Communications
DOI: 10.1002/anie.201004963
Natural Products Synthesis
Total Synthesis of Tryprostatins A and B**
Takayuki Yamakawa, Eiji Ideue, Jun Shimokawa, and Tohru Fukuyama*
Multiple-drug resistance toward cell-cycle inhibitors fre-
quently becomes an obstacle in cancer chemotherapy. One
strategy for circumventing this problem is to develop
antimitotic agents that operate by a new mode of action.
Two such compounds, tryprostatins A and B, were isolated in
1995 from the fermentation broth of Aspergillus fumigatus
BM939 by Osada and co-workers.[1] Tryprostatin A holds
great promise, because it selectively arrests the cell cycle at
the mitotic phase in tsFT210 cells.[2] Interesting biological
activity combined with an apparently simple structure has
stimulated the synthetic community, and several total syn-
theses have already been reported.[3,4]
Our research group has long been involved with the
radical-mediated construction of a variety of indole cores and
the application of these methods to natural product syn-
thesis.[5,6] We envisioned that our method could also be
Scheme 1. Retrosynthetic analysis. Boc=tert-butoxycarbonyl.
applied to the synthesis of the 2,3-disubstituted indole moiety
of the tryprostatins. The interesting structural features as well
as the therapeutic potential of tryprostatin A analogues
indicated in a recent structure–activity-relationship study[4e]
prompted us to launch a program toward the synthesis of
tryprostatins.
We reasoned that radical-mediated cyclization and sub-
sequent palladium-mediated coupling with a prenyl-group
donor would enable facile construction of the 2,3-disubsti-
tuted indole core structure 3 (Scheme 1). The requisite ortho-
alkenyl isocyanide 4 would be prepared from the alkyne 5,
which in turn could be accessed by Sonogashira coupling of
the aromatic iodide 6 with the terminal alkyne 7. To enable
synthesis of the target compounds with high enantiomeric
purity, the alkyne 7 derived from the Garner aldehyde (8)[7]
was employed as a latent amino acid unit to be incorporated
into the diketopiperazine.
Initially, we focused our efforts on the synthesis of the
isocyanide 12 as a radical-cyclization precursor (Scheme 2).
The alkyne 7 was prepared from 8 according to the known
protocol[8] with a slight modification. After the Sonogashira
coupling between 7 and 2-iodoformanilide (9), partial reduc-
tion of the triple bond was examined. Whereas the use of the
Lindlar catalyst, Pd/C, nickel boride,[9] or diimide[10] resulted
in no reaction or overreduction, treatment with Zn/LiCuBr2
Scheme 2. Synthesis of the ortho-alkenyl isocyanide 12: a) CBr4, PPh3,
Et3N, CH2Cl2, À60–08C, 88%; b) EtMgBr, THF, 08C, 98%; c) 9, CuI,
[PdCl2(PPh3)2], Et3N, room temperature, 97%; d) Zn, BrCH2CH2Br,
CuBr, LiBr, THF, CF3CH2OH, 708C, 99%; e) triphosgene, pyridine,
CH2Cl2, 08C, 87%.
in ethanol[11] gave the desired product 11 along with the
corresponding amine. The use of 2,2,2-trifluoroethanol[12] as
the solvent suppressed the undesired solvolysis and improved
the yield of 11 to 99%. Subsequent dehydration with
bis(trichloromethyl) carbonate (triphosgene) gave the
ortho-alkenyl isocyanide 12 and thus set the stage for a
radical-mediated cyclization.
When isocyanide 12 thus obtained was subjected to our
previously established radical-cyclization conditions,[5a] the
desired 5-exo adduct 13 was obtained in moderate yield after
acidic treatment with silica gel along with a considerable
amount of products 14 and 15 of a 6-endo cyclization–
cleavage process (Scheme 3). We were aware of the tendency
of this imidoyl-radical cyclization to give a mixture of the
5-exo and 6-endo products if the intermediate radical of the
[*] T. Yamakawa, E. Ideue, J. Shimokawa, Prof. Dr. T. Fukuyama
Graduate School of Pharmaceutical Sciences, University of Tokyo
7-3-1 Hongo, Bunkyo-ku, Tokyo 113-0033 (Japan)
Fax: (+81)358-028-694
E-mail: fukuyama@mol.f.u-tokyo.ac.jp
[**] Financial support for this research was provided by Grants-in-Aid
(21790009 and 20002004) from the Ministry of Education, Culture,
Sports, Science and Technology of Japan.
