Asymmetric Hydrogenation of 3-Amido-2-arylpyridinium Salts by Triply Chloride-Bridged Dinuclear Iridium Complexes Bearing Enantiopure Diphosphine Ligands: Synthesis of Neurokinin-1 Receptor Antagonist Derivatives

Article abstract of DOI:10.1002/adsc.201600203

We describe a most straightforward synthetic method for preparing neurokinin-1 (NK1) receptor antagonist derivatives by asymmetric hydrogenation of 3-amido-2-arylpyridinium salts using dinuclear iridium complexes with enantiopure diphosphine ligands, affo

Full text of DOI:10.1002/adsc.201600203

COMMUNICATIONS
DOI: 10.1002/adsc.201600203
Asymmetric Hydrogenation of 3-Amido-2-arylpyridinium Salts by
Triply Chloride-Bridged Dinuclear Iridium Complexes Bearing
Enantiopure Diphosphine Ligands: Synthesis of Neurokinin-1
Receptor Antagonist Derivatives
Atsuhiro Iimuro,a Kosuke Higashida,a Yusuke Kita,a and Kazushi Mashimaa,*
a
Department of Chemistry, Graduate School of Engineering Science, Osaka University, Toyonaka, Osaka 560-8531, Japan
Fax: (+81)-(0)6-6850-6249; e-mail: mashima@chem.es.osaka-u.ac.jp
Received: February 19, 2016; Revised: April 11, 2016; Published online: June 2, 2016
Supporting information for this article is available on the WWW under http://dx.doi.org/10.1002/adsc.201600203.
Abstract: We describe a most straightforward syn-
thetic method for preparing neurokinin-1 (NK1) re-
ceptor antagonist derivatives by asymmetric hydro-
genation of 3-amido-2-arylpyridinium salts using di-
nuclear iridium complexes with enantiopure diphos-
phine ligands, affording the corresponding chiral pi-
peridines in high cis-diastereoselectivity (>95:5)
and moderately high enantioselectivity (up to
86%). Deprotection treatments afforded the NK-
1 receptor antagonist (+)-CP-99,994 (83% ee). In
addition, we observed unique additive effects of 10-
Figure 1. Antagonists of neurokinin-1 (NK1) substance P re-
ceptor.
camphorsulfonic acid in the asymmetric hydrogena-
tion of 3-amido-2-arylpyridinium salts.
Keywords: asymmetric catalysis; hydrogenation; iri-
dium; nitrogen heterocycles
method for preparing chiral 2-aryl-3-aminopiperi-
dines; however, the aromatic nature and strong coor-
dination ability of pyridine and piperidine derivatives
has prevented the practical development of such an
Optically active piperidines are highly important mo- asymmetric hydrogenation of pyridines.[5–8] In fact,
lecular skeletons abundant in natural alkaloids and a strategy of modifying pyridines, i.e., N-iminopyridi-
biologically active compounds, and are key intermedi- nium ylides[9] and N-benzylpyridinium salts,[10] is re-
ates for synthesizing drugs and fragrances. Among quired to actuate substrates for asymmetric hydroge-
them, 3-amino-2-phenylpiperidine and its derivatives nation. We recently developed a protocol for the
have attracted special interest due to their strong bio- asymmetric hydrogenation of the hydrogen halide
logical relevance as non-peptide antagonists of neuro- salts of multisubstituted pyridines using enantiopure
kinin-1 (NK-1) substance
P receptors, such as dinuclear iridium complexes 1 (Figure 2) to furnish
(+)-(2S,3S)-CP-99,994, (+)-(2S,3S)-GR-205,171, and the corresponding chiral piperidines with high diaste-
(+)-(2S,3S)-T-2,328, as shown in Figure 1.[1] From reoselectivity and enantioselectivity.[11] Soon after,
a synthetic point of view, chiral pool synthesis[1b,2] and Zhou et al. applied our synthetic method to the asym-
diastereoselective reactions[3] for constructing the ste- metric hydrogenation of the HCl salts of trisubstitut-
reochemistry of the C-2 and C-3 positions of chiral pi- ed pyridine.[12] In this communication, we report that
peridine derivatives have been investigated, but these the asymmetric hydrogenation of 3-amido-2-arylpyri-
synthetic methodologies require multistep synthesis dinium salts catalyzed by enantiopure dinuclear iridi-
after constructing the stereogenic centers.[4] Thus, um complexes 1 in the presence of additional organic
asymmetric hydrogenation of 2-aryl-3-aminopyridines acids afforded the corresponding 3-amido-2-arylpiper-
is considered the most simple and atom economical idines in high diastereoselectivity and very high enan-
Adv. Synth. Catal. 2016, 358, 1929 – 1933
1929
ꢀ 2016 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim

COMMUNICATIONS
asc.wiley-vch.de
Table 1. Screening of Brønsted acids.[a,b]
[a]
[b]
Reaction conditions: mixture of 2a·HCl (0.15 mmol), (S)-
1d (7.5 mmol), Brønsted acid (0.15 mmol), and 1,4-diox-
ane (3 mL) under H2 (30 bar) for 18 h.
