction
OCOR
OCOR
4a-d
5a-d
a
b
c
d
: R=CH3
: R=(CH2)2CH3
: R=(CH2)6CH3
: R=(CH2)16CH3
We performed some experiments varying the solvent, reaction time, and temperature (Table 1). In
all cases an excess of IBX was used (1.2 equiv.); Na2S2O4 in tetrahydrofuran (1.0 M) was the reducing
solution. Reactions were monitored by chromatographic analysis (TLC and HPLC). On the basis of the
literature data [49], first we used methanol as solvent and a low temperature reaction but under these
experimental conditions 3,5-di-O-acetyl piceatannol (5a) was isolated in low yield (Table 1, entry 1).
The best result in terms of solubility, conversion and yield was obtained by dissolving compound 4a in

Molecules 2009, 14
4673
dimethyl sulfoxide (DMSO) at room temperature. In these experimental conditions, piceatannol
derivative 5a was isolated in quantitative yield after only 1 h (Table 1, entry 4). The oxidative step was
both chemoselective and regioselective the double bond present of 5a being unaffected.
Table 1. Aromatic hydroxylation of 3,5-di-O-acetyl resveratrol (4a) with IBX/Na2S2O4 procedure.
Entry
Solvent
T (°C) Time (h) Conv. (%) Yield of 5a (%)
1
2
3
4
Methanol
Methanol/Chloroform=1/1
Dimethyl carbonate
0
0
25
25
1
1
2
1
20
70
50
20
68
46
95
Dimethyl sulfoxide
>98
A significative region of the 13C-NMR spectrum of the new synthesized 3,5-di-O-acetyl piceatannol
(5a) is shown in Figure 4. The presence of the catecholic moiety in the B-ring of 3,5-di-O-acetyl
piceatannol (5a) was confirmed by analyzing this spectroscopic region, which showed the lack of
symmetry of the B-ring, two quaternary carbon atoms (C-3’ and C-4’) at 140.4 and 144.2 ppm and
three C-H carbons (C-2’, C-5’, C-5’) at 113.5, 115.3 and 116.8 ppm, respectively.
Figure 4. 13C-NMR spectrum (180-110 ppm region) of 3,5-di-O-acetyl piceatannol (5a).
Furthermore, the presence of two free hydroxyl groups in 5a was chemically demonstrated by an
esterification reaction of 5a under classical conditions with acetic anhydride in pyridine (Scheme 3).
As expected, the proton magnetic resonance spectrum (1H-NMR) of the resulting product 6a
evidenced the presence of two singlets at 2.23 and 2.25 ppm attributable to the twelve protons of the
four acetyl groups of 6a.

Molecules 2009, 14
Scheme 3. Acetylation of 3,5-di-O-acyl piceatannol derivative 4a.
4674
OH
OCOCH3
OCOCH3
OH
H3COCO
H3COCO
(CH3CO)2O, Py, rt, 6h
OCOCH3
OCOCH3
5a
6a
As already reported, a plausible ionic mechanism for the regioselective aromatic hydroxylation of
phenol derivatives was reported by Pettus et al. [42]. The phenol added to the iodine-(V) center of IBX
to give a λ5-iodanyl intermediate and to extrude H2O. The intramolecular (and regioselective) delivery
of an oxygen atom from this specie lead to a λ3-iodanyl intermediate which undergoes tautomerization
and oxidatively collapses to produce an ortho-quinone derivative and 2-iodobenzoic acid (IBA), the
only by-product of the reaction. The catecholic moiety was finally obtained after the in situ
reductive step.
On the basis of the good results, this simple efficient and useful synthetic procedure was applied to
3,5,4’-tri-O-butanoyl resveratrol (4b); 3,5,4’-tri-O-octanoyl resveratrol (4c) and 3,5,4’-tri-O-palmitoyl
resveratrol (4d) (Scheme 2). The corresponding lipophilic piceatannol derivatives 5b-d were isolated
in satisfactory yields (Table 2, entry 1-3) and with a high degree of purity.
Table 2. Aromatic hydroxylation of resveratrol derivatives 4a-d with IBX/Na2S2O4 procedure. a
Entry
Substrate
Time (h)
Conv. (%)
Yield (%)
5b: 88
5c: 84
5d: 82
1
2
3
4b
4c
4d
1
2
2
92
90
90
a Oxidation reactions were performed in DMSO at room temperature.