Supporting information for this article is available on the WWW
under http://dx.doi.org/10.1002/anie.201004963.
9262
ꢀ 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2010, 49, 9262 –9265

Angewandte
Chemie
When this method was applied to the radical cyclization of
the isocyanide 12, complete selectivity was observed for the
cyclization of the imidoyl radical to give the 2-stannylindole
21 (Scheme 4). Although we previously reported a one-pot
Stille-type coupling reaction between aromatic or vinylic
halides and 2-stannylindoles generated in situ for the
Scheme 3. Troublesome radical-mediated cyclization: a) nBu3SnH
(2.0 equiv), AIBN (15 mol%), MeCN, 1008C; silica gel, room temper-
ature. AIBN=azobisisobutyronitrile.
5-exo cyclization is not stabilized by the neighboring sub-
stituent.[5] Although we showed in our previous studies that
the 5-exo cyclization is dominant under conditions of kinetic
control,[5d] generally applicable conditions for the formation
of 2-stannylindoles had yet to be determined. In an attempt to
reduce the reaction temperature, we employed 2,2’-azobis(4-
methoxy-2,4-dimethylvaleronitrile) (V-70, 20) as a radical
initiator with a lower decomposition temperature.[13] To assess
the potential of V-70, we chose substrates without radical-
stabilizing substituents. When subjected to the reported
conditions (AIBN, 1008C), substrates 16 and 17 afforded a
mixture of the 5-exo adduct 18 and the 6-endo adduct 19, and
cyclization of the trans isomer 17 proved to be more difficult
than that of the cis isomer 16 (Table 1, entries 1 and 4).[14]
However, the use of V-70 at 308C virtually suppressed the
formation of the 6-endo adduct: after acidic treatment, indole
18 was obtained in good yield as the dominant product,
regardless of the configuration of the substrate (Table 1,
entries 3 and 6). Thus, we established reliable conditions for
imidoyl-radical-mediated indole synthesis.
Scheme 4. Total synthesis of tryprostatin B: a) nBu3SnH (3.0 equiv),
V-70 (20, 20 mol%), toluene, 308C; b) 22, LiCl (3.0 equiv), [Pd2(dba)3]
(10 mol%), AsPh3 (40 mol%), DMF, 808C, 73%; c) Boc2O, DMAP,
MeCN, room temperature, 99%; d) TFA/THF/H2O (4:2:1), 08C, 88%;
e) TEMPO, PhI(OAc)2, MeCN, phosphate buffer (pH 6.8), room tem-
perature, 91%; f) 26, HATU, iPr2NEt, CH2Cl2, room temperature, 88%;
g) NMP, reflux, 89%. dba=dibenzylideneacetone, DMAP=4-dimethyl-
aminopyridine, DMF=N,N-dimethylformamide, HATU=O-(7-azaben-
zotriazol-1-yl)-N,N,N’,N’-tetramethyluronium hexafluorophosphate,
TEMPO=2,2,6,6-tetramethylpiperidin-1-oxyl, TFA=trifluoroacetic acid.
Table 1: Low-temperature radical cyclization.
preparation of 2,3-disubstituted indoles,[5a] no such coupling
reactions with allylic systems have been reported. When
[Pd(PPh3)4] was used as the catalyst, the desired product was
obtained in only 29% yield with prenyl acetate (22) as the
coupling partner. Extensive investigations revealed that a
combination of [Pd2(dba)3], triphenylarsine, and lithium
chloride gave the best results and afforded the desired
product 23 in 82% yield in a one-pot process from the
isocyanide 12.
