Influence of the Annealing Temperature on the Photovoltaic Performance
and Film Morphology Applying Novel Thermocleavable Materials
Martin Helgesen,*,† Morten Bjerring,‡ Niels Chr. Nielsen,‡ and Frederik C. Krebs†
†Risø National Laboratory for Sustainable Energy, Technical University of Denmark,
Frederiksborgvej 399, DK-4000 Roskilde, Denmark, and ‡Center for Insoluble Protein Structures (inSPIN),
Interdisciplinary Nanoscience Center (iNANO) and Department of Chemistry, Aarhus University,
DK-8000 Aarhus C, Denmark
Received July 14, 2010. Revised Manuscript Received August 25, 2010
Di-2-thienyl-2,1,3-benzothiadiazole (DTBT) bearing thermally cleavable ester groups in different
positions were prepared and copolymerized with alkylsubstituted cyclopentadithiophene (CPDT). The
polymers were found to have band gaps in the range of 1.66-2.03 eV and were explored in polymer
photovoltaic devices as mixtures with soluble methanofullerenes. The positioning of the ester groups
proved to be very significant despite the identical conjugated backbone of 2-methyl-2-hexyl 5-(4,4-
bis(2-ethylhexyl)-4H-cyclopenta[1,2-b:5,4-b0]dithiophen-2-yl)-2-(7-(3-(((2-methylhexan-2-yl)oxy)-car-
bonyl)thiophen-2-yl)benzo[c][1,2,5]thiadiazol-4-yl)thiophene-3-carboxylate (T1) and 2-methyl-2-hexyl
2-(4,4-bis(2-ethylhexyl)-4H-cyclopenta[1,2-b:5,4-b0]dithiophen-2-yl)-5-(7-(4-(((2-methylhexan-2-yl)oxy)-
carbonyl)thiophen-2-yl)benzo[c][1,2,5]thiadiazol-4-yl)thiophene-3-carboxylate (T2). Power conversion
efficiencies of up to 1.92% were observed for polymers bearing ester groups on the 4-positions of the
thienyl groups (T2), but shifting them to the 3-positions (T1) reduced the efficiency significantly to 0.18%.
The thermal behavior of the polymers was studied with thermogravimetric analysis (TGA) that showed a
weight loss around 200 °C corresponding to elimination of the ester side chains followed by a second
weight loss around 300 °C corresponding to loss of CO2 via decarboxylation. The temperature of
thermocleavage of the active layer films was optimized to 265 °C whereby the T2:PCBM solar cells
maintained a significant performance giving efficiencies up to 1.49%.
Introduction
material which offers significant advantages, both in terms of
conjugated polymer synthesis,7-11 device processing,3,12,13
and operational stability.14-17 To overcome the fact that
the softness/photochemistry provided by solubilizing chains
has been linked to the instability of polymer solar cells,18-25
the thermocleavable materials exploit a thermally labile
bond in the molecule that functions as the linker between
From a materials point of view the state-of-the-art in the
field of organic photovoltaics is currently represented by
bulk heterojunction solar cells based on a polymer/copolymer
and a methanofullerene ([60]PCBM and [70]PCBM) where
power conversion efficiencies are approaching encourag-
ing 8% for small area devices.1 The steady increase in
performance during the past 10 years reveals a great poten-
tial for polymer solar cells as a low-cost renewable energy
source,2-6 but aside from the efficiency, processing and
stability are two other important aspects that have to be
addressed with equal intensity to fully realize that potential.
To combine all three parameters into a useful material and
device further research in device science and new materials is
needed. A recent approach is to utilize a thermocleavable
(7) Banishoeib, F.; Adriaensens, P.; Berson, S.; Guillerez, S.; Douheret,
O.; Manca, J.; Fourier, S.; Cleij, T. J.; Lutsen, L.; Vanderzande, D.
Sol. Energy Mater. Sol. Cells 2007, 91(11), 1026–1034.
(8) Banishoeib, F.; Henckens, A.; Fourier, S.; Vanhooyland, G.;
Breselge, M.; Manca, J.; Cleij, T. J.; Lutsen, L.; Vanderzande,
D.; Nguyen, L. H.; Neugebauer, H.; Sariciftci, N. S. Thin Solid
Films 2008, 516(12), 3978–3988.
(9) Girotto, C.; Cheyns, D.; Aernouts, T.; Banishoeib, F.; Lutsen, L.;
Cleij, T. J.; Vanderzande, D.; Genoe, J.; Poortman, J.; Heremans,
P. Org. Electron. 2008, 9(5), 740–746.
(10) Palmaerts, A.; Lutsen, L.; Cleij, T. J.; Vanderzande, D.; Pivrikas,
A.; Neugebauer, H.; Sariciftci, N. S. Polymer 2009, 50(21), 5007–
5015.
(11) Vandenbergh, J.; Wouters, J.; Adriaensens, P. J.; Mens, R.; Cleij,
T. J.; Lutsen, L.; Vanderzande, D. J. M. Macromolecules 2009, 42
(11), 3661–3668.