2.3. Evaluation of the antioxidant activity of 5a-d
After their preparation, we evaluated the radical scavenging activity of compounds 5a-d using the
stable 2,2-diphenyl-1-picrylhydrazyl (DPPH•) radical commonly and widely utilized for testing this
activity in natural phenolic compounds. Experimental results are reported in Table 3 and Figure 5. The
parameter SC50 is the Scavenging Capacity that is the concentration of compound (expressed in μM)
able to quench the 50% of DPPH radical in a 184 μM solution (see Experimental section for details).
As shown, SC50 values of lipophilic derivatives 5a-d were in the range 28.9–35.6 μM. All tested
compounds exhibited an antioxidant activity superior to that of resveratrol 1 and comparable to that of
piceatannol 2 [50]. The length of the alkyl chain does not influence the radical-scavenging activity.

Molecules 2009, 14
Figure 5. DPPH• scavenging activity of compounds 5a-d expressed as 100/SC50.
4675
Table 3. DPPH• scavenging activity of compounds 5a-d expressed as SC50.
Compound
SC50 (μM)a ± SD
35.6 ± 2.1
5a
5b
5c
5d
32.2 ± 2.5
30.0 ± 1.6
28.9 ± 1.4
a Each reported value is the mean of three separate measurements.
3. Experimental
3.1. Materials and methods
Resveratrol was purchased from Aldrich Company (Milan, Italy) as well all other solvents and
reagents. All chemicals used were of analytical grade. IBX was prepared in our laboratory as described
in the literature [51]. The Candida antarctica lipase (Chirazyme L-2, c. –f., C2, Lyo) was a gift from
Roche. HPLC analyses were performed on a Varian Prostar 325 apparatus equipped with a Varian
Pursuit 5μ C18 column (150 × 4.6 mm) and a dual wavelength UV-Vis detector selected on λ = 280 nm.
Elutions were carried out at a 1 mL/min flow rate using a H2O/CH3CN mixture (90:10, v/v) for the
1
13
first minute and a gradient to 40:60 within the following 30 minutes. H- and C-NMR spectra were
recorded in CD3COCD3 or CDCl3/CD3OD using a Bruker 200 MHz spectrometer. All chemical shifts
are expressed in parts per million (δ scale) and referenced to either the residual protons or carbon of
the solvent. HRMS were recorded with Micromass Q-TOF Spectrometer (Waters). Compounds 4a-d
were purified by flash chromatography on silica gel using the Buchi-Biotage FLASH 12™ system
equipped with prepacked silica gel cartridges 12S. Analytical Thin-Layer Chromatography (TLC)
were performed on silica gel (Merck 60 F254) plates using cerium sulphate as developing reagent.
3.2. Preparation of 3,5-di-O-acyl piceatannol derivatives 5a-d
Step a. Acylation reactions of resveratrol (1). Peracylated derivatives [3,5,4’-tri-O-acetylresveratrol
(3a); 3,5,4’-tri-O-butanoylresveratrol (3b); 3,5,4’-tri-O-octanoylresveratrol (3c) and 3,5,4’-tri-O-
palmitoylresveratrol (3d)] were prepared using acetic and butyric anhydride in pyridine (1:1) and

Molecules 2009, 14
4676
octanoyl and palmitoyl chloride in pyridine (1:1), respectively. The solutions were stirred at room
temperature for 6-12 h; then, they were acidified with HCl 2N and extracted with ethyl acetate; the
organic layer was washed with a solution of NaHCO3, and dried with Na2SO4. The solvent was
removed under reduced pressure to afford the peracylated derivatives 3a-d in 90-95% yields.
Step b. Enzymatic alcoholysis of 3,5,4’-triO-acylresveratrol derivatives 3a-d. Compounds 3a-d
(200 mg) were dispersed in t-butyl methyl ether (20 mL) and n-butanol (0.8 mL); Candida antarctica
lipase (200 mg) was added to the solution of 3a-d and the mixture was shaken (400 rpm) at 40 °C.
Finally, reactions were quenched by filtering off the enzyme and the filtrate was evaporated in vacuo.