Once construction of the indole moiety was complete, 23
was converted into the corresponding amino acid 25 in a
three-step sequence consisting of protection of the indole
with a Boc group, hydrolysis of the acetonide, and oxidation
of the resulting alcohol 24 to the carboxylic acid 25 with
TEMPO. After condensation with l-proline methyl ester
Entry Substrate Initiator Solvent T [8C] 18 [%][d] 19 [%][d]
1[a]
2[b]
3[c]
4[a]
5[b]
6[c]
16
16
16
17
17
17
AIBN
AIBN
V-70
AIBN
AIBN
V-70
MeCN
toluene 100
toluene
MeCN
toluene 100
toluene 30
100
72
64
84
51
48
77
18
23
2
33
34
6
30
100
[a] See reference [5a] for the reaction conditions. [b] Reaction conditions:
nBu3SnH (2.0 equiv), AIBN (15 mol%), toluene (0.2m), 1 h, 1008C; 1m
aqueous HCl, room temperature. [c] Reaction conditions: nBu3SnH
(2.0 equiv), V-70 (20, 15 mol%), toluene (0.2m), 3 h, 308C; 1m aqueous
HCl, room temperature. [d] Yield of the isolated product.
Angew. Chem. Int. Ed. 2010, 49, 9262 –9265
ꢀ 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org 9263

Communications
Scheme 5. Total synthesis of tryprostatin A: a) HCO2H, Ac2O, CH2Cl2, 08C, 98%; b) 7, CuI, [PdCl2(PPh3)2], Et3N/THF, room temperature, 98%;
c) Zn, BrCH2CH2Br, CuBr, LiBr, THF, CF3CH2OH, 708C, 94%; d) triphosgene, pyridine, CH2Cl2, 08C, 85%; e) nBu3SnH (3.0 equiv), V-70
(20 mol%), toluene, 308C; f) 22, LiCl (3.0 equiv), [Pd2(dba)3] (10 mol%), AsPh3 (40 mol%), DMF, 808C, 80%; g) Boc2O, DMAP, MeCN, room
temperature, 92%; h) TFA/THF/H2O (4:2:1), 08C, 96%; i) TEMPO, PhI(OAc)2, phosphate buffer (pH 6.8), MeCN, 08C, 91%; j) 26, HATU,
iPr2NEt, CH2Cl2, room temperature, 77%; k) NMP, reflux, 78%.
b) C.-B. Cui, H. Kakeya, G. Okada, R. Onose, H. Osada, J.
(26), the remaining transformations involved the removal of
Antibiot. 1996, 49, 527 – 533; c) C.-B. Cui, H. Kakeya, H. Osada,
J. Antibiot. 1996, 49, 534 – 540.
the two Boc groups in 27 and cyclization to construct a
diketopiperazine core structure. However, the conventional
method for removing Boc groups under acidic conditions
caused substantial decomposition of the substrate. Thus, we
attempted thermal removal of the Boc groups.[15] After
extensive optimization, this transformation was carried out
by heating the substrate under reflux in N-methylpyrrolidi-
none (NMP). Under these conditions, spontaneous cycliza-
tion occurred to give tryprostatin B (2) in 89% yield. Thus,
tryprostatin B was synthesized in 11 steps from 8 in 33%
overall yield on a half-gram scale.
Having established a generally applicable protocol for the
preparation of 2-stannylindoles with V-70, we undertook the
total synthesis of tryprostatin A (1) to showcase the synthetic
utility of this approach (Scheme 5). The synthesis commenced
with the preparation of 28 from 4-methoxy-2-nitroaniline in a
two-step, slightly modified sequence, including the Sand-
meyer reaction and iron-mediated reduction.[4c,16] By follow-
ing the route established for tryprostatin B, we synthesized
tryprostatin A in 30% overall yield from 28 on a half-gram
scale.
In summary, optimization of the radical-mediated indole
synthesis by the use of V-70 made it possible to access
2-stannyl 3-substituted indoles with substituents at C3 that
cannot effectively stabilize the radical intermediate. In
combination with a subsequent palladium-mediated coupling
reaction at C2, the radical cyclization enables the preparation
of a variety of 2,3-disubstituted indoles, such as tryprosta-
tins A and B. Further investigations into the synthesis and
biological activity of tryprostatin analogues are under way.
[2] a) T. Usui, M. Kondoh, C.-B. Cui, T. Mayumi, H. Osada,
Biochem. J. 1998, 333, 543 – 548; b) M. Kondoh, T. Usui, T.
