Benzothiazole-Based Fluorophores of Donor-π-Acceptor-π-Donor

Type Displaying High Two-Photon Absorption

,‡,§

Veronika Hrobarikova, Peter Hrobarik,* Peter Gajdos, Ioannis Fitilis,

^

ꢀ

ꢀ ^†,‡

ꢀ

ꢁ ^†

Mihalis Fakis,^{^}Peter Persephonis,^{^}and Pavol Zahradnık^†

´

†

ꢀ

Department of Organic Chemistry, Faculty of Natural Sciences, Comenius University, Mlynska dolina,

SK-84215 Bratislava, Slovakia, ^‡Institut fu€r Physikalische und Theoretische Chemie,

€

Julius-Maximilians-Universitat Wurzburg, Am Hubland, DE-97074 Wurzburg, Germany,

§

Institute of Inorganic Chemistry, Slovak Academy of Sciences, Duꢀbravskaꢀ cesta 9, SK-84536 Bratislava,

Slovakia, and ^{^}Department of Physics, University of Patras, GR-26504 Patras, Greece

peter.hrobarik@savba.sk

Received February 25, 2010

A series of novel heterocycle-based dyes with donor-π-bridge-acceptor-π-bridge-donor (D-π-

A-π-D) structural motif, where benzothiazole serves as an electron-withdrawing core, have been

designed and synthesized via palladium-catalyzed Sonogashira and Suzuki-type cross-coupling reac-

tions. All the target chromophores show strong one-photon and two-photon excited emission. The

maximum two-photon absorption (TPA) cross sections δ_TPAof the prepared derivatives bearing

diphenylamino functionalities occur at wavelengths ranging from 760 to 800 nm and are as large

as ∼900-1100 GM. One- and two-photon absorption characteristics of the title dyes have also been

investigated by using density functional theory (DFT) and the structure-property relationships

are discussed. The TPA cross sections calculated by means of quadratic response time-dependent

DFT using the Coulomb-attenuated CAM-B3LYP functional support the experimentally

observed trends within the series, as well as higher δ_TPAvalues of the title compounds compared

to those of analogous fluorene or carbazole-derived dyes. In contrast, the traditional B3LYP

functional was not successful in predicting the observed trend of TPA cross sections for systems

with different central cores. In general, structural modification of the π-bridge composition by

replacement of ethynylene (alkyne) with E-ethenylene (alkene) linkages and/or replacement of

dialkylamino electron-donating edge substituents by diarylamino ones results in an increase of

δ_TPAvalues. The combination of large TPA cross sections and high emission quantum yields

makes the title benzothiazole-based dyes attractive for applications involving two-photon

excited fluorescence (TPEF).

Introduction

and optoelectronics, such as three-dimensional optical data

storage, fluorescence imaging, nonlinear optics, microfabri-

cation, etc.³All these TPA-based applications benefit mainly

from the following attributes of the two-photon absorption

process: (a) the activation of high-energy photophysical

properties by low-energy near-IR excitation (simultaneous

absorption of two photons of half the excitation energy by a

single molecule), resulting in larger material penetration com-

pared to excitations by visible or UV light, and (b) quadratic

The development of materials displaying high two-photon

absorption (TPA)^1,2has attracted great interest in the past

decade due to a variety of potential applications in photonics

(1) Pawlicki, M.; Collins, H. A.; Denning, R. G.; Anderson, H. L. Angew.

Chem., Int. Ed. 2009, 48, 3244–3266.

(2) Terenziani, F.; Katan, C.; Badaeva, E.; Tretiak, S.; Blanchard-Desce,

M. Adv. Mater. 2008, 20, 4641–4678.

DOI: 10.1021/jo100359q

r

Published on Web 04/01/2010

J. Org. Chem. 2010, 75, 3053–3068 3053

2010 American Chemical Society

ꢀ

Hrobarikova et al.

ꢀ

JOCArticle

dependence of the two-photon absorption on the intensity of

light, which allows for more control and higher spatial

resolution. In view of biological applications, such as in vivo

imaging, these advantages play an important role as they

lead to a finer resolution and a better in-depth tissue penet-

ration, combined with reduced cell damage. As a consequence,

the two-photon microscopy experiences an increasing popu-

larity.⁴Furthermore, the combination of the two-photon

absorbers with efficient singlet oxygen generation offers

great potential for further development of photodynamic

cancer therapy (PDT) methods.⁵The two-photon absorp-

tion process is, however, statistically disfavored and hence

the performance of classical one-photon fluorophores is

usually not sufficient for a potential application, due to their

low two-photon absorption cross sections (δ_TPA). To fully

exploit the great potential of the TPA process, research

focused on the design and synthesis of molecules exhibiting

large δ_TPAis still ongoing.^6-9Apart from the large TPA

absorption, high two-photon excited fluorescence (TPEF)

quantum yields, good photostability, appreciable solubility,

and proper response wavelengths are also required to meet

practical application needs in fields such as fluorescence

microscopy or upconverted lasing.¹⁰

π-conjugated systems symmetrically substituted with elec-

tron-donating (D) and/or electron-accepting (A) functional-

ities have been revealed as efficient TPA dyes. On the basis of

this general setting, many factors play an important role in

increasing δ_TPA, such as the efficiency of intramolecular

charge transfer (ICT), the conjugation length, the molecular

planarity, the dimensionality of the charge-transfer network,

the vibronic coupling, and the donating and withdrawing

abilities of the electron donor and acceptor.¹⁵

Although a number of efficient TPA chromophores are

already available, many of them consist only from substi-

tuted conjugated aromatic rings, such as benzene or fluorene,

and rely on the electronic properties of simple electron-

donating and/or electron-withdrawing functionalities. Re-

placement of these aromatic systems with more easily deloca-

lizable π-excessive or π-deficient heteroaromatics has been

shown to result in an increased intramolecular charge trans-

fer (ICT) as well as an enhanced two-photon absorption,

while the chemical and photochemical stability of these

systems has been preserved.^9,16Moreover, modification

of the structure by incorporation of heteroaromatics into

π-conjugated systems allows for fine-tuning of the electronic

and optical properties and often results in strong fluores-

cence emission, which is an essential prerequisite for certain

TPA-based applications (vide supra).¹⁷

The strategy for the construction of molecules with large

TPA cross sections has been studied both experimentally^11,12

and theoretically,^13,14and a certain part of the structure-

property relations has been explored. In particular, extended

The employment of heterocycles, such as thiophene,^18,19

pyrrole,^19,20or carbazole,^21,22in the design of novel dyes with

enhanced TPA has already been reported. Among various

heterocycles, benzothiazole has attractive chemical and

physical properties making it an appropriate building block

in construction of chromophores for nonlinear optics.^23-25