The residue was subjected to flash chromatography to obtain the di-O-acyl derivatives 4a-d in 60–90%
1
yields. MS-FAB and H-NMR spectra of 3a-d and 4a-d were identical to those reported in the
literature [47–48].
3.3. Aromatic hydroxylation of 3,5-di-O-acyl resveratrol derivatives 4a-d
Compounds 4a-d (0.5 mmol) were dissolved in dimethyl solfoxide (5 mL) and then 2-iodoxy-
benzoic (IBX) was added (1.2 eq.). The mixture was kept under magnetic stirring at room temperature
and monitorated by TLC. When the substrates disappeared, water (5 mL) and sodium dithionite (0.5
mmol) were added. A chromatic change of the solution from red to colorless was observed. After
5 minutes, the mixtures were extracted with ethyl acetate (3 × 10 mL). The organic phases were
washed with a solution of NaHCO3and then dried on Na2SO4. The organic solvent was evaporated
under reduced pressure obtaining a crude. Final products 5a-d were purified by chromatographic
purification on silica gel and characterized by spectroscopic analysis.
1
3,5-Di-O-acetylpiceatannol (5a). Colorless oil, quantitative yield. H-NMR (CD3COCD3) δ 2.27 (s,
6H, 2 × CH3), 2.99 (2H, OH), 6.80-7.20 (m, 8H, CHα=CHβ, H-2,4,6,2’,5’,6’); 13C-NMR (CD3COCD3)
δ 21.1, 113.1, 113.6, 115.3, 116.9, 120.1, 123.9, 129.7, 130.3, 140.4, 144.2 , 144.3, 151.2, 170.0;
HRMS found: 328.22; C18H16O6 requires 328.09.
1
3,5-Di-O-butanoyl piceatannol (5b). Yellow oil, 88% yield. H-NMR (CD3COCD3) δ 1.02 (t, 6H,
J = 7.3 Hz, 2 × CH3), 1.65-1.83 (m, 4H, 2 × CH2CH3), 2.56 (t, J = 9.8 Hz, 4H, OCOCH2), 6.79-7.20
13
(m, 8H, CHα=CHβ, H-2,4,6,2’,5’,6’); C-NMR (CD3COCD3) δ 13.7, 18.9, 36.4, 114.0, 114.9, 116.2,
117.3, 120.3, 124.8, 130.1 , 131.5, 141.1, 146.1, 146.5, 152.6, 172.1; HRMS found: 384.34; C22H24O6
requires 384.16.
3,5-Di-O-octanoyl piceatannol (5c). Yellow oil, 84% yield. 1H-NMR (CD3COCD3) δ 0.86 (m, 6H, 2 ×
CH3), 1.28-1.42 (m, 16H, 8 × CH2), 1.62-1.76 (m, 4H, 2 × CH2), 2.56 (t, J = 7.2 Hz, 4H, 2 × CH2),
6.75-7.15 (m, 8H, CHα=CHβ, H-2,4,6,2’,5’,6’); 13C-NMR (CD3COCD3) δ 14.2, 23.2, 25.5, 29.6, 29.7,
32.3, 34.5, 114.0, 114.9, 116.2, 117.3, 120.3, 124.8, 130.1, 131.5, 141.0, 146.1, 146.5, 152.6, 172.1;
HRMS found: 496.08; C30H40O6 requires 496.28.
1
3,5-Di-O-palmitoyl piceatannol (5d). Yellow oil, 82% yield. H-NMR (CDCl3+CD3OD) δ 0.83 (m,
6H, 2 × CH3), 1.12-1.38 (m, 48H, 24 × CH2), 1.66-1.73 (m, 4H, 2 × CH2), 2.50 (t, J = 7.3 Hz, 4H, 2 ×

Molecules 2009, 14
4677
13
CH2), 6.68-7.01 (m, 8H, CHα=CHβ, H-2,4,6,2’,5’,6’); C-NMR (CDCl3+CD3OD) δ 14.0, 22.6, 24.8,
29.1, 29.2, 29.3, 29.4, 29.6, 29.7, 31.9, 34.4, 112.7, 113.7, 115.1, 116.5, 119.8, 124.5, 129.5, 130.6,
140.1, 144.5, 144.8, 151.3, 172.2; HRMS found: 720.21; C42H72O6 requires 720.53.