cis-(2R,3R)-3a was only observed in the H NMR spec-
trum, and thus diastereoselectivity was estimated to be
1
Figure 2. Chloride-bridged dinuclear iridium complexes
bearing enantiopure diphosphine ligands.
more than 95%.
Determined by H NMR analysis using phenanthrene as
an internal standard.
Determined by HPLC analysis of corresponding
trifluoroacetamide.
Reaction conditions: mixture of 2a (0.15 mmol), (S)-1d
(7.5 mmol), (À)-CSA (0.30 mmol), and 1,4-dioxane
(3 mL) under H2 (30 bar) was heated at 608C for 18 h.
Complex mixture was obtained. 1H NMR and HPLC
analysis were not applicable.
[c]
[d]
[e]
1
tioselectivity, providing a reliable access to the synthe-
sis of NK1 receptor antagonist derivatives.
We selected 3-(N-benzyl-2,2,2-trifluoroacetamido)-
2-phenylpyridin-1-ium chloride (2a·HCl) as a test sub-
strate, and began by its hydrogenation under the con-
ditions of [{Ir(H)[(S)-segphos]}2(m-Cl)3]Cl [(S)-1d] in
1,4-dioxane at 608C for 18 h under H2 (30 bar) to
obtain the corresponding piperidine derivative
(2R,3R)-3a in 60% yield with 82% ee after a basic
work-up (Table 1, entry 1). After hydrogenation, we
[f]
1
measured the H NMR spectrum of the crude mixture
to detect a trihyride dinuclear iridium complex (S)-4d
(Figure 3), which was already reported to be catalyti-
cally inactive, but reactivated by the addition of suita-
ble Brønsted acids.[13] Accordingly, we surveyed some
Brønsted acids (100 mol% to the substrate) for ad-
justing the asymmetric hydrogenation of 2a·HCl by
(S)-1d, and the results are summarized in Table 1. Ad-
dition of (À)-10-camphorsulfonic acid [(À)-CSA] sig-
nificantly increased the yield from 60% to 85% and
the enantioselectivity from 82% to 84% (entry 1 vs.
Figure 3. Structure of (S)-4d.
2). On the other hand, (+)-CSA had smaller additive tion catalyzed by palladium and iridium complexes.[14]
effects on the reactivity and enantioselectivity than Among the Brønsted acids examined, (À)-CSA was
(À)-CSA (entry 3). These match/mismatch effects of found to be superior to other additives, including
CSA suggested that CSA interacted with the catalyti- TsOH·H2O, acetic acid, adamantanecarboxylic acid
cally active species. CSA was reported to activate in- (AdCOOH), benzoic acid, and pentafluorobenzoic
doles and qunolines prior to asymmetric hydrogena- acid (entries 4–8). In contrast to pyridinium salts,
Adv. Synth. Catal. 2016, 358, 1929 – 1933
1930
ꢀ 2016 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim

COMMUNICATIONS
asc.wiley-vch.de
Table 3. Ir-catalyzed asymmetric hydrogenation of 2·HCl.[a]
unionized pyridine 2a was not hydrogenated at all to
(2R,3R)-3a under the reaction conditions at 608C
using 200 mol% of (À)-CSA, indicating that hydrogen
chloride was crucially required for the reaction to
proceed (entry 9).