(12) Hagemann, O.; Bjerring, M.; Nielsen, N. C.; Krebs, F. C. Sol.
Energy Mater. Sol. Cells 2008, 92(11), 1327–1335.
(13) Krebs, F. C.; Norrman, K. ACS Appl. Mater. Interfaces 2010, 2(3),
877–887.
*To whom correspondence should be addressed. E-mail: manp@risoe.
dtu.dk.
(1) Chen, H. Y.; Hou, J. H.; Zhang, S. Q.; Liang, Y. Y.; Yang, G. W.;
Yang, Y.; Yu, L. P.; Wu, Y.; Li, G. Nat. Photonics 2009, 3(11), 649–
653.
(2) Dennler, G.; Scharber, M. C.; Brabec, C. J. Adv. Mater. 2009, 21
(13), 1323–1338.
(3) Helgesen, M.; Søndergaard, R.; Krebs, F. C. J. Mater. Chem. 2010,
20(1), 36–60.
(14) Bjerring, M.; Nielsen, J. S.; Siu, A.; Nielsen, N. C.; Krebs, F. C. Sol.
Energy Mater. Sol. Cells 2008, 92(7), 772–784.
(15) Gevorgyan, S. A.; Krebs, F. C. Chem. Mater. 2008, 20(13), 4386–
4390.
(16) Krebs, F. C.; Spanggaard, H. Chem. Mater. 2005, 17(21), 5235–
5237.
(17) Krebs, F. C. Sol. Energy Mater. Sol. Cells 2008, 92(7), 715–726.
(4) Kippelen, B.; Bredas, J. L. Energy Environ. Sci. 2009, 2(3), 251–261.
(5) Thompson, B. C.; Frechet, J. M. J. Angew. Chem., Int. Ed. 2008, 47
(1), 58–77.
€
(6) Gunes, S.; Neugebauer, H.; Sariciftci, N. S. Chem. Rev. 2007, 107
(4), 1324–1338.
r
2010 American Chemical Society
Published on Web 09/08/2010
pubs.acs.org/cm

5618 Chem. Mater., Vol. 22, No. 19, 2010
Helgesen et al.
high chromophore density. The positioning of the ester
groups together with the annealing temperature has a
pronounced effect on the photovoltaic performance and
film morphology of the polymer:PCBM solar cells which
is presented.
Experimental Section
Synthetic procedures for synthesis of monomers and poly-
mers according to Schemes 1 and 2, and their characterization
data (incl. 1H and 13C liquid-state -NMR) are described in detail
in the Supporting Information together with general experi-
mental details.
Polymer Solar Cell Fabrication and Analysis. Photovoltaic
devices were made by spin coating PEDOT:PSS (Aldrich,
1.3 wt % aqueous solution) onto precleaned, patterned indium
tin oxide (ITO) substrates (9-15 Ωper square) (LumTec) followed
by annealing at 140 °C for 5 min. The active layer was deposited, in
a glovebox, by spin coating a blend of the polymer and PCBM
dissolved in o-dichlorobenzene (40 mg/mL). After a thermal
treatment (see Table 2) the counter electrode of aluminum was
deposited by vacuum evaporation at 2-3 ꢀ 10-6 mbar. The active
area of the cells was 0.5 cm2. I-V characteristics were measured
under AM1.5G corresponding to 100 mW/cm2 white light from a
multiwavelength high-power LED array using a Keithley 2400
source meter. IPCE spectra were recorded on the same solar test
platform28 with the LED based illumination system.
Figure 1. Polymers based on DTBT bearing thermocleavable ester
groups and CPDT.
the solubilizing group and the photoactive material. When
the polymer is heated this bond breaks whereby the solubi-
lizing group can be removed in a post-processing step form-
ing a harder insoluble material. At this point, thermoclea-
vage of bulk heterojunction polymer:PCBM solar cells has
generally lead to a drop in the photovoltaic performance
which has been linked to extensive phase segregation of the
polymer and PCBM upon annealing.26 However, there
are a few examples where similar or better performance
has been obtained after thermocleavage of the film15,27
and these examples possibly represent cases where the
morphology does not change before thermocleavage.
Herein we report our efforts in advancing thermocleav-
able materials in bulk heterojunction solar cells through
the synthesis of two new polymers with reduced band gap.
The polymers T1 and T2 (Figure 1) are copolymers based
on di-2-thienyl-2,1,3-benzothiadiazole (DTBT) and 4,4-
bis(2-ethylhexyl)-4H-cyclopenta[1,2-b:5,4-b0]dithiophene
(CPDT). For thermocleavability and improved solubil-
ity, ester side chains are attached to the thiophene units
through a thermally labile ester bond. The ester groups
can be removed, at temperatures in the range 200-
300 °C, via elimination and decarboxylation in a post-
processing step leaving a harder polymer material with
Results and Discussion
Synthesis. The synthetic steps involved in the prepara-
tion of the monomers 7a and 7b are outlined in Scheme 1.
The esterification of thiophene-3-carboxylic acid (1) em-