3.4. Acetylation of 3,5-di-O-acetyl piceatannol (5a)
Compound 5a (1.0 mmol) was solubilized in pyridine (10 mL) and acetic anhydride was added
(10 mL) overnight. At the end of the reaction, a 1 M solution of HCl (10 mL) was added and the final
product was extracted with ethyl acetate (3 × 10 mL). The combined organic phases were washed with
a solution of NaHCO3 (20 mL) and with a saturated solution of NaCl (20 mL), then dried over Na2SO4.
After evaporation of the solvent, and chromatographic purification on silica gel, 3,5,3’,4’-tetra-O-
acetyl piceatannol (6a) was isolated in quantitative yield and characterized by spectroscopic data.
Colorless oil; 1H-NMR (CDCl3) δ 2.23 (s, 6H, 2 × CH3), 2.25 (s, 6H, 2 × CH3), 6.84 (t, J = 2.0 Hz, 1H,
H-4), 6.96 (d, J = 16 Hz, 2H, CH=CHβ), 7.02 (d, J = 16 Hz, 2H, CHα=CH), 7.10 (d, J = 2.0 Hz, H-
13
2,6), 7.18 (d, J = 8.5 Hz, H-5’), 7.30 (d, J = 1.5 Hz, H-2’), 7.34 (dd, J = 8.5 and 1.5 Hz, H-6’). C-
NMR (CDCl3) δ 20.6, 21.1, 114.6, 117.0, 121.2, 123.6, 125. 0, 128.2, 128.8, 139.2, 141.7, 141.7,
142.3, 151.3, 168.2, 168.9; HRMS found: 412.24; C18H16O6 requires 412.12.
3.5. Measure of antioxidant activity of compounds 5a-d
The radical scavenging activity of compounds 5a-d was evaluated in the presence of stable radical
DPPH• according to the method of Brand-Williams et al. [46]. The initial concentration of DPPH• in
acetone was controlled for every experiment from a calibration curve made by measuring the
absorbance at λ = 517 nm of standard DPPH• solutions at different concentrations. The equation of the
curve was ABS515nm = 10,865 × [DPPH•], as determined by linear regression. The compounds 5a-d
were tested at three different concentrations and each concentration was analyzed in triplicate. In a
typical procedure, 10, 20 and 30 μL of freshly prepared acetone solution of compounds 5a-d were
added to 2 mL of freshly prepared 184 μM acetone solution of DPPH•. The solutions were shaken for
30 min in the dark at 25 °C. The results were plotted as the percentage of reacted DPPH• [(ABS0h –
ABS30min)/ABS0h × 100] vs the concentration (μM) of the added compounds 5a-d. The results were
expressed as SC50 that is the concentration of compound required to quench 50% of the initial DPPH•
radicals under the experimental conditions given.
4. Conclusions
In summary, we have described a simple and efficient procedure to prepare new piceatannol
derivatives from naturally occurring resveratrol. These compounds possess a free-catecholic moiety in
the B ring and long alkyl chains on the A ring. With these chemical features they exhibited an
antioxidant activity similar to that of piceatannol, but a greater lipophilicity, therefore, they may be
advatageously used as food antioxidants in bulk lipids or emulsions, and could be further evaluated for
possible applications in the pharmaceutical, nutritional and cosmetic fields.

Molecules 2009, 14
4678
Acknowledgements
The authors like to thank Ministero dell’Università e della Ricerca Scientifica e Tecnologica (PRIN
2007) and University of Viterbo and Catania (Progetti di Ricerca di Ateneo, Italy) for financial
support.
References and Notes
1. Murias, M.; Handler, N.; Erker, T.; Pleban K.; Ecker, G.; Saiko, P.; Szekeres, T.; Jager, W.
Resveratrol analogues as selective cyclooxygenase-2-inhibitors: Synthesis and structure-activity
relationship. Bioorg. Med. Chem. 2004, 12, 5571–5578.
2. Murias, M.; Jager, W.; Handler, N.; Erker, T.; Horvath, Z.; Szekeres, T.; Nohl, H.; Gille, L.
Antioxidant, prooxidant and cytotoxic activity of hydroxylated resveratrol analogues: Structure-
activity relationship. Biochem. Pharm. 2005, 69, 903–912.