Further optimization was carried out using various
iridium complexes (S)-1a–(S)-1e using 100 mol% of
(À)-CSA (Figure 2 and Table 2). Hydrogenation using
(S)-1a [L=(S)-BINAP] and (S)-1c [L=(S)-DI-
FLUORPHOS] furnished (2R,3R)-3a in lower yield
and lower enantioselectivity than when using (S)-1d
(entries 1 and 3). (S)-1b [L=(S)-SYNPHOS] in-
creased the yield to 88%; however, enantioselectivity
was decreased to 72% (entry 2). Sterically-bulky (S)-
1e [L=(S)-DM-SEGPHOS] did not improve the
enantioselectivity (entry 5). Accordingly, we selected
(S)-1d [L=(S)-SEGPHOS] as the optimal catalyst. In
the 1.5 mmol scale reaction under the optimized con-
ditions, (2R,3R)-3a was isolated in 70% with 85% ee.
A series of 3-amido-2-arylpyridinium salts was sub-
jected to asymmetric hydrogenation under the opti-
mized reaction conditions (Table 3). 2b·HCl bearing
an electron-donating group on the aryl group was hy-
drogenated with high enantioselectivity, although
a higher temperature was required (entry 2). 2c·HCl
and 2d·HCl bearing electron-withdrawing groups
were also hydrogenated with moderate enantiomeric
excess (entries 3 and 4). Hydrogenation of 2e·HCl,
[a]
Reaction conditions: A mixture of 2·HCl (0.15 mmol),
(S)-1d (7.5 mmol), (À)-CSA (0.15 mmol), and 1,4-dioxane
(3 mL) under H2 (30 bar) was heated for 18 h.
[b]
Determined by 1H NMR analysis.
[c]
Isolated yield.
[d]
Determined by HPLC analysis of corresponding
Table 2. Optimization of the reaction conditions.[a,b]
trifluoroacetamide.
[e]
A 1H NMR analysis was not applicable.
[f]
An HPLC analysis was not applicable.
Determined by HPLC analysis.
[g]
whose aryl groups bear ortho substituents, led to
lower reactivity because of the steric hindrance of the
substituent in the ortho position (entry 5). A 2-thienyl
group was tolerated under the hydrogenation condi-
tions (entry 6). Salt 2g·HCl bearing a 2-naphthyl
group was also hydrogenated with moderate enantio-
meric excess (entry 7), and salt 2h·HCl without any
substituent on the 2-position was not hydrogenated
probably due to the tightly coordinating ability of
substrate lacking a 2-aryl substituent (entry 8). Other
protecting groups of the amino group were examined
(entries 9 and 10): A benzoyl group improved the
enantioselectivity (entry 9), while a 3,5-bis(trifluoro-
methyl)benzoyl group completely retarded the reac-
tion (entry 10).
[a]
Reaction conditions: A mixture of 2a·HCl (0.15 mmol),
(S)-1 (7.5 mmol), (À)-CSA (0.15 mmol), and 1,4-dioxane
(3 mL) under H2 (30 bar) was heated at 608C for 18 h.
[b]
1
cis-(2R,3R)-3a was only observed in the H NMR spec-
trum, and thus diastereoselectivity was estimated to be
We applied this asymmetric hydrogenation as a key
step in the synthesis of (+)-CP-99,994, a non-peptide
antagonist of the NK1 receptor,[1b,c] to demonstrate
the advantage of this synthetic protocol. The catalytic
hydrogenation of 2a·HCl using the combination of
more than 95%.
Determined by the H NMR analysis using phenanthrene
[c]
[d]
[e]
1
as an internal standard.
Determined by HPLC analysis of corresponding
trifluoroacetamide.
Isolated yield obtained in the 1.5 mmol scale reaction.
