Organic Process Research & Development
TECHNICAL NOTE
’ EXPERIMENTAL SECTION
waterꢀisopropanol to provide (1S,2S)-2-vinyl-cyclopropane-1,1-di-
carboxylic acid isopropyl ester dibenzylamine salt (12) as a white
crystalline solid (21.0 g, 50%, >99% ee). 12: [R]20D = ꢀ19.8 (c 1.0,
MeOH); 1H NMR (400 MHz, CD3OD): δ = 7.44 (m, 10H), 5.39
(m, 1H),5.19(m,1H),4.99(m, 2H),4.16(s, 4H),2.39(dd,J= 15.6,
8.6 Hz, 1H), 1.37 (m, 2H), 1.24 (d, J = 6.3 Hz, 3H), 1.20 (d, J = 6.2
Hz, 3H); 13C NMR (100 MHz, CD3OD): δ = 176.1, 171.3, 136.7,
133.6, 131.0, 130.3, 130.2, 69.6, 52.0, 39.7, 31.0, 22.2, 21.0, 19.6; ESI-
MS: m/z 199 [M ꢀ Bn2NH þ H]þ, 198 [Bn2NH þ H]þ; HRMS
calcd for C24H30NO4 396.2169, found 396.2212.
Isopropyl (1R,2S)-1-Amino-2-vinylcyclopropanecarboxylate
p-Toluenesulfonic Acid Salt (13).15. To a suspension of (1S,2S)-
2-vinyl-cyclopropane-1,1-dicarboxylic acid isopropyl ester dibenzyla-
mine salt (12, 18 g, 45.5 mmol, 1 equiv) in MTBE (200 mL) was
added a 15% H3PO4 solution (w/w, 200 mL), and the resulting
mixture was stirred at rt for 10 min. The organic phase was separated,
washed with 5% NaCl (100 mL), and concentrated to a minimum
amount of volume (∼20 mL). To the residue was added acetone
(100 mL) and triethylamine (5.1 g, 50.1 mmol, 1.1 equiv), followed
by ethyl chloroformate (5.4 g, 50 0.1 mol, 1.1 equiv) at ꢀ5 °C over
5 min. The resulting mixture was stirred at ꢀ5 to 0 °C for 10 min.
Upon the complete formation of the mixed anhydride, sodium azide
(5.9 g, 91.0 mmol, 2 equiv) in water (60 mL) was added at ꢀ5 to
0 °C over 5 min. The mixture was further stirred at ꢀ5 to 0 °C for
10 min. Toluene (200 mL) and water (200 mL) were added. The
toluene layer was separated, washed with water (100 mL) and brine
(100 mL), and concentrated to an ∼50 mL total volume. To a
refluxed mixture of toluene (80 mL) and tert-butanol (80 mL) was
added the aforementioned toluene solution over 20 min. Gas was
generated instantaneously during the addition. The mixture was
further stirred at reflux (∼85 °C) for 3 h, then concentrated to a
minimum amount of volume, and retreated with 2-propanol
(S)-4-(2-Chloro-ethyl)-[1,3,2]dioxathiolane 2,2-Dioxide (5).
To a 3-L three-necked flask equipped with a condenser and an
additional funnel were charged (S)-1,2,4-butanetriol (100 g, 0.94
mol) and dichloroethane (600 mL). To the mixture at rt was added
thionyl chloride (336.3 g, 2.827 mol, 3 equiv) over 30 min. The
resulting mixture was stirred at reflux for 4 h and then concentrated
under a reduced pressure. The residue was further treated with
MeCN (300 mL), dichloromethane (300 mL), and water (400 mL)
to form a biphasic solution. To the mixture at 10 °C was added
RuCl3 xH2O (2.4 g) followed by the addition of NaIO4 (282.1 g,
3
1.32 mol, 1.4 equiv) in portions over 30 min while controlling the
reaction temperature below 25 °C. After the addition, the mixture
was further stirred at rt for 1 h and then quenched by the addition of
MTBE (500 mL) and water (500 mL). The organic phase was
separated, filtered though a pad of Celite; washed sequentially with
water (500 mL), 10% Na2SO3 solution (500 mL), and brine
(300 mL); and then concentrated and distilled under vacuum
(130ꢀ135 °C/6 mmHg) to provide the desired pure product 6
as a colorless oil (145 g, 83%, >97% ee). 5: [R]20D = ꢀ60.4 (c 1.0,
CHCl3); 1H NMR (500 MHz, CDCl3): δ = 5.21 (m, 1H), 4.81 (m,
1H), 4.41 (m, 1H), 3.69 (m, 2H), 2.43 (m, 1H), 2.16 (m, 1H); 13C
NMR (125 MHz, CDCl3): δ = 79.9, 72.4, 39.2, 34.9. EI-MS: m/z
186 [M þ H]þ; HRMS calcd for C4H8ClO4S þ CH3OH
219.0088, found 219.0111.