3. Riviére, C.; Richard, T.; Quentin, L.; Krisa, S.; Mérillon, J.M.; Monti, J.P. Inhibitory activity of
stilbenes on Alzheimer’s B-amyloid fibrils in vitro. Bioorg. Med. Chem. 2007, 15, 1160–1167.
4. Langcake, P.; Pryce, R.J. The production of resveratrol by Vitis vinifera and other members of the
Vitaceae as a response to infection or injury. Physiol. Plant Pathol. 1976, 9, 77–86.
5. Siemann E.H.; Creasy, L.L. Concentration of the phytoalexin resveratrol in wine. Am. J. Enol.
Vitic. 1992, 43, 49–52.
6. Renaud, S.; De Lorgeril, M. Wine, alcohol, platelets and the French paradox for coronary heart
disease. Lancet 1992, 339, 1523–1526.
7. Fremont, L. Biological effects of resveratrol. Life Sci. 2000, 66, 663–673.
8. Baur, J.A.; Sinclair, D.A. Therapeutic potential of resveratrol: The in vivo evidence. Nat. Rev.
Drug Discov. 2006, 5, 493–506.
9. Gusman, J.; Malonne, H.; Atassi, G. A reappraisal of the potential chemopreventive properties of
resveratrol. Carcinogenesis 2001, 22, 1111–1117.
10. Jang, M.; Cai, L.; Udeani, G.O.; Slowing, K.V.; Thomas, C.F.; Beecher, C.W. Cancer
chemopreventive activity of resveratrol, a natural product derived from grapes. Science 1997, 275,
218–220.
11. Dong, Z. Molecular mechanism of the chemopreventive effect of resveratrol. Mutat. Res. 2003,
523-524, 145–150.
12. Ramon, M.A.; Villegas, I.; La-Casa, C.; de La Lastra, A.C. Resveratrol, a polyphenol found in
grapes, suppresses oxidative damage and stimulate apoptosis during early colonic inflammation in
rats. Biochem. Pharm. 2004, 67, 1399–1410.
13. Tadolini, B.; Juliano, C.; Piu, L.; Franconi, F.; Cabrini, L. Resveratrol inhibition of lipid
peroxidation. Free Radic. Res. 2000, 33, 105–114.
14. Lembège-Varache, M.; Teguo, P.W.; Richard, T.; Monti, J.P.; Deffiuex, G.; Vercauteren, J.;
Mérillon, J.M.; Nuhrich, A. Structure-activity relationships of polyhydroxystilbene derivatives
extracted from Vitis vinifera cell cultures as inhibitors of human platetelet aggregation. Med.
Chem. Res. 2000, 10, 253–267.
15. Bavaresco, L.; Fregoni, M.; Trevisan, M.; Mattivi, F.; Vrhovsek, U.; Flachetti, R. The occurrence
of the stilbene piceatannol in grapes. Vitis 2002, 41, 133–136.

Molecules 2009, 14
4679
16. Ku, K.L.; Chang, P.S.; Cheng, Y.C.; Lien, C.Y. Production of stilbenoids from the callus of
Arachis hypogaea: A novel source of the anticancer compound piceatannol. J. Agr. Food Chem.
2005, 53, 3877–3881.
17. Ferrigni, N.R.; Mclaughlin, J.L.; Powell, R.G.; Smith, C.R. Isolation of piceatannol as the
antileukaemic principle from the seeds of Euphorbia lagascae. J. Nat. Prod. 1984, 47, 347–352.
18. Rimando, A.M.; Kalt, W.; Magee, J.B.; Dewey, J.; Ballington, J. Resveratrol, pterostilbene and
piceatannol in Vaccinium berries. J. Agr. Food Chem. 2004, 52, 4713–4719.
19. Larrosa, M.; Tomas-Barberan, F.A.; Espin, J.C. The grape and wine polyphenol piceatannol is a
potent inducer of apoptosis in human SK-Mel-28 melanoma cells. Eur. J. Nutr. 2004, 43,
275–284.
20. Wieder, T.; Prokop, A.; Bagci, B.; Essmann, F.; Bernicke, D.; Schulze-Osthoff, K.; Dorken, B.;
Schmalz, H.G.; Daniel, P.T.; Henze, G. Piceatannol, a hydroxylated analogue of the
chemopreventive agent resveratrol, is a potent inducer of apoptosis in the lymphoma cell line
BJAB and in primary, leukemic lymphoblasts. Leukemia 2001, 15, 1735–1742.