[{Ir(H)[(R)-segphos]}2(m-Cl)3]Cl
[(R)-1d]
and
Adv. Synth. Catal. 2016, 358, 1929 – 1933
1931
ꢀ 2016 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim

COMMUNICATIONS
asc.wiley-vch.de
night. The reaction mixture was washed with 1M aqueous
solution of HCl and poured into a saturated aqueous solu-
tion of NaHCO3. After filtration through a short plug of
Na2SO4 and silica gel and eluted with EtOAc the filtrate
was concentrated under vacuum to provide a yellowish
brown oil, which was dissolved in HPLC-grade IPA and ana-
lyzed by HPLC.
Scheme 1. Synthetic application of Ir-catalyzed hydrogena-
tion. Reagents and conditions: a) (R)-1d (5.0 mol%),
(+)-CSA (100 mol%), 1,4-dioxane, 608C, H2 (30 bar), 18 h,
then basic work-up; b) K2CO3, MeOH/H2O (3/1), 658C,
12 h; c) Pd(OH)2/C, HCl (ether solution), MeOH, 508C, H2
(15 bar), 18 h; d) o-anisaldehyde, NaBH(OAc)3, i-PrOAc,
room temperature, 3 h.
Acknowledgements
This work was financially supported by a Grant-in-Aid for
Scientific Research (A) from the Japan Society for the Pro-
motion of Science (JSPS KAKENHI Grant Number
26248028). A.I. expresses his special thanks for the JSPS Re-
search Fellowships for Young Scientists for financial support.
(+)-CSA, followed by a basic work-up gave (2S,3S)-
3a in 79% yield with 83% ee, similar to the reaction
using (S)-1d (Table 1, entry 2). After deprotection of
the trifluoromethyl group and benzyl group, an o-me-
thoxybenzyl group was attached to the 3-amino group
without loss of enantiomeric purity, achieving the
asymmetric synthesis of (+)-CP-99,994 (Scheme 1).
In summary, 3-amido-2-arylpyridinium salts were
hydrogenated by chloride-bridged dinuclear iridium
complexes to the corresponding 2-aryl-3-amidopiperi-
dines in high diastereoselectivity and moderately high
enantioselectivity. Current efforts are directed toward
mechanistic studies on the effects of CSA on the
asymmetric hydrogenation of pyridinium salts.
References
[1] a) S.-C. Huang, V. L. Korlipara, Expert Opin. Ther. Pat.
2010, 20, 1019–1045; b) M. C. Desai, S. L. Letkowitz,
P. F. Thadeio, K. P. Longo, R. M. Snider, J. Med. Chem.
1992, 35, 4911–4913; c) G. J. Boks, J. P. Tollenaere, J.
Kroon, Bioorg. Med. Chem. 1997, 5, 535–547.
[2] a) T. J. Rosen, K. J. Coffman, S. McLean, R. T. Craw-
ford, D. K. Bryce, Y. Gohda, M. Tsuchiya, A. Nagahisa,
M. Nakane, J. A. Lowe III, Bioorg. Med. Chem. Lett.
1998, 8, 281–284; b) S. Chandrasekhar, P. K. Monhanty,
Tetrahedron Lett. 1999, 40, 5071–5072; c) P.-Q. Huang,
L.-X. Liu, B.-G. Wei, Y.-P. Ruan, Org. Lett. 2003, 5,
1927–1927; d) M. Atobe, N. Yamazaki, C. Kibayashi, J.
Org. Chem. 2004, 69, 5595–5607; e) T. Oshitari, T.
Mandai, Synlett 2006, 3395–3398; f) P. R. Sultane, R. G.
Bhat, J. Org. Chem. 2012, 77, 11349–11354; g) E.
Semina, F. Colpaert, K. Van Hecke, N. De Kimpe, S.
Mangelinckx, Eur. J. Org. Chem. 2015, 4847–4859.
[3] a) F. A. Davis, Y. Zhang, D. Li, Tetrahedron Lett. 2007,
48, 7838–7840; b) R.-H. Liu, K. Fang, B. Wang, M.-H.
