Enantioselective Hydrogenation Catalysis Aided by a σ-Bonded
Calix[4]arene to a P-Chirogenic Aminophosphane Phosphinite
Rhodium Complex†
‡
‡
Naıma Khiri,‡ Etienne Bertrand,‡,§ Marie-Joelle Ondel-Eymin, Yoann Rousselin,
€
Jerome Bayardon, Pierre D. Harvey,* and Sylvain Juge*
‡
,§
,‡
ꢀ ^
ꢀ
‡
ꢀ
Institut de Chimie Moleculaire de l’Universite de Bourgogne, UMR CNRS 5260, 9 Avenue Alain Savary BP
47870, 21078 Dijon Cedex, France, and Departement de Chimie, Universite de Sherbrooke, Sherbrooke,
ꢀ
ꢀ
§
ꢀ
Queꢀbec, Canada J1K 2R1
Received May 27, 2010
The first P-chirogenic aminophosphane-phosphinite (AMP*P) ligand (4a) supported on the
upper rim of a calix[4]arene moiety was synthesized in two steps using the ephedrine methodology.
Ligand 4a was used for the preparation of the corresponding rhodium complex [Rh(COD)-
(AMP*P)]BF4 (5a) (COD=1,8-cyclooctadienyl), which was tested for asymmetric catalyzed hydro-
genation of various substrates. The structures of the AMP*P ligand as diborane and rhodium
complexes 3a and 5a were established by X-ray analysis. The asymmetric hydrogenation catalyzed
with the Rh complex 5a exhibits excellent enantioselectivities up to 98%. Investigation of modified
P-chirogenic aminophosphane-phosphinite ligands 4b,c, bearing an isoelectronic or a sterically
similar substituent on the P-chirogenic aminophosphane unit, demonstrates that the calix[4]arene
substituent of the aminophosphane moiety plays a major role in the better asymmetric induction. The
enantioselectivity of the catalyzed hydrogenation was weakly influenced by the hydrogen pressure,
which is in good agreement with a stereodetermining step involving the substrate-rhodium
complexes. Computer modeling indicated the presence of two conformers for the active AMP*P
rhodium species, according to whether the rhodium metal is outside or inside the calix[4]arene cavity
(called outer and inner). It is obvious that the complexation of the substrate with the active rhodium
species forces this complex to adopt fully the outer conformation and hence explains why the
calixarene fragment plays a key role in the stereodetermining step.
Introduction
restricted by the availability of a library of chiral ligands7
or by the structure modification of an efficient lead series
such as BINAP,8 DUPHOS,9 PHOX,10 monophos,11
bisP*,12 and SDP.13
Aminophosphane phosphinites (AMPP) are also conveni-
ent chiral ligands capable of improving highly steroselective
Asymmetric catalysis using chiral transition metal com-
plexes is a powerful method for the synthesis of chiral
substances, in laboratory scale as well as industrially.1-4
So far, mostly chiral catalysts were prepared by complexa-
tion of a chiral organophosphorus ligand and a transition
metal.5,6 However, improving an asymmetric catalytic reac-
tion for a new substrate is never trivial and is mainly
(8) Berthod, M.; Migniani, G.; Woodward, G.; Lemaire, M. Chem.
Rev. 2005, 105, 1801–1836.
(9) Clark, T. P.; Landis, C. R. Tetrahedron: Asymmetry 2004, 15,
2123–2137.
(10) Hargaden, G. C.; Guiry, P. J. Chem. Rev. 2009, 109, 2505–2550.
(11) (a) van den Berg, M.; Minnaard, A. J.; Schudde, E. P.; van Esch,
J.; de Vries, A. H. M.; de Vries, J. G.; Feringa, B. L. J. Am. Chem. Soc.
2000, 122, 11539–11540. (b) van den Berg, M.; Minnaard, A. J.; Haak, R. M.;
Leeman, M.; Schudde, E. P.; Meetsma, A.; Feringa, B. L.; de Vries, A. H. M.;
Maljaars, C. E. P.; Hyett, D.; Willans, C. E.; Boogers, J. A. F.; Henderickx,
H. J. W.; de Vries, J. G. Adv. Synth. Catal. 2003, 345, 308–323.
† This paper is dedicated to Prof. H. Kagan for his 80th birthday.
*To whom correspondence should be addressed. E-mail: Sylvain.Juge@
u-bourgogne.fr. Tel: þ33 (0)3 80 39 61 13. E-mail: Pierre.Harvey@
USherbrooke. Tel: 1-819-821-7092.
(1) Ojima, I. Catalytic Asymmetric Synthesis, 2nd ed.; Wiley-VCH:
Weinheim, 2000.
(2) Jacobsen, E. N.; Pfaltz, A.; Yamamoto, H. Comprehensive Asym-
ꢀ
(12) (a) Crepy, K. V. L.; Imamoto, T. Top. Curr. Chem. 2003, 229
metric Catalysis: Springer: New York, 2000.