21. Wieder, F.; Prokop, A.; Bagci, B.; Essmann, F.; Bernicke, D.; Schulze-Osthoff, K.; Dorken, B.;
Schmalz, H.G.; Daniel, P.T.; Henze, G. Piceatannol, a hydroxylated analog of the
chemopreventive agent resveratrol, is a potent inducer of apoptosis in the lymphoma cell line
BJAB and in primary, leukemic lymphoblasts. Leukemia 2001, 15, 1735–1742.
22. Larrosa, M.; Tomas-Barberan, F.A.; Espin, J.C. The grape and wine polyphenol piceatannol is a
potent inducer of apoptosis in human SK-Mel-28 melanoma cells. J. Nutr. 2002, 13, 369–372.
23. Ovesna, Z.; Kozics, K.; Bader, Y.; Saiko, P.; Handler, N.; Erker, T.; Szkeres, T. Antioxidant
activity of resveratrol, piceatannol and 3,3’,4,4’,5,5’-hexahydroxy-trans-stilbene in three
leukemia cell lines. Oncol. Rep. 2006, 16, 617–624.
24. Potter, G.A.; Patterson, L.H.; Wanogho, E.; Perry, P.J.; Butler, P.C.; Ijaz, T.; Ruparelia, K.C.;
Lamb, J.H.; Farmer, P.B.; Stanley, L.A.; Burke, M.D. The cancer preventative agent resveratrol is
converted to the anticancer agent piceatannol by the cytochrome P450 enzyme CYP1B1. Br. J.
Cancer 2002, 86, 774–778.
25. Cai, Y.I.; Wei, Q.Y.; Fang, J.G.; Yang, L.; Liu, Z.L.; Wyche, J.H.; Han, Z. The 3,4-dihydroxyl
groups are important for trans-resveratrol analogs to exhibit enhanced antioxidant and apoptotic
activities. Anticancer Res. 2004, 24, 999–1002.
26. Visioli, F.; Galli, C. Olive oil phenols and their potential effects on human health. J. Agric. Food
Chem. 1998, 46, 4292–4296.
27. Tuck, K.L.; Hayball, P.J.; Stupans, I. Structural characterization of the metabolites of
hydroxytyrosol, the principal phenolic component in olive oil, in rats. J. Agric. Food Chem. 2002,
50, 2404–2409.
28. Figueroa-Espinoza, M.C.; Villeneuve, P. Phenolic acids enzymatic lipophilization. J. Agric. Food
Chem. 2005, 53, 2779–2787.
29. Buisman, G.J.H.; Helteren, C.T.W.; Kramer, G.F.H.; Veldsink, J.W.; Derksen, J.T.P.; Cuperus,
F.P. Enzymatic esterification of functionalized phenols for the synthesis of lipophilic antioxidants.
Biotecn. Lett. 1998, 20, 131–136.
30. Pignataro, B.; Sardone, L.; Marletta, G. Self-organizing fiberlike nanostructures and wrapping-up
processes in Languimir-Blodgett films. Langmuir 2003, 19, 5912–5917.

Molecules 2009, 14
4680
31. Bernini, R.; Mincione, E.; Barontini M.; Crisante, F. Method for preparing hydroxytyrosol and
hydroxytyrosol derivatives. WO Pat. 2008110908, 2008.
32. Bernini, R.; Mincione, E.; Barontini, M.; Crisante, F. Convenient synthesis of hydroxytyrosol and
its lipophilic derivatives from tyrosol or homovanillyl alcohol. J. Agric. Food Chem. 2008, 56,
8897–8904.
33. Bernini, R.; Cacchi, S.; Fabrizi, G.; Filisti, E. 2-Arylhydroxytyrosol derivatives via Suzuki-
Miyaura cross-coupling. Org. Lett. 2008, 10, 3457–3460.
34. Bernini, R.; Mincione, E.; Crisante, F.; Barontini, M.; Fabrizi, G. A novel use of the recyclable
polymer-supported IBX: An efficient chemoselective and regioselective oxidation of phenolic
compounds. The case of hydroxytyrosol derivatives. Tetrahedron Lett. 2009, 50, 1307–1310.