Xu, G.-Q. Lin, J. Org. Chem. 2008, 73, 3307–3310;
c) M. Ahari, A. Perez, C. Menant, J.-L. Vasse, J. Szy-
moniak, Org. Lett. 2008, 10, 2473–2476; d) J. M. Hum-
phrey, E. P. Arnold, T. A. Chappie, J. B. Feltenberger,
A. Nagel, W. Simon, M. Suarez-Contreras, N. J. Tom,
B. T. OꢁNeill, J. Org. Chem. 2009, 74, 4525–4536.
[4] a) N. Tsuritani, K.-i. Yamada, N. Yoshikawa, M. Shiba-
saki, Chem. Lett. 2002, 276–277; b) X. Xu, T. Furukawa,
T. Okino, H. Miyabe, Y. Takemoto, Chem. Eur. J. 2006,
12, 466–476; c) F. A. Davis, Y. Zhang, D. Li, Tetrahe-
dron Lett. 2007, 48, 7838–7840; d) R. Fu, B. Zhao, Y.
Shi, J. Org. Chem. 2009, 74, 7577–7580; e) S. V. Pan-
sare, E. K. Paul, Org. Biomol. Chem. 2012, 10, 2119–
2125.
[5] For recent reviews, see: a) F. Glorius, Org. Biomol.
Chem. 2005, 3, 4171–4175; b) Y.-G. Zhou, Acc. Chem.
Res. 2007, 40, 1357–1366; c) R. Kuwano, Heterocycles
2008, 76, 909–922; d) N. Fleury-BrØgeot, V. de La
Fuente, S. Castillón, C. Claver, ChemCatChem 2010, 2,
1346–1371; e) M. A. Palmer, A. Zanotti-Gerosa, Curr.
Opin. Drug Discov. Devel. 2010, 13, 698–716; f) D.-S.
Wang, Q.-A. Chen, S.-M. Lu, Y.-G. Zhou, Chem. Rev.
Experimental Section
General Procedure
Iridium complex (7.5 mmol, 5.0 mol%) and pyridinium salts
(0.15 mmol, 1.0 equiv.) were added to a glass tube in a stain-
less autoclave reactor and the tube was charged with argon.
Dry 1,4-dioxane (3 mL) was added into the glass tube in the
reactor from the inlet, and charged with H2 and the pressure
was increased to the desired pressure. The reaction mixture
was stirred for the appropriate period of time. After release
of H2, the reaction mixture with an internal standard (phen-
anthrene) was poured into a saturated aqueous solution of
NaHCO3 and extracted with EtOAc. The organic layer was
passed through MgSO4 and eluted with EtOAc. The filtrate
was concentrated under vacuum to provide a yellow oil. The
NMR yield was determined by 1H NMR analysis using
phenanthrene as internal standard. Purification by column
chromatography on silica gel (hexane/EtOAc =70/30 to 50/
50) afforded the product. KMnO4 was used as a TLC stain
for the detection of piperidines. Trifluoroacetylation was
needed for determination of their enantiomeric excess. The
NMR sample was cooled to 08C by using an ice bath. Then
ten drops of Et3N and five drops of trifluoroacetic anhydride
were added to the reaction mixture at 08C. The reaction
mixture was warmed to room temperature and stirred over-
Adv. Synth. Catal. 2016, 358, 1929 – 1933
1932
ꢀ 2016 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim

COMMUNICATIONS
asc.wiley-vch.de
2012, 112, 2557–2590; g) Z. Yu, W. Jin, Q. Jiang,
Angew. Chem. 2012, 124, 6164–6177; Angew. Chem. Int.
Ed. 2012, 51, 6060–6072; h) Q.-A. Chen, Z.-S. Ye, Y.
Duan, Y.-G. Zhou, Chem. Soc. Rev. 2013, 42, 497–511;
i) P. Etayo, A. Vidal-Ferran, Chem. Soc. Rev. 2013, 42,
728–754; j) A. Bartoszewicz, N. Ahlsten, B. Martín-
Matute, Chem. Eur. J. 2013, 19, 7274–7304; k) K. H.