Mayumi, H. Osada, J. Antibiot. 1998, 51, 801 – 804; c) H.
Woehlecke, H. Osada, A. Herrmann, H. Lage, Int. J. Cancer
2003, 107, 721 – 728.
[3] a) K. M. Depew, S. J. Danishefsky, N. Rosen, L. Sepp-Lorenzino,
J. Am. Chem. Soc. 1996, 118, 12463 – 12464; b) J. M. Schker-
yantz, J. C. G. Woo, P. Siliphaivanh, K. M. Depew, S. J. Dani-
shefsky, J. Am. Chem. Soc. 1999, 121, 11964 – 11975; c) T. Gan,
J. M. Cook, Tetrahedron Lett. 1997, 38, 1301 – 1304; d) T. Gan, R.
Liu, P. Yu, S. Zhao, J. M. Cook, J. Org. Chem. 1997, 62, 9298 –
9304; e) S. Zhao, T. Gan, P. Yu, J. M. Cook, Tetrahedron Lett.
1998, 39, 7009 – 7012; f) A. S. Cardoso, A. M. Lobo, S. Prabha-
kar, Tetrahedron Lett. 2000, 41, 3611 – 3613; g) B. Wang, L. Chen,
K. Kim, Tetrahedron Lett. 2001, 42, 1463 – 1466; h) E. Caballero,
C. Avendaꢀo, J. C. Menꢁndez, J. Org. Chem. 2003, 68, 6944 –
6951; i) A. S. P. Cardoso, M. M. B. Marques, N. Srinivasan, S.
Prabhakar, A. M. Lobo, H. S. Rzepa, Org. Biomol. Chem. 2006,
4, 3966 – 3972.
[4] For syntheses of analogues, see: a) J. F. Sanz-Cervera, E. M.
Stocking, T. Usui, H. Osada, R. M. Williams, Bioorg. Med.
Chem. 2000, 8, 2407 – 2415; b) H. Wang, T. Usui, H. Osada, A.
Ganesan, J. Med. Chem. 2000, 43, 1577 – 1585; c) C. Ma, X. Liu,
X. Li, J. Flippen-Anderson, S. Yu, J. M. Cook, J. Org. Chem.
2001, 66, 4525 – 4542; d) S. Zhao, K. S. Smith, A. M. Deveau,
C. M. Dieckhaus, M. A. Johnson, T. L. Macdonald, J. M. Cook, J.
Med. Chem. 2002, 45, 1559 – 1562; e) H. D. Jain, C. Zhang, S.
Zhou, H. Zhou, J. Ma, X. Liu, X. Liao, A. M. Deveau, C. M.
Dieckhaus, M. A. Johnson, K. S. Smith, T. L. Macdonald, H.
Kakeya, H. Osada, J. M. Cook, Bioorg. Med. Chem. 2008, 16,
4626 – 4651; f) J. Wagger, J. Svete, B. Stanovnik, Synthesis 2008,
1436 – 1442.
[5] a) T. Fukuyama, X. Chen, G. Peng, J. Am. Chem. Soc. 1994, 116,
3127 – 3128; b) S. Kobayashi, T. Fukuyama, J. Heterocycl. Chem.
1998, 35, 1043 – 1055; c) S. Kobayashi, G. Peng, T. Fukuyama,
Tetrahedron Lett. 1999, 40, 1519 – 1522; d) S. Kobayashi, T.
Ueda, T. Fukuyama, Synlett 2000, 883 – 886; e) H. Tokuyama, M.
Watanabe, Y. Hayashi, T. Kurokawa, G. Peng, T. Fukuyama,
Synlett 2001, 1403 – 1406; f) H. Tokuyama, T. Fukuyama, Chem.
Rec. 2002, 2, 37 – 45; g) S. Sumi, K. Matsumoto, H. Tokuyama, T.
Fukuyama, Org. Lett. 2003, 5, 1891 – 1893; h) S. Sumi, K.
Matsumoto, H. Tokuyama, T. Fukuyama, Tetrahedron 2003, 59,
8571 – 8587.
Received: August 9, 2010
Published online: October 28, 2010
Keywords: alkaloids · heterocycles · natural products ·
.
radical reactions · total synthesis
[1] a) C.-B. Cui, H. Kakeya, G. Okada, R. Onose, M. Ubukata, I.