35. Bernini, R.; Mincione, E.; Crisante, F.; Barontini, M.; Fabrizi, G. Oxidation of tyrosol derivatives
using polymer-supported IBX. Synfacts 2009, 5, 571.
36. Bernini, R.; Barontini, M.; Mosesso, P.; Pepe, G.; Willför, S.M.; Sjöholm, R.E.; Eklund, P.C.;
Saladino, R. A selective de-O-methylation of guaiacyl lignans to corresponding catechol
derivatives by 2-iodoxybenzoic acid (IBX). The role of the catechol moiety on the toxicity of
lignans. Org. Bio. Chem. 2009, 7, 2367–2377.
37. Bernini, R.; Crisante, F.; Barontini, M.; Fabrizi, G. A new and efficient route for the synthesis of
naturally occurring catecholamines. Synthesis 2009, 22, 3838–3842.
38. Hartmann, C.; Mayer, V. Ueber Jodobenzoësäure. Chem. Ber. 1893, 26, 1727–1732.
39. Varvoglis, A. Hypervalent Iodine in Organic Synthesis; Academic Press: London, UK, 1997.
40. Zhdankin, V.V.; Stang, P.J. Recent development in the chemistry of polyvalent iodinee
compounds. Chem. Rev. 2002, 102, 2523–2584.
41. Ladziata, U.; Zhadankin, V.V. Hypervalent iodine (V) reagents in organic synthesis. ARKIVOC
2006, IX, 26–58.
42. Magdziak, D.; Rodriguez, A.A.; Van De Water, R.W.; Pettus, T.R.R. Regioselective oxidation of
phenols to o-quinones with o-iodoxybenzoic acid. Org. Lett. 2002, 4, 285–288.
43. Ozanne, A.; Pouységu, L.; Depernet, D.; Francois, B.; Quideau, S. A stabilized formulation of
IBX (SIBX) for safe oxidation reactions including a new oxidative demethylation of phenolic
methyl aryl ethers. Org. Lett. 2003, 5, 2903–2906.
44. Quideau, S.; Pouysegu, L.; Deffieux, D.; Ozanne, A.; Gagnepain, J.; Fabre, I.; Oxoby, M. Iodane-
mediated and electrochemical oxidative transformations of 2-methoxy-and 2-methylphenols.
Arkivoc 2003, VI, 106–119.
45. Ulrich, R.; Hofrichter, M. Enzymatic hydroxylation of aromatic compounds. Cell. Mol. Life Sci.
2007, 64, 271–293.
46. Brand-Williams, W.; Cuvelier, M.E.; Berzet, C. Use of a free radical method to evaluate
antioxidant activity. Food Sci. Technol. 1995, 28, 25–30.
47. Nicolosi, G.; Spatafora, C.; Tringali, C. Chemo-enzymatic preparation of resveratrol derivatives.
J. Mol. Cat. B Enzym. 2002, 16, 223–229.
48. Cardile, V.; Lombardo, L.; Spatafora, C.; Tringali, C. Chemo-enzymatic synthesis and cell-
growth inhibition activity of resveratrol analogues. Bioorg. Chem. 2005, 33, 22–33.

Molecules 2009, 14
4681
49. De Lucia, M.; Panzella, L.; Pezzella, A.; Napolitano, A.; D’Ischia, M. Plant catechols and their S-
glutathionyl conjugates as antinitrosating agents: Expedient synthesis and remarkable potency of
5-S-glutathionylpiceatannol. Chem. Res. Toxicol. 2008, 21, 2407–2413.
50. Teguo, P.W.; Fauconneau, B.; Deffieux, G.; Huguet, F.; Vercauteren, J.; Merillon, J.M. Isolation,
identification, and antioxidant activity of three stilbene glucosides newly extracted from Vitis
vinifera cell cultures. J. Nat. Prod. 1998, 61, 655–657.
51. Frigerio, M.; Santagostino, M; Sputore, S. A user-friendly entry to 2-iodoxybenzoic acid (IBX). J.
Org. Chem. 1999, 64, 4537–4538.
Sample Availability: Samples of the compounds 5a-d are available from the authors.
© 2009 by the authors; licensee Molecular Diversity Preservation International, Basel, Switzerland.
This article is an open-access article distributed under the terms and conditions of the Creative
Commons Attribution license (http://creativecommons.org/licenses/by/3.0/).