Hopmann, A. Bayer, Coord. Chem. Rev. 2014, 268, 59–
82; l) T. Nagano, A. Iimuro, K. Yamaji, Y. Kita, K. Ma-
shima, Heterocycles 2014, 88, 103–127; m) B. Balakrish-
na, J. L. NfflÇez-Rico, A. Vidal-Ferran, Eur. J. Org.
Chem. 2015, 5293–5303.
[9] a) C. Y. Legault, A. B. Charette, J. Am. Chem. Soc.
2005, 127, 8966–8967; b) C. Y. Legault, A. B. Charette,
P. G. Cozzi, Heterocycles 2008, 76, 1271–1283; c) A.
Cadu, P. K. Upadhyay, P. G. Andersson, Asian J. Org.
Chem. 2013, 2, 1061–1065.
[10] a) Z.-S. Ye, M.-W. Chen, Q.-A. Chen, L. Shi, Y. Duan,
Y.-G. Zhou, Angew. Chem. 2012, 124, 10328–10331;
Angew. Chem. Int. Ed. 2012, 51, 10181–10184; b) M.
Chang, Y. Huang, S. Liu, Y. Chen, S. W. Krska, I. W.
Davies, X. Zhang, Angew. Chem. 2014, 126, 12975–
12978; Angew. Chem. Int. Ed. 2014, 53, 12761–12764.
[11] Y. Kita, A. Iimuro, S. Hida, K. Mashima, Chem. Lett.
2014, 43, 284–286.
[6] M. Studer, C. Wedemeyer-Exl, F. Spindler, H.-U.
[12] M.-W. Chen, Z.-S. Ye, Z.-P. Chen, B. Wu, Y.-G. Zhou,
Blaser, Monatsh. Chem. 2000, 131, 1335–1343.
Org. Chem. Front. 2015, 2, 586–589.
[7] a) L. Hegedffls, V. Hµda, A. Tungler, T. MµnthØ, L.
Szepesy, Appl. Catal. A 2000, 201, 107–114; b) F. Glo-
rius, N. Spielkamp, S. Holle, R. Goddard, C. W. Leh-
mann, Angew. Chem. 2004, 116, 2910–2913; Angew.
Chem. Int. Ed. 2004, 43, 2850–2852; c) M. Heitbaum,
R. Frçhlich, F. Glorius, Adv. Synth. Catal. 2010, 352,
357–362.
[8] a) X.-B. Wang, W. Zeng, Y.-G. Zhou, Tetrahedron Lett.
2008, 49, 4922–4924; b) W. Tang, Y. Sun, Lijin Xu, T.
Wang, Q. Fan, K.-H. Lam, A. S. C. Chan, Org. Biomol.
Chem. 2010, 8, 3464–3471; c) W.-J. Tang, J. Tan, L.-J.
Xu, K.-H. Lam, Q.-H. Fan, A. S. C. Chan, Adv. Synth.
Catal. 2010, 352, 1055–1062.
[13] a) T. Nagano, A. Iimuro, R. Schwenk, T. Ohshima, Y.
Kita, A. Togni, K. Mashima, Chem. Eur. J. 2012, 18,
11578–11592; b) Y. Kita, K. Yamaji, K. Higashida, K.
Sathaiah, A. Iimuro, K. Mashima, Chem. Eur. J. 2015,
21, 1915–1927.
[14] a) J. L. NfflÇez-Rico, H. Fernµndez-PØrez, J. Benet-
Buchholz, A. Vidal-Ferran, Organometallics 2010, 29,
6627–6631; b) D. S. Wang, Q.-A. Chen, W. Li, C.-B. Yu,
Y.-G. Zhou, X. Zhang, J. Am. Chem. Soc. 2010, 132,
8909–8911; c) D.-S. Wang, J. Tang, Y.-G. Zhou, M.-W.
Chen, C.-B. Yu, Y. Duan, G.-F Jiang, Chem. Sci. 2011,
2, 803–806; d) J. L. NfflÇez-Rico, H. Fernµndez-PØrez,
A. Vidal-Ferran, Green Chem. 2014, 16, 1153–1157.
Adv. Synth. Catal. 2016, 358, 1929 – 1933
1933
ꢀ 2016 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