Takahashi, K. Isono, H. Osada, J. Antibiot. 1995, 48, 1382 – 1384;
9264 www.angewandte.org
ꢀ 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2010, 49, 9262 –9265

Angewandte
Chemie
[6] a) H. Tokuyama, T. Yamashita, M. T. Reding, Y. Kaburagi, T.
Fukuyama, J. Am. Chem. Soc. 1999, 121, 3791 – 3792; b) M. T.
Reding, T. Fukuyama, Org. Lett. 1999, 1, 973 – 976; c) M. T.
Reding, Y. Kaburagi, H. Tokuyama, T. Fukuyama, Heterocycles
2002, 56, 313 – 330; d) S. Yokoshima, T. Ueda, S. Kobayashi, A.
Sato, T. Kuboyama, H. Tokuyama, T. Fukuyama, J. Am. Chem.
Soc. 2002, 124, 2137 – 2139; e) S. Yokoshima, T. Ueda, S.
Kobayashi, A. Sato, T. Kuboyama, H. Tokuyama, T. Fukuyama,
Pure Appl. Chem. 2003, 75, 29 – 38; f) T. Kuboyama, S. Yokosh-
ima, H. Tokuyama, T. Fukuyama, Proc. Natl. Acad. Sci. USA
2004, 101, 11966 – 11970; g) Y. Kaburagi, H. Tokuyama, T.
Fukuyama, J. Am. Chem. Soc. 2004, 126, 10246 – 10247; h) T.
Miyazaki, S. Yokoshima, S. Simizu, H. Osada, H. Tokuyama, T.
Fukuyama, Org. Lett. 2007, 9, 4737 – 4740.
[7] a) A. Dondoni, D. Perrone in Org. Synth. Coll. Vol. 10 (Ed.: J. P.
Freeman), Wiley, Hoboken, NJ, 2004, pp. 320 – 326; b) P. Garner,
J. M. Park, Org. Synth. Coll. Vol. 9 (Ed.: J. P. Freeman), Wiley,
Hoboken, NJ, 1998, pp. 300 – 306.
[8] J. Erdsack, N. Krause, Synthesis 2007, 3741 – 3750.
[9] C. A. Brown, V. K. Ahuja, J. Chem. Soc. Chem. Commun. 1973,
553 – 554.
[10] a) K. R. Buszek, N. Brown, J. Org. Chem. 2007, 72, 3125 – 3128;
b) A. G. Myers, B. Zheng, M. Movassaghi, J. Org. Chem. 1997,
62, 7507 – 7507.
[11] M. H. P. J. Aerssens, R. van der Heiden, M. Heus, L. Brandsma,
Synth. Commun. 1990, 20, 3421 – 3425.
[12] S. Minegishi, S. Kobayashi, H. Mayr, J. Am. Chem. Soc. 2004,
126, 5174 – 5181.
[13] a) Y. Kita, K. Gotanda, K. Murata, M. Suemura, A. Sano, T.
Yamaguchi, M. Oka, M. Matsugi, Org. Process Res. Dev. 1998, 2,
250 – 254; b) Y. Kita, A. Sano, T. Yamaguchi, M. Oka, K.
Gotanda, M. Matsugi, J. Org. Chem. 1999, 64, 675 – 678; c) Y.
Kita, A. Sano, T. Yamaguchi, M. Oka, K. Gotanda, M. Matsugi,
Tetrahedron Lett. 1997, 38, 3549 – 3552.
[14] Dihydroquinoline intermediate underwent further reduction to
afford tetrahydroquinoline 19.
[15] a) A. Lꢂpez-Cobeꢀas, P. Cledera, J. D. Sꢃnchez, P. Lꢂpez-
Alvarado, M. T. Ramos, C. Avendaꢀo, J. C. Menꢁndez, Synthesis
2005, 3412 – 3422; b) V. H. Rawal, M. P. Cava, Tetrahedron Lett.
1985, 26, 6141 – 6142.
[16] See the Supporting Information for a detailed description of the
preparation of 28.
Angew. Chem. Int. Ed. 2010, 49, 9262 –9265
ꢀ 2010 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org 9265