1–40. (b) Imamoto, T. J. Synth. Org. Chem., Jpn. 2007, 65, 1060–1069.
(13) Xie, J.-H; Zhou, Q.-L. Acc. Chem. Res. 2008, 41, 581–593.
(14) (a) Kreuzfeld, H. J.; Schmidt, U.; Dobler, C.; Krause,
(3) (a) Blaser, H. U.; Spindler, F.; Studler, M. Appl. Catal. A: Gen.
2001, 221, 119–143. (b) Blaser, H. U.; Malan, C.; Pugin, B.; Spindler, F.;
Steiner, H.; Studer, M. Adv. Synth. Catal. 2003, 345, 103–151. (c) Blaser,
H. U.; Schmidt, E. Asymmetric Catalysis on Industrial Scale; Wiley-VCH:
Weinheim, 2003. (d) Blaser, H. U.; Pugin, B.; Spindler, F.; Tommen, M. Acc.
Chem. Res. 2007, 40, 1240–1250.
€
H. W. Tetrahedron: Asymmetry 1996, 7, 1011–1018. (b) Agbossou., F.;
Carpentier, J. F.; Hapiot, F.; Suisse, I.; Mortreux, A. Coord. Chem. Rev.
1998, 178-180, 1615–1645. (c) Broger, E. A.; Burkart, W.; Hennig, M.;
Scalone, M.; Schmidt, R. Tetrahedron: Asymmetry 1998, 9, 4043–4054. (d)
Lot, O.; Suisse, I.; Mortreux, A.; Agbossou, F. J. Mol. Catal. A 2000, 164,
125–130. (e) Chen, G.; Li, X.; Gang, L.; Mi, A.; Cui, X.; Jiang, Y.; Choi,
M. C. K.; Chan, A. S. C. Tetrahedron: Asymmetry 2002, 13, 809–813. (f)
(4) Johnson, N. B.; Lennon, I. C.; Moran, P. H.; Ramsden, J. A. Acc.
Chem. Res. 2007, 40, 1291–1299.
(5) Tang, W.; Zang, X. Chem. Rev. 2003, 103, 3029–3069.
€
€
(6) Jakel, C.; Paciello, R. Chem. Rev. 2006, 106, 2912–2942.
Dubrovina, N. V.; Tararov, V. I.; Kadyrova, Z.; Monsees, A.; Borner, A.
(7) Zhang, W.; Chi, Y.; Zhang, X. Acc. Chem. Res. 2007, 40, 1278–1290.
Synthesis 2004, 12, 2047–2051.
r
pubs.acs.org/Organometallics
Published on Web 07/23/2010
2010 American Chemical Society

Article
Organometallics, Vol. 29, No. 16, 2010 3623
catalysis, because libraries of such compounds can easily be
synthesized from available chiral amino alcohols in a few
steps.14-16 Numerous works have demonstrated the efficiency
of the synthesis of chiral AMPP ligands that can be applied to
asymmetric catalyses from their corresponding Rh, Ru, Pd, or
Ni complexes.14b,16,17 Recently, we and other groups have
independently described a series of P-chirogenic AMP*P
ligands derived from ephedrine, for catalytic asymmetric hydro-
genation and hydroformylation reactions involving rhodium
complexes18,19
Over the past decades, phosphorus ligands containing
calix[n]arenes have also received extensive attention for their
coordination chemistry and in transition metal catalysis.20
The use of calix[4]arene-based phosphorus ligands in cata-
lysis has been more recently recognized for their potential
applications and has already been evaluated in olefin
hydroformylation,21 oligomerization and polymerization
reactions,22 hydrogenation,21a,23 olefin oxidation,24 carbon-
carbon bond forming reactions,25 and allylic alkylation.26
So far, many chiral organophosphorus ligands derived
from calix[n]arene are known,20-26 but only a few asym-
metric catalyses were described.23 We now report herein the
first stereoselective synthesis of a P-chirogenic AMP*P
ligand with a calix[4]arene as substituent of the amino-
phosphane moiety along with an investigation of a
Rh(I)-catalyzed asymmetric hydrogenation. It is clearly
demonstrated that the calix[4]arene plays a key role in the
enantioselectivity.
Results and Discussion
P-Chirogenic aminophosphane-phosphinite ligand 4a is
prepared in two steps from the (þ)-oxazaphospholidine
borane 1, derived from (-)-ephedrine, according to the
general procedure described for the AMP*P.19 The reaction
of the starting complex 1 with the 25,26,27,28-tetrapro-
poxycalix[4]aren-5-yl lithium reagent leads, after P-O bond
cleavage, to the ring-opening alcoholate intermediate 2a,
which is trapped with chlorodiphenylphosphane. Subse-
quently, it is further trapped with borane to afford the
AMP*P in 62% yield as diborane complex 3a (Scheme 1).