(1S,2S)-2-Vinyl-cyclopropane-1,1-dicarboxylic Acid Isopropyl
Ester Dibenzylamine Salt (12). To a solution of (S)-4-(2-chloro-
ethyl)-[1,3,2]dioxathiolane 2,2-dioxide (5, 21.8 g, 117 mmol, 1.1
equiv) and diisopropyl malonate (4c, 20.0 g, 106 mmol, 1.0 equiv) in
toluene (350 mL) at ꢀ10 °C was added lithium tert-butoxide (18.7 g,
234 mmol, 2.2 equiv). The mixture was stirred at ꢀ10 °C for 20 min,
then allowed to warm to rt over 30 min, and further stirred at rt for
12 h. To the mixture was added a 2 N NaOH solution (200 mL), and
the resulting mixture was stirred at rt for 10 min. The organic phase
was separated, washed sequentially with water (200 mL) and brine
(200 mL), and concentrated to give the crude cyclopropane product
4c as a colorless oil, which was further treated with THF (40 mL) to
form a solution. To a solution of KHMDS in THF (0.9 M, 236 mL,
212.5 mmol, 2.0 equiv) at rt was charged isopropanol (12.8 g, 212.5
mmol, 2.0 equiv) over 5 min. The resulting slurry was stirred at rt for
10 min. To the mixture at rt was then charged the aforementioned
THF solution of 4c over 10 min. The resulting solution was then
warmed to 40 °C and stirred at this temperature for 4 h. Upon
complete elimination monitored by HPLC, the mixture was cooled to
0 °C and quenched by the addition of a 1 N HCl solution (200 mL).
To the mixture was added MTBE (300 mL), and the organic phase
was separated, washed with water (200 mL) and brine (200 mL), and
concentrated to a minimum volume to provide the crude vinylcyclo-
propane product 3c as a light yellow oil. To the residue were added
isopropanol (120 mL) and water (24 mL) to form a clean solution.
Tetramethylammonium hydroxide pentahydrate (20.5 g, 112 mmol,
1.1 equiv) was added in one portion, and the mixture was heated to
40 °C and stirred at this temperature for 6 h. At ∼95% conversion by
HPLC, the mixture was quenched by the addition of a 2 N HCl
solution (200 mL) and heptane (200 mL), then concentrated under
a reduced pressure to remove most of the organic phase, and further
treated with heptane (200 mL). After passing through a pad of Celite,
the organic phase was separated and concentrated to an ∼200 mL
total volume. To the mixture was added dibenzylamine (20.9 g, 106.3
mmol, 1.0 equiv), and the resulting slurry was further stirred at 0 °C
for 30 min and then filtered. The white solid was recrystallized from
(20 mL). TsOH H2O (9.52 g, 50.1 mol, 1.1 equiv) was added to
3
the solution, and the mixture was stirred at 50 °C for 12 h before
cooled to rt. To the solution was added isopropyl acetate (100 mL),
and the mixture was then concentrated to a minimum amount of
volume (∼20 mL). The residue was further treated with isopropyl
acetate (100 mL), stirred at 0 °C for 10 min, and then filtered. The
cake was washed with isopropyl acetate (25 mL ꢁ 2) and dried at rt
under a reduced pressure to give isopropyl (1R,2S)-1-amino-2-
vinylcyclopropanecarboxylate p-toluenesulfonic acid salt (13) as a
white crystalline solid (10.1 g, 29.6 mmol, 65%). 13: [R]20D = þ27.4
(c 1.0, MeOH); 1H NMR (400 MHz, CDCl3): δ = 8.59 (s, 1H),
7.74 (d, J = 7.7 Hz, 2H), 7.15 (d, J = 7.7 Hz, 2H), 5.59 (m, 1H), 5.17
(d, J = 17.1 Hz, 1H), 5.07 (d, J = 10.3 Hz, 1H), 4.96 (m, 1H), 5.54
(dd, J = 17.8, 8.8 Hz, 1H), 2.35 (s, 3H), 1.91 (dd, J = 10.0, 6.4 Hz,
1H), 1.18 (d, J = 6.2 Hz, 3H), 1.14 (d, J = 6.2 Hz, 3H); 13C NMR
(100 MHz, CDCl3): δ = 141.3, 140.5, 131.8, 128.9, 126.0, 119.2,
70.8, 30.4, 21.6, 19.2; ESI-MS: m/z 170 [M ꢀ TsOH þ H]þ;
HRMS calcd for C9H16NO2 170.1175, found 170.1195.
’ ASSOCIATED CONTENT
S
Supporting Information. Analysis of the enantiomeric
b
purities of 12 and 13; NMR spectra of compound 5, 3c, 12, and
13. This material is available free of charge via the Internet at
